PVH0950Wireless Communication System Module

Ersteller: Dirk Brandhorst Revision: 00 Erstelldatum: 02.01.2012 Datum: 00.00.00 Seite 1 von 1 Nonroutine Long-term Confidentiality Request PHOENIX TESTLAB GmbH Date: 2 May 2012 Product Certification Königswinkel 10 D 32825 Blomberg FCC ID: PVH0950 To Whom it may concerns, Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rule and KDB726920, we hereby request nonroutine confidential treatment of information accompanying this application as outlined below: Internal Photos of a consumer device where the circuit board is enclosed in epoxy or in a material that would destroy the circuit board if removed, or the device is sealed and disassembly would destroy the product. Internal Photos of a non-consumer device where the device is not accessible to the general public (for example a device mounted on the top of a large tower (or in a fenced enclosure) that is only serviceable by the licensee or designated technicians). Installation Manual is very technical and is not provided to the consumer because the consumer cannot service the device. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. Thank you for your attention in this matter. Applicant’s Company address : Norra vallgatan 64 211 22 malmö SWEDEN Signature : Job Title and Dept. : CTO connectBlue

2012-04-30 Reference: connectBlue ab residence: malmö VAT no. se 556589-0851-01 Norra vallgatan 64 se-211 22 malmö sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.com page 1 of 1 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: CONFIDENTIALITY REQUEST FOR FCC ID PVH0950 Family model name: cB-0950 It is requested that the following information is to be held confidential on behalf of connectBlue AB.  Block Diagram  Schematics  Schematics (Component mounting Documentation)  BOM  Operational description  Operational Description (PCB specification) The above material contains trade secrets not customarily released to public that are judged to have the potential to cause detriment to the applicant and provide unjustified benefits to its competitors. Hardware manual cB-0950.pdf is a highly technical integration manual not addressed to the end-user. This information should not be available for public disclosure for an indefinite period of time Yours sincerely Mats Andersson, CTO connectBlue

2012-04-30 Reference: cBSales-1202-01 (1) connectBlue ab residence: malmö VAT no. se 556589-0851-01 Norra Vallgatan 64 se-211 22 malmö sweden tel.+46 (0)40-237100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.com page 1 of 4 NON DISCLOSURE AGREEMENT Between connectBlue AB, Norra Vallgatan 62, 211 22 Malmö, Sweden and .............................. (”counterpart”) 2012-04-30 Page 2 of 4 Whereas connectBlue and the “Counterpart” are investigating the possibilities of cooperation regarding cB-0950 Bluetooth module hereinafter referred to as “subject”). For the purpose of such co-operation each party will disclose to the other party information which is proprietary to the disclosing party and which such party wishes the other party to treat as confidential. It is requested that the following information is to be held confidential on behalf of connectBlue AB. Block diagram Schematic BOM Operational description PCB specification Component mounting Documentation Hardware manual The above material contains trade secrets not customarily released to public that are judged to have the potential to cause detriment to the applicant and provide unjustified benefits to its competitors. Hardware manual is a highly technical integration manual not addressed to the end-user. This information should not be available for public disclosure for an indefinite period of time Whereas both parties, for their mutual benefits, wish to discuss certain technical and business matters concerning the ”subject”; and whereas during the course of such discussion, each parties may wish to disclose to or receive from the other information and ideas which the disclosing party consider to be proprietary and wishes to protect. Now therefore the parties hereby mutually agree that: Proprietary Information shall mean information and/or ideas relating to the “subject” which the disclosing party wishes to keep confidential and so indicates, if information and/or ideas are in written form, by an appropriate legend, marking, or stamp thereon, or if orally or visually disclosed, are in writing within thirty (30) days after disclosure. The parties each agrees to keep it in confidence and nor to use, except for purpose related to the “subject”, or to disclose to third parties, any Proprietary Information disclosed to it by the other. In addition both parties shall limit the internal disclosure of Proprietary Information to those employees who have a need to know and an obligation to protect it. Notwithstanding the foregoing, no liability shall arise hereunder for use or disclosure of Proprietary Information which is: In the public domain at the time of disclosure, or subsequently comes within the public domain without fault of the receiving party, Knowing to receiving party at the time of disclosure or independently developed by the receiving party, Used or disclosed by the receiving party with the prior written approval of the disclosing party or Properly disclosed to the receiving party without restriction from a source other than the disclosing party. Neither party shall be liable for the inadvertent disclosure of 2012-04-30 Page 3 of 4 Proprietary Information hereunder provided that it has exercised the same agree of care to protect such Proprietary Information as it uses to protect its own Proprietary Information, and provided that such degree of care is at least reasonable. Neither the execution of this agreement, nor the disclosure of any Proprietary Information hereunder shall be concurred as granting either expressly or by implication, estoppels or otherwise, any license under any invention or patent now or hereafter owned by or controlled by the disclosing party; or as an obligation to enter into a further contract or to reimburse the cost of any effort expended by either party. The receiving party shall only make such copies of the disclosing party’s proprietary Information as are necessary for the purpose of the “subject”. Upon termination or expiration of this agreement all such copies along with the original shall, upon request, be promptly returned to the disclosing party or destroyed. The receiving party may, however retain in the file of its legal counsel, for archival purpose only, one copy of any such Proprietary Information returned or destroyed. This agreement shall expire five (5) years from the date of its execution unless terminated sooner via thirty (30) days written notice to the other party. Neither expiration nor termination of this agreement shall effect obligations with respect to Proprietary Information exchanged prior to the effective date of termination or expiration All disputes or differences arising regarding the validity and/or interpretation of the provision of this agreement shall be submitted to and determined by arbitration according to the Rules of Conciliation and Arbitration of the international Chamber of Commerce by three (3) arbitrations appointed in accordance with the said rules. Swedish substantive as well as procedural law shall govern this agreement. ---- connectBlue AB _____________________________ _____________________________ _____________________________ _____________________________ Rolf Nilsson, President Ty ped Name Ty ped Name Who warrants to be duly authorized Who warrants to be duly authorized 2012-04-30 Page 4 of 4 Date ___________________________ Date ___________________________

2012-04-30 Reference: cBProject-1202-01 (1) connectBlue ab residence: malmö VAT no. se 556589-0851-01 Norra Vallgatan 64 3V se-211 22 malmö sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.se page 1 of 2 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: PART 15 UNLICENSED MODULAR TRANSMITTER APPROVAL To Whom It May Concern: We, connectBlue AB, hereby requests a Limited Modular Approval of our OEM-Bluetooth module, described as follows: Brand name: connectBlue AB Model name: cB-0950 Type number: cB-0950 FCC ID: PVH0950 In FCC Public Notice DA 00-1407 released June 26, 2000 there are eight numbered requirements that our OEM-Bluetooth module type cB-0950 complies with. 1. The modular transmitter must have its own shielding. The modular transmitter has its own shielding as shown on photo exhibits. 2. The modular transmitter must have buffered modulation/data inputs The module has a memory management unit inside of the IC (U1). It buffers the data inputs from UART and SPI terminal. 3. The modular transmitter must have its own power supply regulation The IC contains an own voltage regulation inside the radio (U1). In case of changes in the supply voltage VCC (for example caused by temperature changes or other effects), the internal voltage will be stabilized. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204c The module is either equipped with on-board chip antenna or unique (U.FL) antenna connector. For further details please refer to the antenna data sheet included in the filing. 5. The modular transmitter must be tested in a stand-alone configuration The EUT was tested in a stand-alone configuration. 2012-04-30 Page 2 of 2 6. The modular transmitter must be labelled with its own FCC ID number The EUT will be labelled with its own FCC ID number. The label is specified in Exhibit D. If the module is installed inside of an end-product, the label will not be visible. In this case the OEM customer will be instructed to how to apply the exterior label. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The EUT is compliant with all applicable FCC rules. Detail instructions are given in the product Users Guide. 8. The modular transmitter must comply with any applicable RF exposure requirements. The maximum measured power output is about 3 dBm (2 mW) peak conducted with a maximum antenna gain of + 3.4 dBi which results in an EIRP of about 4.4 mW. This is far below the low threshold (60/2.4 GHz ~ 25 mW) for d |< 2.5 cm and therefore categorically excluded from the FCC RF Exposure Requirements.

SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 1 - Technical Data Sheet of BT/WLAN Antenna on Murata Standard PCB Low Profile ANCG1 series Size: 8x2mm, t2mm max. Note Please confirm the latest specification for antenna shape and dimensions. Capacitors and Inductors used in this report are as follows unless otherwise specified. The values of each component are mentioned in the report. In case using different series or manufactures' components, another value may be required to get the proper result. Capacitors: GRM15 series (Murata) Inductors: LQG15HS series (Murata) Kanazawa Murata Mfg.Co.,Ltd Antenna Products Department SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 2 - Measurement Conclusion PWB Size: 37x80mm Condition1Condition2Condition3Condition4 Sample No. ANS5CASR0-11 ANS5CASR0-14 ANS5CASR0-12 ANS5CASR0-14 Antenna[mm]8x2mm, t2mm max. PWB size[mm]37x80mm ShuntNoneNoneNoneNone Fine TuneNoneNone0.3pFNone Efficiency at 2442MHz -2.0dB-3.7dB-2.2dB-2.6dB -7.0 -6.0 -5.0 -4.0 -3.0 -2.0 -1.0 0.0 2380 2400 2420 2440 2460 2480 2500 Frequency[MHz] A n t e n n a E f f i c i e n c y [ d B ] Condition1 Condition2 Condition3 Condition4 Fig. 1: Antenna efficiency of Condition1-4 SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 3 - 1.Measurement condition Fig. 2: Condition 1 (ANS5CASR0-11, shunt = none, fine tune = none) Fig. 3: Condition 2 (ANS5CASR0-14, shunt = none, fine tune = none) SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 4 - 1.Measurement condition Fig. 4: Condition 3 (ANS5CASR0-12, shunt = none, fine tune = 0.3pF) Fig. 5: Condition 4 (ANS5CASR0-14, shunt = none, fine tune = none) 0.3pF SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 5 - 2. Measurement direction vertical horizontal XY plane YZ plane ZX plane Fig. 6: Measurement direction in Free Space 3D measurement Stargate32 (Satimo) 0deg 0deg 0deg -90deg 90deg 90deg SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 6 - 3. Measurement results 3.1: Return loss Fig. 7: Condition 1 (ANS5CASR0-11) Fig. 8: Condition 2 (ANS5CASR0-14) SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 7 - 3. Measurement results 3.1: Return loss Fig. 9: Condition 3 (ANS5CASR0-12) Fig. 10: Condition 4 (ANS5CASR0-14) SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 8 - 3. Measurement results 3.2: Antenna gain [dBi][dBi][dB] Total hor.ver.hor.ver. Average MAX -2.3-9.3-2.1-4.8 AVE-5.3 -13.1 -6.5-7.5-4.0-3.9 MAX -0.5 -7.4 -0.2 -2.8 AVE -3.5 -11.1 -4.8 -5.2 -2.1 -2.0 MAX-2.9-9.7-2.5-4.9 AVE-5.8 -13.3 -7.0-7.2-4.4-4.3 LINEAR YZ-plane Efficiency POLARIZATION 2400 ZX-plane MHz 2442 MHz 2484 MHz Table 1: Condition 1 (ANS5CASR0-11) [dBi][dBi][dB] Total hor.ver.hor.ver. Average MAX -2.8-8.5-2.7-7.7 AVE-8.7 -11.6 -8.7-9.8-7.0-6.6 MAX 0.4 -5.5 0.2 -4.5 AVE -5.7 -9.0 -6.2 -6.7 -4.1 -3.7 MAX-2.0-7.8-2.7-6.0 AVE-8.2 -11.7 -9.0-8.7-6.7-6.3 MHz 2442 MHz 2484 MHz LINEAR YZ-plane Efficiency POLARIZATION 2400 ZX-plane Table 2: Condition 2 (ANS5CASR0-14) [dBi][dBi][dB] Total hor.ver.hor.ver. Average MAX -3.6 -13.6 -14.0 -3.5 AVE-5.8 -17.7 -19.8 -5.3-5.2-5.3 MAX -0.2 -10.1 -9.9 -0.1 AVE -2.7 -14.6 -15.9 -2.2 -2.2 -2.2 MAX-2.3-11.8-11.3-2.1 AVE-4.6 -16.4 -17.0 -4.0-4.1-4.0 LINEAR YZ-plane Efficiency POLARIZATION 2400 ZX-plane MHz 2442 MHz 2484 MHz Table 3: Condition 3 (ANS5CASR0-12) [dBi][dBi][dB] Total hor.ver.hor.ver. Average MAX -3.8 -12.5 -14.6 -3.6 AVE-6.4 -17.0 -20.2 -5.3-5.5-5.6 MAX -0.6 -9.2 -10.5 -0.5 AVE -3.4 -14.0 -16.4 -2.2 -2.5 -2.6 MAX-3.0-11.8-12.0-2.7 AVE-5.6 -16.3 -17.6 -4.4-4.7-4.8 MHz 2442 MHz 2484 MHz LINEAR YZ-plane Efficiency POLARIZATION 2400 ZX-plane Table 4: Condition 4 (ANS5CASR0-14) SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 9 - 3. Measurement results 5.3: Radiation Pattern XY planeYZ planeZX plane HOR. VER.HOR. VER.HOR. VER. MAX -10.92.0MAX -0.5-7.4MAX -0.2-2.8 AVE-15.4-1.9AVE-3.5-11.1AVE-4.8-5.2 -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical Fig. 2: Condition 1 (ANS5CASR0-11) XY planeYZ planeZX plane HOR. VER.HOR. VER.HOR. VER. MAX -9.5-1.1MAX0.4-5.5MAX0.2-4.5 AVE-13.0-5.9AVE-5.7-9.0AVE-6.2-6.7 -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical Fig. 3: Condition 2 (ANS5CASR0-14) SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 10 - 3. Measurement results 5.3: Radiation Pattern XY planeYZ planeZX plane HOR. VER.HOR. VER.HOR. VER. MAX -0.5-1.6MAX -0.2 -10.1MAX -9.9-0.1 AVE-5.2-5.0AVE-2.7-14.6AVE-15.9-2.2 -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical Fig. 4: Condition 3 (ANS5CASR0-12) XY planeYZ planeZX plane HOR. VER.HOR. VER.HOR. VER. MAX -1.1-2.2MAX -0.6-9.2MAX -10.5 -0.5 AVE-5.3-5.7AVE-3.4-14.0AVE-16.4-2.2 -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical Fig. 5: Condition 4 (ANS5CASR0-14)

Ex-IT 2400 MHF 28 Applications M2M-communications Telemetric Automated Meter Reading Alarms Specification Frequency:2400 -2485 MHz VSWR:< 3:1 (on ProAnt demo box) Gain:Max: 2 dBi Height: 28 mm, excluding cable and thread. Diameter:12 mm Temperature:-30 to +85°C RoHS compliant

Ex-IT 2400 28-00x A pplications M 2M - com m unications Te le m e tric A utom ate d M e te r Re ading A larm s Spe cification Fre q ue ncy:2400 - 2485 M H z VSWR:< 3:1 (on ProA nt de m o b ox) G ain:M ax: 3 dBi Le ng th : 28 m m Width :8 m m Te m pe rature :- 30 to + 85°C

Ex-IT 2400 SMA 70-00x A pplications M 2M - com m unications Te le m e tric A utom ate d M e te r Re ading A larm s Spe cification Fre q ue ncy:2400 - 2485 M H z VSWR:< 2:1 (on ProA nt de m o b ox) G ain:M ax: 3 dBi H e ig h t: 107 m m , Ex- IT 2400 SM A 70- 001. 83 m m , Ex- IT 2400 SM A 70- 002 Width :10 m m Te m pe rature :- 30 to + 85°C Ex-IT 2400 SM A 70-001 Ex-IT 2400 SM A 70-002

O utSide™ 2400 Spe cification Fre q ue ncy:2400 - 2485 M H z VSWR:< 3:1 G ain:M ax: 3 dBi D im e nsion: 50 m m diam e te r, h e ig h t 30 m m M ounting : Scre w on SM A jack conne ctor. Te m pe rature :- 30 to + 85°C A pplications M 2M - com m unications Te le m e tric A utom ate d M e te r Re ading A larm s

SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 1 - Technical Data Sheet of BT/WLAN Antenna on Murata Standard PCB Low Profile ANCG1 series Size: 8x2mm, t2mm max. Note Please confirm the latest specification for antenna shape and dimensions. Capacitors and Inductors used in this report are as follows unless otherwise specified. The values of each component are mentioned in the report. In case using different series or manufactures' components, another value may be required to get the proper result. Capacitors: GRM15 series (Murata) Inductors: LQG15HS series (Murata) Kanazawa Murata Mfg.Co.,Ltd Antenna Products Department SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 2 - Measurement Conclusion PWB Size: 37x80mm Condition1Condition2Condition3Condition4 Sample No. ANS5CASR0-11 ANS5CASR0-14 ANS5CASR0-12 ANS5CASR0-14 Antenna[mm]8x2mm, t2mm max. PWB size[mm]37x80mm ShuntNoneNoneNoneNone Fine TuneNoneNone0.3pFNone Efficiency at 2442MHz -2.0dB-3.7dB-2.2dB-2.6dB -7.0 -6.0 -5.0 -4.0 -3.0 -2.0 -1.0 0.0 2380 2400 2420 2440 2460 2480 2500 Frequency[MHz] A n t e n n a E f f i c i e n c y [ d B ] Condition1 Condition2 Condition3 Condition4 Fig. 1: Antenna efficiency of Condition1-4 SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 3 - 1.Measurement condition Fig. 2: Condition 1 (ANS5CASR0-11, shunt = none, fine tune = none) Fig. 3: Condition 2 (ANS5CASR0-14, shunt = none, fine tune = none) SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 4 - 1.Measurement condition Fig. 4: Condition 3 (ANS5CASR0-12, shunt = none, fine tune = 0.3pF) Fig. 5: Condition 4 (ANS5CASR0-14, shunt = none, fine tune = none) 0.3pF SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 5 - 2. Measurement direction vertical horizontal XY plane YZ plane ZX plane Fig. 6: Measurement direction in Free Space 3D measurement Stargate32 (Satimo) 0deg 0deg 0deg -90deg 90deg 90deg SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 6 - 3. Measurement results 3.1: Return loss Fig. 7: Condition 1 (ANS5CASR0-11) Fig. 8: Condition 2 (ANS5CASR0-14) SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 7 - 3. Measurement results 3.1: Return loss Fig. 9: Condition 3 (ANS5CASR0-12) Fig. 10: Condition 4 (ANS5CASR0-14) SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 8 - 3. Measurement results 3.2: Antenna gain [dBi][dBi][dB] Total hor.ver.hor.ver. Average MAX -2.3-9.3-2.1-4.8 AVE-5.3 -13.1 -6.5-7.5-4.0-3.9 MAX -0.5 -7.4 -0.2 -2.8 AVE -3.5 -11.1 -4.8 -5.2 -2.1 -2.0 MAX-2.9-9.7-2.5-4.9 AVE-5.8 -13.3 -7.0-7.2-4.4-4.3 LINEAR YZ-plane Efficiency POLARIZATION 2400 ZX-plane MHz 2442 MHz 2484 MHz Table 1: Condition 1 (ANS5CASR0-11) [dBi][dBi][dB] Total hor.ver.hor.ver. Average MAX -2.8-8.5-2.7-7.7 AVE-8.7 -11.6 -8.7-9.8-7.0-6.6 MAX 0.4 -5.5 0.2 -4.5 AVE -5.7 -9.0 -6.2 -6.7 -4.1 -3.7 MAX-2.0-7.8-2.7-6.0 AVE-8.2 -11.7 -9.0-8.7-6.7-6.3 MHz 2442 MHz 2484 MHz LINEAR YZ-plane Efficiency POLARIZATION 2400 ZX-plane Table 2: Condition 2 (ANS5CASR0-14) [dBi][dBi][dB] Total hor.ver.hor.ver. Average MAX -3.6 -13.6 -14.0 -3.5 AVE-5.8 -17.7 -19.8 -5.3-5.2-5.3 MAX -0.2 -10.1 -9.9 -0.1 AVE -2.7 -14.6 -15.9 -2.2 -2.2 -2.2 MAX-2.3-11.8-11.3-2.1 AVE-4.6 -16.4 -17.0 -4.0-4.1-4.0 LINEAR YZ-plane Efficiency POLARIZATION 2400 ZX-plane MHz 2442 MHz 2484 MHz Table 3: Condition 3 (ANS5CASR0-12) [dBi][dBi][dB] Total hor.ver.hor.ver. Average MAX -3.8 -12.5 -14.6 -3.6 AVE-6.4 -17.0 -20.2 -5.3-5.5-5.6 MAX -0.6 -9.2 -10.5 -0.5 AVE -3.4 -14.0 -16.4 -2.2 -2.5 -2.6 MAX-3.0-11.8-12.0-2.7 AVE-5.6 -16.3 -17.6 -4.4-4.7-4.8 MHz 2442 MHz 2484 MHz LINEAR YZ-plane Efficiency POLARIZATION 2400 ZX-plane Table 4: Condition 4 (ANS5CASR0-14) SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 9 - 3. Measurement results 5.3: Radiation Pattern XY planeYZ planeZX plane HOR. VER.HOR. VER.HOR. VER. MAX -10.92.0MAX -0.5-7.4MAX -0.2-2.8 AVE-15.4-1.9AVE-3.5-11.1AVE-4.8-5.2 -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical Fig. 2: Condition 1 (ANS5CASR0-11) XY planeYZ planeZX plane HOR. VER.HOR. VER.HOR. VER. MAX -9.5-1.1MAX0.4-5.5MAX0.2-4.5 AVE-13.0-5.9AVE-5.7-9.0AVE-6.2-6.7 -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical Fig. 3: Condition 2 (ANS5CASR0-14) SET-DSK0893C Mar 14, 2011 Murata Proprietary, Murata Confidential - 10 - 3. Measurement results 5.3: Radiation Pattern XY planeYZ planeZX plane HOR. VER.HOR. VER.HOR. VER. MAX -0.5-1.6MAX -0.2 -10.1MAX -9.9-0.1 AVE-5.2-5.0AVE-2.7-14.6AVE-15.9-2.2 -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical Fig. 4: Condition 3 (ANS5CASR0-12) XY planeYZ planeZX plane HOR. VER.HOR. VER.HOR. VER. MAX -1.1-2.2MAX -0.6-9.2MAX -10.5 -0.5 AVE-5.3-5.7AVE-3.4-14.0AVE-16.4-2.2 -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical -30 -25 -20 -15 -10 -5 0 0 90 180 270 horizontal vertical Fig. 5: Condition 4 (ANS5CASR0-14)

Ex-IT 2400 MHF 28 Applications M2M-communications Telemetric Automated Meter Reading Alarms Specification Frequency:2400 -2485 MHz VSWR:< 3:1 (on ProAnt demo box) Gain:Max: 2 dBi Height: 28 mm, excluding cable and thread. Diameter:12 mm Temperature:-30 to +85°C RoHS compliant

Ex-IT 2400 28-00x A pplications M 2M - com m unications Te le m e tric A utom ate d M e te r Re ading A larm s Spe cification Fre q ue ncy:2400 - 2485 M H z VSWR:< 3:1 (on ProA nt de m o b ox) G ain:M ax: 3 dBi Le ng th : 28 m m Width :8 m m Te m pe rature :- 30 to + 85°C

O utSide™ 2400 Spe cification Fre q ue ncy:2400 - 2485 M H z VSWR:< 3:1 G ain:M ax: 3 dBi D im e nsion: 50 m m diam e te r, h e ig h t 30 m m M ounting : Scre w on SM A jack conne ctor. Te m pe rature :- 30 to + 85°C A pplications M 2M - com m unications Te le m e tric A utom ate d M e te r Re ading A larm s

InSide™ 2400 Spe cification Fre q ue ncy:2400 - 2485 M H z VSWR:< 2:1 (on ProA nt de m o b oard) G ain:M ax: 3 dBi D im e nsion: 27 x 12 m m (triang ular), th ick ne ss 1 m m M ounting : 1 adh e sive tape , 3M 467 Inte rface :10 cm coaxial w ith U.FL IPEX conne ctor (oth e r options upon re q ue st) Te m pe rature :- 30 to + 85°C Re g iste re d Com m unity D e sig n: 683354- 0002 RoH S Com pliant A pplications M 2M - com m unications Te le m e tric A utom ate d M e te r Re ading A larm s

datasheet m70cxr V2.0.doc roof antenna for bluetooth roof installation planTec® – bluetooth Bestellnr.: m70cxr 0300 00 xx xx 76,0 mm 20,7 mm 13,6 mm Gewinde M 16 The planar antennas of the latest technology offers you decisive advantages: roof installation, not only for car, truck and bus installation on all plain surfaces possible (application at container, automatic machines and railroads...) waterproof with two independent washers in mounted condition flat design (approx. 20 mm high ), no additional rod antennas necessary other cable lengths or connectors on request at car wash no disassembly necessary waterproof IPX6 and IPX9K TECHNICAL DATA: GSM: frequency range: 2400 - 2500 MHz VSWR: < 2,0 typical gain: 1,0 dB typical power max.: ≤ 10 watt dimensions and connectors: connection (standard): 3m RF-cable RG 174 with connector GSM/FME(f) (other cable-length or connectors on request) dimensions (∅/h): approx. 75 mm / 20 mm temperature range: from –40°C up to +85°C

Specifications subject to change without notice. 3425 N.44 th Street, LINCOLN, NE 68504 USA SALES PHONE: 800.228.4563 PHONE: 402.467.4491 • FAX: 402.467.4528 www.centurion.com • [email protected] Copyright  2004 Centurion Wireless Technologies, Inc. All Rights Reserved Specifications: ƒ Versatile and easy to use antenna for 2.4 to 2.5 GHz Bluetooth and IEEE 802.11 devices ƒ Designed for easy connection to radio cards ƒ Utilizes Centurion’s patented PCB Microsphere technology ƒ Has a ground plane incorporated into the resonator structure, therefore no additional ground plane is required to radiate efficiently Frequency Range 2.4 – 2.5 GHz Gain 2 dBi Polarization Linear Impedance 50 ohms VSWR <2.5:1 Dimensions (L x W x H) 1.88" x .5"x .032" Weight 2 g Cable & Connector: Model # Part # Cable Connector NanoBlue-IP04 MAF94045 100mm, Ø 1.13mm IPEX MHF NanoBlue MAF94102 100mm, RG-178 Flying Lead NanoBlue a – 9/05/05 NanoBlue Model Number: NanoBlue Internal Antenna – Embedded Azimuth Plane 2.45 GHz Elevation Plane Phi = 90 2.45 GHz Elevation Plane Phi = 0 2.45 GHz 1.88"

OutSide™ 2400 Specification Frequency:2400 - 2485 MHz VSWR:< 3:1 Gain:Max: 3 dBi Dimension: 36 x 18 mm, height 16 mm Interface:U.FL IPEX or MMCX on 7 cm cable. Mounting: 2 x 3 mm screws or adhesive tape. Temperature:-30 to +85°C RoHS compliant Applications M2M-communications Telemetric Automated Meter Reading Alarms

TECHNICAL DATA SHEET 1 / 3 STRAIGHT DIPOLE SMA 2.4GHZ PACKAGING 25 R380.500.139 OMNIDIRECTIONAL ANTENNA Series : ANTENNA Issue : 0740 A In the effort to improve our products, we reserve the right to make changes judged to be necessary. All dimensions are in mm .. pnao TECHNICAL DATA SHEET 2 / 3 STRAIGHT DIPOLE SMA 2.4GHZ PACKAGING 25 R380.500.139 OMNIDIRECTIONAL ANTENNA Series : ANTENNA Issue : 0740 A In the effort to improve our products, we reserve the right to make changes judged to be necessary. ELECTRICAL CHARACTERISTICS Frequency : ...................................... 2.4-2.485 GHz Nominal Impedance : ...................... 50 Ω VSWR : ............................................ 2 Max Gain (Overall gain) :........................ 2 dBi Radiation PatternOmni-directional in the horizontal plane Polarization :.................................... VERTICAL Power withstanding : ....................... 1 W Connector type : .............................. Reverse SMA Plug (Male) (gold plated) MECHANICAL CHARACTERISTICS Plastic radome :................................ HYTREL G 3548 L Color : .............................................. BLACK Ingress Protection : .......................... IP 54 Weight :............................................ 10.2 g Overall length : ............................... 61.1 mm Flexibility : ...................................... 100 Cycles ± 180° Pull Force : ...................................... 68 N Torque Resistance : ......................... 18 N.cm Flammability : ................................. UL94-HB Drop test resistance : ....................... 5 ft drop to concrete (x30) mounted of a 800 g handheld terminal TECHNICAL DATA SHEET 3 / 3 STRAIGHT DIPOLE SMA 2.4GHZ PACKAGING 25 R380.500.139 OMNIDIRECTIONAL ANTENNA Series : ANTENNA Issue : 0740 A In the effort to improve our products, we reserve the right to make changes judged to be necessary. TESTS MECHANICAL Test report n° 2003-13-9245 ENVIRONMENTAL CHARACTERISTICS Operating temperature : ....................... -20/+50 ° C Storage temperature : ........................... -40/+70 ° C TESTS ENVIRONMENTAL Test report n° 2003-19-8353 In accordance with the DEF STAN 00-35 PACKAGING StandardUnitOther 25‘W’ optionContact us

horizontal vertical Radiation Pattern HUBER+SUHNER ® OMNI ANTENNA FOR WIRELESS COMMUNICATION SOA 2400/360/6/0/V Technical Data Electrical Properties Frequency range 2400 - 2500 MHz Impedance 50 Ω VSWR < 1.8 Polarization linear, vertical Gain 6.0 dBi 3 dB beamwidth horizontal 360° Downtilt 0° Lightining protection DC grounded Max. power 25 W Mechanical & Environmental Properties Dimensions Ø 22 x 250 mm (Ø 0.87” x 9.84”) Weight 0.3 kg (0.66 lbs.) Radome material fibre glass UL94 Back/base plane material aluminium 2002/95/EC (RoHS) compliant Operating temperature range - 40°C to + 80°C Storage temperature range - 40°C to + 80°C Windload 3 N at 160km/h (100mph) Available Types Article no. 1324.17.0043 84004596 N female (nato green) 1324.17.0047 84008543 N female (RAL 7035, light grey) Mast mount (9091.99.0173 bracket + 2 metal bands) included Documents 01.02.0777 security instruction Document no.: 01.02.1087 Uncontrolled Copy Issue no.: 6 Issued/Checked/Released: 4159/4174/09.2004 Supersedes: 07.2006 Last amended: 4417/08.2006 WAIVER! It is exclusively in written agreements that we provide our customers with warrants and represen…
