PMLILIONBDTubular Motor

EN - Installation and operating instructions and warnings. Tubular motor Era Inn Edge DC S Li-Ion BD E EDGE SI 228 DC BD Note on the references in the manual - Some of the illustrations mentioned in the text can be found at the end of the manual. GENERAL WARNINGS: SAFETY - INSTALLATION - OPERATION (original instructions in Italian). ATTENTIONImportant safety instructions. Follow all instructions as improper installation can lead to serious damage. ATTENTIONImportant safety instructions. It is important for personal safety that you follow these instructions. Keep these instructions in a safe place. •Before you start the installation, you should check the ‘Technical data of the product’, in particular whether this product is suitable for the automation of your training room. If this is not the case, DO NOT carry out the installation. •The product may only be used after it has been commissioned in accordance with the chapter ‘Testing and commissioning’. ATTENTIONAccording to the latest European legislation, the manufacture of an automated system must comply with the harmonised standards provided for in the Machinery Directive in force, on the basis of which the presumed conformity of the automated system can be declared. For this reason, all work relating to connection to the mains, testing, commissioning and maintenance of the product must only be carried out by a qualified and competent technician! •Before installing the product, ensure that all materials to be used are in good condition and suitable for use. •The product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or lack of experience or knowledge. •Children must not play with the appliance. •Do not allow children to play with the appliance controls. Keep the remote controls away from children. •Handle the product with care during installation and avoid crushing it, knocking it, dropping it or allowing it to come into contact with liquids of any kind. Do not place the product near heat sources and do not expose it to naked flames. All these actions can damage it and lead to malfunctions or dangerous situations. In this case, stop the installation immediately and contact customer service. •The manufacturer is not liable for damage to property or personal injury caused by failure to follow the installation instructions. The guarantee for material defects is excluded in these cases. •The sound pressure level of the A-weighted emission is below 70 dB(A). •Cleaning and maintenance intended by the user must not be carried out by unsupervised children. •Check the system frequently, especially the cables, springs and brackets, to ensure that they are not out of balance and show no signs of wear or damage. Do not use if repair or adjustment is required as incorrect installation or a poorly balanced drive can cause injury. •The product's packaging material must be disposed of in accordance with local regulations. •A distance of at least 0.4 m must be maintained between the driven parts and fixed objects. •The labelling on the tubular motors can be covered after installation. •Watch out for the moving roller shutter and keep your distance until the roller shutter is fully lowered. •Be careful when operating the manual release device, as a raised roller shutter can fall down quickly if the springs are weak or broken. •Do not use the external blind if maintenance work, such as window cleaning, is being carried out nearby. •Disconnect the awning from the power supply if maintenance work, e.g. window cleaning, is being carried out in the vicinity. Warning for the ‘automatically controlled roller blind’. INSTALLATION WARNINGS •Before installing the drive motor, remove all unnecessary cables and switch off all devices that are not required for motorised operation. •Install the manual release actuator at a height of less than 1.8 metres. NOTE: If it is removable, the actuator must remain in close proximity to the door. •Make sure that the actuators are away from the moving parts, but still allow a direct view of them. The actuating element of a manually operated switch must be in a position that is visible from the guided part but away from moving parts. It must be mounted at a height of at least 1.5 metres. •Permanently installed operating devices must be positioned so that they are visible. •For drive motors that allow access to unprotected moving parts after installation, these parts must be installed at a height of more than 2.5 m above the floor or at another level that allows access. •This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. To ensure compliance, a minimum separation distance of 20 cm must be maintained between the device and the user during normal operation. 1 – English PRODUCT DESCRIPTION AND INTENDED USE 1 This product is a tubular motor that allows you to automate an indoor roller blind, or an indoor sun screen, or a similar rolling device (fig. 1). Any other use is prohibited! The manufacturer is not liable for damage resulting from improper use of the product, with respect to what is described in this manual. The product has the following functional characteristics: • is powered by a rechargeable battery (see the data on the engine plate); • is installed inside the roller blind; the part of the motor that protrudes from the roller (electronic head) is fixed to the ceiling or wall with special support brackets (not in- cluded in the package); • integrates a radio receiver and a control unit with encoder technology which guar- antees electronic control of the movement and the precision of the limit switches; • can be configured and operate with both ONE-WAY and TWO-WAY transmission logic. Nice's new two-way radio protocol allows communication in both directions between the transmitter and the receiver, as well as the mesh network functionality that allows you to reach any Nice automation within radio range. The signal give…

Text truncated - open the document above for the full version.

092723-17 rev 10 U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Nice North America LLC Contact Name: Alan Hutchinson Street Address: 5919 Sea Otter Place STE 100 City/Province/Zip: Carlsbad, CA 92010 Telephone No: 408-607-4476 Email: [email protected] FRN #: 0006674840 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: 5/20/2026 Signed by: Alan Hutchinson – Senior Product Regulatory and Certification Engineer The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: NICE S.p.A. Grantee Code: PML FRN #: 0010852580 Contact Name: Giovanna Algise Street Address: Via Callalta, 1 City/Province/Zip: Oderzo (TV) 31046, Italy Telephone No: +39 0422 505686 Email: [email protected] Applicant Signature 1 : Date: 18/05/2026 Signed by: Giovanna Algise – Laboratory Manager 1 - Letters must be placed on appropriate letterhead. The signee for the applicant must be one of the following: Applicant (grantee) contact of record in the FCC’s authorization system, or authorized officers or employee of the applicant (grantee).

092723-17 rev 10 Certification Application Attestation Statements Date: marzo 30, 2026 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) ______Nice S.p.A.______ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ______Nice S.p.A.______ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ☒ - is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates – see KDB 986446 Question 5) as an entity producing “covered” equipment. The applicant also certifies that the device does not have cybersecurity and/or anti-virus software produced by Kaspersky Lab, Inc or any of its successors and assignees identified on the covered list installed on the device, nor will it be installed by the applicant at any time after certification. Thank you, By: _______________________________ ______Giovanna Algise___ (Signature ) (Print name) Title: ___Laboratory Manager___ Company: ___Nice S.P.A._______ Telephone: __+39 0422 505686_____ 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist .

Nice SpA Via Pezza Alta, 13 Z.I. Rustignè I-31046 Oderzo TV Italia Cap. Soc. € 11.600.000 i.v. Phone +39.0422.853838 Fax +39.0422.853585 P.IVA 03099360269 [email protected] www.niceforyou.com 050222-17 Request for Confidentiality Date: June 4, 2025 Subject: Confidentiality Request for: ______PMLILIONBD______ Pursuant to FCC 47 CFR 0.457(d) and 0.459 and/or IC RSP-100, Section 12.4, the applicant requests that a part of the subject application(s) be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term --------------------------- External Photos ☒ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☒ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term --------------------------- Test Setup Photos ☐ Short Term ☐ Permanent * 1 User’s Manual _____ NICE S.p.A.______ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality for FCC Applications: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of __ 45 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Short Term Confidentiality for Industry Canada Applications: Starting May 2022, ISED will recognize short term confidentiality on certain exhibits until the intended date of marketing. The applicant requests the exhibits selected above as short term confidential be withheld from public view until: (specify ISED expiration date / date of marketing) . June 4, 2025 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. Nice SpA Via Pezza Alta, 13 Z.I. Rustignè I-31046 Oderzo TV Italia Cap. Soc. € 11.600.000 i.v. Phone +39.0422.853838 Fax +39.0422.853585 P.IVA 03099360269 [email protected] www.niceforyou.com 050222-17 Sincerely, By: _____ _____ Nicola Bottolo ______ (Signature/Title 3 ) (Print name) 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Nice SpA Via Pezza Alta, 13 Z.I. Rustignè I-31046 Oderzo TV Italia Cap. Soc. € 11.600.000 i.v. Phone +39.0422.853838 Fax +39.0422.853585 P.IVA 03099360269 [email protected] www.niceforyou.com 050222-17 Authority to Act as Agent Date: July 22, 2024 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: ______IMQ S.p.A.______ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: ____ 12 months _____ By: ____ ______ Nicola Bottolo _______ (Signature 1 ) (Print name) Title: ___ Laboratory Manager ___ On behalf of: _____ NICE S.p.A. _____ (Company Name) Telephone: ____ +39 0422 853838 _____ 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

FCC ID: PMLILIONBD IC ID: 6140A-ILIONBD Nice – Model: E EDGE SI 228 DC BD External Photos

Etichetta motore Motor label 30·50 Tubo Tube Ghiera Ring Testa Head Posizionamento etichetta motore tubolare Tubolar motor label positioning

NICE SPA Label Laser engraving on box. Cod e Product Label EIS0260B014B

B USINESS U NIT P RODOTTO – A PPARECCHIATURE RADIO EMF ASSESSMENT REPORT FCC Rules: Code of Federal Regulations (CFR) no. 47 RF Exposure Report Number. .............................. : AR23-0095886-01 Rev. 0 Date of issue ................................... : 2025-01-21 Total number of pages ................... : 9 Name of Testing Laboratory preparing the Report ...................... : IMQ S.p.A. Applicant’s name ............................ : NICE S.p.A. Address ........................................... : Via Callalta, 1 – IT-31046 Oderzo (TV) Test specification: ß 47 CFR 1.1307 and 447498 D04 v01 Standards ....................................... : Test Report Form No. ..................... : TRF 3609/6 Test Report Form(s) Originator ..... : IMQ S.p.A. Master TRF ...................................... : Dated 2024-01-19 Test item description ..................... : LPD transmitter for tubular motors Trademark or brand name ............. : NICE Manufacturer ................................... : NICE S.p.A. – Via Callalta, 1 – IT-31046 Oderzo (TV) Model/Type reference(s) ................ : E EDGE SI 228 DC BD Ratings ............................................ : FCC ID: ........................................... : 11.1 V DC PLMILIONBD General disclaimer: The results of tests and checks reported in this Test Report refer exclusively to the samples tested and described in the Report itself. This Report shall not be reproduced partially the written approval of IMQ S.p.A.. The authenticity of this Test Report and its contents can be verified by contacting IMQ S.p.A., responsible for this Test Report. Page 2 of 9 Report No. AR23-0095886-01 Mod. TRF 3609/6 B USINESS U NIT P RODOTTO – A PPARECCHIATURE RADIO Responsible Assessment Laboratory and testing location(s): Assessment Laboratory: IMQ S.p.A. Assessment location/ address .................... : Viale Lombardia, 20 – IT-20021 Bollate (MI) Assessed by (name, function, signature) .. : Alessandro MacrÏ [Laboratory technician] Approved by (name, function, signature) .. : Roberto Colombo [Laboratory manager] Page 3 of 9 Report No. AR23-0095886-01 Mod. TRF 3609/6 B USINESS U NIT P RODOTTO – A PPARECCHIATURE RADIO List of Attachments (including a total number of pages in each attachment): / Summary of testing Tests performed (name of test and test clause): Human exposure to electromagnetic fields Testing location: Viale Lombardia, 20 – IT-20021 Bollate (MI) Page 4 of 9 Report No. AR23-0095886-01 Mod. TRF 3609/6 B USINESS U NIT P RODOTTO – A PPARECCHIATURE RADIO Possible test case verdicts: - test case does not apply to the test item . : N/A (Not Applicable) - test item does meet the requirement ....... : P (Pass) - test item does not meet the requirement . : F (Fail) IMQ reference samples BEM 117806 (Item(s) sampled and sent by applicant) Date of receipt of test item .......................... : 2024-06-12 Date of acceptance of test item 2024-06-25 Date (s) of performance of tests ................. : 2024-07-11 General remarks: Throughout this report a comma / point is used as the decimal separator. Throughout this report, the term “Test item” is used over terms such as Test object, EUT or DUT. Name and address of factory (ies) .............. : / General product information (GPI) and other remarks: The ability or reliability of this product to perform its intended function in a particular application has not been investigated. The test results apply to the sample as received. All information relating to the details of the equipment under test at the ß 1 of this document was provided by the applicant. IMQ declines any responsibility derived from missing or wrong information provided aside by the applicant. Environmental reference conditions .......... : The climatic conditions during the tests are within the limits specified by the manufacturer for the operation of the EUT and the test equipment. The climatic conditions during the tests were within the following limits: Temperature Humidity Atmospheric pressure 15 ∞C – 35 ∞C 30 % - 60 % 800 hPa – 1060 hPa If explicitly required in the basic standard or applied product standard the climatic values are recorded and documented separately in this test report. The laboratory is monitored by a continuous environmental conditions measurements system. Temperature, humidity and pressure data are recorded on a weekly basis and stored in local archive. Page 5 of 9 Report No. AR23-0095886-01 Mod. TRF 3609/6 B USINESS U NIT P RODOTTO – A PPARECCHIATURE RADIO Table of Contents: 1 General description of test item........................................................................................................ 6 1.1 Photo(s) of the test item ...................................................................................................... 6 1.2 Test item(s) ......................................................................................................................... 6 1.3 Port(s) .................................................................................................................................. 6 1.4 Power rating(s) .................................................................................................................... 6 1.5 Additional parameters ......................................................................................................... 7 1.6 Electromagnetically relevant components ........................................................................... 7 1.7 Documents as provided by the applicant ............................................................................ 7 2 Verdict summary section .................................................................................................................. 8 3 RESULTS OF RF EXPOSURE EVALUATION ................................................................................ 9 Page 6 of 9 Report No. AR23-0095886-01 Mod. TRF 3609/6 B USINESS U NIT P RODOTTO – A PPARECCHIATURE RADIO 1 General d…

Text truncated - open the document above for the full version.

The results of tests and checks reported in this Test Report refer exclusively to the samples tested and described in the Report itself. This Report shall not be reproduced partially the written approval of IMQ S.p.A.. The authenticity of this Test Report and its contents can be verified by contacting IMQ S.p.A., responsible for this Test Report. TEST REPORT No. AR23-0095884-01 performed in accordance with FCC Rules: Code of Federal Regulations (CFR) no. 47 Part 15 Subpart C Section 15.231 PRODUCT LPD transmitter for tubular motors MODEL(s) TESTED E EDGE SI 228 DC BD FCC ID PMLILIONBD TRADE MARK(s) NICE APPLICANT NICE S.p.A. – Via Callalta, 1 – IT-31046 Oderzo (TV) Tested by Alessandro MacrÏ [Laboratory technician] Approved by Federico Sirtori [Laboratory manager] Revision Sheet Release No. Date Revision Description Rev. 0 2026-04-14 First edition Digital signed - AR23-0095884-01_TR_FCC Part C 15.231 - NICE- E EDGE SI 228 DC BD Mod. TRF 3724/ 4 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY Test Report No. AR23-0095884-01 Date: 2026-04-14 Page 2 of 25 Mod. TRF 3724/4 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY 1. GENERAL DATA SAMPLE Samples received on 2024-06-12 (Item(s) sampled and sent by applicant) IMQ reference samples BEM 117806 Samples tested No. 1 Object under analysis recognition Not carried out Date of acceptance of test item 2024-06-25 TEST LOCATION Testing dates 2024-06-25 ̃ 2024-07-04 Testing laboratory IMQ S.p.A. Testing site Viale Lombardia, 20 – IT-20021 Bollate (MI) CAB designation number IT0013 ENVIRONMENTAL CONDITIONING Parameter Measured Ambient Temperature 23.2  26.6 C Relative Humidity 48  54 % Atmospheric Pressure 954  1025 mbar The laboratory is monitored by a continuous environmental conditions measurements system. Temperature, humidity and pressure data are recorded on a weekly basis and stored in local archive. REMARKS Throughout this report a point is used as the decimal separator. The ability or reliability of this product to perform its intended function in a particular application has not been investigated. The test results apply to the sample as received. All information relating to the details of the equipment under test at the ß 3 of this document was provided by the applicant. IMQ declines any responsibility derived from missing or wrong information provided aside by the applicant. Test Report No. AR23-0095884-01 Date: 2026-04-14 Page 3 of 25 Mod. TRF 3724/4 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY 2. REFERENCE DOCUMENT DOCUMENT DATE TITLE 47 CFR Part 15 2023 Radio Frequency Device ANSI C63.4 2014 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz ANSI C63.10 2020 American National Standard for Testing Unlicensed Wireless Devices Test Report No. AR23-0095884-01 Date: 2026-04-14 Page 4 of 25 Mod. TRF 3724/4 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY 3. EQUIPMENT UNDER TEST (EUT) DETAILS GENERAL DATA MODEL (basic) Description E EDGE SI 228 DC BD LPD transmitter for tubular motors VARIANTS ß MODEL DERIVED Description / / FCC ID PMLILIONBD Manufacturer NICE S.p.A. – Via Callalta, 1 – IT-31046 Oderzo (TV) Type of equipment LPD transmitter for tubular motors Operating frequency: 433.92 MHz – Operation Command (Tx and Rx) 434.67MHz – Wake up Command (Rx only) Maximum RF radiated power: 91.30 dBμV/m (PEAK at 3m distance, 433.92 MHz) Modulation: GFSK Channel Spacing: / Antenna: Soldered onto the PCB RX sensitivity: / Channel bandwidth 160 kHz Number of channels 2 ß not object to ACCREDIA accreditation Test Report No. AR23-0095884-01 Date: 2026-04-14 Page 5 of 25 Mod. TRF 3724/4 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY 4. TEST CONFIGURATION OF EQUIPMENT UNDER TEST EUT PORTS Port Description Max length Enclosure Plastic and metal / AC power / / DC power 11V (3S1P Li-ion battery) / Signal / / Control / / Antenna Soldered onto the PCB 17 cm STATE OF THE EUT DURING TESTS Ref. Mode Description #1 Operating Continuous modulated transmission (100% duty cycle) (Possibility of selecting the desired frequencies). Dedicated SW (E EDGE SI 228 DC BD) for tests. #2 Operating Continuous reception, original SW #3 Operating Normal transmission, original SW EUT Antenna Port AC Power Port Earth Port Wired network Port Signal/Control Port DC Power Port Enclosure Port Test Report No. AR23-0095884-01 Date: 2026-04-14 Page 6 of 25 Mod. TRF 3724/4 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY SUPPORT EQUIPMENT Defined as equipment needed for correct operation or loading of the EUT, but not considered as tested: Equipment Manufacturer Model AC-DC power supply Samsung EP-TA200 ELECTROMAGNETICALLY RELEVANT COMPONENTS Component No. Manufacturer Model Microcontroller 1 STMicroelectronics STM32G071CB PCB board 1 NICE SB685 PCB board 1 NICE SB683A Radio module 1 Silicon LABS Si4461 RFI SUPPRESSION DEVICES Component No. Manufacturer Model / / / / EMI PROTECTION DEVICES Component No. Manufacturer Model / / / / EUT TECHNICAL DOCUMENTATION Document Reference / / Test Report No. AR23-0095884-01 Date: 2026-04-14 Page 7 of 25 Mod. TRF 3724/4 B.U. P RODUCTS C ONFORMITY A SSESSMENT – EMC & R ADIO E QUIPMENT L ABORATORY 5. METHODS OF MEASUREMENT All compliance measurements have been carried out using the procedures described in the standard ANSI C63.4:2014, ANSI C63.10:2020 and Section 15.31 of CFR47 Part 15 – Subpart A (General). Additional test requirements have been adopted according to the reference Section indicated in the ß 6 of this test report. FREQUENCY RANGE INVESTIGATED Conducted emission tests: from 150 kHz to 30 MHz. Radiated emission tests: from 9 kHz to tenth harmonic of fundamental BLOCK DIAGRAM OF THE TEST SETUP Test Report No. AR23-0095884-01 Date: 2026-04-14 Page 8 of 25 Mod. TRF 3724/4 B.U. P RODUCTS C …

Text truncated - open the document above for the full version.

Annex 1 of Test Report No. AR23-0095884-01 Date: 2025-07-10 Page 1 of 4 B.U. P RODUCTS C ONFORMITY A SSESSMENT - EMC & R ADIO E QUIPMENT L ABORATORY TEST REPORT NO. AR23-0095884-01 ANNEX 1 PHOTOGRAPHIC DOCUMENTATION EUT IDENTIFICATION – External views B.U. P RODUCTS C ONFORMITY A SSESSMENT - EMC & R ADIO E QUIPMENT L ABORATORY Annex 1 of Test Report No. AR23-0095884-01 Date: 2025-07-10 Page 2 of 4 B.U. P RODUCTS C ONFORMITY A SSESSMENT - EMC & R ADIO E QUIPMENT L ABORATORY TEST SET-UP – Axis orientation Annex 1 of Test Report No. AR23-0095884-01 Date: 2025-07-10 Page 3 of 4 B.U. P RODUCTS C ONFORMITY A SSESSMENT - EMC & R ADIO E QUIPMENT L ABORATORY TEST SET-UP –Conducted tests 0.15 – 30 MHz TEST SET-UP –Radiated tests 0.009 – 30 MHz Annex 1 of Test Report No. AR23-0095884-01 Date: 2025-07-10 Page 4 of 4 B.U. P RODUCTS C ONFORMITY A SSESSMENT - EMC & R ADIO E QUIPMENT L ABORATORY TEST SET-UP – Radiated tests 30-6000MHz – Worst case axis END OF DOCUMENT
