PVH0946Bluetooth module

u-blox Malmo AB

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Aug 22, 2011
Application Purpose: Original Equipment
Date of Application: Aug 03, 2011
Equipment Note: Bluetooth module
Frequency Range: 2402.00000000 - 2480.00000000
Company: u-blox Malmo AB
Country: Sweden

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Attestation Statements

Reference: cB1202-MA00047480 2012-02-16 connectBlue AB Residence: Malmö VAT no. se 556589-0851-01 Norra Vallgatan 64 3V SE-211 22 Malmö Sweden Tel.+46 (0)40-6307100 Fax.+46 (0)40-237137 E-mail: [email protected] http://www.connectBlue.se Page 1 (1) To whom it may concern While performing delta measurements with different variants of the device certified under the above listed FCC ID, we figured out with the test laboratory PHOENIX-TESTLAB GmbH that some measurement results as documented in the test report (F111592E2) and uploaded into the FCC database under FCC ID PVH0946 may not be correct. Several measurements have been repeated in January 2012 with the original device (same HW/SW) under identical test operating conditions to evaluate and clearly identify the error causing some differences in the measurement results. We finally figured out a programming error in the final radiated emission measurement procedure for Bluetooth Low Energy devices so that the results in the frequency range 1 GHz to 4 GHz were measured and documented with a wrong resolution bandwidth of the measuring receiver. These measurements were repeated with the corrected program and the correct resolution bandwidth and documented in a revised test report F111592E3 2 nd version. Furthermore a defect adapter cable from U.FL to SMA was obviously used during the original conducted peak output power measurements. These measurements were also repeated with a new cable. We hereby declare, that we have not marketed the device with the Bluetooth Low Energy option till now. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely, CTO connectBlue AB

Cover Letter(s)

2011-08-03 Reference: cBSales-0411-14 (1) NON DISCLOSURE AGREEMENT Between connectBlue AB, Norra Vallgatan 62, 211 22 Malmö, Sweden and .............................. (”counterpart”) connectBlue ab residence: malmö Norra Vallgatan 64 se-211 22 malmö VAT no. se 556589-0851-01 sweden tel.+46 (0)40-237100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.com page 1 of 3 2011-08-03 Whereas connectBlue and the “Counterpart” are investigating the possibilities of cooperation regarding cB- 0946 Bluetooth module hereinafter referred to as “subject”). For the purpose of such co-operation each party will disclose to the other party information which is proprietary to the disclosing party and which such party wishes the other party to treat as confidential. It is requested that the following information is to be held confidential on behalf of connectBlue AB. Hardware manual The above material contains trade secrets not customarily released to public that are judged to have the potential to cause detriment to the applicant and provide unjustified benefits to its competitors. Hardware manual is a highly technical integration manual not addressed to the end-user. This information should not be available for public disclosure for an indefinite period of time Whereas both parties, for their mutual benefits, wish to discuss certain technical and business matters concerning the ”subject”; and whereas during the course of such discussion, each parties may wish to disclose to or receive from the other information and ideas which the disclosing party consider to be proprietary and wishes to protect. Now therefore the parties hereby mutually agree that: Proprietary Information shall mean information and/or ideas relating to the “subject” which the disclosing party wishes to keep confidential and so indicates, if information and/or ideas are in written form, by an appropriate legend, marking, or stamp thereon, or if orally or visually disclosed, are in writing within thirty (30) days after disclosure. The parties each agrees to keep it in confidence and nor to use, except for purpose related to the “subject”, or to disclose to third parties, any Proprietary Information disclosed to it by the other. In addition both parties shall limit the internal disclosure of Proprietary Information to those employees who have a need to know and an obligation to protect it. Notwithstanding the foregoing, no liability shall arise hereunder for use or disclosure of Proprietary Information which is: In the public domain at the time of disclosure, or subsequently comes within the public domain without fault of the receiving party, Knowing to receiving party at the time of disclosure or independently developed by the receiving party, Used or disclosed by the receiving party with the prior written approval of the disclosing party or Properly disclosed to the receiving party without restriction from a source other than the disclosing party. Neither party shall be liable for the inadvertent disclosure of Proprietary Information hereunder provided that it has exercised the same agree of care to protect such Proprietary Information as it uses to protect its own Proprietary Information, and provided that such degree of care is at least reasonable. Neither the execution of this agreement, nor the disclosure of any Proprietary Information hereunder shall be concurred as granting either expressly or by implication, estoppels or otherwise, any license under any invention or patent now or hereafter owned by or controlled by the disclosing party; or as an obligation to enter into a further contract or to reimburse the cost of any effort expended by either party. The receiving party shall only make such copies of the disclosing party’s proprietary Information as are necessary for the purpose of the “subject”. Upon termination or expiration of this agreement all such copies along with the original shall, upon request, be promptly returned to the disclosing party or destroyed. The receiving party may, however retain in the file of its legal counsel, for archival purpose only, one copy of any such Proprietary Information returned or destroyed. Page 2 of 3 2011-08-03 This agreement shall expire five (5) years from the date of its execution unless terminated sooner via thirty (30) days written notice to the other party. Neither expiration nor termination of this agreement shall effect obligations with respect to Proprietary Information exchanged prior to the effective date of termination or expiration All disputes or differences arising regarding the validity and/or interpretation of the provision of this agreement shall be submitted to and determined by arbitration according to the Rules of Conciliation and Arbitration of the international Chamber of Commerce by three (3) arbitrations appointed in accordance with the said rules. Swedish substantive as well as procedural law shall govern this agreement. ---- connectBlue AB _____________________________ _____________________________ _____________________________ _____________________________ Rolf Nilsson, President Ty ped Name Ty ped Name Who warrants to be duly authorized Who warrants to be duly authorized Date ___________________________ Date ___________________________ Page 3 of 3

Cover Letter(s)

2011-06-25 Reference: cBProject-0502-18 (3) Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: PART 15 UNLICENSED MODULAR TRANSMITTER APPROVAL To Whom It May Concern: We, connectBlue AB, hereby requests a Limited Modular Approval of our OEM-Bluetooth module, described as follows: Brand name: connectBlue AB Model name: cB-0946 Type number: cB-0946 FCC ID: PVH0946 In FCC Public Notice DA 00-1407 released June 26,2000 there are eight numbered requirements that our OEM-Bluetooth module type cB-0946 complies with. 1. The modular transmitter must have its own shielding. The modular transmitter has its own shielding as shown on the photo exhibits. 2. The modular transmitter must have buffered modulation/data inputs The module has a memory management unit inside of the IC (U1). It buffers the data inputs from UART and SPI terminal. 3. The modular transmitter must have its own power supply regulation The IC contains an own voltage regulation (U8-U10). In case of changes in the supply voltage VCC (for example caused by temperature changes or other effects), the internal voltage will be stabilized. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204c The module is either equipped with on-board chip antenna or unique (U.FL) antenna connector. For further details please refer to the antenna data sheet included in the filing. 5. The modular transmitter must be tested in a stand-alone configuration The EUT was tested in a stand-alone configuration. connectBlue ab residence: malmö Norra Vallgatan 64 3V se-211 22 malmö VAT no. se 556589-0851-01 sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.se page 1 of 2 2011-06-25 6. The modular transmitter must be labelled with its own FCC ID number The EUT will be labelled with its own FCC ID number. The label is specified in Exhibit D. If the module is installed inside of an end-product, the label will not be visible. In this case the OEM customer will be instructed to how to apply the exterior label. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The EUT is compliant with all applicable FCC rules. Detail instructions are given in the product Users Guide 8. The modular transmitter must comply with any applicable RF exposure requirements. The maximum measured power output is less than 11.3 mW (10.5 dBm), the maximum antenna gain is + 3,4 dBi = numeric gain 2,2 (acc to FCC test report). The maximum permissible exposure is defined in 47 CFR 1.1310 with 1 mW/cm². The maximum permitted level is calculated using the general equation: S = P*G / 4pR² P = 11.3 mW, G = 2,2 (numeric gain; + 3,4 dBi = linear power gain relative to the isotropic radiator), R = 2.5 cm p = 3,1416 Solving for S, the power density at 2.5 cm is less than 0,32 mW/cm². So the 1mW/cm² limit is kept. Page 2 of 2

Cover Letter(s)

2011-08-23 Reference: connectBlue ab residence: malmö VAT no. se 556589-0851-01 Norra vallgatan 64 se-211 22 malmö sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.com page 1 of 1 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: CONFIDENTIALITY REQUEST FOR FCC ID PVH0946 Family model name: cB-0946 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rule, the applicant hereby requests confidential treatment of information accompanying this application as outlined below:  cB-0946 Block diagram.jpg  Schematic cB-0946.pdf  BOM cB-0946.xls  cB-0946 Operational description.doc  PCB specification cB-0946-A.pdf  Component mounting Documentation cB-0946-A.pdf  Hardware manual cB-0946.pdf, (Integration manual for OEM integrator, highly technical) The above material contains trade secrets not customarily released to public that are judged to have the potential to cause detriment to the applicant and provide unjustified benefits to its competitors. Hardware manual cB-0946.pdf is a highly technical integration manual not addressed to the end-user. This information should not be available for public disclosure for an indefinite period of time Yours sincerely Mats Andersson, CTO connectBlue

External Photos

ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3 Date of issue:27 June 2011Order No.:11-111592page1 of11 111592_b.JPG: cB-0946 mounted on the cB-0903-03 (carrier board) ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3 Date of issue:27 June 2011Order No.:11-111592page2 of11 111592_j.JPG: cB-0946 mounted on the cB-0924-02 (EPA) ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3 Date of issue:27 June 2011Order No.:11-111592page3 of11 111592_i.JPG: cB-0946 with internal antenna, PCB, top view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3 Date of issue:27 June 2011Order No.:11-111592page4 of11 111592_h.JPG: cB-0946 with internal antenna, PCB, top view,shielding removed ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3 Date of issue:27 June 2011Order No.:11-111592page5 of11 111592_g.JPG: cB-0946 with antenna connector, PCB, top view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3 Date of issue:27 June 2011Order No.:11-111592page6 of11 111592_f.JPG: cB-0946, PCB, bottom view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3 Date of issue:27 June 2011Order No.:11-111592page7 of11 111592_d.JPG: cB-0903, PCB, top view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3 Date of issue:27 June 2011Order No.:11-111592page8 of11 111592_c.JPG: cB-0903, PCB, bottom view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3 Date of issue:27 June 2011Order No.:11-111592page9 of11 111592_l.JPG: cB-0924-02, top view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3 Date of issue:27 June 2011Order No.:11-111592page10of11 111592_k.JPG: cB-0924-02, bottom view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3 Date of issue:27 June 2011Order No.:11-111592page11of11 111592_m.JPG: cB-0924-02, bottom view, antenna removed

ID Label/Location Info

2011-06-27 cB-0946 Label and FCC/IC Identifier FCC/IC identifiers are hard-printed on the PCB: connectBlue ab residence: malmö Norra vallgatan 64 3V se-211 22 malmö VAT no. se 556589-0851-01 sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.se page 1 of 2 2011-07-29 The Serial/Product information is available on a label: Serial label S/N: ###### Model: cB-0946 The above labels will be attached to the module topside and located as shown in the figures below. Serial label An auxiliary label will be provided for systems using the module where the original label not will be visible when the module is installed. Instructions on how to attach the auxiliary label in compliance with the modular approval guidelines developed by the FCC will be provided. The instructions will call attention to place the auxiliary label on an exterior surface of the device such that it will be visible upon inspection. The auxiliary label will have at least the information as shown in the figure below This device contains FCC ID PVH0946 IC: 5325A-0946 Page 2 of 2

Internal Photos

ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3, 2 nd version Date of issue:12 January 2012Order No.:1 1-111592page1 of11 111592_b.JPG: cB-0946 mounted on the cB-0903-03 (carrier board) ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3, 2 nd version Date of issue:12 January 2012Order No.:1 1-111592page2 of11 111592_j.JPG: cB-0946 mounted on the cB-0924-02 (EPA) ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3, 2 nd version Date of issue:12 January 2012Order No.:1 1-111592page3 of11 111592_i.JPG: cB-0946 with internal antenna, PCB, top view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3, 2 nd version Date of issue:12 January 2012Order No.:1 1-111592page4 of11 111592_h.JPG: cB-0946 with internal antenna, PCB, top view,shielding removed ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3, 2 nd version Date of issue:12 January 2012Order No.:1 1-111592page5 of11 111592_g.JPG: cB-0946 with antenna connector, PCB, top view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3, 2 nd version Date of issue:12 January 2012Order No.:1 1-111592page6 of11 111592_f.JPG: cB-0946, PCB, bottom view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3, 2 nd version Date of issue:12 January 2012Order No.:1 1-111592page7 of11 111592_d.JPG: cB-0903, PCB, top view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3, 2 nd version Date of issue:12 January 2012Order No.:1 1-111592page8 of11 111592_c.JPG: cB-0903, PCB, bottom view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3, 2 nd version Date of issue:12 January 2012Order No.:1 1-111592page9 of11 111592_l.JPG: cB-0924-02, top view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3, 2 nd version Date of issue:12 January 2012Order No.:1 1-111592page10of11 111592_k.JPG: cB-0924-02, bottom view ANNEX B:INTERNAL PHOTOS OF THE EUT Examiner:Thomas KÜHNTest Report No.:F111592E3, 2 nd version Date of issue:12 January 2012Order No.:1 1-111592page11of11 111592_m.JPG: cB-0924-02, bottom view, antenna removed

Test Report

datasheet m70cxr V2.0.doc roof antenna for bluetooth roof installation planTec® – bluetooth Bestellnr.: m70cxr 0300 00 xx xx 76,0 mm 20,7 mm 13,6 mm Gewinde M 16 The planar antennas of the latest technology offers you decisive advantages: roof installation, not only for car, truck and bus installation on all plain surfaces possible (application at container, automatic machines and railroads...) waterproof with two independent washers in mounted condition flat design (approx. 20 mm high ), no additional rod antennas necessary other cable lengths or connectors on request at car wash no disassembly necessary waterproof IPX6 and IPX9K TECHNICAL DATA: GSM: frequency range: 2400 - 2500 MHz VSWR: < 2,0 typical gain: 1,0 dB typical power max.: ≤ 10 watt dimensions and connectors: connection (standard): 3m RF-cable RG 174 with connector GSM/FME(f) (other cable-length or connectors on request) dimensions (∅/h): approx. 75 mm / 20 mm temperature range: from –40°C up to +85°C

Test Report

Ex-IT 2400 28-00x A pplications M 2M - com m unications Te le m e tric A utom ate d M e te r Re ading A larm s Spe cification Fre q ue ncy:2400 - 2485 M H z VSWR:< 3:1 (on ProA nt de m o b ox) G ain:M ax: 3 dBi Le ng th : 28 m m Width :8 m m Te m pe rature :- 30 to + 85°C

Test Report

Ex-IT 2400 MHF 28 Applications M2M-communications Telemetric Automated Meter Reading Alarms Specification Frequency:2400 -2485 MHz VSWR:< 3:1 (on ProAnt demo box) Gain:Max: 2 dBi Height: 28 mm, excluding cable and thread. Diameter:12 mm Temperature:-30 to +85°C RoHS compliant

Test Report

Ex-IT 2400 MH F 70-001 A pplications M 2M - com m unications Te le m e tric A utom ate d M e te r Re ading A larm s Spe cification Fre q ue ncy:2400 - 2485 M H z VSWR:< 2:1 (on ProA nt de m o b ox) G ain:M ax: 3 dBi H e ig h t: 70 m m , e xcluding cab le and th re ad. Width :9 ,5 m m Te m pe rature :- 30 to + 85°C

Test Report

Ex-IT 2400 SMA 70-00x A pplications M 2M - com m unications Te le m e tric A utom ate d M e te r Re ading A larm s Spe cification Fre q ue ncy:2400 - 2485 M H z VSWR:< 2:1 (on ProA nt de m o b ox) G ain:M ax: 3 dBi H e ig h t: 107 m m , Ex- IT 2400 SM A 70- 001. 83 m m , Ex- IT 2400 SM A 70- 002 Width :10 m m Te m pe rature :- 30 to + 85°C Ex-IT 2400 SM A 70-001 Ex-IT 2400 SM A 70-002

Test Report

O utSide™ 2400 Spe cification Fre q ue ncy:2400 - 2485 M H z VSWR:< 3:1 G ain:M ax: 3 dBi D im e nsion: 50 m m diam e te r, h e ig h t 30 m m M ounting : Scre w on SM A jack conne ctor. Te m pe rature :- 30 to + 85°C A pplications M 2M - com m unications Te le m e tric A utom ate d M e te r Re ading A larm s

Test Report

Ref: UM_FR05-S1-N-0-102 April 2008 Page 1 2008 © FRACTUS, S.A. Fractus Compact Reach Xtend™ Bluetooth ® , 802.11b/g WLAN Chip Antenna Antenna Part Number: FR05-S1-N-0-102 Ref: UM_FR05-S1-N-0-102 April 2008 Page 2 2008 © FRACTUS, S.A. TABLE OF CONTENTS NOTES ______________________________________________________________________2 ANTENNA DESCRIPTION ________________________________________________________3 QUICK REFERENCE GUIDE _______________________________________________________3 ELECTRICAL PERFORMANCE _____________________________________________________4 FRACTUS EVALUATION BOARD __________________________________________________4 CAPABILITIES AND MEASUREMENT SYSTEMS ______________________________________6 MECHANICAL CHARACTERISTICS _________________________________________________7 DIMENSIONS, TOLERANCES & MATERIALS ________________________________________7 SPECIFICATIONS FOR INK _____________________________________________________8 ASSEMBLY PROCESS__________________________________________________________9 ANTENNA FOOTPRINT _______________________________________________________11 PACKAGING _______________________________________________________________12 Fractus is an ISO 9001:2000 certified company All our antennas are lead-free and RoHS compliant NOTES The product described in this document is protected worldwide by the following Patents and Patent Applications owned by Fractus: US7148850, US7164386, US7202822; PAT.PEND.WO0154225. Any update on new patents linked to this product will appear in http://www.fractus.com/index.php/fractus/patents All information contained within this document is property of Fractus and is subject to change without prior notice. Information is provided “as is” and without warranties. It is prohibited to copy or reproduce this information without prior approval. Ref: UM_FR05-S1-N-0-102 April 2008 Page 3 2008 © FRACTUS, S.A. ANTENNA DESCRIPTION Fractus  Compact Reach Xtend TM chip antenna is engineered specifically for Bluetooth ® , WLAN 802.11 b/g and other wireless devices operating at the ISM 2.4 GHz band. Compact Reach Xtend combines small form factor size and high performance to improve the functionality of your wireless devices. The Compact Reach Xtend is a low-cost antenna solution that combines small form factor and high performance with integration flexibility making it ideal for small consumer electronics devices such as wireless headsets and USB dongles. Front Back APPLICATIONS • Wireless Headsets • WLAN 802.11 b/g USB-dongles • Bluetooth USB and serial Dongles • Compact Flash (CF) and Secure Digital (SD) cards • Cellular handsets • Digital Cameras BENEFITS • Low cost • High efficiency • Small form factor QUICK REFERENCE GUIDE Technical Features Frequency range 2400-2500 MHz Radiation Efficiency > 70% Radiation Pattern Omnidirectional Peak Gain > 1 dBi VSWR < 2:1 Polarization Linear Weight 0.1 g Temperature -40 to + 85ºC Impedance 50Ω Dimensions 7x3x2 mm (L x W x H) Table 1 -Technical Features Note : results measured in a reference evaluation board of 47x23 mm described in the following section. Please contact your sales representative at [email protected] if you require additional information on antenna integration or optimisation on your PCB. FRACTUS S.A. www.fractus.com Tel: +34 935442690 Fax: +34 935442691 3 mm 7 mm 2 mm Ref: UM_FR05-S1-N-0-102 April 2008 Page 4 2008 © FRACTUS, S.A. ELECTRICAL PERFORMANCE FRACTUS EVALUATION BOARD The Fractus configuration used in testing the Compact Reach Xtend chip antenna is displayed in Figure 1. Figure 1 – Compact Reach Xtend Evaluation Board VSWR VSWR (Voltage Standing Wave Ratio) versus Frequency (GHz) <2:1 within the ISM-2.4 GHz band o 2.4-2.483 in US and Europe o 2.471-2.497 in Japan A 41.0 mm B 23.0 mm C 47.0 mm D 8.0 mm E 26.0 mm Material: the evaluation board is built on FR4 substrate of 1.0 mm of thickness. Note: refer to the Antenna Footprint section on page 10 of this User Manual for additional information about the clearance area and antenna footprint. SMA Connector 50 Ohms feeding line Compact Reach Xtend Antenna Ground Plane (Grey Colour) A B E C D Antenna Clearance 2.2 2.3 2.4 2.5 2.6 2.7 1 1.5 2 2.5 3 3.5 4 4.5 5 VSWR Frequency (GHz) Ref: UM_FR05-S1-N-0-102 April 2008 Page 5 2008 © FRACTUS, S.A. Radiation Pattern, Gain and Efficiency 0 30330 60300 90270 120240 150210 180 -30 -25 -20 -15 -10 -5 0 5 Gain (dB): Theta=90º cut Orientation Azimuth Cut θ = 90º 0 30330 60300 270 120240 150210 180 -30 -25 -20 -15 -10 -5 0 5 Gain (dB): Phi=0º cut 0 30330 60300 90270 120240 150210 180 -30 -25 -20 -15 -10 -5 0 5 Gain (dB): Phi=90º cut Elevation Cut φ φφ φ = 0 Elevation Cut φ φφ φ = 90 Peak Gain 1.5 dBi Gain Average Gain -2.3 dBi Peak Efficiency 75 % Efficiency Average Efficiency 70 % Table 2 – Antenna Gain and Efficiency within the 2.4-2.5 GHz band Ref: UM_FR05-S1-N-0-102 April 2008 Page 6 2008 © FRACTUS, S.A. CAPABILITIES AND MEASUREMENT SYSTEMS Fractus specialises in designing and manufacturing optimsed antennas for wireless applications and providing our clients with RF expertise. We offer turn-key antenna products and antenna integration support to minimise your time requirement and maximize your return on investment during your product development efforts. We also provide our clients with the opportunity to leverage our in-house testing and measurement facilities to obtain accurate results quickly and efficiently. 22.533.544.555.56 -20 -18 -16 -14 -12 -10 -8 -6 -4 -2 0 Return Lo s s (dB) Fre que ncy (GHz) Le ft Ante nna Rig ht Ante nna Is o latio n VSWR=2 22.533.544.555.56 -20 -18 -16 -14 -12 -10 -8 -6 -4 -2 0 Return Lo s s (dB) Fre que ncy (GHz) Le ft Ante nna Rig ht Ante nna Is o latio n VSWR=2 VSWR & S Parameters 0 30330 60300 90270 120240 150210 180 -30 -25 -20 -15 -10 -5 0 5 f=5350MHz 0 30330 60300 90270 120240 150210 180 -30 -25 -20 -15 -10 -5 0 5 f=5350MHz Radiation Pattern & Efficiency SATIMO’s STARGATE 32 R&S VNA 20Khz-8GHz ZVCE SAR Levels DASY-4 (SPEAG) Anechoic and semi-anecho…

Text truncated - open the document above for the full version.

Test Report

Ref: UM_ FR05-S1-N-0-104 April 2008 Page 1 2008 © FRACTUS, S.A. Fractus Slim Reach Xtend™ Bluetooth ® Chip Antenna Antenna Part Number: FR05-S1-N-0-104 Ref: UM_ FR05-S1-N-0-104 April 2008 Page 2 2008 © FRACTUS, S.A. TABLE OF CONTENTS NOTES _______________________________________________________________________2 ANTENNA DESCRIPTION _________________________________________________________3 QUICK REFERENCE GUIDE ________________________________________________________3 ELECTRICAL PERFORMANCE ______________________________________________________4 FRACTUS EVALUATION BOARD___________________________________________________4 CAPABILITIES AND MEASUREMENT SYSTEMS _______________________________________6 MECHANICAL CHARACTERISTICS __________________________________________________7 DIMENSIONS, TOLERANCES & MATERIALS _________________________________________7 SPECIFICATIONS FOR INK ______________________________________________________8 ASSEMBLY PROCESS_______________________…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Filip Kruzela(Certification Manager)

[email protected]+46 40 6307100Fax: +46 40 23 7137

Test Firm

PHOENIX TESTLAB GmbHHolger Bentje

[email protected]49-5235-9500-24Fax: 49-5235-9500-28

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	3.00 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Output Power listed is peak conducted. This device must not be co-located or operating in conjunction with any other antenna or transmitter. The grant has been revised as of 02/20/2012 to reflect changes as noted in the exhibits contained in the Attestation Statements exhibit folder.
