Technical Description of the Circuit: The product can divide into two part, RF and Baseband , the RF circuit is a single conversion, super-heterodyne architecture receiver IC. The incoming RF signal received by the antenna is fed to the RF input terminal of the IC RX3310A,then the RF signal is then amplified by the LNA in the IC RX3310A. The amplified signal will fed to the mixer input, the LO for the mixer is generated by the external LC tank circuit, in the above circuit, the LO is 432.12MHz, the IF(F RF -F LO )is then demodulated by the demodulator in the IC RX3310A and the IC RX 3310A provide the raw data. The data is then fed to the baseband MCU TM8706 for decoding and the MCU TM8706 will display the decoded temperature and the rain information at the LCD. Also the MCU equipped a time keeping clock for time and date function as well as alarm function. Page 1April 2004 RX3310A UHF ASK Receiver HiMARK Technology, Inc. reserves the right to change the product described in this datasheet. All information contained in this datasheet is subject to change without prior notice. HiMARK Technology, Inc. assumes no responsibility for the use of any circuits shown in this datasheet. Description The RX3310A is a fully integrated, amplitude-shift-keying (ASK) modulation, single chip receiver. It is designed to operate in a variety of low power radio applications. All popular radio frequencies from 250 MHz to 450 MHz may be supported by simply choosing the appropriate external components. Particular emphasis has been placed on low current con- sumption. Features ‹Wide frequency range: 250 MHz to 450 MHz ‹High sensitivity ‹Low power consumption ‹Automotive temperature range ‹High integration level requiring few and inexpensive external components ‹SOP 18L package or SSOP 20L (150 mil) package Applications ‹Remote control systems ‹Car alarm and other security systems ‹Baby finder, wireless doorbell, wireless toys Block Diagram RF AMP MIXER OSC IF FILTER COMPARATOR IF AMP BUFFER LIMITER BANDGAP REFERENCE FO OSC1OSC2 CPA CPBCPO VSSDATADISABLE VCCVEEVIRF VCCLINCPC LFB VORF MIXIN RX3310A Page 2April 2004 Package and Pin Assignment: SOP 18L or SSOP 20L Sym bols SOP 18L (dimensions in mm) SOP 18L (dimensions in inch) SSOP 20L (dimensions in mm) SSOP 20L (dimensions in inch) MIN.NOM.MAX.MIN.NOM.MAX.MIN.NOM.MAX.MIN.NOM.MAX. A------2.640------0.1041.351.601.750.0530.0640.069 A10.100------0.004------0.1---0.250.004---0.010 A22.1902.2902.3900.0860.0900.094---1.45------0.057--- b0.3600.4100.4600.0140.0160.0180.200.250.300.0080.0100.012 C0.2420.2500.2580.0070.0100.0130.19---0.250.007---0.010 D11.4611.5611.660.4510.4550.4598.55---8.750.337---0.344 SOP 18L package VCC MIXIN VORF VEE VIRF LFB VCC LIN 18 17 16 15 14 13 12 11 10 CPC OSC1 OSC2 FO CPA CPB CPO VSS DATA 1 2 3 4 5 6 7 8 HiMARK RX3310A 9 DISABLE SSOP 20L package VCC VORF VEE VIRF LFB VCC LIN 18 17 16 15 14 13 12 11 CPC OSC1 OSC2 FO CPA CPB CPO VSS DATA HiMARK RX3310A DISABLE 1 2 3 4 5 6 7 8 9 10 19 20 MIXIN VCC VSS RX3310A Page 3April 2004 RX3310A Chip Window E10.0410.3410.640.3950.4070.4195.80---6.200.228---0.244 E17.3907.4907.5900.2910.2950.2993.80---4.000.150---0.157 e1.2201.2701.3200.0480.0500.052---0.64------0.025--- L0.6400.8401.0400.0250.0330.0410.40---1.270.016---0.050 θ 0 °---8°0°---8°0° --- 8 °0° --- 8 ° y --- ---0.050 --- ---0.002------0.10------0.004 Sym bols SOP 18L (dimensions in mm) SOP 18L (dimensions in inch) SSOP 20L (dimensions in mm) SSOP 20L (dimensions in inch) MIN.NOM.MAX.MIN.NOM.MAX.MIN.NOM.MAX.MIN.NOM.MAX. RX3310A Page 4April 2004 Pin Descriptions Number (18L SOP) Number (20L SSOP) NameI/ODescription 120OSC1IOOscillator tank connection 21OSC2IOOscillator tank connection 32FOOIF filter output 43CPAIComparator input A 54CPBIComparator input B 65CPOIComparator offset adjustment 76,7VSSGNDGround 88DATAOData output 99DISABLEIDisable input. See Electrical Characteristics (cont.) on page 6 1010CPCIComparator input C 1111LINILimiter input 1212VCCPOWERPositive supply voltage 1313LFBIOLimiter feedback B 1414VIRFIRF amplifier input (requires external ac decoupling capacitor) 1515VEEGNDGround for RF amplifier 1616VORFORF amplifier output 1717MIXINIMixer input (requires external ac decoupling capacitor) 1818,19VCCPOWERPositive supply voltage RX3310A Page 5April 2004 Absolute Maximum Ratings V SS = 0 V Recommended Operating Conditions V SS = 0 V ParameterSymbolRatingUnit Supply voltage V CC V SS – 0.3 to V SS + 6.0 V Operating temperature range T OPR –60 to 85 °C Storage temperature range T STG –60 to 125 °C Soldering temperature range T SLD 255 °C Soldering time range t SLD 10s ParameterSymbol Va l u e Unit min.typ.max. Supply voltage range V CC 2.03.06.0V Operating temperature T A –402585 °C RX3310A Page 6April 2004 Receiver Characteristics (V CC = 2.0 to 6.0 V, LO-RF=1.8MHz,All tests at T A = 25 °C unless otherwise noted) Electrical Characteristics (V CC = 3.0 V, V SS = 0 V, All tests at T A = 25 °C unless otherwise noted) Electrical Characteristics (cont.) (V CC = 5.0 V, V SS = 0 V, All tests at T A = 25°C unless otherwise noted) ParameterSymbolCondition Va l u e Unit min.typ.max. Sensitivity P sens V CC = 3.0 V, T A = 27 °C, AM 99%, sine wave (ASK square wave) -100 (-104) -98 (-102) dBm Maximum input powerP in,max -35-30dBm Receiver turn-on timet ON 5ms ParameterSymbolCondition Va l u e Unit min.typ.max. Supply currentI CC 34.5mA Standby currentI CC,sb DISABLE = high510μA Disable pin input logic high a a.Note: If the Disable pad is connected to an off-chip signal (open), then the pad is internally grounded. V DIH 2.02.4V Disable pin input logic low a V DIL 0.8V Data output logic high V OH V PP b – - 0.3 V b. Note: V PP is the pull-up voltage for open collector data output. It may be as high as 13 V. V Data output logic low V OL 0.3V ParameterSymbolCondition Va l u e Unit min.typ.max. Supply currentI CC 4.55.0mA Standby currentI CC,sb DISABLE = high5 10 μA Disable pin input logic high a a.Note: If the Disable pad is connected to an off-chip …
