PML433A01Receiver

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device my not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications made to this equipment not expressly approved by NICE S.p.A. may void the FCC authorization to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. IST173 4 8 51 rev.0 00

tubular motor Instrukcje i uwagi dla instalatora neoplus Istruzioni ed avvertenze per l’installatore Instructions and warnings for the fitter Instructions et recommandations pour l’installateur Anweisungen und Hinweise für den Installateur Instrucciones y advertencias para el instalador 2 Warnings: Warning: it is important that you comply with these instructions for your own and other people’s safety. Store this manual in a safe place for future reference. This manual contains important safety provisions; incorrect installation may create serious hazards. The “NEOPLUS” motors have been designed for the automation of shut- ters and awnings; any other use is improper and prohibited. These motors are intended for residential use. Maximum continuous operating time is 4 minutes with a 20% cycle. When selecting the motor based on the application requirements, the nominal torque and operating time shown in the rating plate must be considered. The minimum diameter of the tube on which the motor can be installed is 52 mm. The motor must be installed by qualified person- nel in compliance with current safety regulations, especially as regards the electrical connections. All unnecessary electrical cables must be removed before installation; all mechanisms not required for motorized operation must be disabled. Minimum installation height is 2.5 m off the ground or floor. Easy access must in any case be ensured. For awning applications, the horizontal clearance between the fully open awning and any stationary object must be at least 0.4 m. In the case of units for outdoor use, the power supply cable must be installed inside a protective duct. The tubular motor must not be sub- jected to crushing, impacts, falls or contact with any kind of liquid. Do not perforate or drive screws into any part of the tubular motor (fig. 1). For maintenance and repairs contact a qualified technician. The application must be visible from the control buttons, which must be positioned away from any moving parts, at a height of at least 1.5 m off the ground. Keep people away from the shutter when the latter is in motion. If any work, such as window cleaning, is being carried out near the awning, do not operate it; in case of automatic control, disconnect the power supply as well. Do not allow children to play with the controls and keep all radio controls away from their reach. Check the balancing springs (if any) and the wear of cables at frequent intervals. The “NEOPLUS” series motors (fig. 2) contain a control unit with incor- porated radio receiver which works at a frequency of 433.92 MHz using rolling code technology in order to ensure high security levels. It is possi- ble to memorise up to 14 radio commands in the “ERGO” and “PLANO” series (figs. 3 and 4) or radio-sensors for each motor. After each com- mand, the motor is powered for about 2 minutes and an internal electri- cal limit switch stops movement when the required position has been reached. Additional functions can be programmed via the radio control units. An acoustic “Beep” guides users through the various phases. It is also possible to control the motors via an external button (using the Step- by-Step function) or “TTBUS” Bus. Optional wind, sun and rain sensors automatically activate the system according to weather conditions. 1) Product description 2.1) Electrical connections The cable, complete with connector which allows the motor to be rapidly disconnected, has 6 connector wires: •Mains power input:Phase, Neutral and Earth •Very low voltage command signals (SELV): Step-by-Step or “TTBUS” Bus and weather sensors WARNING: observe the connection layout carefully, if you have any doubts do NOT make experiments but consult the relevant technical sheets which are also available on the web site "www.niceforyou.com". An incorrect connec- tion may cause faults in the control unit For motor connections, an omnipolar disconnecting device with a 3-mm minimum distance between contacts must be provided for disconnection from the mains power supply (disconnecting switch or plug and socket, etc.). 2) Installation 1. Fit the motor (A) into the winding tube until it touches the end of the travel stop ring nut (E). 2. Fix the tube with the draw ring nut (D) using the M4x10 screw in order to prevent the motor from slipping or sliding axially (fig. 6). Figure 5 A:NEOPLUS tubular motor B:Clip and spacer for mounting C:Support D:Draw ring nut E:Travel stop ring nut Brown= Phase Blue= Neutral Yellow/Green = Earth Black= Common (0V) White=Step-by-St. + “TTBUS” Orange = Weather sensors ! Yellow label Green label NEOPLUS is produced by Motus S.p.a. (TV) I. ERGO and PLANO are produced by Nice S.p.a.(TV) I. Motus s.r.l. is an afiliate of the Nice S.p.a. group ! GB 3 2.1.1) “Step-by-Step” input: To manually command the automation device, connect a simple but- ton (between Common and the Step-by-Step input). The operating method follows the sequence: up-stop-down-stop. If the button is kept pressed for more than 3 seconds (but less than 10) an up manoeuvre is always carried out (corresponding to the ▲ button on the radio control units). If the button is kept pressed for more than 10 seconds a down manoeuvre is always carried out (corresponding to the ▼button). This function can be used to “synchronise” multiple motors to carry out the same manoeuvre, regardless of their operating status. 2.2) Connector and power cord (only for customer service technicians) WARNING: if the if the power cord is damaged it must be replaced with an identical type supplied by the manufac- turer or service centre. WARNING: the power cable may only be disconnected by the manufacturer, its customer service technicians or a sim- ilarly qualified person. If the motor must be disconnected from the power cord, proceed as shown in the following figures: ! ! 2.1.2) “TTBUS” input: “TTBUS” is a Bus that was developed to control the control units of motors for awnings and rolling shutters. This Bus can individuall…

Text truncated - open the document above for the full version.

N N i i c c e e S S p p A A V V i i a a P P e e z z z z a a A A l l t t a a , , 1 1 3 3 Z Z . . I I . . R R u u s s t t i i g g n n è è I I - - 3 3 1 1 0 0 4 4 6 6 O O d d e e r r z z o o T T V V I I t t a a l l i i a a P P h h o o n n e e + + 3 3 9 9 . . 0 0 4 4 2 2 2 2 . . 8 8 5 5 3 3 8 8 3 3 8 8 F F a a x x + + 3 3 9 9 . . 0 0 4 4 2 2 2 2 . . 8 8 5 5 3 3 5 5 8 8 5 5 P P . . I I V V A A 0 0 3 3 0 0 9 9 9 9 3 3 6 6 0 0 2 2 6 6 9 9 i i n n f f o o @ @ n n i i c c e e f f o o r r y y o o u u . . c c o o m m w w w w w w . . n n i i c c e e f f o o r r y y o o u u . . c c o o m m CONFIDENTIALITY REQUEST Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 DATE 22/03/2004 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Company requests confidentiality for the following products: FCC ID Number Product Title/Model PML 433A01 NEOA01/V1 For the product stated above, we request that the following information be held confidential: 1. Circuit diagrams, BOM, and PCBs submitted as Equipment Authorization Electronic Filing attachment: "schematics”. 2. Block diagram submitted as Equipment Authorization Electronic Filing attachment: “blockdiagram”. 3. Operational description submitted as Equipment Authorization Electronic Filing attachment: “operational description” The above exhibits contain Company trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our mobile handset. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Oscar Marchetto Company: Nice S.p.A. Address: Via Pezza Alta, 13 Z.I. Rustignè I-31046 Oderzo (TV) Phone: +39.0422853838 Email: [email protected]

CETECOM ICT Services GmbH Test report no.: 2-3605-01-04/04 Issue Date: 2004-04-22 Page 18 (21) Photographs of the equipment Photograph no.: 1 CETECOM ICT Services GmbH Test report no.: 2-3605-01-04/04 Issue Date: 2004-04-22 Page 19 (21) Photographs of the equipment Photograph no.: 2

Neo A01 labeling Redatto da: Data: Campagnaro Paolo 21/07/04 Dimensions: 47 X 38 mm (l Xh)

CETECOM ICT Services GmbH Test report no.: 2-3605-01-04/04 Issue Date: 2004-04-22 Page 20 (21) Photographs of the equipment Photograph no.: 3 CETECOM ICT Services GmbH Test report no.: 2-3605-01-04/04 Issue Date: 2004-04-22 Page 21 (21) Photographs of the equipment Photograph no.: 4

CETECOM ICT Services GmbH Test report no.: 2-3605-01-04/04 Issue Date: 2004-04-22 Page 15 (21) Test site CETECOM ICT Services GmbH Test report no.: 2-3605-01-04/04 Issue Date: 2004-04-22 Page 16 (21) Test site CETECOM ICT Services GmbH Test report no.: 2-3605-01-04/04 Issue Date: 2004-04-22 Page 17 (21) Test site
