P4YSHP-DS510Digital door lock

Samsung SDS Co., Ltd.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Apr 16, 2015
Application Purpose: Original Equipment
Date of Application: Apr 16, 2015
Equipment Note: Digital door lock
Frequency Range: 13.56000000 - 13.56000000
Company: Samsung SDS Co., Ltd.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Please review all included documentation and use the product as intended. Safety precautions must be followed to avoid personal injury or property damage. Samsung Smart Door Lock User Guide SHP-DS510 Smart Door Lock SHP-DS510 | Table of Contents Congratulations on the purchase of your Samsung Smart Door Lock! Your lock has a touch sensitive number display pad and optionally a 13.56MHz Card reader. Up to 100 users can be registered to gain access with unique Codes or Access Cards (supports ISO14443A type). The touchscreen makes it convenient to enter the code and the Randomizer function helps prevent lockpicking using fingerprint traces on the touchscreen. Other convenient functions such as Automatic Locking / Sound Setting, etc. provide advanced security and peace of mind.You can unlock the door using video intercom’s monitor after connecting a Samsung video intercom. (Refer to page 9 for connection diagram to a video intercom). | Helpful Tips | Introduction Do not attempt to repair the product yourself. Change your codes regularly to ensure the security of your codes. Minimize the lock’s exposure to moisture including wet hands and direct contact with liquids. Do not exert excessive force or use sharp instrument on the touchscreen. Insert the batteries according to correct polarity. When the low-battery warning sounds, replace all batteries immediately. Do not mix old batteries with new batteries. Use soft, dry cloth to clean the lock and avoid cleaning with water, alcohol or other chemicals. Introduction & Helpful Tips �� 2 Installation �� 3 Components & Tools �� 3 Door Preparation �� 4-5 Preparing the parts �� 6 Installing Lock �� 7 Setting of Right-Handed / Left Handed �� 10 Programming �� 11 Programming Features �� 11-12 Definitions & Status Indicators �� 12-14 Lock Activation & Changing the Master PIN Code �� 14 Managing User Pin Code/ Card�� 15-16 Basic Lock Operation Overview �� 17 Privacy Mode Functions �� 17 Programming Through Menu Mode Using Master Code �� 18 Miscellaneous �� 19 Miscellaneous Information �� 19 Troubleshooting �� 20-21 User Registration Table �� 22 Product Specifications �� …

Text truncated - open the document above for the full version.

Cover Letter(s)

Rev 11/20/07 125, Olympic-ro 35-gil, Songpa-gu, Seoul, Korea Tel No : +82-2-6155-5105 Fax No : +82-2-6155-0374 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: P4YSHP-DS510 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Parts List Operational description Block Diagram (P4YSHP-DS510).pdf Schematics (P4YSHP-DS510).pdf Part List (P4YSHP-DS510).pdf Operational Description (P4YSHP-DS510).pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name - - Sincerely, Myoung Kue Lee / Manager Samsung SDS Co., Ltd.

External Photos

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com EUT External Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com

ID Label/Location Info

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Label Photographs

Internal Photos

1.MainPCB 1.1MainPCBTop 1.2MainPCBBottom 2.KeyPCB 2.1KeyPCBTop 2.2KeyPCBBottom 3.TAMPERPCB 3.1TAMPERPCBTop 3.2TAMPERPCBBottom 4.ANTPCB 5.TOUCHPCB

Internal Photos

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com EUT Internal Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com RFID Antenna

Test Report

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Test Report No.: CTK-2015-00437 Date: 2015-04-15 Page 1 of 21 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15(Rev.3.3) TEST REPORT For FCC FCC Standards : FCC 47CFR part 15 subpart C Test Report No. : CTK-2015-00437 Date of Issue : 2015-04-15 FCC ID : P4YSHP-DS510 Model/Type No. : SHP-DS510 Kind of Product : Digital door lock Applicant : Samsung SDS Co., Ltd. Applicant Address : 125, Olympic-ro 35-gil, Songpa-gu, Seoul, Korea Manufacturer : Meta Networks Co. Ltd. Manufacturer Address : 55, Galmachi-ro 281beon-gil, Jungwon-gu, Seongnam-si, Gyeonggi-do Contact Person : Yu Seungkwan / Advisory Engineer Telephone : +82-2-6155-5105 Received Date : 2015-04-10 Test period : Start : 2015-04-13 End : 2015-04-15 Test Results : In Compliance Not in Compliance The test results presented in this report relate only to the object tested. Tested by Reviewed by Young-taek Lee Test Engineer Young-Joon, Park Technical Manager Date: 2015-04-15 Date: 2015-04-15 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Test Report No.: CTK-2015-00437 Date: 2015-04-15 Page 2 of 21 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15(Rev.3.3) REPORT REVISION HISTORY Date Revision Revision 2015-04-15 Issued (CTK-2015-00437) This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. will constitute fraud and shall nullify the document. CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Test Report No.: CTK-2015-00437 Date: 2015-04-15 Page 3 of 21 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15(Rev.3.3) TABLE OF CONTENTS REPORT REVISION HISTORY ........................................................................................... 2 1.0 General Product Description ................................................................................ 4 1.1 Model Differences .............................................................................................. 4 1.2 Device Modifications ........................................................................................... 4 1.3 EUT Configuration(s) .......................................................................................... 5 1.4 Test Software .................................................................................................... 5 1.5 EUT Operating Mode(s) ...................................................................................... 5 1.6 Configuration .................................................................................................... 6 1.7 Calibration Details of Equipment Used for Measurement ......................................... 7 1.8 Test Facility ....................................................................................................... 7 1.9 Measurement Procedure ..................................................................................... 7 1.10 Laboratory Accreditations and Listings .................................................................. 8 2.0 Emissions Test Regulations ................................................................................. 9 2.1 Radiated Electric Field Emissions - 15.225(a) ...................................................... 10 2.2 Radiated Electric Field Emissions - 15.225(b)(c) .................................................. 12 2.3 Radiated Electric Field Emissions - 15.225(d) ...................................................... 13 2.4 Frequency Stability – 15.225(e) ........................................................................ 15 2.5 Conducted Voltage Emissions – 15.207 ............................................................... 17 APPENDIX A – TEST DATA............................................................................................. 18 Radiated Electric Field Emissions .............................................................................. 18 Bandwidth of the Operating Frequency ..................................................................... 21 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Test Report No.: CTK-2015-00437 Date: 2015-04-15 Page 4 of 21 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15(Rev.3.3) 1.0 General Product Description 1.0.1 Tested Equipment Unless otherwise indicated, all tests were conducted on Model SHP-DS510K. Tests performed on Model were considered to be representative of Model(s) . 1.0.2 Equipment Size, Mobility and Identification Dimensions: 68(W) by 180(L) by 36.5(H) mm (Outdoor Unit) 68(W) by 180(L) by 38.3(H) mm (Indoor Unit) Mobility: Portable Table-top Built-in Floor-standing Serial No.: Prototype 1.0.3 Electrical Ratings Input : 6 Vdc (4 AA Alkaline 1.5 V Batteries (LR6)) Output : - 1.0.4 Test Voltage & Frequency Unless indicated otherwise on the individual data sheet or test results, the test voltage and frequency was as indicated below. Voltage: 6 Vdc (Battery) Frequency: - 1.0.5 Clock & Other Frequencies Utilized 16 MHz (CPU), 13.56 MHz (RFID) 1.1 Model Differences Not applicable 1.2 Device Modifications Not applicable CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Test Report No.: CTK-2…

Text truncated - open the document above for the full version.

Test Setup Photos

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Setup Photos and Configuration Radiated Electric Field Emissions (9 kHz ~ 30 MHz) (30 MHz ~ 1000 MHz) CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Frequency Stability

Contact Information

Applicant

Myoung Kue Lee(Advisory Engineer)

[email protected]82-2-6484-0557Fax: 82-2-6484-0688

Test Firm

CTK Co., Ltd.Young-Joon Park

[email protected]82-31-339-9871Fax: 82-31-624-9501

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	13.56 MHz - 13.56 MHz	-

Confidentiality

Long Term
