PVH090202SSerial Port Adapter

u-blox Malmo AB

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Nov 29, 2005
Application Purpose: Original Equipment
Date of Application: Nov 29, 2005
Equipment Note: Serial Port Adapter
Frequency Range: 2402.00000000 - 2480.00000000
Company: u-blox Malmo AB
Country: Sweden

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

INDUSTRIAL BLUETOOTH™ OEM Serial Port Adapter™ cB-0902 Electrical & Mechanical Datasheet OEM Serial Port Adapter™ cB-0902 Electrical & Mechanical Datasheet Copyright © 2005 connectBlue AB. The contents of this document can be changed by connectBlue AB without prior no- tice and do not constitute any binding undertakings from connectBlue AB. con- nectBlue AB is not responsible under any circumstances for direct, indirect, unex- pected damage or consequent damage that is caused by this document. All rights reserved. Release: 2005-11 Document version: 0.4 Draft 1 Document number: cBProduct-0503-01 Printed in Sweden. Trademarks Registered trademarks from other companies are: Bluetooth is a trademark owned by the Bluetooth SIG, Inc., Microsoft™, Windows™, Windows NT™, Windows 2000™, Windows CE™, Windows ME™, are registered trademarks from Microsoft Corporation. Version 0.4 Draft 1 - 2005-11 4 Contents 1 Introduction 5 1.1 Related Documents...........................................................................5 1.2 Product Variants................................................................................6 1.3 cB-0902..............................................................................................7 1.4 Block Diagram cB-0902.....................................................................8 2 Electrical Interface and Connectors 9 2.1 Pin Numbering.................................................................................10 2.2 Pin Description.................................................................................11 2.3 Characteristics.................................................................................17 2.4 Hardware Reset...............................................................................21 2.5 Power Control..................................................................................21 3 Operating Status 22 4 Antennas 23 4.1 Surface Mounted Antenna (Internal)................................................23 4.2 External antennas............................................................................24 5 Mounting Information 27 5.1 Board Outlines.................................................................................27 5.2 Using the J2/J3 Board-to-Board Connectors...................................29 5.3 Using Press-Fit Nuts for Mounting the Module................................33 5.4 Antenna Issues................................................................................33 6 Bluetooth Information 34 6.1 General information.........................................................................34 6.2 Bluetooth Qualification information..................................................35 7 Regulatory Information 36 7.1 Declaration of Conformity................................................................36 7.2 FCC, IC and Safety Compliance......................................................37 7.3 UL listing information.......................................................................39 7.4 Compliance with RoHS directive.....................................................39 Appendix A - Application Notes 40 A.1 Step-by-Step Guide.........................................................................40 A.2 Design Examples.............................................................................42 Version 0.4 Draft 1 - 2005-11 5 1 Introduction 1.1 Related Documents There are some documents related to the Serial Port Adapter: - The Serial Port Adapter AT Commands document contains a description of the AT commands supported in the Serial Port Adapter. It also contains information on how to use the AT commands to create Bluetooth applications. - The OEM Serial Port Adapter Electrical & Mechanical Datasheet (this document) contains important information about the OEM Serial Port Adapter. Read this document if you are using the OEM Serial Port Adapter. Version 0.4 Draft 1 - 2005-11 6 1.2 Product Variants This Electrical and Mechanical datasheet contains information about the 16 variants of OEM Serial Port Adapters based on the PCB cB-0902. This document makes references to the OEM Module ID, not the Product Name (see Table 1). Table 1: Product variants Product Name OEM Module ID / FCC Type No. Bluetooth Type Description CB-OEMSPA312i-02 cB-0069 cB-0902-0201 Class 1 / +7dBm 5mW OEM Serial Port Adapter 312i with internal antenna, 2mm pin connector CB-OEMSPA312i-04 cB-0070 cB-0902-0201 Class 1 / +7dBm 5mW OEM Serial Port Adapter 312i with internal antenna, no connectors CB-OEMSPA312i-06 cB-0071 cB-0902-0201 Class 1 / +7dBm 5mW OEM Serial Port Adapter 312i with internal antenna, JST 6-pol Class 1 +7dBm Internal antenna CB-OEMSPA312i-07 cB-0072 cB-0902-0201 Class 1 / +7dBm 5mW OEM Serial Port Adapter 312i with internal antenna, Flexfilm CB-OEMSPA312x-02 cB-0073 cB-0902-0201 Class 1 / +7dBm 5mW OEM Serial Port Adapter 312x with external antenna, 2mm pin connector CB-OEMSPA312x-04 cB-0074 cB-0902-0201 Class 1 / +7dBm 5mW OEM Serial Port Adapter 312x with external antenna, no connectors CB-OEMSPA312x-06 cB-0075 cB-0902-0201 Class 1 / +7dBm 5mW OEM Serial Port Adapter 312x with external antenna, JST 6-pol Class 1 +7dBm External antenna CB-OEMSPA312x-07 cB-0076 cB-0902-0201 Class 1 / +7dBm 5mW OEM Serial Port Adapter 312x with external antenna, Flexfilm 1.3 cB-0902 Version 0.4 Draft 1 - 2005-11 7 cB-0902 is a small size Bluetooth module based on the Phillips BGB203 system in package (SiP). The BGB203 has on chip SRAM and FLASH stacked in the same package. The mod- ules are available in many variants with different antenna / connectors and output power combinations. See Picture 1 - Picture 3 for some of the available models. All models are de- scribed in Table 1. The cB-0902 has an RS232 interface and is fully compatible with the connectBlue 2:nd Gen- eration Class 2 Serial Port Adapter. Picture 1: CB-OEMSPA332x-02 OEM Serial Port Adapter long range with external antenna and 2mm pin connector Picture 2: CB-OEM…

Text truncated - open the document above for the full version.

Users Manual

INDUSTRIAL BLUETOOTH™ Serial Port Adapter™ Version 2 and 3 AT Commands Serial Port Adapter™ Version 2 and 3 AT Commands iii Copyright © 2003 connectBlue AB. The contents of this document can be changed by connectBlue AB without prior notice and do not constitute any binding undertakings from connectBlue AB. con- nectBlue AB is not responsible under any circumstances for direct, indirect, unex- pected damage or consequent damage that is caused by this document. All rights reserved. Release: 0510 Document version: 3.2 Document number: cBProject-0501-11 (8) Printed in Sweden. Trademarks The BLUETOOTH trademarks are owned by their proprietor and used by con- nectBlue under license. Third party brands and names are the property of their respective owners. 4 Contents 1. Introduction 8 1.1 Related Documents ........................................................................... 8 2. Data Mode and AT Mode 9 3. Baud Rate 10 4. Configuration and Operation 11 4.1 LED Indication ................................................................................. 11 4.2 Bluetooth Settings............................................................................ 11 4.3 Searching for Other Bluetooth Devices ........................................... 12 4.4 Searching for Services..................................................................... 12 4.5 Creating Serial Connections and Sending Data .............................. 12 How to Select What Profile to Use .............................................. 12 Client or Server............................................................................ 12 Wireless Multidrop™ ................................................................... 12 Connection Establishment – Server ............................................ 13 Connection Establishment – Client.............................................. 13 4.6 Master/Slave Handling..................................................................... 13 4.7 Bluetooth Security............................................................................ 14 Security Modes ............................................................................ 14 Bonding and Pairing .................................................................... 15 5. Power Save Modes 16 5.1 How to Use the Stop Mode Feature ................................................ 16 6. Restoring Default Configuration 17 6.1 Serial Settings.................................................................................. 17 6.2 Factory Settings ............................................................................... 17 7. AT Commands Over Bluetooth 18 8. Optimization 19 9. Version 3 vs. Version 2 20 10. Syntax 21 10.1 Command Line Format .................................................................... 21 10.2 Data Types ...................................................................................... 21 String 22 Integer 22 Enumerator .................................................................................. 22 Bd_Addr ....................................................................................... 22 Introduction 5 11. AT Commands Reference 23 11.1 Standard AT Commands ................................................................. 23 Command “AT” ............................................................................ 23 Command “AT*”........................................................................... 23 Command “ATZ”.......................................................................... 23 Command “AT&F” ....................................................................... 24 Command “ATS2”........................................................................ 24 Command “ATE”.......................................................................... 24 11.2 GAP Commands.............................................................................. 25 Read_Discoverability_Mode (AT*AGDM?) ................................. 25 Write_Discoverability_Mode (AT*AGDM=) ................................. 25 Read_Connectability_Mode (AT*AGCM?) .................................. 26 Write_Connectability_Mode (AT*AGCM=) .................................. 26 Read_Pairing_Mode (AT*AGPM?).............................................. 27 Write_Pairing_Mode (AT*AGPM=).............................................. 27 Read_Security_Mode (AT*AGSM?)............................................ 28 Write_Security_Mode (AT*AGSM=) ............................................ 28 Name_Discovery (AT*AGND=) ................................................... 28 Device_Discovery (AT*AGDD=).................................................. 29 Inquiry (AT*AGI=) ........................................................................ 30 Bond (AT*AGB=) ......................................................................... 31 Un_Bond (AT*AGUB=)................................................................ 31 Read_Bonded_Devices (AT*AGBD?) ......................................... 32 Read_Fixed_PIN (AT*AGFP?).................................................... 32 Write_Fixed_PIN (AT*AGFP=) .................................................... 33 Read_Local_Name (AT*AGLN?) ................................................ 33 Write_Local_Name (AT*AGLN=) ................................................ 33 Read_Local_COD (AT*AGLC?) .................................................. 34 Write_Local_COD (AT*AGLC=) .................................................. 35 Get_MasterSlaveRole (AT*AGGMSR=)...................................... 36 Change_MasterSlaveRole (AT*AGCMSR=) ............................... 36 Read_MasterSlaveRole_Policy (AT*AGMSP?) .......................... 37 Write_MasterSlaveRole_Policy (AT*AGMSP=) .......................... 37 Get_RSSI (AT*AGRSS=) ............................................................ 38 11.3 Service Search Commands............................................................. 39 Serv…

Text truncated - open the document above for the full version.

Cover Letter(s)

2005-11-29 Reference: Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: CONFIDENTIALITY REQUEST FOR FCC ID PVH090202S Model name: Class 1 OEM Bluetooth Unit, Type number: cB-0902-0201 To Whom It May Concern: This letter serves as an official request for confidentiality under the FCC Rule Section 0.457 and 0.459 . . We have requested that the schematic diagrams, required to be submitted with this application be withheld from public review. The reason for this request is that these documents are company proprietary information that should never get into the possession of competitors, which would be harmful for our business. Please contact me if there is any information you may need. Regards, Mats Andersson, CTO connectBlue connectBlue ab residence: malmö isbergs gata 3 se-211 19 malmö VAT no. se 556589-0851-01 sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.se page 1 of 1

Cover Letter(s)

2005-11-29 Reference: cBProject-0502-18 (3) Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: PART 15 UNLICENSED MODULAR TRANSMITTER APPROVAL To Whom It May Concern: We, connectBlue AB, hereby requests for part 15 unlicensed modular transmitter approval of our OEM-Bluetooth module, described as follows: Brand name: connectBlue AB Model name: OEM-Bluetooth module Type number: cB-0902-0201 FCC ID: PVH090202S In FCC Public Notice DA 00-1407 released June 26,2000 there are eight numbered requirements that our OEM-Bluetooth module type cB-0902-0201 complies with. 1. The modular transmitter must have its own shielding. The module fulfils the emission requirements of the FCC rules without additional shielding. 2. The modular transmitter must have buffered modulation/data inputs The module has a memory management unit inside of the IC. It buffers the data inputs from UART and USB terminal. 3. The modular transmitter must have its own power supply regulation The IC contains an own voltage regulation. In case of changes in the supply voltage VCC (for example caused by temperature changes or other effects), the internal voltage will be stabilized. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204c The module is for OEM integration only. The end-user product will be professionally installed in such a manner that only the authorized antennas are used. 5. The modular transmitter must be tested in a stand-alone configuration The EUT was tested in a stand-alone configuration. 6. The modular transmitter must be labelled with its own FCC ID number The EUT will be labelled with its own FCC ID number. The label is specified in Exhibit D. If the module is installed inside of an end-product, the label will not be visible. In this case the OEM customer will be instructed to how to apply the exterior label. connectBlue ab residence: malmö Norra Vallgatan 64 3V se-211 22 malmö VAT no. se 556589-0851-01 sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.se page 1 of 2 2005-11-29 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The EUT is compliant with all applicable FCC rules. Detail instructions are given in the product Users Guide 8. The modular transmitter must comply with any applicable RF exposure requirements. The maximum measured power output is 4,5mW, and the maximum antenna gain is 2.5 dBi, which is far below the low threshold defined as (60/f GHz) mW for d < 2.5 cm in the TCB exclusion list. Page 2 of 2

External Photos

Annex B of test report R51984_A Edition 1 EUT: cB-0902-0201 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 18 November 2005page 1 of 5 51984_3.jpgcB-0902-0201 Sample “12”, top view Annex B of test report R51984_A Edition 1 EUT: cB-0902-0201 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 18 November 2005page 2 of 5 51984_1.jpgcB-0902-0201 Sample “8”, top view Annex B of test report R51984_A Edition 1 EUT: cB-0902-0201 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 18 November 2005page 3 of 5 51984_2.jpgcB-0902-0201 bottom view Annex B of test report R51984_A Edition 1 EUT: cB-0902-0201 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 18 November 2005page 4 of 5 51984_5.jpgcB-0903-02 carrier board, top view Annex B of test report R51984_A Edition 1 EUT: cB-0902-0201 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 18 November 2005page 5 of 5 51984_4.jpgcB-0903-02 carrier board, bottom view

ID Label/Location Info

2005-11-30 Reference: cBProject-0511-02 (2) FCC identifier label for Bluetooth unit cB-0902-0201 S/N:0902-02-01xxxx FCC ID PVH090202S IC: 5325A-090202S The above labels will be attached to the module top side since it is not allowed to attach sticker on the bottom side of the board since the integrator of the module can solder the module on their motherboard. The label is too thick, so that the PCB will wobble in the soldering process. Through that a secure solder is not guaranteed. The labels will be located as shown in the figures below. Regulatory label S/N label An auxiliary label will be provided for systems using the module where the original label not will be visible when the module is installed. Instructions on how to attach the auxiliary label in compliance with the modular approval guidelines developed by the FCC will be provided. The instructions will call attention to place the auxiliary label on an exterior surface of the device such that it will be visible upon inspection. The auxiliary label will have at least the information as shown in the figure below This device contains FCC ID PVH090202S IC: 5325A-090202S connectBlue ab residence: malmö Norra vallgatan 64 3V se-211 22 malmö VAT no. se 556589-0851-01 sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.se page 1 of 1

Internal Photos

Operational Description

Data sheet 2.4 GHz Mica SMD Antenna Miniature, low-weight unit for automatic assembly This surface-mounted, high-performance miniature antenna is intended for use with all 2.4 GHz applications; where small size and low weight are key factors. The antenna requires a ground plane, i.e. your device acts as an active part of the antenna and thus demands careful consideration concerning its placement. For optimal performance, we strongly recommend those customers not very well acquainted with RF technology to use our know-how when it comes to implementing the antenna in your application. We can offer advanced measuring equipment, custom tuning and technical support to obtain a secure and reliable implementation. It is important to note that, upon request, the Mica antenna can be customized according to your design. Typical application areas are: • Mobile phones • PDAs • Headsets • Laptop PCs • Peripheral equipment • PC cards Description The Mica antenna is an integrated low-weight antenna, only 20.5x3.35x3.6 mm in size. It is designed for automatic assembly (DFA). Matching network is needed. Size:20.5x3.35x3.6 mm Art No: 30201840 x gigaAnt, E-mail: [email protected], www.gigaAnt.com Specification subject to change without notice, FE010119-C, Oct 10-01 Antenna Specification Frequency:2.4-2.5 GHz Type:Ground plane dependent Efficiency:> 50%* Gain:2.5 dBi* Nominal impedance:50 Ohm VSWR:<2.0:1* Mounting:SMD Operating temperatur:-40 °C – +85 °C Relative humidity:93% at +40 °C Weight:0.4g * Typical values Mounting interface 3D Radiation pattern Product name / Article No. Mica30201840 9 Mica30201840 2 Mica30201840 3 Horizontal cut, xy-planeVertical cut, xz-plane Detailed foot print see application note Packaging Tape on reel / Bulk Tape on reel / 500 Pcs Tape on reel / 2000 Pcs Dimensions (mm) dBi

Operational Description

Features: Versatile and easy to use antenna for 2.4 to 2.5 GHz Bluetooth and IEEE 802.11 devices Designed for easy connection to radio cards Utilizes Centurion’s patented PCB Microsphere technology Has a ground plane incorporated into the resonator structure, therefore no additional ground plane is required to radiate efficiently Specifications: Frequency Range 2.4 – 2.5 GHz Polarization Linear Peak Gain 1.5 dBi Average Gain >0 dBi Nominal Impedance 50 ohms 2.4 - 2.5 GHz < 1.8:1 VSWR (Min. Performance) > 600 MHz 2.0:1 Temperature Range -40° to +85°C Vibration 6G RMS (9.04g2/Hz) for 15 minutes each in vertical and horizontal. No appearance or functional axis. Thermal Shock Change after 4 repeated cycles of 1 hr. at +85°C and 1 hr. at -40°C. Transfer time is 5 min. Dimensions (L x W x T) 1.88" x .89" x .032" Standard Cable 8" Brown RG-178 Coax Standard Connector R. A. MMCX Plug MicroBlue Part Number (P/N): CAF94131 MicroBlue – 10/28/02 Elevation Plane, Phi = 0 2450 MHz Elevation Plane, Phi = 90 2450 MHz Azimuth Plane 2450 MHz Internal Wireless Device Antenna

Operational Description

© Phoenix Contact 2003 Phoenix Contact GmbH & Co. KGD-32823 Blomberg, GermanyF ax +49-(0)5235-341200, Tel. +49-(0)5235-300 TNR 9017692-00 / 09.2003 www.phoenixcontact.com Deutsch English Français Español T emperatur- bereich T emperature r ange T empérature Margen de temperatura -20 °C ... +65 °C Schutzart Protection type Degré protection Tipo de protección IP65 Gewinn Gain Gain Ganancia 2 dBi MontageanleitungAssembly instructionsInstructions de montageInstrucciones de montaje RAD-ISM-2400-ANT-OMNI-2-1 Artikel-Nr. / Order No. / Référence / Código : 28 67 46 1 D GB F E Schrank-Montage / Cabinet mounting / Montage sur armoire / Montaje en armario ∅ = 10 mm 82,5 mm W and-Montage / Wall mounting / Montage mural / Montaje sobre pared 90 -90 -60 -120 -150 180 0 -30 150 30 60 120 0 90 60 120 150 180 0 30 -150 -30 -60 -120 0 -90 -30 -30 Richtcharakteristik / Radiation pattern / Diagramme de rayonnement / Característica direccional horizontal vertikal / vertical

Operational Description

Specifications subject to change without notice. 3425 N.44 th Street, LINCOLN, NE 68504 USA SALES PHONE: 800.228.4563 PHONE: 402.467.4491 • FAX: 402.467.4528 www.centurion.com • [email protected] Copyright  2004 Centurion Wireless Technologies, Inc. All Rights Reserved Specifications: ½ wave coaxial dipole Flexible element Frequency 2.4 - 2.5 GHz Polarization Vertical Gain 2.0 dBi Nominal Impedance 50 ohms VSWR 1.5:1 max at resonance RF Power Handling 50 watts Length 7.6 cm (90° Bent) or 10.8 cm (180° Straight) Temperature Range -40° to +80°C Drop Test 1M Cables & Connectors: Model # Part # Cable Connector WCR2400-FL04 MAF94015 100 mm RG-178 Flying Lead WCR2400-IP04 MAF94017 100 mm RG-178 IPEX U.FL WCR Snap-in a – 5/20/04 WCR Model Number: WCR2400-IP WCR2400-FL External Antenna – Snap-in/Captive Azimuth 2.45 GHz Antenna Bent @ 90° Antenna Straight @ 180° Elevation phi=0 2.45 GHz 7.6 cm

Operational Description

2005-11-29 Reference: Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Operational Description of cB-0902-0201 This Bluetooth modular transmitter can be integrated in different end-products. Bluetooth is a short-range radio link intended to be a cable replacement between portable and/or fixed electronic devices. Bluetooth operates in the unlicensed ISM Band at 2.4 GHz. In the US a band of 83.5 MHz width is available. In this band, 79 RF channels spaced 1MHz apart are defined. The channel is represented by a pseudo-random hopping sequence through the 79 channels. The channel is devided into time slots, with a nominal slot length of 625μs, where each slot corresponds to different RF hop frequencies. The nominal hop rate is 1600 hops/s. All frequencies are equally used. The average time of occupancy is 0.3797 s within a 30 second period. The symbol rate on the channel is 1Ms/s. Regards connectBlue connectBlue ab residence: malmö norra vallgatan 64 se-211 22 malmö VAT no. se 556589-0851-01 sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.se page 1 of 1

Test Report

Königswinkel 10 32825 Blomberg Germany Phone+49 5235 9500-0 Fax+49 5235 9500-10 TEST REPORT Test Report Reference: R51984_A Edition 1 Equipment under Test: cB-0902-0201 Serial Number: none Applicant: connectBlue AB Manufacturer: connectBlue AB Test Laboratory (CAB) accredited by DATech e.V. in compliance with DIN EN ISO/IEC 17025 under the Reg. No. DAT-P-105/99-21, FCC Test site registration number 90877 and Industry Canada Test site registration IC3469 TEST REPORT REFERENCE: R51984_A Edition 1 Examiner: Thomas KÜHNDate of issue: 18 November 2005Page 2 of 85 Contents:Page 1 IDENTIFICATION.....................................................................................................................................4 1.1 APPLICANT.....................................................................................................................................4 1.2 MANUFACTURER..........................................................................................................................4 1.3 DATES.............................................................................................................................................4 1.4 TEST LABORATORY......................................................................................................................5 1.5 RESERVATION...............................................................................................................................5 1.6 NORMATIVE REFERENCES..........................................................................................................5 1.7 TEST RESULTS..............................................................................................................................5 2 TECHNICAL DATA OF EQUIPMENT......................................................................................................6 2.1 DEVICE UNDER TEST...................................................................................................................6 2.2 PERIPHERY DEVICES...................................................................................................................7 3 OPERATIONAL STATES AND PHYSICAL BOUNDARIES.....................................................................7 4 APPLICATION OVERVIEW.....................................................................................................................8 5 TEST RESULTS.......................................................................................................................................9 5.1 20 dB BANDWIDTH........................................................................................................................9 5.1.1 METHODE OF MEASUREMENT (20 dB BANDWIDTH)...................................................9 5.1.2 TEST RESULTS (20 dB BANDWIDTH)..............................................................................10 5.2 CARRIER FREQUENCY SEPARATION.........................................................................................13 5.2.1 METHODE OF MEASUREMENT (CARRIER FREQUENCY SEPARATION)....................13 5.2.2 TEST RESULTS (CARRIER FREQUENCY SEPARATION)..............................................14 5.3 NUMBER OF HOPPING FREQUENCIES......................................................................................16 5.3.1 METHODE OF MEASUREMENT (NUMBER OF HOPPING FREQUENCIES)..................16 5.3.2 TEST RESULTS (NUMBER OF HOPPING FREQUENCIES)............................................17 5.4 DWELL TIME...................................................................................................................................18 5.4.1 METHODE OF MEASUREMENT (DWELL TIME)..............................................................18 5.4.2 TEST RESULTS (DWELL TIME)........................................................................................19 5.5 MAXIMUM PEAK OUTPUT POWER..............................................................................................21 5.5.1 METHODE OF MEASUREMENT (MAXIMUM PEAK OUTPUT POWER).........................21 5.5.2 TEST RESULTS (MAXIMUM PEAK OUTPUT POWER)...................................................22 5.6 POWER SPECTRAL DENSITY......................................................................................................25 5.6.1 METHODE OF MEASUREMENT (POWER SPECTRAL DENSITY).................................25 5.6.2 TEST RESULTS (POWER SPECTRAL DENSITY)............................................................26 5.7 BAND-EDGE COMPLIANCE...........................................................................................................28 5.7.1 METHODE OF MEASUREMENT (BAND-EDGE COMPLIANCE)......................................28 5.7.2 TEST RESULT (BAND-EDGE COMPLIANCE)..................................................................29 5.8 CONDUCTED EMISSIONS (TRANSMITTER)...............................................................................32 5.8.1 MET…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Filip Kruzela(Certification Manager)

[email protected]+46 40 6307100Fax: +46 40 23 7137

Test Firm

Phoenix TestLab GmbHH. Altmaier

[email protected]49-5235-9500-0Fax: 49-5235-9500-10

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	2.80 mW

Modular Type

Limited Single Modular Approval

Confidentiality

Long Term

Grant Notes

Output power is conducted. Limited Modular Approval only for OEM integration of the device. This device and its antenna(s) must not be co-located or operated in conjunction with any other antenna or transmitter. End users may not be provided with instructions to remove or install this device.
