OS3OPU04Oplink Processing Unit Router

User Manual – OPU3120 1 / 3 Oplink Communications, Inc. OPU(Oplink Processing Unit) Model No: OPU3120 User Manual Version 1.0.0 August, 2014 User Manual – OPU3120 2 / 3 1. Assemble OPU3120 Station And Connect To Router A B C 2. Contents A. OPU3120 B. Ethernet Cable C. Power Adapter User Manual – OPU3120 3 / 3 3. Installation OPU3120 Installation a. Connect the OPU to the home router using the provided Ethernet Cable. b. Plug Power Adapter to the OPU3120 and an outlet.

ETC Report No.:14-06-RBF-038-04 Sheet 1 of 7 Sheets FCC ID: OS3OPU04 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 1. 2. ETC Report No.:14-06-RBF-038-04 Sheet 2 of 7 Sheets FCC ID: OS3OPU04 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 3. 4. ETC Report No.:14-06-RBF-038-04 Sheet 3 of 7 Sheets FCC ID: OS3OPU04 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 5. 6.

Label Information Trade Name: OPU Model Number: OPU3120 Label Size: 44x19 cm Printing color: Black Label material: Label is Printed in the EUT Glue Material: Label is Printed in the EUT Label Size: 44x19 mm Label location:

ETC Report No.:14-06-RBF-038-04 Sheet 4 of 7 Sheets FCC ID: OS3OPU04 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 7. 8. ETC Report No.:14-06-RBF-038-04 Sheet 5 of 7 Sheets FCC ID: OS3OPU04 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 9. ETC Report No.:14-06-RBF-038-04 Sheet 6 of 7 Sheets FCC ID: OS3OPU04 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 10. 11. ETC Report No.:14-06-RBF-038-04 Sheet 7 of 7 Sheets FCC ID: OS3OPU04 Rev. No 1.0 CONSTRUCTED PHOTOS of EUT 12. 13.

FCC ID: OS3OPU04 RF Exposure Evaluation of E.U.T. : OPU router FCC ID. : OS3OPU04 MODEL : OPU3120 for APPLICANT : Zhuhai FTZ Oplink Communications, Inc ADDRESS : #29,#30 Lianfeng Avenue, Free Trade zone, Zhuhai City, Guangdong province,, 519030 China Prepared by ELECTRONICS TESTING CENTER, TAIWAN NO. 34. LIN 5. DINGFU, LINKOU DIST., NEW TAIPEI CITY, TAIWAN, 24442, R.O.C. Tel:(02)26023052 Fax:(02)26010910 http://www.etc.org.tw ; e-mail: [email protected] Report Number : 14-06-RBF-038-MPE FCC ID: OS3OPU04 TEST REPORT CERTIFICATION Applicant : Zhuhai FTZ Oplink Communications, Inc #29,#30 Lianfeng Avenue, Free Trade zone, Zhuhai City, Guangdong province,, 519030 China Manufacturer : FOWCOMM INC. 11F., No.3-2, Yuanqu St., Nangang Dist., Taipei City 115, Taiwan (R.O.C.) Description of EUT a) Type of EUT : OPU router b) Trade Name : OPLINK c) Model No. : OPU3120 d) Power Supply : AC/DC Adapter I/P: AC 100-240V, 50/60Hz, 0.5A O/P: DC 5V, 2.0A Regulation Applied : OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01), the equipment fulfills the requirements on power density for general population/uncontrolled exposure and therefore fulfills the requirements of 47 CFR Part 15.247 (b)(5). Note: 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of ETC FCC ID: OS3OPU04 Date Test Item Received : Jun. 20, 2014 Date Test Campaign Completed : Jul. 22, 2014 Date of Issue : Jul. 31, 2014 Test Engineer : (Jiapeng Chen, Engineer ) Approve & Authorized Signer : S. S. Liou, Section Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN FCC ID: OS3OPU04 Product Information: Type of EUT: OPU router FCC ID: OS3OPU04 Model: OPU3120 Description: The OPU3120 has a build-in 2T2R SDIO interface for Wireless/Lan connection. It is a device used for 2.4G ISM band, and supported 802.11b(1,2,5.5,11Mbps), 802.11g (6,9,12,18,24,36,48,54Mbps) and 802.11n(20MHz & 40 MHz). The operation frequency is 2412~2462 MHz and 433.92MHz. Maximum conducted output power (measured): 16.24 dBm or 42.072mW The following table lists the provided authorized antennas: Antenna Gain Model Antenna Type (dBi) Numeric A9701690 Dipole Antenna 5.46 3.52 Below is an example of the RF Exposure Statement: IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. No change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. FCC ID: OS3OPU04 Relative Requirement for Compliance According to section 1.1310 of FCC 47 CFR Part 1, limits for maximum permissible exposure (MPE) are as following: TABLE 1 – LIMITS FOR MAXIMUN PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3-3.0 .................. 6141.63*(100) 6 3-30 ..................... 1842/f4.89/f *(900/f 2 ) 6 30-300 .................. 61.40.1631.0 6 300-1500 ............... ...................... ......................f/300 6 1500-100,000 ......... ...................... ......................5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 ............... 6141.63*(100) 30 1.34-30 ............... 824/f2.19/f*(180/f2) 30 30-300 .................. 27.50.0730.2 30 300-1500 ............... ...................... ......................f/1500 30 1500-100,000 ......... ...................... ......................1.0 30 f = frequency in MHz * = Plane-wave equivalent power density NOTE 1 TO TABLE 1: Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational / controlled limits apply provided he or she is made aware of the potential for exposure. NOTE 2 TO TABLE 1: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. FCC ID: OS3OPU04 RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1.0 mW/cm 2 uncontrolled exposure limit. The formula shown in OET Bulletin 65 is used in the calculation. Equation from page 19 of OET Bulletin 65, Edition 97-01 is: S= PG / 4πR 2 where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) hence R= (PG / 4πS) 1/2 For our device P = 42.072mW G = 3.52 R = 20 cm S = (42.072 * 3.52) / (4*π*20 2 ) = 0.0294 mW/cm 2 < 1.0 mW/cm 2 For complying the FCC limits for general population/uncontrolled exposure, the power density limit is 1.0 mW/cm 2 . The calculation result of the power density at a distance of 20 cm of our device is less than the limit. This means that according to OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01), the equipment fulfills the requirements on power density for general population/uncontrolled exposure and …
