OHRCP-TXDUAL FREQUENCY R/C TX

8701 Castle Park Drive n Indianapolis, Indiana 46256 Telephone: (800) 842-2545/(317) 842-2545 n www.mssedco.com n [email protected] Page 1 Section 1 General Description Section 2 . Section 3 Figure 2 LOCK LIP B A T T E R Y P C B ! ! CP/TX Universal 300/390 MHz Transmitter with Surface Mounting Box The CP/TX radio transmitter is designed to provide reliable WIRELESS activation of any automatic door. It is part of the most extensive line of programmable wireless products available and compatible with MS Sedco switches. The CP/TX radio transmitter is a universal unit which can operate in either the 300MHz or 390MHz systems. The CP/TX comes with the transmitter prewired and installed in the mounting box for easy installation. One screw access also allows for easy battery placement. Basic Installation 1) Drill at least two holes in the box back plate and secure it to its intended location. 2) If the weatherproof gasket (MS Sedco #10001) is to be installed, apply per the instructions provided with it. 3) Secure the door activator switch assembly (purchased separately) to the box frame with two #6-32 screws (provided with the switch). NOTICE: Drill out pilot holes when necessary to mount door activator switch. 4) Program the transmitter, located in the box frame, by setting the 12 dip switches on the printed circuit board (PCB) to match the receiver. Only use the first 10 switches for the 300MHz system. Then, set the slide switch (SW2) to either 300MHz or 390MHz as shown below (fig. 1). 5) Plug the 2-lead transmitter wiring harness onto the “COM” & “N.O.” (Normally open) contacts on the door activator’s microswitch. 6) Attach the box frame to the back plate by placing the “lock lip” of the frame over the top of the back plate and pushing downward in a hinge-like motion (fig 2). 7) Secure the box frame to its back plate at the underside with a 1/4-20 screw (supplied). CP-TX CP/TX Figure 1 CP/TX PCB 390 300 SW2 (FRONT VIEW - MOUNTING BOX ONLY) (REAR VIEW) BACK PLATE 1/4-20 SCREW FRAME DOOR ACTIVATOR SWITCH WARNING: Any changes or modifications not expressly approved by MS Sedco could avoid the user’s authority to operate this equipment INSTALLATION INSTRUCTIONS

8701 Castle Park Drive Indianapolis, Indiana 46256 Dwg. # DA TE: SCALE: TITLE: REV : 1:1 4-9-03 FCC LABEL---CP-TX A MS SEDCO MA TERIAL IS 0.003 THICK VINYL WITH SELF ADHESIVE BACKING PRINTING IS BLACK LETTERS ON WHITE BACKGROUND. 1.700 0.950 THIS DEVICE COMPLIES WITH P ART 15 OF THE FCC RULES. OPERA TION OF THIS DEVICE IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MA Y NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THA T MA Y CAUSE UNDESIRED OPERA TION. MODEL NO. CP-TX P A TENT PENDING FCC ID: OHRCP-TX S W I T C H E S

CP-TX CIRCUIT DESCRIPTION The CP-TX remote control transmitter basically consists of an RF oscillator section that is driven and controlled by a single chip microprocessor. (see block diagram) The RF oscillator / amp section is a simple one stage element composed of integrated circuit IC2 and SAW resonators CR2 & CR3. The operating frequencies are 300MHz and 387MHz. Microprocessor IC1, upon power up, reads a number of jumpers and switches to determine its operating frequency, function and what ID code data is to be sent. Once this has been determined, the single stage RF section is then AM modulated with the proper data. For the carrier operating frequency of 387MHz, the data is formatted such that a logical "1" is 10KHz and a logical "0" is 20KHz. For the operating carrier frequency of 300MHz, a logical "1" is just simply leaving the carrier on for 1.5mSec and turning it off for 0.5mSec. A logical "0" is reversed from this.

MS SEDCO TRANSMITTER B.O.M. ----MODEL CP-TX 5-22-03 ITEM # REF # PART DESCRIPTION MAN. PART # VENDOR & PART # 1 SW1 12 BIT SPST DIP SW CTS# 209-12LPST use only approved subs 2 SW2 DPDT SLIDE SWITCH , MINATURE E-SWITCH # EG-2305 3 IC1 UPC2792TB MMIC AMP NEC 4 IC2 PIC16C54C-04/SO MICROPROCESSOR MICROCHIP 5 IC3 5V 50mA REGULATER, SOT23 ZETEX# ZMR500FCT 6 L1 27nH 5% COILCRAFT3 100BCS-270XJ 7 RN1&RN2 4.7k smt 8 element bussed resistor network CTS# 745C101472J 8 R1 100K 1206 SMT 5% CF RESISTOR DALE# CRCW1206104JRT1 9 R2 1K 1206 SMT 5% CF RESISTOR DALE# CRCW1206102JRT1 10 R3 NOT USED 11 R4 560 Ohm 0805 SMT 5% CF RESISTOR DALE# CRCW0805560JRT1 12 R5 1K 0805 SMT 5% CF RESISTOR DALE# CRCW0805102JRT1 13 R6 100K 0805 SMT 5% CF RESISTOR DALE# CRCW0805104JRT1 14 R7 100K 0805 SMT 5% CF RESISTOR DALE# CRCW1206104JRT1 15 C1 0.1uF X7R 50V CER CHIP 0805 PANASONIC# ECJ-2YB1H104K AVX# 08055C104KATM 16 C2 0.1uF X7R 50V CER CHIP 0805 PANASONIC# ECJ-2YB1H104K AVX# 08055C104KATM 17 C3 0.1uF X7R 16V CER CHIP 1206 PANASONIC# ECJ-3VB1C104K 18 C4 4.7uF X7R 10V CER CHIP 1206 MURATA# GRM42-6X5R475K010AL 19 C5 1pF NPO 50V CER CHIP 0805 PANASONIC# ECJ-2VC1H010C AVX# 08055A1R0CATN 20 C6 0.1uF X7R 50V CER CHIP 0805 PANASONIC# ECJ-2YB1H104K AVX# 08055C104KATM 21 C7 3pF NPO 50V CER CHIP 0805 PANASONIC# ECJ-2VC1H030C AVX# 08055A3R0CATN 22 C8 8pF NPO 50V CER CHIP 0805 PANASONIC# ECJ-2VC1H080D AVX# 08055A8R0CATN 23 C9 68pF NPO 50V CER CHIP 0805 PANASONIC# ECJ-2VC1H680J 24 C10 12pF NPO 50V CER CHIP 0805 PANASONIC# ECJ-2VC1H120D 25 C11 1pF NPO 50V CER CHIP 0805 PANASONIC# ECJ-2VC1H010C AVX# 08055A1R0CATN 26 C12 6pF NPO 50V CER CHIP 0805 PANASONIC# ECJ-2VC1H060D AVX# 08055A6R0CATN 27 C13 15pF NPO 50V CER CHIP 0805 PANASONIC# ECJ-2VC1H150D AVX# 08055A15R0CATN 28 Q1 NPN TRANSISTOR WITH BIAS RESISTORS MOT# MMUN2211LT1 29 Q2 PNP TRANSISTOR WITH BIAS RESISTORS MOT# MMUN2111LT1 30 Q3 NPN TRANSISTOR WITH BIAS RESISTORS MOT# MMUN2211LT1 31 Q4 PNP TRANSISTOR WITH BIAS RESISTORS MOT# MMUN2111LT1 32 CN2 2 PIN MALE HEADER 0.1LS MOLEX 22-23-2021 33 D1 RED LED SMT KING BRIGHT# KP3015HC STANLEY# PR1101W-TR 34 DA1 SMT DUAL SWITCHING DIODE MOT# BAV99LT1 (SOT-23) 35 DA2 SMT DUAL SWITCHING DIODE MOT# BAV99LT1 (SOT-23) 36 DA3 SMT DUAL SWITCHING DIODE MOT# BAV99LT1 (SOT-23) 37 DA4 SMT DUAL SWITCHING DIODE MOT# BAV70LT1 (SOT-23) 38 CR1 4MHZ CERAMIC RES MURATA# CST4.00MGW 39 CR2 300MHZ SAW Res (Two- Port) Abundance Enterprise Co NMB300 (+/- 100KHz) 40 CR3 387MHZ SAW Res (Two-Port) Abundance Enterprise Co NMB387 (+/- 100KHz) 41 MISC 9V BATTERY (CARBON / ZINC) 42 MISC SPACER ( FOR SAW RESONATORS) BIVAR# 515-020 2 PCS REQUIRED 43 BS1 9V BATTERY SNAP EAGLE 44 MISC FERRITE BEAD, BALUN TYPE EASEHOUSE CORE # RID 4.1 X 6.3 X 7 45 MISC FCC LABEL MS SEDCO# 81A??? 46 PCB1 PCB FR4 1 OZ COPPER CLAD 2 SIDE 3.133 SQ. IN.

A 10K 02 MMUN2111LTI 10K 2 9VDC 2 PINHDR SEQUENCETIMINGCHART 3 4 A B 10K 10K 03 MMUN2211LTI B NORMAL/DUALFUNCTIONJUMPER (INFORNORMALTXOPERATION) "" DMJP3 SEOUENCETIMING (SEECHART) JP1DA2 R2 IK BS"118 2 "'3 JP2DAI B4"10 17 RI 100K RTCCI3 MCLR.. ICI PIC16C54 VSS"5 300MH, SW2-B 387MH, +5V R6 W0K 0805 RNI 4.7K CTS#745C101472J SW1 DIP SWITCH -::- B LNI27IR-TR C6DI, 0.1"F'. +1(1I' DM 2...,3 R7 100K 0805 c R4 560 01 MMUN2211LTI 10K -::- C9 I 68pF C WK -::- D +5V 10K -C4 I 4.7VF 1206 10K 04 MMUN2111LTI. 2 SW2-A CR3 300MH, I C7 3.0pF I C8 8.0pF l CI3 15pF 3 ~E H" 1DM2 ~E H' 1 DAI-DA32 NOTES, ALLRESISTORSARE1206UNLESSOTHERWISESTATED AlLCAPSARE0805UNLESSOTHERWISESTATED AlLTRANSISTORSARESOT-23 c B Title14 MSSEDCOTX-DUALFREQ/FUNCTION ~Number CP-TX~ E Date5-22-03 Filename Drawnb Sheet RGBJ of D JP2JPITIMING INRTeC OUT OUT10SEC0 OUT IN SSEC 4 INOUT3SEC8 ININ0SEC12

APPLICANT: SEDCO INC. FCC ID: OHRCP-TX REPORT #: S/SEDCO_OHR\567ZUT3\567ZUT3TestReport.doc TABLE OF CONTENTS LIST TABLE OF CONTENTS APPLICANT: SEDCO INC. FCC ID: OHRCP-TX TEST REPORT CONTAINING: PAGE 1-4...........TEST EQUIPMENT LIST PAGE 5.............TEST PROCEDURE PAGE 6.............RADIATION INTERFERENCE TEST DATA NORMAL DOOR OPENER PAGE 7.............OCCUPIED BANDWIDTH – NORMAL DOOR OPENER PAGE 8.............RADIATION INTERFERENCE TEST DATA HANDICAP EUT PAGE 9.............DUTY CYCLE CALCULATION –HANDICAP EUT PAGE 10............DUTY CYCLE PLOT - SMALL PULSES PAGE 11............DUTY CYCLE PLOT - LONG PULSES PAGE 12............DUTY CYCLE PLOT – COMPLETE PULSE TRAIN PAGE 13............OCCUPIED BANDWIDTH – HANDICAP EUT EXHIBIT ATTACHMENTS: EXHIBIT 1...........BLOCK DIAGRAM EXHIBIT 2...........SCHEMATIC EXHIBIT 3...........PARTS LIST EXHIBIT 4...........INSTRUCTION MANUAL EXHIBIT 5...........LABEL SAMPLE EXHIBIT 6...........LABEL LOCATION EXHIBIT 7...........EXTERNAL PHOTOGRAPHS EXHIBIT 8...........INTERNAL PHOTOGRAPHS – NORMAL DOOR OPENER EXHIBIT 9...........INTERNAL PHOTOGRAPHS – HANDICAP EUT EXHIBIT 10..........TEST SET UP PHOTOGRAPH EXHIBIT 11..........CIRCUIT DESCRIPTION APPLICANT: SEDCO INC. FCC ID: OHRCP-TX REPORT #: S/SEDCO_OHR\567ZUT3\567ZUT3TestReport.doc Page 1 of 13 EMC Equipment List DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS X 3-Meter OATS TEI N/A N/A Listed 1/13/03 1/13/06 3/10-Meter OATS TEI N/A N/A Listed 3/26/01 3/26/04 Receiver, Beige Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 8/31/01 8/31/03 RF Preselector HP 85685A 3221A01400 CAL 8/31/01 8/31/03 Quasi-Peak Adapter HP 85650A 3303A01690 CAL 8/31/01 8/31/03 X Receiver, Blue Tower X Spectrum Analyzer HP 8568B 2928A04729 2848A18049 CAL 4/15/03 4/15/05 X RF Preselector HP 85685A 2926A00983 CAL 4/15/03 4/15/05 X Quasi-Peak Adapter HP 85650A 2811A01279 CAL 4/15/03 4/15/05 Receiver, Silver/Grey Tower Spectrum Analyzer HP 8566B Opt 462 3552A22064 3638A08608 CAL 10/14/02 10/14/04 RF Preselector HP 85685A 2620A00294 CAL 10/14/02 10/14/04 Quasi-Peak Adapter HP 85650A 3303A01844 CAL 10/14/02 10/14/04 Preamplifier HP 8449B 3008A01075 CHAR 1/28/02 1/28/04 X Biconnical Antenna Electro-Metrics BIA-25 1171 CAL 4/26/01 4/26/03 Biconnical Antenna Eaton 94455-1 1096 CAL 10/1/01 10/1/03 Biconnical Antenna Eaton 94455-1 1057 CAL 3/18/03 3/18/05 BiconiLog Antenna EMCO 3143 9409-1043 X Log-Periodic Antenna Electro-Metrics LPA-25 1122 CAL 10/2/01 10/2/03 Log-Periodic Antenna Electro-Metrics EM-6950 632 CHAR 10/15/01 10/15/03 Log-Periodic Antenna Electro-Metrics LPA-30 409 CAL 3/4/03 3/4/05 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 152 CAL 3/21/01 3/21/04 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 153 CAL 9/26/02 9/26/05 APPLICANT: SEDCO INC. FCC ID: OHRCP-TX REPORT #: S/SEDCO_OHR\567ZUT3\567ZUT3TestReport.doc Page 2 of 13 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Double-Ridged Horn Antenna Electro-Metrics RGA-180 2319 CAL 2/17/03 2/17/05 Horn Antenna Electro-Metrics EM-6961 6246 CAL 3/31/03 3/31/05 Horn Antenna ATM 19-443-6R None No Cal Required Passive Loop Antenna EMC Test Systems EMCO 6512 9706-1211 CHAR 7/10/01 7/10/03 Line Impedance Stabilization . . . Electro-Metrics ANS-25/2 2604 CAL 10/9/01 10/9/03 Line Impedance Stabilization . . . Electro-Metrics EM-7820 2682 CAL 3/12/03 3/12/05 Termaline Wattmeter Bird Electronic Corporation 611 16405 CAL 5/25/99 5/25/01 Termaline Wattmeter Bird Electronic Corporation 6104 1926 CHAR 12/12/01 12/12/03 Oscilloscope Tektronix 2230 300572 CHAR 2/1/01 2/1/03 System One Audio Precision System One SYS1-45868 CHAR 4/25/02 4/25/04 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 1/22/02 1/22/04 AC Voltmeter HP 400FL 2213A14499 CAL 10/9/01 10/9/03 AC Voltmeter HP 400FL 2213A14261 CHAR 10/15/01 10/15/03 AC Voltmeter HP 400FL 2213A14728 CHAR 10/15/01 10/15/03 X Digital Multimeter Fluke 77 35053830 CHAR 1/8/02 1/8/04 Digital Multimeter Fluke 77 43850817 CHAR 1/8/02 1/8/04 Digital Multimeter HP E2377A 2927J05849 CHAR 1/8/02 1/8/04 Multimeter Fluke FLUKE-77-3 79510405 CHAR 9/26/01 9/26/03 Peak Power Meter HP 8900C 2131A00545 CHAR 1/26/01 1/26/03 Power Meter HP 432A 1141A07655 CAL 4/15/03 4/15/05 Power Meter And Sensor Bird 4421-107 4022 0166 0218 CAL 4/16/03 4/16/05 Power Sensor HP 478A 72129 CAL 4/15/03 4/15/05 Digital Thermometer Fluke 2166A 42032 CAL 1/16/02 1/16/04 Thermometer Traulsen SK-128 CHAR 1/22/02 1/22/04 APPLICANT: SEDCO INC. FCC ID: OHRCP-TX REPORT #: S/SEDCO_OHR\567ZUT3\567ZUT3TestReport.doc Page 3 of 13 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Thermometer Extech 4028 14871-2 CAL 3/7/03 3/7/05 X Hygro-Thermometer Extech 445703 0602 CAL 10/4/02 10/4/04 Frequency Counter HP 5352B 2632A00165 CAL 11/28/01 11/28/03 Frequency Counter HP 5385A 2730A03025 CAL 3/7/03 3/7/05 Power Sensor Agilent Technologies 84811A 2551A02705 CHAR 1/26/01 1/26/03 Service Monitor IFR FM/AM 500A 5182 CAL 11/22/00 11/22/02 Comm. Serv. Monitor IFR FM/AM 1200S 6593 CAL 5/12/02 5/12/04 Signal Generator HP 8640B 2308A21464 CAL 2/15/02 2/15/04 Sweep Generator Wiltron 6648 101009 CAL 4/15/03 4/15/05 Sweep Generator Wiltron 6669M 007005 CAL 3/3/03 3/3/05 Modulation Analyzer HP 8901A 3435A06868 CAL 9/5/01 9/5/03 Modulation Meter Boonton 8220 10901AB CAL 4/15/03 4/15/05 Near Field Probe HP HP11940A 2650A02748 CHAR 2/1/01 2/1/03 BandReject Filter Lorch Microwave 5BR4-2400/ 60-N Z1 CHAR 3/2/01 3/2/03 BandReject Filter Lorch Microwave 6BR6-2442/ 300-N Z1 CHAR 3/2/01 3/2/03 BandReject Filter Lorch Microwave 5BR4-10525/ 900-S Z1 CHAR 3/2/01 3/2/03 High Pass Filter Microlab HA-10N CHAR 10/4/01 10/4/03 High Pass Filter Microlab HA-20N CHAR 2/7/03 2/7/05 Audio Oscillator HP 653A 832-00260 CHAR 3/1/01 3/1/03 Frequency Counter HP 5382A 1620A03535 CHAR 3/2/01 3/2/03 Frequency Counter HP 5385A 3242A07460 CAL 3/7/03 3/7/05 Preamplifier HP 8449B-H02 3008A00372 CHAR 3/4/01 3/4/03 Amplifier HP 11975A 2738A01969 CHAR 3/1/01 3/1/03 Egg Timer Unk CHAR 8/31/01 8/31/03 APPLICA…
