PVH090502LWireless Communication System Module

u-blox Malmo AB

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Aug 17, 2006
Application Purpose: Original Equipment
Date of Application: Aug 17, 2006
Equipment Note: Wireless Communication System Module
Frequency Range: 2402.00000000 - 2480.00000000
Company: u-blox Malmo AB
Country: Sweden

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

INDUSTRIAL BLUETOOTH™ OEM Serial Port Adapter™ cB-0905 Electrical & Mechanical Datasheet OEM Serial Port Adapter™ cB-0905 Electrical & Mechanical Datasheet Copyright © 2006 connectBlue AB. The contents of this document can be changed by connectBlue AB without prior notice and do not constitute any binding undertakings from connectBlue AB. connectBlue AB is not responsible under any circumstances for direct, indirect, unexpected damage or consequent damage that is caused by this document. All rights reserved. Release: 2006-08 Document version: 1 Document number: cBProduct-0605-05 Printed in Sweden. Trademarks Registered trademarks from other companies are: Bluetooth is a trademark owned by the Bluetooth SIG, Inc., Microsoft™, Windows™, Windows NT™, Windows 2000™, Windows CE™, Windows ME™, are registered trademarks from Microsoft Corporation. Version 1.0 - 2006-08 4 Contents 1 Introduction 5 1.1 Related Documents ...........................................................................5 1.2 Product Variants ................................................................................6 1.3 cB-0905 ..........................................................................................7 1.4 Block Diagram cB-0905 .....................................................................8 2 Electrical Interface and Connectors 9 2.1 Pin Numbering .................................................................................10 2.2 Pin Description .................................................................................11 2.3 Characteristics .................................................................................14 2.4 Hardware Reset ...............................................................................17 2.5 Power Control ..................................................................................17 3 Operating Status 18 4 Antennas 19 4.1 Surface Mounted Antenna (Internal)................................................19 4.2 External antennas ............................................................................20 5 Mounting Information 23 5.1 Board Outlines .................................................................................23 5.2 Using the J2/J3 Board-to-Board Connectors ...................................25 5.3 Using Press-Fit Nuts for Mounting the Module ................................29 5.4 Antenna Issues ................................................................................29 6 Bluetooth Information 30 6.1 General information .........................................................................30 6.2 Bluetooth Qualification information ..................................................31 7 Regulatory Information 32 7.1 Declaration of Conformity ................................................................32 7.2 Safety Compliance ...........................................................................33 7.3 FCC and IC Compliance ..................................................................33 7.4 UL listing information .......................................................................35 7.5 Compliance with RoHS directive......................................................35 8 Guidelines for Efficient and Safe Use 36 8.1 General ........................................................................................36 8.2 Product Care ....................................................................................36 8.3 Radio Frequency Exposure .............................................................36 8.4 Electronic Equipment .......................................................................37 8.5 Potentially Explosive Atmospheres..................................................37 8.6 Power Supply ...................................................................................37 Appendix A - Application Notes 38 A.1 Step-by-Step Guide .........................................................................38 A.2 Design Examples .............................................................................39 Version 1.0 - 2006-08 5 1 Introduction 1.1 Related Documents There are some documents related to the Serial Port Adapter: - The Serial Port Adapter AT Commands document contains a description of the AT commands supported in the Serial Port Adapter. It also contains information on how to use the AT commands to create Bluetooth applications. - The OEM Serial Port Adapter Electrical & Mechanical Datasheet (this document) contains important information about the OEM Serial Port Adapter. Read this document if you are using the OEM Serial Port Adapter. Version 1.0 - 2006-08 6 1.2 Product Variants This Electrical and Mechanical datasheet contains information about the 4 variants of OEM Serial Port Adapters based on the PCB cB-0905. This document makes references to the OEM Module ID, not the Product Name (see Table 1). Table 1: Product variants Product Name OEM Module ID / FCC ID Bluetooth Type Description CB-OEMSPA333i-02 cB-0099-01 PVH090502L Class 1 / TBDdBm TBDmW OEM Serial Port Adapter 333i with internal antenna, 2mm pin connector Class 1 TBDdBm Internal antenna CB-OEMSPA333i-04 cB-0100-01 PVH090502L Class 1 / TBDdBm TBDmW OEM Serial Port Adapter 333i with internal antenna, no connectors CB-OEMSPA333x-02 cB-0101-01 PVH090502L Class 1 / TBDdBm TBDmW OEM Serial Port Adapter 333x with external antenna, 2mm pin connector Class 1 TBDdBm External antenna CB-OEMSPA333x-04 cB-0102-01 PVH090502L Class 1 / TBDdBm TBDmW OEM Serial Port Adapter 333x with external antenna, no connectors Version 1.0 - 2006-08 7 1.3 cB-0905 cB-0905 is a small size Bluetooth module based on the Phillips BGB204 system in package (SiP). The Bluetooth host and the SPA application are running on a separate Host CPU. The Bluetooth signal is amplified with a power amplifier (PA) built on discrete components, which is covered by a shield box. The modules are available in many variants with different antenna / connectors. Se…

Text truncated - open the document above for the full version.

Cover Letter(s)

Page 1 (1) DECLARATION OF EQUALITY 2006-08-16 DECLARATION We, connectBlue AB, declare that the antenna referred to as MicroBlue CAP24235 is the same antenna as MicroBlue CAF94131. MicroBlue CAP24235 is connectBlue internal id for the version of MicroBlue CAF94131, which is produced exclusively for connectBlue AB. Mats Andersson, CTO connectBlue AB

Cover Letter(s)

2006-08-14 Reference: connectBlue ab residence: malmö VAT no. se 556589-0851-01 isbergs gata 3 se-211 19 malmö sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] Fehler! Hyperlink-Referenz ungültig. page 1 of 1 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: CONFIDENTIALITY REQUEST FOR FCC ID PVH090502L Model name: Class 1 OEM Bluetooth Unit, Type number: cB-0905-0202 To Whom It May Concern: This letter serves as an official request for confidentiality under the FCC Rule Section 0.457 and 0.459 . . We have requested that the schematic diagrams, required to be submitted with this application be withheld from public review. The reason for this request is that these documents are company proprietary information that should never get into the possession of competitors, which would be harmful for our business. Please contact me if there is any information you may need. Regards, Mats Andersson, CTO connectBlue

Cover Letter(s)

2006-08-15 Reference: cBProject-0502-18 (3) connectBlue ab residence: malmö VAT no. se 556589-0851-01 Norra Vallgatan 64 3V se-211 22 malmö sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] Fehler! Hyperlink-Referenz ungültig. page 1 of 2 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: PART 15 UNLICENSED LIMITED MODULAR TRANSMITTER APPROVAL To Whom It May Concern: We, connectBlue AB, hereby requests for part 15 unlicensed modular transmitter approval of our OEM-Bluetooth module, described as follows: Brand name: connectBlue AB Model name: OEM-Bluetooth module Type number: cB-0905-0202 FCC ID: PVH090502L In FCC Public Notice DA 00-1407 released June 26, 2000 there are eight numbered requirements that our OEM-Bluetooth module type cB-0905-0202 complies with. 1. The modular transmitter must have its own shielding. The shielding of the radio portion can be demonstrated in exhibition External Photos. 2. The modular transmitter must have buffered modulation/data inputs The module has a memory management unit inside of the IC. It buffers the data inputs from UART and USB terminal. 3. The modular transmitter must have its own power supply regulation The IC contains an own voltage regulation. In case of changes in the supply voltage VCC (for example caused by temperature changes or other effects), the internal voltage will be stabilized. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204c The module has either got an internal onboard antenna or alternatively an UFL connector for using external antennas mounted. This module is limited for OEM integration only. 5. The modular transmitter must be tested in a stand-alone configuration The EUT was tested in a stand-alone configuration. 6. The modular transmitter must be labelled with its own FCC ID number The EUT will be labelled with its own FCC ID number. The label is specified in Exhibit D. If the module is installed inside an end-product, the label will not be visible. In this case the OEM customer will be instructed to how to apply the exterior label. 2006-08-15 Page 2 of 2 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The EUT is compliant with all applicable FCC rules. Detail instructions are given in the product Users Guide 8. The modular transmitter must comply with any applicable RF exposure requirements. The maximum measured power output is 46 mW (16,6 dBm), the maximum antenna gain is + 2,5 dBi = numeric gain 1,8 (acc to FCC test report). The maximum permissible exposure is defined in 47 CFR 1.1310 with 1 mW/cm². The maximum permitted level is calculated using the general equation: S = P*G / 4pR² P = 46 mW, G = 1,8 (numeric gain; + 2,5 dBi = linear power gain relative to the isotropic radiator), R = 20 cm p = 3,1416 Solving for S, the power density at 20 cm is 0,017 mW/cm². So the 1mW/cm² limit is kept.

External Photos

Annex B of test report R61184_A Edition 1 EUT:cB-0905-02 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 12 July 2006page1 of7 61184_e.jpgcB-0905-02sample “16”, top view Annex B of test report R61184_A Edition 1 EUT:cB-0905-02 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 12 July 2006page2 of7 61184_h.jpgcB-0905-02 sample “16”, cover removed, top view Annex B of test report R61184_A Edition 1 EUT:cB-0905-02 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 12 July 2006page3 of7 61184_b.jpgcB-0905-02 sample “24”, top view Annex B of test report R61184_A Edition 1 EUT:cB-0905-02 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 12 July 2006page4 of7 61184_a.jpgcB-0905-02 sample “24”, cover removed, top view Annex B of test report R61184_A Edition 1 EUT:cB-0905-02 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 12 July 2006page5 of7 61184_c.jpgcB-09 05 -02bottom view Annex B of test report R61184_A Edition 1 EUT:cB-0905-02 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 12 July 2006page6 of7 61184_g.jpgcB-0903-02, carrier board, top view Annex B of test report R61184_A Edition 1 EUT:cB-0905-02 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 12 July 2006page7 of7 61184_f.jpgcB-0903-02, carrier board,bottomview

ID Label/Location Info

2006-08-14 Reference: cBProject-0511-02 (2) connectBlue ab residence: malmö VAT no. se 556589-0851-01 Norra vallgatan 64 3V se-211 22 malmö sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] Fehler! Hyperlink-Referenz ungültig. page 1 of 1 FCC identifier label for Bluetooth unit cB-0905-0202 S/N:0905-02-02xxxx FCC ID PVH090502L IC: 5325A-090502L The labels will be located as shown in the figures below. An auxiliary label will be provided for systems using the module where the original label not will be visible when the module is installed. Instructions on how to attach the auxiliary label in compliance with the modular approval guidelines developed by the FCC will be provided. The instructions will call attention to place the auxiliary label on an exterior surface of the device such that it will be visible upon inspection. The auxiliary label will have at least the information as shown in the figure below This device contains FCC ID PVH090502L IC: 5325A-090502L S/N label Regulatory label

Internal Photos

Operational Description

2006-08-15 Reference: connectBlue ab residence: malmö VAT no. se 556589-0851-01 norra vallgatan 64 se-211 22 malmö sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] Fehler! Hyperlink-Referenz ungültig. page 1 of 1 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Operational Description of cB-0905-0202 This Bluetooth modular transmitter can be integrated in different end products. Bluetooth is a short-range radio link intended to be a cable replacement between portable and/or fixed electronic devices. Bluetooth operates in the unlicensed ISM Band at 2.4 GHz. In the US a band of 83.5 MHz width is available. In this band, 79 RF channels spaced 1MHz apart are defined. The channel is represented by a pseudo-random hopping sequence through the 79 channels. The channel is divided into time slots, with a nominal slot length of 625μs, where each slot corresponds to different RF hop frequencies. The nominal hop rate is 1600 hops/s. All frequencies are equally used. The average time of occupancy is 0.3797 s within a 30 second period. The symbol rate on the channel is 1Ms/s. Parameter Data Bluetooth radio / Bluetooth base band controllerPhilips BGB204 Radio power amplifier muRata MF2400PS-AL0909 (+20dB) RF output power Class 1 Receive input level (max) +16dBm Output frequency 2.402 –2.480 GHz, ISM band Bluetooth stack Embedded host stack Bluetooth qualification 2.0 Antenna 2.4 GHz Mica SMD or UFL connector Power Supply 3.3 VDC (min) / 6.0 VDC (max) Dimensions 23 mm x 36 mm Regards connectBlue

Operational Description

Data sheet 2.4 GHz Mica SMD Antenna Miniature, low-weight unit for automatic assembly This surface-mounted, high-performance miniature antenna is intended for use with all 2.4 GHz applications; where small size and low weight are key factors. The antenna requires a ground plane, i.e. your device acts as an active part of the antenna and thus demands careful consideration concerning its placement. For optimal performance, we strongly recommend those customers not very well acquainted with RF technology to use our know-how when it comes to implementing the antenna in your application. We can offer advanced measuring equipment, custom tuning and technical support to obtain a secure and reliable implementation. It is important to note that, upon request, the Mica antenna can be customized according to your design. Typical application areas are: • Mobile phones • PDAs • Headsets • Laptop PCs • Peripheral equipment • PC cards Description The Mica antenna is an integrated low-weight antenna, only 20.5x3.35x3.6 mm in size. It is designed for automatic assembly (DFA). Matching network is needed. Size:20.5x3.35x3.6 mm Art No: 30201840 x gigaAnt, E-mail: [email protected], www.gigaAnt.com Specification subject to change without notice, FE010119-C, Oct 10-01 Antenna Specification Frequency:2.4-2.5 GHz Type:Ground plane dependent Efficiency:> 50%* Gain:2.5 dBi* Nominal impedance:50 Ohm VSWR:<2.0:1* Mounting:SMD Operating temperatur:-40 °C – +85 °C Relative humidity:93% at +40 °C Weight:0.4g * Typical values Mounting interface 3D Radiation pattern Product name / Article No. Mica30201840 9 Mica30201840 2 Mica30201840 3 Horizontal cut, xy-planeVertical cut, xz-plane Detailed foot print see application note Packaging Tape on reel / Bulk Tape on reel / 500 Pcs Tape on reel / 2000 Pcs Dimensions (mm) dBi

Operational Description

Features: Versatile and easy to use antenna for 2.4 to 2.5 GHz Bluetooth and IEEE 802.11 devices Designed for easy connection to radio cards Utilizes Centurion’s patented PCB Microsphere technology Has a ground plane incorporated into the resonator structure, therefore no additional ground plane is required to radiate efficiently Specifications: Frequency Range 2.4 – 2.5 GHz Polarization Linear Peak Gain 1.5 dBi Average Gain >0 dBi Nominal Impedance 50 ohms 2.4 - 2.5 GHz < 1.8:1 VSWR (Min. Performance) > 600 MHz 2.0:1 Temperature Range -40° to +85°C Vibration 6G RMS (9.04g2/Hz) for 15 minutes each in vertical and horizontal. No appearance or functional axis. Thermal Shock Change after 4 repeated cycles of 1 hr. at +85°C and 1 hr. at -40°C. Transfer time is 5 min. Dimensions (L x W x T) 1.88" x .89" x .032" Standard Cable 8" Brown RG-178 Coax Standard Connector R. A. MMCX Plug MicroBlue Part Number (P/N): CAF94131 MicroBlue – 10/28/02 Elevation Plane, Phi = 0 2450 MHz Elevation Plane, Phi = 90 2450 MHz Azimuth Plane 2450 MHz Internal Wireless Device Antenna

Operational Description

Specifications subject to change without notice. 3425 N.44 th Street, LINCOLN, NE 68504 USA SALES PHONE: 800.228.4563 PHONE: 402.467.4491 • FAX: 402.467.4528 www.centurion.com • [email protected] Copyright  2004 Centurion Wireless Technologies, Inc. All Rights Reserved Specifications: Versatile and easy to use antenna for 2.4 to 2.5 GHz Bluetooth and IEEE 802.11 devices Designed for easy connection to radio cards Utilizes Centurion’s patented PCB Microsphere technology Has a ground plane incorporated into the resonator structure, therefore no additional ground plane is required to radiate efficiently Frequency Range 2.4 – 2.5 GHz Gain 2 dBi Polarization Linear Impedance 50 ohms VSWR <2.5:1 Dimensions (L x W x H) 1.88" x .5"x .032" Weight 2 g Cable & Connector: Model # Part # Cable Connector NanoBlue-IP04 MAF94045 100mm, Ø 1.13mm IPEX MHF NanoBlue MAF94102 100mm, RG-178 Flying Lead NanoBlue a – 9/05/05 NanoBlue Model Number: NanoBlue Internal Antenna – Embedded Azimuth Plane 2.45 GHz Elevation Plane Phi = 90 2.45 GHz Elevation Plane Phi = 0 2.45 GHz 1.88"

Operational Description

Specifications subject to change without notice. 3425 N.44 th Street, LINCOLN, NE 68504 USA SALES PHONE: 800.228.4563 PHONE: 402.467.4491 • FAX: 402.467.4528 www.centurion.com • [email protected] Copyright  2004 Centurion Wireless Technologies, Inc. All Rights Reserved Specifications: ½ wave coaxial dipole Flexible element Frequency 2.4 - 2.5 GHz Polarization Vertical Gain 2.0 dBi Nominal Impedance 50 ohms VSWR 1.5:1 max at resonance RF Power Handling 50 watts Length 7.6 cm (90° Bent) or 10.8 cm (180° Straight) Temperature Range -40° to +80°C Drop Test 1M Cables & Connectors: Model # Part # Cable Connector WCR2400-FL04 MAF94015 100 mm RG-178 Flying Lead WCR2400-IP04 MAF94017 100 mm RG-178 IPEX U.FL WCR Snap-in a – 5/20/04 WCR Model Number: WCR2400-IP WCR2400-FL External Antenna – Snap-in/Captive Azimuth 2.45 GHz Antenna Bent @ 90° Antenna Straight @ 180° Elevation phi=0 2.45 GHz 7.6 cm

Test Report

Königswinkel 10 D -32825 Blomberg, Germany Phone+49 (0) 52 35 95 00-0 Fax+49 (0) 52 35 95 00-20 [email protected] w ww.phoenix-testlab.de 07 August 2006 Altmaier-IPS Bank:Stadtsparkasse BlombergGeneral Manager:Dr.-Ing.Holger AltmaierLegal Form:GmbH Routing Code:476 512 25Headquarter:Blomberg/Lippe AccountNo.:113 720Register of Companies:Amtsgericht Lemgo HRB 5233 Swift-Code:WELA DE D1 BLOOur VAT-No.:DE 162977933 Additional declaration part according to FCC 15.247 for Bluetooth TM devices 1.Output power and channel separation of a Bluetooth device in different operating modes The different operating modes (data mode, acquisition mode) of aBluetooth device don’tinfluence the output power and the channel spacing. There is only one transmitter which is driven by identical input parameters concerning thesetwo parameters. Only a different hopping sequence will be used. For this reason the check of these RF parameters in one operatingmode is sufficient. 2.Frequency rangeof a Bluetooth device Hereby we declare that the maximum frequency of this device is : 2402– 2480 MHz. This is according to Bluetooth Core Specifications (+ critical errata) for devices which will be operated in the USA. This was checked during the BluetoothQualification tests (Test Case: TRM/CA/04-E). Other frequency ranges (e.g. Spain, France,Japan) which are allowed according the Core Specification are not supported by this device. 3.Co-ordination of the hopping sequence in data mode to avoid simultaneous occupancy by multiple transmitters Bluetoothunits, which want to communicate with other units must be organised in a structure called piconet. This piconet consists of max. 8 Bluetooth units. One unit is the master and the other seven are slaves. The master co-ordinatesthefrequency occupation in this piconet for all units. As the masterhop sequence is derived from this BDaddresswhich is unique for each Bluetooth device, additional masters intending to establish new piconets will always use different hop sequences. FCC Federal Communications Commission PHOENIX TESTLAB GmbH • Königswinkel 10 • D-32825 Blomberg - 2 - 4.Examples of hopping sequences Example of a 79 hopping sequence indata mode: 40, 21, 44, 23, 42, 53, 46, 55, 48, 33, 52, 35, 50, 65, 54, 67, 56, 37, 60, 39, 58, 69, 62, 71, 64, 25, 68, 27, 66, 57, 70, 59, 72, 29, 76, 31, 74, 61, 78, 63, 01, 41, 05, 43, 03, 73, 07, 75, 09, 45, 13, 47, 11, 77, 15, 00, 64, 49, 66, 53, 68,02, 70, 06, 01, 51, 03, 55, 05, 04 5.Equally average use of frequencies in data modeand behaviour for short transmissions The generation of the hopping sequence in connection mode depends essentially on two input values: 1.LAP/UAP of the master of the connection 2.Internal master clock The LAP (loweraddresspart) are the 24 LSB ́s of the 48 BD_ADRESS. The BD_ADRESS is an unambiguous number of every Bluetoothunit. UAP (upperaddress part) are the 24 MSB ́s of the 48 BD_ADRESS. The internal clock of a Bluetooth unit is derived from a free running clock which is never adjusted and is never turned off. For synchronisation with other units only offset are used. It has no relation to time of the day. Its resolution is at least half the RX/TX slot length of 312.5 μs. The clock has a cycle of about one day (23h30). In most case it is implemented as a 28 bit counter. For the deriving of the hopping sequence the entire LAP (24 bits), 4 LSB ́s (4 bits) (Input1) and the 27 MSB ́s of the clock (Input2) are used. With this input values different mathematic procedures (permutations, additions, XOR-operations) are performed to generate the sequence. This will be done at the beginning of every new transmission. Regarding short transmissions theBluetooth system has the following behaviour: The first connection between the two devices established, a hopping sequence was generated. For transmitting the wanted data the complete sequence was not use. The connection ended. The second connection will be established. A new hopping sequence is generated. Due to the fact that the Bluetooth clock has a different value, because the period between the two transmissions is longer (and cannot be shorter) than the minimum resolution of the clock (312.5μs). Thehopping sequence will always differ from the first one. - 3 - 6.The receiver input bandwidthand behaviour for repeated single and multiple packets The inputbandwidthof the receiver is 1 MHz. In every connection one Bluetooth device is the master and the other one is the slave. The master determines the hopping sequence (see Clause5.). The slave follows this sequence. Both devices shift between RX and TX time slot according to the clock of the master. Additionally the type of connection (e.g. single or multislot packet) is set up at the beginning of the connection. The master adapts its hopping frequency and its TX/RX timing according to the packet type of the connection. Also the slave of the connection will use thesesettings. Repeating of a packet has no influence on the hopping sequence. The hopping sequence generated by the master of the connection will be followed in any case. That means, a repeated packet will not be send on the same frequency, it is send on the next frequency of the hopping sequence. 7.Dwell time in data mode The dwell time of the 0.3797 s with in a 30second period in data mode is independent from the packet tape (packet length). The calculation for a30 second period is a follows: Dwell time = time slot length * hop rate / number of hopping channels * 30s Dwell time = 625μs * 1600 1/s / 79 * 30s = 0.3797s (in a 30s period) For multislot packet the hopping is reduced according to the length of the packet. Example for a DH5 packet (with a maximum length of 5 timeslots) Dwell time = 5 * 625μs * 1600 1/5 * 1/s / 79 * 30s = 0.3797s (in a 30s period) This is according theBluetoothCore Specifications V 1.0B (+critical errata) for all Bluetooth devices. Therefore all Bluetooth devices comply with theFCC dwell time requirement in data mode. This was checkedd…

Text truncated - open the document above for the full version.

Test Report

Königswinkel 10 32825 Blomberg Germany Phone+49 5235 9500-0 Fax+49 5235 9500-10 TEST REPORT Test Report Reference: R61184_A Edition 1 Equipment under Test: cB-0905-02 Serial Number: none FCC ID:PVH090502L Applicant: connectBlue AB Manufacturer: connectBlue AB Test Laboratory (CAB) accredited by DATech e.V. in compliance with DIN EN ISO/IEC 17025 under the Reg. No. DAT-P-105/99-21, listed by FCC 31040/SIT1300F2 and OATS listed by IC 3469 TEST REPORT REFERENCE: R61184_A Edition 1 Examiner: Thomas KÜHNDate of issue: 12 July 2006Page2 of119 Contents:Page 1 IDENTIFICATION.....................................................................................................................................4 1.1 APPLICANT.....................................................................................................................................4 1.2 MANUFACTURER..........................................................................................................................4 1.3 DATES.............................................................................................................................................4 1.4 TEST LABORATORY......................................................................................................................5 1.5 RESERVATION...............................................................................................................................5 1.6 NORMATIVE REFERENCES..........................................................................................................5 1.7 TEST RESULTS..............................................................................................................................5 2 TECHNICAL DATA OF EQUIPMENT......................................................................................................6 2.1 DEVICE UNDER TEST...................................................................................................................6 2.2 PERIPHERY DEVICES...................................................................................................................7 3 OPERATIONAL STATES AND PHYSICAL BOUNDARIES.....................................................................7 4 LIST OF MEASUREMENTS.....................................................................................................................8 5 TEST RESULTS.......................................................................................................................................9 5.1 20 dB BANDWIDTH........................................................................................................................9 5.1.1METHODOF MEASUREMENT (20 dBBANDWIDTH)......................................................9 5.1.2TEST RESULTS (20 dBBANDWIDTH)..............................................................................10 5.2CARRIER FREQUENCY SEPARATION.........................................................................................13 5.2.1METHODOF MEASUREMENT (CARRIER FREQUENCY SEPARATION)......................13 5.2.2 TESTRESULTS (CARRIER FREQUENCY SEPARATION)..............................................14 5.3 NUMBER OF HOPPING FREQUENCIES......................................................................................16 5.3.1METHODOF MEASUREMENT (NUMBER OF HOPPING FREQUEN…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Filip Kruzela(Certification Manager)

[email protected]+46 40 6307100Fax: +46 40 23 7137

Test Firm

PHOENIX TESTLAB GmbHHolger Bentje

[email protected]49-5235-9500-24Fax: 49-5235-9500-28

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	46.00 mW

Modular Type

Limited Single Modular Approval

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. Limited Modular Approval. This OEM module is approved for use in products operating as mobile transmitting device. The only antennas approved for use with this module are those documented in the filing, and must be installed in the manner specified therein. This device and its antenna(s) must operate with a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Grantee shall provide installation and operating instructions for satisfying RF exposure requirements to OEM integrators and installers.
