This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device my not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications made to this equipment not expressly approved by NICE S.p.A. may void the FCC authorization to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. IST173 4 8 51 rev.0 00
neomat A tubular motor Instrukcje i uwagi dla instalatora Istruzioni ed avvertenze per l’installatore Instructions and warnings for the fitter Instructions et recommandations pour l’installateur Anweisungen und Hinweise für den Installateur Instrucciones y advertencias para el instalador 2 Warnings: The “NEOMAT A” series motors have been designed for the automation of roller shutters; any other use is considered improper and is prohibited. These motors are intended for residential use. Maximum continuous oper- ating time is 4 minutes with a 20% cycle. When selecting the type of motor based on the application, you should consider the nominal torque and the operating time shown on the rating plate. The minimum diameter of the tube in which the motor can be installed is 40 mm for NEOMAT SA and 70 mm for NOEMAT LA. The motor must be installed by qualified person- nel in compliance with current safety regulations. As regards units for out- door use, the PVC power supply cable must be installed inside a protec- tive duct. The tubular motor must not be subjected to crushing, impacts, falls or contact with any kind of liquid. Do not perforate or drive screws into any part of the tubular motor (fig. 1). For maintenance and repairs contact a qualified technician. Warning:some programming phases may use the mechanical stops on the rolling shutter (rubber stops and/or anti-burglar latches). In such cas- es, the motor with the most suitable torque for a given application must be chosen, taking into consideration the effective weight of the rolling shutter in order to avoid choosing too powerful motors. The NEOMAT SA Ø35mm, NEOMAT MA Ø45mm (fig. 2) and NEO- MAT LA Ø58mm tubular motors feature an electronic control unit with incorporated radio receiver, operating at a frequency of 433.92 MHz, with rolling code technology, to guarantee high levels of secu- rity. Up to 14 “ERGO” and “PLANO” or “VOLO S RADIO” series radio controls (fig. 3 and 4) can be memorised for each motor. The control unit incorporated in the motor features a high precision electronic limit switch system capable of continuously monitoring the position of the shutter. The range of movement, i.e. the closed/open positions (plus any intermediate positions) can be programmed and memorised; after each command, the movement stops automatical- ly when these positions are reached. The control unit will also reveal any sharp variations and excessive strain on the motor, and quickly block the movement. This feature is also used to automatically programme the manoeuvring limits if the rolling shutter has upper limit switch rubber stops and anti-burglar latches. The range of movement and a few additional functions can be pro- grammed through the radio controls. A beep will sound to guide the various phases. The motors can also be controlled through an exter- nal button (with step-by-step function) or a Bus (“TTBUS”). Optional wind, sun and rain sensors can activate the system automatically whenever the weather conditions demand it. 1) Product description 2) Installation Proceed as follows to prepare the motor (fig. 4): 1. Position the idle ring nut (E) on the motor (A) until it fits into the corresponding idle ring (F). 2. Mount the draw ring nut (D) on the motor shaft. On NEOMAT SA the ring nut snaps on automatically. 3. On NEOMAT MA, fasten the draw ring nut with the snap ring. Figure 4 A:NEOMAT tubular motor B:Fastening clips or split pins C:Support and spacer D:Draw ring nut E:Idle ring nut F:Idle ring NEOMAT A is produced by Motus S.p.a. (TV) I. ERGO, PLANO, VOLO are produced by Nice S.p.a. (TV) I. Motus S.p.a. is an affiliate of the Nice S.p.a. group Fit the assembled motor into the shutter’s winding tube until it touch- es the end of the idle ring nut (E). Fasten the tube to the draw ring nut (D) using the M4x10 screw in order to prevent the motor from slipping or sliding axially (fig. 5). Finally, secure the motor head to the special support (C) with the spacer (if any), using the clips or split pin (B). 2.1) Electrical connections WARNING: For motor connections, an omnipolar dis- connecting device with a 3-mm minimum distance between contacts must be provided for disconnection from the mains power supply (disconnecting switch or plug and socket, etc.). WARNING: carefully follow all the connection instruc- tions. If you have any doubts do not make experiments but consult the relevant technical specifications sheets which are also available on the web site "www.niceforyou.com". An incorrect connection may be dangerous and cause damage to the system. The cable used for the electrical connections of the NEOMAT A motor has 6 wires: •Supply line from the power mains: Phase, Neutral and Earth •Extra low voltage control signals (SELV): Step-by-step or “TTBUS” Bus and weather sensors ! ! Brown= Phase Blue= Neutral Yellow/Green = Earth Black= Common (0V) White= Step-by-Step + “TTBUS” Orange = Weather sensorsi Yellow label Green label GB 3 2.2) Connector and power supply cable (this section refers only to the NEOMAT A version and concerns customer service per- sonnel only) WARNING: if the power cord is damaged it must be replaced with an identical type supplied by the manufacturer or an authorised customer service centre. !If it is necessary to disconnect the motor from the power supply cable proceed as shown in the figures below: ! The NEOMAT series tubular motors are equipped with an electronic limit switch system. The electronic control unit interrupts the move- ment when the shutter reaches the programmed open or closed positions. These positions must be programmed into the memory after the motor has been installed and the shutter has been fully mounted. The motor can still be controlled even if these two positions, “0” (shutter open) and “1” (shutter close), have not yet been memorised; however, the movement in this case must be controlled manually. It is also possible to program an intermediate position (Pos. “I”) for par- tial opening of th…
