NKH313

Note: The User manual is provided on CD Rom. Below is the “starter page” for the card and the FCC EMC user information that would normally be found by following the link on the Right Hand Side of the Picture. ------------------------------------------------------------------------------------------------------------------------------- EMC compliance statement FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful interference this device must accept any interference that may cause undesired operation This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - reorient or relocate the receiving antenna - increase the separation between the equipment and the receiver - connect the equipment into an outlet on a circuit different from that to which the receiver is connected - consult the dealer or an experienced radio/TV technician for help The user is advised that any modification to the board not expressly authorised by the manufacturer may void the user's authority to operate this device.

NKH313Madge Networks Ltd,ID Label and Location

NKH313Madge Networks Ltd,ID Label and Location

Applies to 151-313-xx (A SSY. FINAL OEM PCI-3 COMPAQ) 3 rd . JUNE 1998 ------------------------------------------------------------------------------------------------------------------------------- -------------- Qty Ref-Des Madge P/N. PCB Site Part Type Additional Part Info. Description------------------------------------------------------------------------------------------------------------------------------- -------------- 1 U3 140-034-01 DIP28/SSOP BLUEBIRD BLUEBIRD ASIC SSSB167 BLUEBIRD TOKEN RING INTERFAC E 1 U4 140-041-02 FPT208 KNOSSOS2 NEC GATE ARRAY K21 MX1 151-107-02 N/A /BRACKET BRKT PCI ISA VERSION CARD RETAINING BRACKET1 MX2 151-309-04 N/A /PCB MAN-SPEC 952-346-04 PCB FROM ARTWORK 952-345-043 Q1-2 Q10 21000320 SOT23N PNP/SOT23A FMMT717 PNP TRANSISTOR1 C30 22000319 1210 C/CERSM,10U, 16V,Y5V MULTI LAYER CERAMIC CHIP CAP ACITOR +80%-20%2 R41 R47 23000155 0603 R/SM,390R,1% 1/16W SURFACE MOUNT RESISTOR4 R12 R49-50 R76 23000224 0603 R/SM,100K,5% 1/16W SURFACE MOUNT RESISTOR1 R19 23000316 0805 R/SM,6R8,5% 1/10W SURFACE MOUNT RESISTOR1 J3 31000321 HDR3RA/WONLAN HDR3RA/WONLAN AMP 173979-3 3 WAY R/A HEADER 2MM PITCH ( WAKE-ON-LAN) 2 MX3-4 400-041 N/A /SCREWLOCK UNC 4-40 X 8mm CLEAR FEMALE SCREWLOCK1 J1 400-100 DCON9/NOSILK CON/D9F 9-PIN FEMALE D-TYPE CONNECTO R 1 J2 422-002 RJ45S CON/RJ45S SHIELDED RJ45-TYPE TELEPHONE SOCKET 1 MX5 425-132 N/A /ICSOCKET 32 PIN DIL SOCKET FOR #110 R24-25 R45 R48 527-008 0603 R/SM,100R,1% 1/16W SURFACE MOUNT RESISTOR R55-602 R18 R36 527-010 0603 R/SM,121R,1% 1/16W SURFACE MOUNT RESISTOR10 R27 R43 R52 R63-65 527-017 0603 R/SM,3K48,1% 1/16W SURFACE MOUNT RESISTOR R70 R74-75 R773 R5-6 R54 527-019 0603 R/SM,576R,1% 1/16W SURFACE MOUNT RESISTOR1 R26 527-020 0603 R/SM,0R SURFACE MOUNT RESISTOR11 R9 R17 R33 R42 527-025 0603 R/SM,165R,1% 1/16W SURFACE MOUNT RESISTOR R61-62 R67-69 R72-731 R46 527-026 0603 R/SM,681R,1% 1/16W SURFACE MOUNT RESISTOR2 R28 R53 527-028 0603 R/SM,6K19,1% 1/16W SURFACE MOUNT RESISTOR4 R14-15 R37 R51 527-038 0603 R/SM,18K2,1% 1/16W SURFACE MOUNT RESISTOR4 R2 R21 R32 R71 528-013 0603 R/SM,2K,5% 1/16W SURFACE MOUNT RESISTOR4 R22-23 R29-30 553-027 1206 R/SM,27R,5% 1/4W SURFACE MOUNT RESISTOR2 C12-13 675-003 TANT/A C/TNTSM,1U5,10% 16V TANTALUM CHIP CAPACITOR1 C34 675-004 TANT/B C/TNTSM,6U8,20% 16V TANTALUM CHIP CAPACITOR6 C16 C23-24 C31 678-109 TANT/B C/TNTSM,10U,20% 16V TANTALUM CHIP CAPACITOR C57-584 C10-11 C32 C63 683-008 0603 C/CERSM,120P,5% 50V,COG MULTI LAYER CERAMIC CHIP CAP ACITOR 28 C3 C5 C22 C27 C29 683-013 0603 C/CERSM,100N,20% 25V,Y5V MULTI LAYER CERAMIC CHIP CAP ACITOR C35-44 C46-56 C59 C643 C14-15 C60 683-019 0603 C/CERSM,15P,5% 50V,COG MULTI LAYER CERAMIC CHIP CAP ACITOR 7 C4 C6-7 C18-19 C21 683-022 0603 C/CERSM,33P,5% 50V,COG MULTI LAYER CERAMIC CHIP CAP ACITOR C612 C20 C62 683-025 0603 C/CERSM,100P,5% 50V,COG MULTI LAYER CERAMIC CHIP CAP ACITOR 5 C2 C25-26 C28 C33 683-026 0603 C/CERSM,330P,5% 50V,COG MULTI LAYER CERAMIC CHIP CAP ACITOR 1 U8 735-012 DIP8/SO SERIAL/EEPROM 93C46 SERIAL EEPROM USE BIA SPEC.9 60-003-07 1 U7 741-019 DIP28/SOJ/300 SRAM32KX8 32K X 8 STATIC RAM3 Q7-9 780-207 SOT23N PNP/SOT23A BCW29L PNP TRANSISTOR7 Q3-4 Q11-12 Q17-18 780-221 SOT23N NPN/SOT23A PMBT2222 NPN TRANSISTOR Q221 U1 783-152 SOT223 LT1117 LINEAR LT1117-3.3 VOLTAGE REGULATOR3 CR1-3 786-001 SOT23N CR2/SOT23A BAV99 DUAL DIODE1 T2 807-045 DIP20/SOWIDE TR/BEL/40 BEL S553-5999-40 DUAL TRANSFORMER/CHOKE4 L1-4 816-111 0805 L/SM,390N,10% TDK MLF2012DR39KT SM INDUCTOR4 FB1-4 817-009 0805 FBEAD BLM21 FERRITE BEAD1 X1 829-512 OSC/8 OSC/8/EN,32MHZ 100PPM CRYSTAL OSCILLATOR MODULE WI TH ENABLE 1 C45 NOT FITTED 0603 C/CERSM,100N,20% 25V,Y5V MULTI LAYER CERAMIC CHIP CAP ACITOR 1 C1 NOT FITTED 0603 C/CERSM,10P,5% 50V,COG MULTI LAYER CERAMIC CHIP CAP ACITOR 1 C17 NOT FITTED 0805 C/CERSM,47N,10% 50V,X7R MULTI LAYER CERAMIC CHIP CAP ACITOR 1 C8 NOT FITTED 0603 C/CERSM,4N7,10% 50V,X7R MULTI LAYER CERAMIC CHIP CAP ACITOR 1 CR4 NOT FITTED SMBJ CR/SCHOTTKY MBRS130LT3 SCHOTTKY DIODE1 U5 NOT FITTED CC32 FLASH5/128KX8 AT29C512/010 5V 128K X 8 FLASH EEPROM1 U6 NOT FITTED DIP32/600 #1 FLASH5/512KX8 AT29C512/010/040 5V 512K X 8 FLASH EEPROM1 L5 NOT FITTED P0231 L/SMT,10uH,10% PULSE P0231 SURFACE MOUNT INDUCTOR1 U2 NOT FITTED DIP8/SO LT1372 LT1372 SWITCHING REGULATOR5 Q5-6 Q13-15 NOT FITTED SOT23N NPN/SOT23A PMBT2222 NPN TRANSISTOR1 X2 NOT FITTED OSC/4/SO OSC/4/SM/E,32MHZ ???PPM,???SIZE CLOCK OSCILLATOR MODULE WITH ENABLE 2 Q16 Q20 NOT FITTED SOT23N PNP/SOT23A BCW29L PNP TRANSISTOR2 Q19 Q21 NOT FITTED SOT23N PNP/SOT23A FMMT717 PNP TRANSISTOR4 R1 R3-4 R8 NOT FITTED 0603 R/SM,0R SURFACE MOUNT RESISTOR2 R7 R38 NOT FITTED 0603 R/SM,100K,5% 1/16W SURFACE MOUNT RESISTOR1 R66 NOT FITTED 0603 R/SM,165R,1% 1/16W SURFACE MOUNT RESISTOR5 R10-11 R13 R35 R44 NOT FITTED 0603 R/SM,18K2,1% 1/16W SURFACE MOUNT RESISTOR2 R31 R40 NOT FITTED 0603 R/SM,2K,5% 1/16W SURFACE MOUNT RESISTOR1 R34 NOT FITTED 0603 R/SM,576R,1% 1/16W SURFACE MOUNT RESISTOR4 R16 R20 R39 R78 NOT FITTED 0603 R/SM,6K19,1% 1/16W SURFACE MOUNT RESISTOR1 T1 NOT FITTED DIP20/SOL TR/BEL/40 VALOR ST4225 DUAL TRANSFORMER/CHOKE

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test Of: Madge Networks Ltd PCI3 (OEM) To: FCC Part 15: 1997 Class B Test Report Serial No: RFI/EMCB1/RP37893ETF01A This Test Report Is Issued Under The Authority Of Brian Watson Technical Director: Checked By: Tested By: pp Release Version No: 01 Issue Date: 15 October 1998Test Date: 25 September 1997 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP37893ETF01A EMC DepartmentPage 2 of 35 Issue Date: 15 October 1998 Test Of:Madge Networks Ltd PCI3 (OEM) To:FCC Part 15: 1997 Class B This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP37893ETF01A EMC DepartmentPage 3 of 35 Issue Date: 15 October 1998 Test Of:Madge Networks Ltd PCI3 (OEM) To:FCC Part 15: 1997 Class B Table of Contents 1. Client Information..........................................................................................................4 2. Equipment Under Test (EUT)........................................................................................5 3. Test Specification, Methods & Procedures..................................................................8 4. Deviations From The Test Specification....................................................................10 5. Operation Of The EUT During Testing........................................................................11 6. Summary Of Test Results...........................................................................................12 7. Measurements, Examinations And Derived Results.................................................13 8. Measurement Uncertainty...........................................................................................27 Appendix 1. Test Equipment Used..................................................................................28 Appendix 2. Measurement Methods................................................................................29 Appendix 3. Test Configuration Drawings......................................................................31 Appendix 4. Photographs of EUT....................................................................................35 RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP37893ETF01A EMC DepartmentPage 4 of 35 Issue Date: 15 October 1998 Test Of:Madge Networks Ltd PCI3 (OEM) To:FCC Part 15: 1997 Class B 1. Client Information Company Name: Madge Networks Ltd Address: Wexham Springs Framewood Road Wexham Slough SL3 6PJ Berks Contact Name: Mr Charlie Blackham RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP37893ETF01A EMC DepartmentPage 5 of 35 Issue Date: 15 October 1998 Test Of:Madge Networks Ltd PCI3 (OEM) To:FCC Part 15: 1997 Class B 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification Of Equipment Under Test (EUT) Brand Name Madge Networks Ltd Model Name or Number PCI 3 (OEM) Unique Type Identification PCB: 151-309-04 Serial Number C601F1 Country Of Manufacture UK F.C.C. ID Number Not applicable Date Of Receipt 6 October 1998 2.2. Description Of EUT The card (EUT) provides an interface between a personal computer and a token ring network. 2.3. Modifications Incorporated In EUT None 2.4. Additional Information Related To Testing Power Supply Requirement: Nominal 115 V, 60 Hz AC Mains Supply 13 Amp (max) Intended Operating Environment: Commercial, Light industry Weight: 100 to 200 g Dimensions: PCB 130mm x 80 mm Interface Ports: Two Token Ring ports: one subminiature-D and one RJ45, either of which may be used at any one time. The subminiature-D supports IBM STP cable. The RJ45 supports either category 3 to 5 STP or category 3 to 5 UTP. The EUT is internal to the Support Computer and is connected to the PCI bus expansion slot. Cycle Time: Less than 1 sec. RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP37893ETF01A EMC DepartmentPage 6 of 35 Issue Date: 15 October 1998 Test Of:Madge Networks Ltd PCI3 (OEM) To:FCC Part 15: 1997 Class B 2.5. Support Equipment The following support equipment was used to exercise the EUT during testing: Description Computer Brand Name Compaq Model Name or Number CPW 5100 6300 1P 64/4G/2D Serial Number 8834BR030101 F.C.C. ID Number Tested to comply with FCC Standards - for home or office use Cable Length And Type EUT internal to PC Connected to Port PCI bus slot Description SVGA Monitor Brand Name Hewlett Packard Model Name or Number D2817A Serial Number JP55006381 F.C.C. ID Number ACJ93312120 Cable Length And Type SVGA cable 2m Connected to Port SVGA port on support PC Description Keyboard Brand Name Compaq Model Name or Number 296433-031 Serial Number B0A260B39G275 F.C.C. ID Number AQ6-22K15 Cable Length And Type Integral 1.5m Connected to Port Keyboard mini DIN on support PC RADIO FREQUENCY INVESTIGATION LTD.Test Report S.No. RFI/EMCB1/RP37893ETF01A EMC DepartmentPage 7 of 35 Issue Date: 15 October 1998 Test Of:Madge Networks Ltd PCI3 (OEM) To:FCC Part 15: 1997 Class B Support Equipment Continued Description Mouse Brand Name Compaq Model Name or Number M-S38 Serial Number F06C10DSBGD4XG F.C.C. ID Number DZL211107 Cable Length And Type Integral 2m Connected to Port Mouse mini DIN on support PC Description Printer Bra…
