Oplink Communications 1 / 3 SRN1300 User Guide I. Product Introduction SRN1300 is a 433MHz wireless siren; if it receives an activating signal from the system, it will sound loudly and indicator light will flash. Siren can be stopped manually by remote control. System Structure Oplink Communications 2 / 3 II. Installation (1) Determine the location of the Indoor Siren, which should be placed: • Indoors and way from direct sunlight. • Away from extreme temperature sources and large metal objects. • Within a few feet of an electrical socket, so the AC adapter can be easily used. (2) Installation: • Hang the siren on to the wall by keyhole, using the wall plugs and screws provided. • Power on Siren. The indicator light will flash every five seconds when the siren is powered on. III. User Instruction & Workflow (1) The siren works in stand-by mode normally. (2) If it receives an activating signal from the system, it will sound loudly and indicator light will flash. (3) Siren can be stopped manually by remote control. Oplink Communications 3 / 3 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help.
