Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
SMART CARD READER/WRITER SAM-CRM-14 System Manual Ver 1.2 SAM-CRM-14_MANUAL Rev. 1.2 Dec. 05, 2013 Copyright ⓒ 2013 Samsung SDS Co., Ltd. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use this document in part or as a whole for any purposes other than those for which this document is disclosed. This document is copyrighted and contains confidential information and other intellectual property rights of Samsung SDS Co., Ltd. Any unauthorized use, copy, disclosure or distribution constitutes infringement of Samsung SDS’ intellectual property rights. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. System Manual – SAM-OCU-14 – 2013.12.05 Copyright ⓒ 2013 Samsung SDS Co., Ltd. All rights reserved | Confidential - 1 - Revision History Document Name Smart Card Reader/Writer System Manual Version Date Notice Writer 0.1 1.0 1.1 1.2 2013.06.20 2013.11.17 2013.11.18 2013.12.05 Draft Revision Revision & Translation Revision Kihyun, Kim Dalyoung, Kim Kihyun, Kim Dalyoung, Kim System Manual – SAM-OCU-14 – 2013.12.05 Copyright ⓒ 2013 Samsung SDS Co., Ltd. All rights reserved | Confidential - 2 - System Manual – SAM-OCU-14 – 2013.12.05 Copyright ⓒ 2013 Samsung SDS Co., Ltd. All rights reserved | Confidential - 3 - 목 차 Table of Contents 1 OVERVIEW .............................................................................................................................................. - 6 - 1.1 GENERAL DESCRIPTION ....................................................................................................................... - 6 - 1.2 OUTSIDE DIMENSION ........................................................................................................................... - 7 - 1.3 SYSTEM CONFIGURATION .................................................................................................................... - 8 - 1.3.1 Block Diagram ............................................................................................................................ - 8 - 1.4 GENERAL SPECIFICATION ..................................................................................................................... - 9 - 2 MODULE CONFIGURATION ............................................................................................................. - 10 - 2.1 CPU MODULE .................................................................................................................................... - 10 - 2.1.1 General Description .................................................................................................................. - 10 - 2.1.2 Block diagram ........................................................................................................................... - 11 - 2.2 BASE BOARD MODULE ........................................................................................................................ - 12 - 2.2.1 General Description .................................................................................................................. - 12 - 2.2.2 Layout of Base board module .................................................................................................... - 12 - 2.2.3 Wi-Fi/Bluetooth module ............................................................................................................ - 13 - 2.2.4 GPS module ............................................................................................................................... - 13 - 2.3 CARD READER/WRITER ..................................................................................................................... - 14 - 2.3.1 General Description .................................................................................................................. - 14 - 2.3.2 Specification .............................................................................................................................. - 14 - 2.4 TOUCH SCREEN DISPLAY ................................................................................................................... - 16 - 2.4.1 General Description .................................................................................................................. - 16 - 2.4.2 Layout........................................................................................................................................ - 16 - 2.4.3 LCD display specification ......................................................................................................... - 17 - 2.4.4 Touch panel specification .......................................................................................................... - 18 - 2.5 BARCODE READER ............................................................................................................................. - 19 - 2.5.1 General Description .................................................................................................................. - 19 - 2.5.2 Layout................................................................................................ ........................................ - 19 - 2.5.3 Specification .............................................................................................................................. - 19 - 2.6 SPEAKER ............................................................................................................................................ - 20 - 2.6.1 General Description .................................................................................................................. - 20 - 2.7 CONNECTOR AND POWER SWITCH ...................................................................................................... - 21 - 2.7.1 Signal & Power connector ...................................…
Text truncated - open the document above for the full version.
SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 SAMSUNG SDS 2014.1.7 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Certification Service Technology Inc. (CSTech) hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description : SMART VALIDATOR model name : SAM-CRM-14 FCC ID : P4YSAM-CRM-14 We affirm that between SIEMIC and Certification Service Technology Inc. (CSTech), any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature : Client’s name / title : Myoung Kue Lee (manager) Contact information / address : Information Company Name SAMSUNG SDS Co., Ltd. Address 707-19, Yoksam 2-dong, Gangnam-gu, Seoul, Korea, 135-918 Name For Contact Purposes E-mail Myoung Kue Lee [email protected] Telephone no. +82-2-6484-0557 Fax no. +82-2-6484-0688
SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 SAMSUNG SDS 2014.1.7 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: P4YSAM-CRM-14 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Myoung Kue Lee (manager) Contact information / address: Information Company Name SAMSUNG SDS Co., Ltd. Address 707-19, Yoksam 2-dong, Gangnam-gu, Seoul, Korea, 135-918 Name For Contact Purposes Myoung Kue Lee E-mail [email protected] Telephone no. +82-2-6484-0557 Fax no. +82-2-6484-0688 SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 3.0 SAMSUNG SDS 2014.1.7 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: P4YSAM-CRM-14 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days (please check one). - External Photo - Internal Photo - Setup Photo - User manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Client’s signature : Client’s name / title : Myoung Kue Lee (manager) Contact information / address : Information Company Name SAMSUNG SDS Co., Ltd. Address 707-19, Yoksam 2-dong, Gangnam-gu, Seoul, Korea, 135-918 Name For Contact Purposes E-mail Myoung Kue Lee [email protected] Telephone no. +82-2-6484-0557 Fax no. +82-2-6484-0688
Photographs of EUT [External View] Front Rear Top Bottom Right Left Label Location Model NO. & Label
Label Location Model NO. & Label
Photographs of EUT [Internal View] Main Board _Front Main Board _Rear Sub Board 1_Front Sub Board 1_Rear Sub Board 2_Front Sub Board 2_Rear LCD Board Front LCD Board Rear Control Board Front Control Board Rear RF Part / Chip Antenna RFID Board Front RFID Board Rear Camera Board Front Camera Board Rear
Page Number : Page 2 to 62 Certification Service Technology http://www.cstlab.co.kr FCC Test Report SAM-CRM-14 Test Report No : CSTS-A14-FCC0002 FCC Test Report Table of Contents 1. General Information .......................................................................... 3 1.1 General Description of EUT ...............................................................................................................3 1.2 Basic Description of EUT ..................................................................................... .4 1.3 Antenna Description ............................................................................................ 4 2. Summary of test results ...................................................................... 5 2.1 Measurement uncertainty .......................................................................................6 2.2 Testing Facility ...................................................................................................7 3. TEST Instruments ............................................................................ 8 4. Configuration of system under test ...................................................... 10 4.1 Conducted Test Setup ...........................................................................................10 4.2 Radiated Test Setup ....................................................................................................10 4.3 Description of support units ...................................................................................12 4.4 Test Software Power Setting (Power Parameters of GFSK / 8-DQPSK) ...............................12 5.Test mode applicability and tested channel detail .......................................12 6. Measurement results ........................................................................13 6.1 Carrier Frequency Separation .................................................................................13 6.2 Number of hopping frequencies ..............................................................................19 6.3 Time of occupancy (Dwell Time) ............................................................................21 6.4 Max. Conducted peak output power .........................................................................24 6.5 Conducted peak power spectral density .......................................................................26 6.6 Band-edge Compliance of RF Conducted emissions ......................................................29 6.7 Band-edge Compliance of RF Radiated emissions .........................................................33 6.8 Spurious RF Conducted emissions ...........................................................................40 6.9 Spurious RF Radiated emissions .............................................................................50 6.10 Antenna requirement ..........................................................................................62 Page Number : Page 3 to 62 Certification Service Technology http://www.cstlab.co.kr FCC Test Report SAM-CRM-14 Test Report No : CSTS-A14-FCC0002 FCC Test Report 1. General Information 1.1 General Description of EUT Applicant’s Information Company Name Samsung SDS Co., Ltd.. Address 707-19, Yoksam 2-dong, Gangnam-gu, Seoul, Korea, 135-918 Name For Contact Purposes Kim Dal-Young E-mail [email protected] Telephone no. +82-2-6484-0756 Fax no. +82-2-6484-1301 Manufacturer Information Company Name SAMSUNG SDS Co., Ltd. Address 707-19, Yoksam 2-dong, Gangnam-gu, Seoul, Korea, 135-918 Page Number : Page 4 to 62 Certification Service Technology http://www.cstlab.co.kr FCC Test Report SAM-CRM-14 Test Report No : CSTS-A14-FCC0002 FCC Test Report 1.2 Basic Description of EUT Basic Description of EUT Equipment Name : SMART VALIDATOR Model NO. : SAM-CRM-14 Serial NO. : - Operating Frequency : 2402 MHz ~ 2480 MHz (Tx / Rx) Channel : 79 Communication Access Method : FHSS (Frequency Hopping Spread Spectrum) Emission Type : F1D, G1D Communication Type : Half duplex Modulation Type : GFSK (BDR), 8-DQPSK (EDR) Oscillation Type : PLL RF Output Power : 10.26 dBm (GFSK mode), 4.25 dBm (8-DQPSK mode) *It is maximum peak conducted power in band Power Source : DC 24V (Car Battery) Dimension : 193.0 mm x 319.0 mm x 61.5 mm FCC ID : P4YSAM-OCU-14 1.3 Antenna Description Antenna Description Type of Antenna : CHIP ANT. Connector Type : - Center Frequency : 2.4 GHz ~ 2.5 GHz Model Name : W5I-BF-XX Gain : 2.5 dBi max Polarization : Linear Length : 10 x 4 x 1.2 mm Page Number : Page 5 to 62 Certification Service Technology http://www.cstlab.co.kr FCC Test Report SAM-CRM-14 Test Report No : CSTS-A14-FCC0002 FCC Test Report 2. Summary of test results The EUT has been tested according to the follow specification: Description of Test FCC Rule Reference Clause Pass/Fail Test Result Carrier frequency separation (20 ㏈ bandwidth) 15.247(a)(1) Clause 5.1 Pass Compliance Number of hopping frequencies 15.247(a)(1)(iii) Clause 5.2 Pass Compliance Time of occupancy (Dwell Time) 15.247(a)(1)(iii) Clause 5.3 Pass Compliance Max. Conducted peak output power 15.247(b)(1) Clause 5.4 Pass Compliance Conducted peak output power spectrum density 15.247(e) Clause 5.5 Pass Compliance Band edge compliance of RF conducted emissions 15.247(d) Clause 5.6 Pass Compliance Band edge compliance of RF radiated emissions 15.247(d) 15.205 & 15.209 Clause 5.7 Pass Compliance Spurious RF conducted emissions 15.247(d) Clause 5.8 Pass Compliance Spurious RF radiated emissions 15.247(d), 15.209Clause 5.9 Pass Compliance Antenna requirement 15.203, 15.247 Clause 5.10 Pass Compliance AC Power line Conducted emission 15.207 Clause 5.10 - - Compliance : The EUT complies with the essential requirements in the standard. Not Compliance : The EUT does not comply with the essential requirements in the standard. N/A : The test was not applicable in the standard. The measurement report and tested in accordance with measure…
Text truncated - open the document above for the full version.
Photographs of test setup - Conducted RF measurements - Radiated RF measurements Radiated RF measurement (Below 30 MHz) Radiated RF measurement (Below 1 ㎓) Radiated RF measurement (Above 1 ㎓)
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 10.62 mW |
