NKHPCI5Smart 100/16/4 PCI Ringnode

Installing a PCI adapter Always turn off the power to your computer before installing or removing any adapters. For information about remote PC wake-up, see Remote PC wake-up. 1. Read the EMC compliance statement for your adapter. 2. Read the handling precautions. 3. Turn off the power to your computer. 4. Remove the blanking plate from an unused PCI slot. 5. Insert the adapter into the slot and secure it by using the retaining screw from the blanking plate that you removed. 6. Connect a data-cable to the appropriate connector on the adapter. 7. Connect the other end of the data-cable to a working token-ring network. 8. Re-boot the computer. 9. Run Madge Assist to check that the adapter and its connection are working correctly. (See Configuring and testing adapters with Madge Assist.) 10. Ensure that the ring speed of the adapter is set to either "Auto" or to the speed of the ring. To do this, use Assist. 11. Install the driver software.

EMC compliance statement The statements on this page apply to the following adapters: • Smart 100/16/4 PCI Ringnode • Smart 16/4 PCI Ringnode Mk2 • Smart 16/4 PCI Ringnode Mk3 (WOL) • Presto PCI 2000 • 16/4 CardBus Adapter Mk2 • Olicom RF 3540 • Olicom RF 3140 • Olicom RF 3140v2 • Olicom RF 3141 • Olicom OC 3137 • Olicom RF 3139 • Olicom GC 3250 • Olicom GC 3221 FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • this device may not cause harmful interference • this device must accept any interference that may cause undesired operation This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • reorient or relocate the receiving antenna • increase the separation between the equipment and the receiver • connect the equipment into an outlet on a circuit different from that to which the receiver is connected • consult the dealer or an experienced radio/TV technician for help The user is advised that any modification to the board not expressly authorised by the manufacturer may void the user's authority to operate this device. Canadian Statement This Class A digital apparatus meets all the requirements of the Canadian Interference- Causing Equipment Regulations. Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. European EMC Directive This product carries the CE mark to indicate that it meets the requirements of the European Directive on Electromagnetic Compatibility (89/336/EEC). It has been tested to the following standards: EN55022:1994, EN50082-1:1992. For operation in commercial or industrial environments (Class A), there are no restrictions on cable types that can be used.

Installing a PCI adapter Always turn off the power to your computer before installing or removing any adapters. For information about remote PC wake-up, see Remote PC wake-up. 1. Read the EMC compliance statement for your adapter. 2. Read the handling precautions. 3. Turn off the power to your computer. 4. Remove the blanking plate from an unused PCI slot. 5. Insert the adapter into the slot and secure it by using the retaining screw from the blanking plate that you removed. 6. Connect a data-cable to the appropriate connector on the adapter. 7. Connect the other end of the data-cable to a working token-ring network. 8. Re-boot the computer. 9. Run Madge Assist to check that the adapter and its connection are working correctly. (See Configuring and testing adapters with Madge Assist.) 10. Ensure that the ring speed of the adapter is set to either "Auto" or to the speed of the ring. To do this, use Assist. 11. Install the driver software.

EMC compliance statement The statements on this page apply to the following adapters: • Smart 100/16/4 PCI Ringnode • Smart 16/4 PCI Ringnode Mk2 • Smart 16/4 PCI Ringnode Mk3 (WOL) • Presto PCI 2000 • 16/4 CardBus Adapter Mk2 • Olicom RF 3540 • Olicom RF 3140 • Olicom RF 3140v2 • Olicom RF 3141 • Olicom OC 3137 • Olicom RF 3139 • Olicom GC 3250 • Olicom GC 3221 FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • this device may not cause harmful interference • this device must accept any interference that may cause undesired operation This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • reorient or relocate the receiving antenna • increase the separation between the equipment and the receiver • connect the equipment into an outlet on a circuit different from that to which the receiver is connected • consult the dealer or an experienced radio/TV technician for help The user is advised that any modification to the board not expressly authorised by the manufacturer may void the user's authority to operate this device. Canadian Statement This Class A digital apparatus meets all the requirements of the Canadian Interference- Causing Equipment Regulations. Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. European EMC Directive This product carries the CE mark to indicate that it meets the requirements of the European Directive on Electromagnetic Compatibility (89/336/EEC). It has been tested to the following standards: EN55022:1994, EN50082-1:1992. For operation in commercial or industrial environments (Class A), there are no restrictions on cable types that can be used.

EEPROM SRAM POWER SUPPLY CONTROL Internal 5V Internal 3.3V PCI 5V PCI 3V_AUX Ext 5V_AUX (Optional supply from motherboard) PCI BUS MAC and PCI BUS INTERFACE LAN INTERFACE UTP TX UTP RX STP TX STP RX Twisted Pair Connections PCI5 Block Diagram

%DMS-S-1, MADGEPDM, Successful completion. Madge Networks Ltd Madge Networks Ltd part41.exe P. 1 Slough, Berkshire Single level BoM Explosion with 19-JUL-2000 18:44:37 1-408-941-4600 Reference Designators for PART\151-336-02\# [SHERPA] Type Item Number Rv Family Order Usage Status Description Qty UM M Status Ref Designator ---- -------------- -- ------------ ----- ------ --------- -------------------- -------------- ----- -- -------- ----------------------------------------------- --- DOCU 151-336-02 A SPECIFICATIO IN_REVIEW ASSY FINAL PCI-5 (STANDARD BRACKET 0 DOCU 185-168-01 A FUNCTIONAL_T IN_REVIEW PROCEDURE FUNC TEST PCI-5 (STANDAR 0 SOFT 185-168-01 A FUNCTIONAL_T IN_REVIEW S/W FUNC TEST PCI-5 (STANDARD BRAC 0 PART 107-739-01 A DEFAULT 1 - RELEASED LABEL BLANK SERIAL NO/PART NO 1 EA ACTIVE PART 140-034-01 B PROG_PART 2 PRIMAR RELEASED BLUEBIRD TR TRANSCIEVER ASIC 1 EA ACTIVE U1 PART 140-042-01 B MADGE_SILICO 5 PRIMAR RELEASED STANDARD CELL ASIC K3 1 EA PDMONLY U7 PART 151-149-02 A METALWORK 10 - ISSUED BRACKET STAMPED PCI- 5 (STANDARD HE 1 EA CREATED PART 151-338-02 A PCB 20 - ISSUED PCB BLANK PCI-5 (LOW PROFILE) 1 EA ACTIVE PART 20000416 A IC_MEMORY 25 PRIMAR RELEASED IC SERIAL EEPROM 1K (X8/X16) 2.7-5 1 EA PDMONLY U11 PART 20000442 A IC_MEMORY 30 PRIMAR RELEASED IC SRAM 32K X 8 15NS 3.3V SOJ28 2 EA PDMONLY U6 U9 PART 20000462 B IC_COMMS 35 PRIMAR RELEASED IC AC101/AM79C874 PHY 10/100 3.3V 1 EA CREATED U8 PART 20000555 A IC_LINEAR 40 PRIMAR RELEASED IC LM339 QUAD COMPARATOR SOIC14 1 EA CREATED U10 PART 21000320 B TRANSISTOR 45 PRIMAR RELEASED TR FMMT717 PNP POWER SOT23 3 EA ACTIVE Q16 Q17 Q18 PART 21000332 C DIODES 50 PRIMAR RELEASED DIODE SCHOTTKY RECT 1A 30V SMB 1 EA CREATED CR3 PART 21000556 B TRANSISTOR 55 PRIMAR RELEASED TR BC847S DUAL NPN BIPOLAR SOT363 7 EA CREATED Q2 Q3 Q5 Q7 Q11 Q12 Q13 PART 22000319 D CAP_CER 60 PRIMAR RELEASED CAP CER 10UF SM1210 Y5V -20/+80% 1 5 EA ACTIVE C15 C43 C49 C62 C79 PART 23000224 A RESISTORS 65 PRIMAR RELEASED RES 100K SM0603 0.0625W 5% 200PPM 14 EA ACTIVE R51 R52 R53 R56 R67 R68 R73 R75 R76 R78 R87 R109 R77 R57 PART 23000271 A RESISTORS 70 - RELEASED RES 220R SM0603 0.0625W 1% 100PPM 5 EA CREATED R111 R11 R84 R4 R5 PART 23000642 A RESISTORS 75 PRIMAR RELEASED RES 12R SM0603 0.0625W 1% 100PPM 2 EA CREATED R44 R80 PART 23000662 A RESISTORS 80 PRIMAR RELEASED RES 59R SM0603 0.0625W 1% 100PPM 12 EA CREATED R1 R47 R48 R58 R70 R79 R90 R25 R26 R28 R29 R24 PART 23000663 A RESISTORS 85 PRIMAR RELEASED RES 2R2 SM0603 0.0625W 5% 600PPM 4 EA CREATED R45 R49 R61 R71 PART 25000475 A INDUCTORS 90 PRIMAR RELEASED INDUCTOR 10UH 20% SHIELDED SMD 1 EA ACTIVE L3 PART 25000541 B INDUCTORS 95 PRIMAR RELEASED INDUCTOR 47NH 5% HI- FREQ SM0603 2 EA CREATED L6 L7 PART 25000590 B INDUCTORS 100 PRIMAR RELEASED INDUCTOR 390NH 10% SM0603 4 EA CREATED L1 L2 L4 L5 PART 26000391 C MAGNETICS 105 PRIMAR RELEASED XFORM DUAL + CHOKE 4/16/100 SMD16 1 EA CREATED T1 PART 28000400 B OSCILLATORS 110 PRIMAR RELEASED OSC 32.00MHZ 100PPM 3.3V SMD TRI-S 1 EA PDMONLY X2 PART 28000439 B OSCILLATORS 115 PRIMAR RELEASED OSC 25.00MHZ 50PPM 3.3V SMD TRI-ST 1 EA PDMONLY X1 PART 31000321 B CONNECTORS 120 PRIMAR RELEASED CON HEADER 3W 2MM PITCH R/A (WAKE- 1 EA ACTIVE J3 PART 31000598 A CONNECTORS 125 PRIMAR RELEASED CON RJ45 SKT SHIELDED INTEG G/Y LE 1 EA CREATED J1 PART 400-041 C FASTENER_OTH 130 PRIMAR RELEASED SCREWLOCK KIT FEMALE 2 EA CREATED MX1 MX5 PART 400-100 D CONNECTORS 135 PRIMAR RELEASED CON D 9WAY SKT R/A PCB BD/LOCKS 1 EA ACTIVE J2 PART 425-132 B CONN_COMP_SO 140 PRIMAR RELEASED SKT IC 32-PIN DUAL WIPE 1 EA ACTIVE U3 PART 527-008 B RESISTORS 145 PRIMAR RELEASED RES 100R SM0603 0.0625W 1% 1 EA ACTIVE R104 Madge Networks Ltd Madge Networks Ltd part41.exe P. 2 Slough, Berkshire Single level BoM Explosion with 19-JUL-2000 18:44:41 1-408-941-4600 Reference Designators for PART\151-336-02\# [SHERPA] Type Item Number Rv Family Order Usage Status Description Qty UM M Status Ref Designator ---- -------------- -- ------------ ----- ------ --------- -------------------- -------------- ----- -- -------- ----------------------------------------------- --- PART 527-009 B RESISTORS 150 PRIMAR RELEASED RES 1K SM0603 0.0625W 1% 3 EA ACTIVE R50 R97 R98 PART 527-010 B RESISTORS 155 PRIMAR RELEASED RES 121R SM0603 0.0625W 1% 2 EA ACTIVE R36 R89 PART 527-017 B RESISTORS 160 PRIMAR RELEASED RES 3K48 SM0603 0.0625W 1% 15 EA ACTIVE R14 R19 R20 R23 R30 R32 R88 R94 R96 R62 R92 R100 R101 R102 R103 PART 527-019 B RESISTORS 165 PRIMAR RELEASED RES 576R SM0603 0.0625W 1% 5 EA ACTIVE R18 R27 R35 R106 R107 PART 527-020 C RESISTORS 170 PRIMAR RELEASED RES 0R SM0603 1A 4 EA ACTIVE R31 R33 R99 R114 PART 527-025 B RESISTORS 175 PRIMAR RELEASED RES 165R SM0603 0.0625W 1% 100PPM 14 EA ACTIVE R6 R9 R13 R17 R21 R22 R34 R37 R86 R8 R10 R39 R46 R108 PART 527-026 B RESISTORS 180 PRIMAR RELEASED RES 681R SM0603 0.0625W 1% 100PPM 2 EA ACTIVE R12 R63 PART 527-027 B RESISTORS 185 PRIMAR RELEASED RES 18K7 SM0603 0.0625W 1% 100PPM 6 EA ACTIVE R43 R54 R55 R64 R72 R74 PART 527-028 B RESISTORS 190 PRIMAR RELEASED RES 6K19 SM0603 0.0625W 1% 100PPM 4 EA ACTIVE R42 R65 R93 R110 PART 527-036 B RESISTORS 195 PRIMAR RELEASED RES 10K SM0603 0.0625W 1% 100PPM 4 EA ACTIVE R59 R81 R112 R113 PART 528-013 A RESISTORS 200 PRIMAR RELEASED RES 2K SM0603 0.0625W 5% 200PPM 4 EA ACTIVE R7 R66 R95 R38 PART 553-027 A RESISTORS 205 PRIMAR RELEASED RES 27R SM1206 0.25W 5% 200PPM 4 EA ACTIVE R2 R3 R15 R16 PART 675-003 A CAP_TANT 210 PRIMAR RELEASED CAP TANT 1U5 SMA 16V 10% 2 EA ACTIVE C5 C16 PART 675-004 A CAP_TANT 215 PRIMAR RELEASED CAP TANT 6U8 SMB 16V 20% 9 EA ACTIVE C2 C3 C27 C51 C53 C54 C60 C94 C52 PART 681-001 B CAP_CER 220 PRIMAR RELEASED CAP CER 47NF SM0805 X7R 10% 50V 1 EA ACTIVE C48 PART 683-008 B CAP_CER 225 PRIMAR RELEASED CAP CER 120PF SM0603 COG 5% 50V 4 EA ACTIVE C26 C34 C35 C96 PART 683-013 C CAP_CER 230 - RELEASED CAP CER 100NF SM0603 Y5V -20/+80% 55 EA ACTIVE C1 C4 C6 C7 C12 C13 C19 C20 C21 C22 C23 C24 C32 C33 C36 C46 C47 C50 C57 C58 C61 C6…

Text truncated - open the document above for the full version.

%DMS-S-1, MADGEPDM, Successful completion. Madge Networks Ltd Madge Networks Ltd part41.exe P. 1 Slough, Berkshire Single level BoM Explosion with 19-JUL-2000 18:44:37 1-408-941-4600 Reference Designators for PART\151-336-02\# [SHERPA] Type Item Number Rv Family Order Usage Status Description Qty UM M Status Ref Designator ---- -------------- -- ------------ ----- ------ --------- -------------------- -------------- ----- -- -------- ----------------------------------------------- --- DOCU 151-336-02 A SPECIFICATIO IN_REVIEW ASSY FINAL PCI-5 (STANDARD BRACKET 0 DOCU 185-168-01 A FUNCTIONAL_T IN_REVIEW PROCEDURE FUNC TEST PCI-5 (STANDAR 0 SOFT 185-168-01 A FUNCTIONAL_T IN_REVIEW S/W FUNC TEST PCI-5 (STANDARD BRAC 0 PART 107-739-01 A DEFAULT 1 - RELEASED LABEL BLANK SERIAL NO/PART NO 1 EA ACTIVE PART 140-034-01 B PROG_PART 2 PRIMAR RELEASED BLUEBIRD TR TRANSCIEVER ASIC 1 EA ACTIVE U1 PART 140-042-01 B MADGE_SILICO 5 PRIMAR RELEASED STANDARD CELL ASIC K3 1 EA PDMONLY U7 PART 151-149-02 A METALWORK 10 - ISSUED BRACKET STAMPED PCI- 5 (STANDARD HE 1 EA CREATED PART 151-338-02 A PCB 20 - ISSUED PCB BLANK PCI-5 (LOW PROFILE) 1 EA ACTIVE PART 20000416 A IC_MEMORY 25 PRIMAR RELEASED IC SERIAL EEPROM 1K (X8/X16) 2.7-5 1 EA PDMONLY U11 PART 20000442 A IC_MEMORY 30 PRIMAR RELEASED IC SRAM 32K X 8 15NS 3.3V SOJ28 2 EA PDMONLY U6 U9 PART 20000462 B IC_COMMS 35 PRIMAR RELEASED IC AC101/AM79C874 PHY 10/100 3.3V 1 EA CREATED U8 PART 20000555 A IC_LINEAR 40 PRIMAR RELEASED IC LM339 QUAD COMPARATOR SOIC14 1 EA CREATED U10 PART 21000320 B TRANSISTOR 45 PRIMAR RELEASED TR FMMT717 PNP POWER SOT23 3 EA ACTIVE Q16 Q17 Q18 PART 21000332 C DIODES 50 PRIMAR RELEASED DIODE SCHOTTKY RECT 1A 30V SMB 1 EA CREATED CR3 PART 21000556 B TRANSISTOR 55 PRIMAR RELEASED TR BC847S DUAL NPN BIPOLAR SOT363 7 EA CREATED Q2 Q3 Q5 Q7 Q11 Q12 Q13 PART 22000319 D CAP_CER 60 PRIMAR RELEASED CAP CER 10UF SM1210 Y5V -20/+80% 1 5 EA ACTIVE C15 C43 C49 C62 C79 PART 23000224 A RESISTORS 65 PRIMAR RELEASED RES 100K SM0603 0.0625W 5% 200PPM 14 EA ACTIVE R51 R52 R53 R56 R67 R68 R73 R75 R76 R78 R87 R109 R77 R57 PART 23000271 A RESISTORS 70 - RELEASED RES 220R SM0603 0.0625W 1% 100PPM 5 EA CREATED R111 R11 R84 R4 R5 PART 23000642 A RESISTORS 75 PRIMAR RELEASED RES 12R SM0603 0.0625W 1% 100PPM 2 EA CREATED R44 R80 PART 23000662 A RESISTORS 80 PRIMAR RELEASED RES 59R SM0603 0.0625W 1% 100PPM 12 EA CREATED R1 R47 R48 R58 R70 R79 R90 R25 R26 R28 R29 R24 PART 23000663 A RESISTORS 85 PRIMAR RELEASED RES 2R2 SM0603 0.0625W 5% 600PPM 4 EA CREATED R45 R49 R61 R71 PART 25000475 A INDUCTORS 90 PRIMAR RELEASED INDUCTOR 10UH 20% SHIELDED SMD 1 EA ACTIVE L3 PART 25000541 B INDUCTORS 95 PRIMAR RELEASED INDUCTOR 47NH 5% HI- FREQ SM0603 2 EA CREATED L6 L7 PART 25000590 B INDUCTORS 100 PRIMAR RELEASED INDUCTOR 390NH 10% SM0603 4 EA CREATED L1 L2 L4 L5 PART 26000391 C MAGNETICS 105 PRIMAR RELEASED XFORM DUAL + CHOKE 4/16/100 SMD16 1 EA CREATED T1 PART 28000400 B OSCILLATORS 110 PRIMAR RELEASED OSC 32.00MHZ 100PPM 3.3V SMD TRI-S 1 EA PDMONLY X2 PART 28000439 B OSCILLATORS 115 PRIMAR RELEASED OSC 25.00MHZ 50PPM 3.3V SMD TRI-ST 1 EA PDMONLY X1 PART 31000321 B CONNECTORS 120 PRIMAR RELEASED CON HEADER 3W 2MM PITCH R/A (WAKE- 1 EA ACTIVE J3 PART 31000598 A CONNECTORS 125 PRIMAR RELEASED CON RJ45 SKT SHIELDED INTEG G/Y LE 1 EA CREATED J1 PART 400-041 C FASTENER_OTH 130 PRIMAR RELEASED SCREWLOCK KIT FEMALE 2 EA CREATED MX1 MX5 PART 400-100 D CONNECTORS 135 PRIMAR RELEASED CON D 9WAY SKT R/A PCB BD/LOCKS 1 EA ACTIVE J2 PART 425-132 B CONN_COMP_SO 140 PRIMAR RELEASED SKT IC 32-PIN DUAL WIPE 1 EA ACTIVE U3 PART 527-008 B RESISTORS 145 PRIMAR RELEASED RES 100R SM0603 0.0625W 1% 1 EA ACTIVE R104 Madge Networks Ltd Madge Networks Ltd part41.exe P. 2 Slough, Berkshire Single level BoM Explosion with 19-JUL-2000 18:44:41 1-408-941-4600 Reference Designators for PART\151-336-02\# [SHERPA] Type Item Number Rv Family Order Usage Status Description Qty UM M Status Ref Designator ---- -------------- -- ------------ ----- ------ --------- -------------------- -------------- ----- -- -------- ----------------------------------------------- --- PART 527-009 B RESISTORS 150 PRIMAR RELEASED RES 1K SM0603 0.0625W 1% 3 EA ACTIVE R50 R97 R98 PART 527-010 B RESISTORS 155 PRIMAR RELEASED RES 121R SM0603 0.0625W 1% 2 EA ACTIVE R36 R89 PART 527-017 B RESISTORS 160 PRIMAR RELEASED RES 3K48 SM0603 0.0625W 1% 15 EA ACTIVE R14 R19 R20 R23 R30 R32 R88 R94 R96 R62 R92 R100 R101 R102 R103 PART 527-019 B RESISTORS 165 PRIMAR RELEASED RES 576R SM0603 0.0625W 1% 5 EA ACTIVE R18 R27 R35 R106 R107 PART 527-020 C RESISTORS 170 PRIMAR RELEASED RES 0R SM0603 1A 4 EA ACTIVE R31 R33 R99 R114 PART 527-025 B RESISTORS 175 PRIMAR RELEASED RES 165R SM0603 0.0625W 1% 100PPM 14 EA ACTIVE R6 R9 R13 R17 R21 R22 R34 R37 R86 R8 R10 R39 R46 R108 PART 527-026 B RESISTORS 180 PRIMAR RELEASED RES 681R SM0603 0.0625W 1% 100PPM 2 EA ACTIVE R12 R63 PART 527-027 B RESISTORS 185 PRIMAR RELEASED RES 18K7 SM0603 0.0625W 1% 100PPM 6 EA ACTIVE R43 R54 R55 R64 R72 R74 PART 527-028 B RESISTORS 190 PRIMAR RELEASED RES 6K19 SM0603 0.0625W 1% 100PPM 4 EA ACTIVE R42 R65 R93 R110 PART 527-036 B RESISTORS 195 PRIMAR RELEASED RES 10K SM0603 0.0625W 1% 100PPM 4 EA ACTIVE R59 R81 R112 R113 PART 528-013 A RESISTORS 200 PRIMAR RELEASED RES 2K SM0603 0.0625W 5% 200PPM 4 EA ACTIVE R7 R66 R95 R38 PART 553-027 A RESISTORS 205 PRIMAR RELEASED RES 27R SM1206 0.25W 5% 200PPM 4 EA ACTIVE R2 R3 R15 R16 PART 675-003 A CAP_TANT 210 PRIMAR RELEASED CAP TANT 1U5 SMA 16V 10% 2 EA ACTIVE C5 C16 PART 675-004 A CAP_TANT 215 PRIMAR RELEASED CAP TANT 6U8 SMB 16V 20% 9 EA ACTIVE C2 C3 C27 C51 C53 C54 C60 C94 C52 PART 681-001 B CAP_CER 220 PRIMAR RELEASED CAP CER 47NF SM0805 X7R 10% 50V 1 EA ACTIVE C48 PART 683-008 B CAP_CER 225 PRIMAR RELEASED CAP CER 120PF SM0603 COG 5% 50V 4 EA ACTIVE C26 C34 C35 C96 PART 683-013 C CAP_CER 230 - RELEASED CAP CER 100NF SM0603 Y5V -20/+80% 55 EA ACTIVE C1 C4 C6 C7 C12 C13 C19 C20 C21 C22 C23 C24 C32 C33 C36 C46 C47 C50 C57 C58 C61 C6…

Text truncated - open the document above for the full version.

%DMS-S-1, MADGEPDM, Successful completion. Madge Networks Ltd Madge Networks Ltd part41.exe P. 1 Slough, Berkshire Single level BoM Explosion with 19-JUL-2000 18:44:37 1-408-941-4600 Reference Designators for PART\151-336-02\# [SHERPA] Type Item Number Rv Family Order Usage Status Description Qty UM M Status Ref Designator ---- -------------- -- ------------ ----- ------ --------- -------------------- -------------- ----- -- -------- ----------------------------------------------- --- DOCU 151-336-02 A SPECIFICATIO IN_REVIEW ASSY FINAL PCI-5 (STANDARD BRACKET 0 DOCU 185-168-01 A FUNCTIONAL_T IN_REVIEW PROCEDURE FUNC TEST PCI-5 (STANDAR 0 SOFT 185-168-01 A FUNCTIONAL_T IN_REVIEW S/W FUNC TEST PCI-5 (STANDARD BRAC 0 PART 107-739-01 A DEFAULT 1 - RELEASED LABEL BLANK SERIAL NO/PART NO 1 EA ACTIVE PART 140-034-01 B PROG_PART 2 PRIMAR RELEASED BLUEBIRD TR TRANSCIEVER ASIC 1 EA ACTIVE U1 PART 140-042-01 B MADGE_SILICO 5 PRIMAR RELEASED STANDARD CELL ASIC K3 1 EA PDMONLY U7 PART 151-149-02 A METALWORK 10 - ISSUED BRACKET STAMPED PCI- 5 (STANDARD HE 1 EA CREATED PART 151-338-02 A PCB 20 - ISSUED PCB BLANK PCI-5 (LOW PROFILE) 1 EA ACTIVE PART 20000416 A IC_MEMORY 25 PRIMAR RELEASED IC SERIAL EEPROM 1K (X8/X16) 2.7-5 1 EA PDMONLY U11 PART 20000442 A IC_MEMORY 30 PRIMAR RELEASED IC SRAM 32K X 8 15NS 3.3V SOJ28 2 EA PDMONLY U6 U9 PART 20000462 B IC_COMMS 35 PRIMAR RELEASED IC AC101/AM79C874 PHY 10/100 3.3V 1 EA CREATED U8 PART 20000555 A IC_LINEAR 40 PRIMAR RELEASED IC LM339 QUAD COMPARATOR SOIC14 1 EA CREATED U10 PART 21000320 B TRANSISTOR 45 PRIMAR RELEASED TR FMMT717 PNP POWER SOT23 3 EA ACTIVE Q16 Q17 Q18 PART 21000332 C DIODES 50 PRIMAR RELEASED DIODE SCHOTTKY RECT 1A 30V SMB 1 EA CREATED CR3 PART 21000556 B TRANSISTOR 55 PRIMAR RELEASED TR BC847S DUAL NPN BIPOLAR SOT363 7 EA CREATED Q2 Q3 Q5 Q7 Q11 Q12 Q13 PART 22000319 D CAP_CER 60 PRIMAR RELEASED CAP CER 10UF SM1210 Y5V -20/+80% 1 5 EA ACTIVE C15 C43 C49 C62 C79 PART 23000224 A RESISTORS 65 PRIMAR RELEASED RES 100K SM0603 0.0625W 5% 200PPM 14 EA ACTIVE R51 R52 R53 R56 R67 R68 R73 R75 R76 R78 R87 R109 R77 R57 PART 23000271 A RESISTORS 70 - RELEASED RES 220R SM0603 0.0625W 1% 100PPM 5 EA CREATED R111 R11 R84 R4 R5 PART 23000642 A RESISTORS 75 PRIMAR RELEASED RES 12R SM0603 0.0625W 1% 100PPM 2 EA CREATED R44 R80 PART 23000662 A RESISTORS 80 PRIMAR RELEASED RES 59R SM0603 0.0625W 1% 100PPM 12 EA CREATED R1 R47 R48 R58 R70 R79 R90 R25 R26 R28 R29 R24 PART 23000663 A RESISTORS 85 PRIMAR RELEASED RES 2R2 SM0603 0.0625W 5% 600PPM 4 EA CREATED R45 R49 R61 R71 PART 25000475 A INDUCTORS 90 PRIMAR RELEASED INDUCTOR 10UH 20% SHIELDED SMD 1 EA ACTIVE L3 PART 25000541 B INDUCTORS 95 PRIMAR RELEASED INDUCTOR 47NH 5% HI- FREQ SM0603 2 EA CREATED L6 L7 PART 25000590 B INDUCTORS 100 PRIMAR RELEASED INDUCTOR 390NH 10% SM0603 4 EA CREATED L1 L2 L4 L5 PART 26000391 C MAGNETICS 105 PRIMAR RELEASED XFORM DUAL + CHOKE 4/16/100 SMD16 1 EA CREATED T1 PART 28000400 B OSCILLATORS 110 PRIMAR RELEASED OSC 32.00MHZ 100PPM 3.3V SMD TRI-S 1 EA PDMONLY X2 PART 28000439 B OSCILLATORS 115 PRIMAR RELEASED OSC 25.00MHZ 50PPM 3.3V SMD TRI-ST 1 EA PDMONLY X1 PART 31000321 B CONNECTORS 120 PRIMAR RELEASED CON HEADER 3W 2MM PITCH R/A (WAKE- 1 EA ACTIVE J3 PART 31000598 A CONNECTORS 125 PRIMAR RELEASED CON RJ45 SKT SHIELDED INTEG G/Y LE 1 EA CREATED J1 PART 400-041 C FASTENER_OTH 130 PRIMAR RELEASED SCREWLOCK KIT FEMALE 2 EA CREATED MX1 MX5 PART 400-100 D CONNECTORS 135 PRIMAR RELEASED CON D 9WAY SKT R/A PCB BD/LOCKS 1 EA ACTIVE J2 PART 425-132 B CONN_COMP_SO 140 PRIMAR RELEASED SKT IC 32-PIN DUAL WIPE 1 EA ACTIVE U3 PART 527-008 B RESISTORS 145 PRIMAR RELEASED RES 100R SM0603 0.0625W 1% 1 EA ACTIVE R104 Madge Networks Ltd Madge Networks Ltd part41.exe P. 2 Slough, Berkshire Single level BoM Explosion with 19-JUL-2000 18:44:41 1-408-941-4600 Reference Designators for PART\151-336-02\# [SHERPA] Type Item Number Rv Family Order Usage Status Description Qty UM M Status Ref Designator ---- -------------- -- ------------ ----- ------ --------- -------------------- -------------- ----- -- -------- ----------------------------------------------- --- PART 527-009 B RESISTORS 150 PRIMAR RELEASED RES 1K SM0603 0.0625W 1% 3 EA ACTIVE R50 R97 R98 PART 527-010 B RESISTORS 155 PRIMAR RELEASED RES 121R SM0603 0.0625W 1% 2 EA ACTIVE R36 R89 PART 527-017 B RESISTORS 160 PRIMAR RELEASED RES 3K48 SM0603 0.0625W 1% 15 EA ACTIVE R14 R19 R20 R23 R30 R32 R88 R94 R96 R62 R92 R100 R101 R102 R103 PART 527-019 B RESISTORS 165 PRIMAR RELEASED RES 576R SM0603 0.0625W 1% 5 EA ACTIVE R18 R27 R35 R106 R107 PART 527-020 C RESISTORS 170 PRIMAR RELEASED RES 0R SM0603 1A 4 EA ACTIVE R31 R33 R99 R114 PART 527-025 B RESISTORS 175 PRIMAR RELEASED RES 165R SM0603 0.0625W 1% 100PPM 14 EA ACTIVE R6 R9 R13 R17 R21 R22 R34 R37 R86 R8 R10 R39 R46 R108 PART 527-026 B RESISTORS 180 PRIMAR RELEASED RES 681R SM0603 0.0625W 1% 100PPM 2 EA ACTIVE R12 R63 PART 527-027 B RESISTORS 185 PRIMAR RELEASED RES 18K7 SM0603 0.0625W 1% 100PPM 6 EA ACTIVE R43 R54 R55 R64 R72 R74 PART 527-028 B RESISTORS 190 PRIMAR RELEASED RES 6K19 SM0603 0.0625W 1% 100PPM 4 EA ACTIVE R42 R65 R93 R110 PART 527-036 B RESISTORS 195 PRIMAR RELEASED RES 10K SM0603 0.0625W 1% 100PPM 4 EA ACTIVE R59 R81 R112 R113 PART 528-013 A RESISTORS 200 PRIMAR RELEASED RES 2K SM0603 0.0625W 5% 200PPM 4 EA ACTIVE R7 R66 R95 R38 PART 553-027 A RESISTORS 205 PRIMAR RELEASED RES 27R SM1206 0.25W 5% 200PPM 4 EA ACTIVE R2 R3 R15 R16 PART 675-003 A CAP_TANT 210 PRIMAR RELEASED CAP TANT 1U5 SMA 16V 10% 2 EA ACTIVE C5 C16 PART 675-004 A CAP_TANT 215 PRIMAR RELEASED CAP TANT 6U8 SMB 16V 20% 9 EA ACTIVE C2 C3 C27 C51 C53 C54 C60 C94 C52 PART 681-001 B CAP_CER 220 PRIMAR RELEASED CAP CER 47NF SM0805 X7R 10% 50V 1 EA ACTIVE C48 PART 683-008 B CAP_CER 225 PRIMAR RELEASED CAP CER 120PF SM0603 COG 5% 50V 4 EA ACTIVE C26 C34 C35 C96 PART 683-013 C CAP_CER 230 - RELEASED CAP CER 100NF SM0603 Y5V -20/+80% 55 EA ACTIVE C1 C4 C6 C7 C12 C13 C19 C20 C21 C22 C23 C24 C32 C33 C36 C46 C47 C50 C57 C58 C61 C6…

Text truncated - open the document above for the full version.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test Of: Madge Networks Ltd. Low Profile PC Card PCI-5 To: FCC Part 15: 1998 Class B Test Report Serial No: RFI/EMCB1/RP41115ETF01B This Test Report Is Issued Under The Authority Of Brian Watson Technical Director: Checked By: Tested By:Release Version No: PDF01 Issue Date: 6 July 2000Test Date: 27 June 2000 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP41115ETF01B EMC DepartmentPage 2 of 26 Issue Date: 6 July 2000 Test Of:Madge Networks Ltd. Low Profile PC Card PCI-5 To:FCC Part 15: 1998 Class B This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP41115ETF01B EMC DepartmentPage 3 of 26 Issue Date: 6 July 2000 Test Of:Madge Networks Ltd. Low Profile PC Card PCI-5 To:FCC Part 15: 1998 Class B Table of Contents 1. Client Information..........................................................................................................4 2. Equipment Under Test (EUT).........................................................................................5 3. Test Specification, Methods & Procedures..................................................................9 4. Deviations From The Test Specification.....................................................................10 5. Operation Of The EUT During Testing........................................................................11 6. Summary Of Test Results............................................................................................12 7. Measurements, Examinations And Derived Results..................................................13 8. Measurement Uncertainty............................................................................................18 Appendix 1. Test Equipment Used...................................................................................19 Appendix 2. Measurement Methods................................................................................20 Appendix 3. Test Configuration Drawings......................................................................22 Appendix 4. Photographs of EUT.....................................................................................26 RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP41115ETF01B EMC DepartmentPage 4 of 26 Issue Date: 6 July 2000 Test Of:Madge Networks Ltd. Low Profile PC Card PCI-5 To:FCC Part 15: 1998 Class B 1. Client Information Company Name: Madge Networks Ltd. Address: Wexham Springs Framewood Road Wexham Slough SL3 6PJ Berks. Contact Name: Mr Jason Borland. RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP41115ETF01B EMC DepartmentPage 5 of 26 Issue Date: 6 July 2000 Test Of:Madge Networks Ltd. Low Profile PC Card PCI-5 To:FCC Part 15: 1998 Class B 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification Of Equipment Under Test (EUT) Brand Name Madge Model Name or Number PCI-5 Unique Type Identification 151-336-01 Serial Number 5B Country Of Manufacture UK F.C.C. ID Number NKHPC15 Date Of Receipt 27 June 2000 2.2. Description Of EUT The card (EUT) provides an interface between a personal computer and a Token Ring Network. 2.3. Modifications Incorporated In EUT None. 2.4. Additional Information Related To Testing Power Supply Requirement: Nominal 115 V, 60 Hz AC Mains Supply 13 Amp (max) Intended Operating Environment: Commercial, Light industry Weight: 150g Dimensions: PCB 130 x 80mm Interface Ports: Two Token Ring Ports: one subminiture-D and one RJ45, Either of which may be used at any one time. The subminiture-D supports IBM STP cable. The RJ45 supports either category 3 to 5 STP or category 3 to 5 UTP. The EUT is internal to the support computer and is connected to the PCI bus expansion slot. Cycle Time: Less than 1 sec. RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP41115ETF01B EMC DepartmentPage 6 of 26 Issue Date: 6 July 2000 Test Of:Madge Networks Ltd. Low Profile PC Card PCI-5 To:FCC Part 15: 1998 Class B 2.5. Support Equipment The following support equipment was used to exercise the EUT during testing: Description PC Brand Name Dell M…

Text truncated - open the document above for the full version.
