OK6X83106VPN router

(this text is converted from HTML and I lost the lay-out, the user manual is supplied on CD-ROM in HTML format and consist of 60 pages) Approvals CE approvals MASQUERADE has been CE approved. The CE Declaration of Conformity is available from LASAT Networks A/S. Other approvals MASQUERADE has been approved by relevant authorities with regard to telecommunications, safety, and EMC regulations. Please contact your vendor for further information. Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Ca utio n: Changes or modifications not expressly approved by LASAT Networks A/S could void the user's authority to operate this equipment according to part 15 of the FCC rules.

Masquerade II Exhibit D Block diagram of the Masquerade II: CPU 66MHz and 33MHz controller SDRAM Flash RAM Ethernet 2 connections 25MHz Harddisk and HD controller ISDN incl. insulation transformer Mains inlet, filter, switch and Switch Mode PSU ISDN SELV

Notice: This i-data product is manufactured under the brand name LASAT x83106 OK6X83106 x82105 is equiped with an ISDN interface and is therefore tested and applied for Part 68 approval. x82105 New FCC ID for part 68 will be included here

LASAT MASQUERADE TM II LASAT MASQUERADE TM II is the all-in-one solution for the small and medium sized company, providing them with a secure and flexible con- nection to the Internet. Technical Specifications Components175 Dhrystone Mips RISC CPU 2Mb Flash 32Mb SDRAM 6,3 Gb hard disk Dual 10/100 Ethernet LAN ports PCI expansion slot for WAN interfaces Built-in ISDN-2 adapter LASAT MASQUERADE TM Control Centre The LASAT MASQUERADE TM management interface, called the Control in Multiple LanguagesCentre can be accessed in four different languages: English, German, French and Danish Virtual Private Network The optional VPN feature provides the ability of up to 20 remote workers to con- nect to the corporate LAN. The solution is based on the IPSec standard and the strongest encryption available on the market, 3-DES encryption Built-in ISDN-2 adapter LASAT MASQUERADE TM provides connectivity through the built-in ISDN- 2 adapter. This internal EU ISDN-2 adapter may be used together with any other connectivity solution using the PCI interface providing redun- dancy on the connectivity interfaces E-mail ServerE-mail protocols and features supported are SMTP, POP3/IMAP-4. If an existing e-mail-server still has to be used SMTP forward is also supported. Supports scheduled e-mail fetching, POP3 client (mail drop) and relay control LASAT MASQUERADE TM User Centre Each user being added to the LASAT MASQUERADE TM Control Centre will also automatically be provided with the ability to handle private account information, like changing password, setting up vacation replies etc. The user will also be able to read and write e-mails through the built-in browser based e-mail client. Any remote access to either the LASAT MASQUERADE TM Control Centre or the User Centre can be set-up by using a secure connection through a SSL connection, using HTTPS. The User Centre also includes a corporate address book containing all corporate users added to the Control Centre www.lasat.com 9052197 løsblad Masqurade II 08/08/00 13:58 Side 1 WAP supportThe LASAT MASQUERADE TM User Centre can also be accessed through any WAP enabled handset, providing remote workers with the ability to keep up-to-date with company e-mails while being on the road. Private WML pages can also be published and accessed through any WAP enabled handset FirewallIncludes various configuration possibilities; e.g. packet filtering and DMZ set-up. Spoofing protection is also part of the firewall functionality Leased Line ConnectivityLASAT MASQUERADE TM II supports the standards V.35 and X.21 on the PCI inter- face providing support for Frame Relay, SPPP and Cisco HDLC xDSL and other WAN TechnologiesThe LASAT MASQUERADE TM II supports any kind of external router providing xDSL, cable and other types of connectivity DHCP The LASAT MASQUERADE TM II can act both as a DHCP Client and as a DHCP Server System Management (Control Centre)The easy-to-use browser-based management interface includes configuration dia- logues to help and guide the user through the initial set-up process and the daily maintenance LASAT MASQUERADE TM Learning Centre To enhance the ease-of-use and to support the end-user in the daily maintenance, the LASAT MASQUERADE TM on-box support system has been supplemented with a Web site located on the Internet. The Web site, called “MASQUERADE TM On-Line Learning Center”, offers a wealth of resources both for novices and experts. The On-line Learning Centre offers an array of different services like technical courses, frequently asked questions (FAQs), troubleshooting guide, encyclopaedia, and help on specific set-up scenarios and information on new product releases. Only by accessing the Internet through the LASAT MASQUERADE TM unit enables you to gain access to this comprehensive web site without using a user id and password DiagnosticsAdvanced tools for diagnosing complicated problems, including debugging tools and different status information Web Server and FTP ServerApache web server including features such as HTTP upload, MIME type editor and access control. A FTP server is also included Operating SystemLinux 2.0 LAN InterfaceIEEE 802.3, dual 10/100 BASE-Tx auto sensing fast Ethernet with RJ45 connectors. Support for all popular LAN environments. Automatic detection of crossed or straight through cables Export LicenceWorldwide 3-DES crypto export licence from the Danish Agency for Trade and Industry Other User InterfacesFront LCD display with status information LEDs for connection and activity on the interfaces PhysicalHeight44mm Width350mm Depth250mm Weight3,5 Kg PowerAC 100-240VAC 47-63Hz Power consumption 12,5W EnvironmentMaximum altitude 3,000 metres Temperature range 1 °C to 40°C, with a humidity range of 5% to 80%, non- condensing ApprovalsEN55022, Class B FCC, part 15, subpart B, Class B CISPR 22, Class B C-UL/UL according to UL 1950, CAN/CSA-C22.2 No 950 CE according to tele, EMC and low voltage directives, CTR 3, EN50081-1, EN50082-1 and EN60950 www.lasat.com MQII-V0200-UK LASAT Networks A/S Headquarters Skalhuse 13 DK-9240 Nibe Denmark Tel.: +45 96 71 10 00 Fax: +45 96 71 10 99 www.lasat.com LASAT Networks A/S Vadstrupvej 35-43 DK-2880 Bagsværd Denmark Tel.: +45 44 36 60 00 Fax: +45 44 36 61 11 www.lasat.com © 2000 LASAT Networks A/S Made in Denmark 9052197 løsblad Masqurade II 08/08/00 13:58 Side 2

LASAT MASQUERADE TM www.lasat.com Internet Access for All Advanced Firewall Protection Features Virtual Private Network (VPN) Unmatched Ease-of-Use LASAT MASQUERADE TM LASAT MASQUERADE TM The simple solution for small- and medium-sized businesses with Internet ambitions One single unit makes it easy For most small and medium-sized businesses it can be both expensive and difficult to capitalize on the opportunities made possible by the Internet. These difficulties are compounded when the company does not possess the necessary IT skills and abilities. Typically, companies without the necessary IT competency bring in external consultants to implement complex solutions. Such complex solutions usually consist of a router, firewall, e-mail server, and possibly a modem pool, which is needed to support installations such as home workstations. Furthermore, the daily maintenance of these solutions is normally far from easy. Fortunately, there is a solution to these problems thanks to the LASAT MASQUERADE TM Thin Server, an all-in-one product which contains all the necessary functionality in one simple unit. Web Server Firewall Router E-mail Server Server Headquarters Internet Remote Worker Modem Pool Traditional Solution Remote Access Solution Tomorrow’s communication...today Simple to set up LASAT MASQUERADE TM contains in a single unit everything a small business needs to operate optimally on the Internet. In other words, it replaces much of the hardware that previously handled functions such as dial-up to the Internet, e-mail, web site hosting, and security. At the same time, LASAT MASQUERADE TM is easy to operate. Its design is based on the requirement for maximum user-friendliness, so that anyone with a minimum of IT knowledge can set up the server and connect it to the Internet and to the company’s local network. From there, it’s only a matter of configu- ring and switching on the server. Lower startup costs, smoother operation LASAT MASQUERADE TM is significantly cheaper to buy than traditional solutions. The unit costs between 30% and 40% of the total price of an equivalent standard solution based on standard separate units, where each has its own specific functions. LASAT’s Thin Server concept, where everything is contained in one box, has another advantage: that the amount of service interruptions and down periods will be significantly decreased in the long term. This is partly due to the user not having access to LASAT MASQUERADE TM ’s operating system, and that the integration of all its functionalities is handled within the LASAT MASQUERADE TM unit. This severely reduces the occurrences of system errors. Furthermore, LASAT MASQUERADE TM makes it so cheap to connect to the Internet that even companies with a small number of staff and a limited need for the Internet will notice immediate benefits. Better security With LASAT MASQUERADE TM your company is well protected against hacker-attacks and unauthorized access to company data. This is ensured by the robust, built-in firewall. As a default the firewall meets most companies’ security demands. However, if required you can change this configuration to meet your company’s needs and adhere to security policy. LASAT MASQUERADE TM LASAT MASQUERADE TM and the Virtual Private Network If your company needs to allow employees and business partners access to all or a part of its local network via a Remote Access Service (RAS), then it will benefit from LASAT MASQUERADE TM ’s VPN (Virtual Private Network) functionality. It is commonplace for companies to deploy and maintain a modem pool that handles this type of RAS solution. Often this turns out to be very expensive, due to regular maintenance and dial-up charges, especially when international calls are involved. With LASAT MASQUERADE TM ’s VPN functionality, it is now possible to use the Internet and still ensure that your company’s information is securely encrypted. This strong encryption, 3-DES, results, in principle, in an Internet-based private network for your company. VPN functionality is included as an extra feature. Mobile User LASAT VPN Client Software LASAT MASQUERADE TM Solution Headquarters Internet LASAT MASQUERADE TM Remote Worker LASAT VPN Client Software ISDN Connection or Leased Line Would you like more info? Go to www.lasat.com Ready for ISDN, or even faster... With LASAT MASQUERADE TM ’s built-in ISDN adapter, smaller companies that want to use an ISDN Internet connection can be connected up immediately without the need for additional hardware. For larger companies, or for those that need a wider bandwidth, LASAT MASQUERADE TM also supports Internet connections via permanent connections, such as Frame Relay. Moreover, companies can employ any other type of technology, such as ADSL or cable modem. This is achieved simply by connecting LASAT MASQUERADE TM to any other external router, which then manages the actual Internet connection. No matter what technology you use to connect your company to the Internet, you will always be able to use ISDN as a backup. Instead of an ISDN Internet connection, LASAT MASQUERADE TM PRO exclusively offers Frame Relay and external solutions, solutions for larger organizations that demand increased capacity and bandwidth. E-mail servers and web sites – LASAT MASQUERADE TM is open to all possibilities Whether your company’s e-mail server is hosted by an Internet Service Provider, or it is located on your own premises, LASAT MASQUERADE TM offers you the right solution. Many smaller companies have their e-mail server hosted by an Internet Service Provider, and for them LASAT MASQUERADE TM will easily handle the internal e-mail distribution. However, even larger companies that do not want their e-mail server located at an Internet Service Provider will also be able to take advantage of LASAT MASQUERADE TM . On the built-in web server, your company can host its own web site. And on the same web server you can create the company intranet. Set-up and con…

Text truncated - open the document above for the full version.

DANAK-195214 DELTA-K221300-1 Page 1 of 13 DELTA Danish Electronics, Light & Acoustic Venlighedsvej 4 DK-2970 Hørsholm Denmark Tel. (+45) 45 86 77 22 Fax (+45) 45 86 58 98 www.delta.dk This report is issued under the rules of DANAK (The Danish Accreditation Scheme) − see overleaf. The report must not be reproduced, except in full, without the written approval of DELTA. 20dan-uk-c Measurements of radio frequency interference from Masquarade II x82 105 / SafePipe x83 106 Performed for i-data International A/S Project no.: K221300-1 Date: 2000-09-21 TEST REPORT DANAK Reg. no. 19 7 annexes LIABILITY The following provisions shall apply in respect of accre- dited testing and calibration tasks conducted by DELTA Danish Electronics, Light & Acoustics (herein- after DEL- TA) and of test reports and calibration certificates issued by DELTA. 1. DELTA shall not be liable for any loss or damage un- less it is established that such loss or damage results from negligence or breach of duty on the part of DELTA. 2. The procedures used for testing/calibration and the preparation of the present test report/calibration certificate are based on the knowledge and techniques available to DELTA at the time of testing/calibration. DELTA shall not be held liable should subsequent technical developments indicate that such knowledge or techniques were inade- quate or incorrect. 3. DELTA shall not be liable for loss or damage -in cases where the product causing such loss or damage has not been tested by DELTA, except where it is estab- lished that such product is identical to one tested or ex- amined by DELTA, or -in cases where such loss or damage results from a property of a product or of a use, to which such product is put, which either has not been tested or examined and de- scribed in the present report or differs from DELTA’s de- scription in that report of the properties of the product or of uses to which it might be put. 4. DELTA will in no event be liable for consequential losses such as, but not limited to, loss of profit. 5. Should a third party enter a claim for compensation which exceeds the limits for DELTA’s liability as set out in § 1-4 above, then defence against any such claim shall be the responsibility of the Client if DELTA so requires, and all costs of such defence and of any litigation in con- nection therewith shall be borne by the Client. Should DELTA be held liable or otherwise be ordered to make payments in excess of the limits set out in § 1-4, then the Client shall be obliged to indemnify and hold DELTA harmless in respect of such excess. 6. Any dispute arising out of or relating to this Test Re- port shall be referred to Copenhagen Arbitration. The inter- pretation and performance of this Test Report shall be gov- erned by and construed in accordance with the laws of Denmark. DANAK (DANISH ACCREDITATION) DANAK was established in 1991 in pursuance of the In- dustry and Trade Promotion Act No. 394 of 13 June 1990. The scheme is a continuation of the accreditation scheme established in 1973 under the auspices of the former Dan- ish National Testing Board (STP). The requirements to the accredited testing laboratories are laid down in the Danish Agency for Development of Trade and Industry Statutory Order No. 258 of 11 April 1994 on accreditation of laboratories to perform technical testing etc. The standards DS/EN 45001 „General criteria for the oper- ation of testing laboratories“ and DS/EN 45002 „General criteria for the assessment of testing laboratories“ are inte- grated parts of the statutory order. In order to obtain accreditation to perform technical testing it is, among other things, required: -that the testing laboratory and its personnel are free from any commercial, financial and other pressures which might influence their technical judgement. -that the testing laboratory operates a quality system which is documented. -that the testing laboratory is furnished with items of -equipment required for correct performance of the tests and measurements which the laboratory is accredited to perform. -that the testing laboratory has sufficient personnel, having the necessary education, training, technical knowl- edge and experience for their assigned functions. -that the testing laboratory has procedures for traceable calibration of equipment used for accredited testing. -that accredited testing is performed after fully docu- mented methods. -that the testing laboratory has records which contain sufficient information to permit repetition of the test. -that the testing laboratory is assessed and surveyed by DANAK on a regular basis. - that the accredited laboratory shall take out an insur- ance which will cover liability in connection with accred- ited testing Test reports carrying the logo of DANAK are used to re- port accredited testing and the logo shows that the testing has been performed in accordance with the rules of ac- creditation. DANAK-195214 DELTA-K221300-1 Page 2 of 13 PeH/aed Title Measurements of radio frequency interference from Masquarade II x82 105 / SafePipe x83 106 Test objects Masquarade II x82 105 / SafePipe x83 106 Report no. DANAK-195214 Project no. K221300-1 Date of test 2000-09-13 Client i-data International A/S Vadstrupvej 27 DK-2880 Bagsværd Denmark Telephone: +45 44 36 60 00 Telefax:+45 44 36 61 11 Contact person Mr. Kim Boll Jensen Manufacturer i-data International A/S Specifications EN 55022:1998 (CISPR 22:1997) FCC part 15 Subpart B class B demonstrated by compli- ance with EN 55022. Results The emission from the test object was below the limit of the above specifications. Test personnel Henrik Egeberg Nielsen Date 2000-09-21 Project manager Per Hansen, Facility Manager, EMC DELTA Responsible Jørgen Duvald Christensen, Department Manager, EMC DELTA The client has received this report in electronic form. DELTA keeps a paper copy of the report. DANAK-195214 DELTA-K221300-1 Page 3 of 13 PeH/aed Table of contentsPage 1.Summary of test results4 2.Test specimen5 …
