PTY-2933-UWPocketPro USB Wireless

PocketPro USB Ethernet and Wireless Print Servers Installation and User’s Guide Part Number 40171-120 Revision AX1 Notice TROY GROUP, INC. SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS OF THIS PRODUCT FOR A PARTICULAR PURPOSE. TROY shall not be liable for any errors contained in this manual or for any damages resulting from loss of use, data, profits, or any incidental or consequential damages arising from the use of TROY products or services. The information contained in this documentation is subject to change without notice. Trademarks HP, HP/UX, LaserJet, DesignJet, DeskJet, PaintJet, JetDirect, and JetAdmin are trademarks of Hewlett-Packard Company. DEC, DECserver, VMS, LAT, and ULTRIX are trademarks of Digital Equipment Corporation. UNIX is a trademark of UNIX Systems Laboratories. Ethernet is a trademark of Xerox Corporation. PostScript is a trademark of Adobe Systems Incorporated. NetWare is a trademark of Novell, Inc. Apple, Macintosh, LaserWriter, and AppleTalk are trademarks of Apple Computer, Inc. IBM, LAN Server, and AIX are trademarks of International Business Machines Corporation. LAN Manager, Windows, and MS-DOS are trademarks of Microsoft Corporation. VINES is a trademark of Banyan Systems Inc. PrintKit is a trademark of Northlake Software. QADD is a trademark of Network Compatibility Group. LAN Attached and UNIX Printing for VINES is a trademark of Incognito Software Inc. ExtendView, Xadmin 32, and WebXAdmin are trademarks of TROY Group, Inc. TROY is a registered trademark of TROY Group, Inc. Information and descriptions contained herein are the property of TROY Group, Inc. Such information and descriptions may not be copied, disseminated, or distributed without the express written consent of TROY Group, Inc. This publication is subject to change without notice. TROY Group, Inc. 2331 S. Pullman Street Santa Ana, CA 92705 TEL: (949) 250-3280 FAX: (949) 250-8972 http://www.troygroup.com [email protected] © Copyright 2003 TROY Group, Inc. Printed in the United States of America October 1, 2003 0560 User’s Guide Document #40171-120 Rev. AX1 TABLE OF CONTENTS Introduction............................................................................................. 1 Package Contents .................................................................................... 1 About this User’s Guide.......................................................................... 2 Print Server Components ........................................................................ 3 LED Indicators ................................................................................. 4 Windows System Requirements ............................................................. 5 Macintosh System Requirements............................................................ 5 Network Protocols Supported ................................................................. 5 Wireless Print Server Requirements ....................................................... 6 Hardware Setup (wired and wireless versions).................................................... 7 Verifying the Connection to the Printer .................................................. 9 Configuring the PocketPro USB ........................................................... 10 Configuring the Print Server Using an Ethernet Connection ......... 10 First-Time Configuration of the Wireless Print Server .................. 13 Windows Print Queue Configuration.................................................... 14 Macintosh Print Queue Configuration .................................................. 15 Management Methods........................................................................... 17 ExtendView Utility ........................................................................ 17 ExtendView Web Utility................................................................ 17 XAdmin32 Utility .......................................................................... 17 WebXAdmin Utility....................................................................... 18 HP JetAdmin Utility....................................................................... 18 HP Web JetAdmin Utility .............................................................. 18 Command Console......................................................................... 18 Troubleshooting .................................................................................... 19 Printing Problems........................................................................... 19 Troubleshooting Network Configuration Problems ....................... 21 Troubleshooting Windows Problems ............................................. 22 Troubleshooting Wireless Configuration Problems.............................. 22 Loading New Firmware (Using the TCP/IP Update Utility)............................... 24 Loading New Firmware (Macintosh OS-X).................................................. 28 Obtaining Technical Assistance............................................................ 29 Returning Products................................................................................ 30 Contacts................................................................................................. 31 Technical Support .......................................................................... 31 Safety and Regulatory Notices.............................................................. 32 User’s Guide Document #40171-120 Rev. AX1 1 TROY Installation Instructions (FOR USE WITH TROY POCKETPRO USB PRINT SERVERS) NOTE: This User’s Guide is available in other languages that can be printed from the TROY PocketPro USB Installation CD. Introduction The TROY PocketPro USB is a high-performance compact print server that connects to the USB port of your printer. This print server supports and automatically senses both 100baseTX Fast Ethernet and 10baseT Ethernet network connections, and the wirele…

Text truncated - open the document above for the full version.

Report Number: B31007B1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report PocketPro USB Wireless Model: 2933-UW Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 20 FCC PART 15, SUBPART B and C TEST REPORT for POCKETPRO USB WIRELESS MODEL: 2933-UW Prepared for TROY GROUP, INC. 2331 SOUTH PULLMAN STREET SANTA ANA, CALIFORNIA 92705 Prepared by:_____________________ MICHAEL CHRISTENSEN Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: DECEMBER 18, 2003 REPORT APPENDICES TOTAL BODY A B C D E PAGES 20 2 2 2 18 44 88 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B31007B1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report PocketPro USB Wireless Model: 2933-UW Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 20 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration - EMI 9 4.1.1 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 11 5.1 EUT and Accessory List 11 5.2 EMI Test Equipment for Brea Facility 12 6. TEST SITE DESCRIPTION 13 6.1 Test Facility Description 13 6.2 EUT Mounting, Bonding and Grounding 13 7. CHARACTERISTICS OF THE TRANSMITTER 14 7.1 Antenna Gain 14 8. TEST PROCEDURES 15 8.1 RF Emissions 15 8.1.1 Conducted Emissions Test 15 8.1.2 Radiated Emissions (Spurious and Harmonics) Test 16 8.2 6 dB Bandwidth 18 8.3 Peak Output Power 18 8.4 RF Antenna Conducted Test 18 8.5 Spectral Density Output 19 8.6 RF Band Edges 19 9. CONCLUSIONS 20 Report Number: B31007B1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report PocketPro USB Wireless Model: 2933-UW Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 20 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated and Conducted Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map and Layout of 3 Meter Radiated Site 3 Plot Map and Layout of 10 Meter Radiated Site Report Number: B31007B1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report PocketPro USB Wireless Model: 2933-UW Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 20 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST, or any other agency of the U.S. Government. Device Tested: PocketPro USB Wireless Model: 2933-UW S/N: 6 Product Description: See Expository Statement. Modifications: The EUT was not modified during the testing. Manufacturer: Troy Group, Inc. 2331 South Pullman Street Santa Ana, California 92705 Test Dates: September 29 and 30 and October 2, 2003. Test Specifications : EMI requirements Limits: EN 55022: 1998 Class B ; CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.207, 15.209, and 15.247 Test Procedure: ANSI C63.4: 2001 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B31007B1 FCC Part 15 Subpart B and FCC Section 15.247 Test Report PocketPro USB Wireless Model: 2933-UW Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 20 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz Complies with the Class B limits of EN 55022: 1998; and the limits of CFR Title 47, Part 15, Subpart C, section 15.207 2 Spurious Radiated RF Emissions, 30 MHz – 1000 MHz Complies with the Class B limits of EN 55022: 1998; and the limits of CFR Title 47, Part 15, Subpart B 3 Spurious Radiated RF Emissions, 10 kHz - 25000 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and CFR Title 47, Part 15, Subpart C, section 15.247(c) 4 Fundamental and Emissions produced by the intentional radiator in non-restricted ban…

Text truncated - open the document above for the full version.

MPE Calculations For RF Exposure Requirements PocketPro USB Wireless Model: 2933-UW Page 1 of 1 MAXIMUM PERMISSIBLE EXPOSURE FOR SUBPART C 2.4 GHz BAND Calculations Power density at the specific separation: S = PG/(4R 2 π) S = (32.66 * 1.413) / (4 * 20 2 * π) S = 0.009 mW/cm 2 where S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) – 15.14 dBm G = Numeric power gain of the antenna R = distance to the center of the radiation of the antenna (20 cm = limit for MPE) The maximum permissible exposure (MPE) for the general population is 1 mW/cm 2 . The power density at 20 cm does not exceed the 1 mW/cm 2 . Therefore, the exposure condition is compliant with FCC rules. The numeric gain (G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain/10) G = Log -1 (1.5 dBi/10) G = 1.413

HOW THE EUT MEETS THE REQUIREMENTS OF 15.31 (e) FOR THE TROY GROUP, INC. POCKETPRO USB WIRELESS MODEL: 2933-UW (EUT) The fundamental was maximized on the Lab B test site using a normal test setup with the EUT’s AC Adapter connected directly to the AC public mains (115 Vac). Next, the EUT’s AC Adapter was then connected to the Staco Energy Products Variable Auto Transformer Model: 3PN1010. The Variable Auto Transformer allows the Vac input to be varied. The EUT’s AC Adapter was then connected to the Staco Energy Products Variable Auto Transformer Model: 3PN1010. The AC input was then dropped to 85% (97.75 Vac) and raised to 115% (132.25 Vac). The actual AC input was measured using a calibrated Fluke Multimeter Model: 87, Serial Number: 51350019, Calibration Due Date: July 11, 2004. The fundamental was then verified again to see that the amplitude did not change. Test Result: The EUT does NOT change amplitude at the fundamental when the AC input voltage is varied between 85% and 115% of the input nominal rated supply voltage.
