PVH090802Wireless Communication System Module

2007-05-09 Reference: cBProject-0704-04(2) connectBlue ab residence: malmö VAT no. se 556589-0851-01 norra vallgatan 64 3V se-211 22 malmö sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.se page 1 of 1 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: PART 15 UNLICENSED MODULAR TRANSMITTER APPROVAL To Whom It May Concern: We, connectBlue AB, hereby requests a Limited Modular Approval of our OEM-WLAN module, described as follows: Brand name: connectBlue AB Model name: OWSPA311g FCC ID: PVH090802 In FCC Public Notice DA 00-1407 released June 26,2000 there are eight numbered requirements. Our OEM-WLAN module OWSPA311g complies with all these requirements. 1. The modular transmitter must have its own shielding. The WLAN-module OWSPA311g has its RF-parts covered by a shield box. 2. The modular transmitter must have buffered modulation/data inputs The WLAN-module OWSPA311g has no modulation inputs. The electrical interface consists of a UART serial interface. 3. The modular transmitter must have its own power supply regulation The WLAN-module OWSPA311g contains its own voltage regulators. In case the supply voltage changes, the internal voltages will be kept unchanged. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204c The WLAN-module OWSPA311gi is equipped with an internal antenna. The WLAN-module OWSPA311gx is equipped with U.FL antenna connectors that are considered unique. 5. The modular transmitter must be tested in a stand-alone configuration The EUT was tested in a stand-alone configuration. 2007-05-09 Page 2 of 2 6. The modular transmitter must be labelled with its own FCC ID number The WLAN-module OWSPA311g will be marked with its own FCC ID number. The FCC ID number is printed in the solder mask of layer 8 on the module PCB. For systems using the module where the original FCC ID marking not will be visible when the module is installed instructions will be provided to the OEM customer how the end product must be label. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The WLAN-module OWSPA311g is compliant with all applicable FCC rules. Detail instructions are given in the product Users Guide. 8. The modular transmitter must comply with any applicable RF exposure requirements. The maximum output power is 155 mW [21.9 dBm]. The maximum antenna gain is 8.5 dBi [equal to a numeric gain of 7.1] The maximum permissible exposure defined in 47 CFR 1.1310 is 1 mW/cm². The maximum level at 20 cm distance is calculated using the general equation: S = P*G / 4πR² P = 155 mW, G = 7.1 (linear power gain relative to the isotropic radiator) R = 20 cm Solving for S, the power density at 20 cm is 0,22 mW/cm². This is well below the 1mW/cm² limit.

2007-06-01 Reference:cBProject-0705-03(1) connectBlue ab residence: malmö VAT no. se 556589-0851-01 norra vallgatan 64 3V se-211 22 malmö sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.se page 1 of 1 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: Compliance Statement Ad-hoc mode FCC ID PVH090802 Model name: OWSPA311g To Whom It May Concern: We, the undersigned, hereby declare that our product type OWSPA311g when operating under the definition of a client in 47 CFR §15.202 is configured to use the most restrictive regulatory domain. For this reason the available operating frequency range is limited to channel 1 – 11 (2412 – 2462 MHz). Please contact me if there is any information you may need. Regards, Mats Andersson, CTO connectBlue

2007-06-01 Reference:cBProject-0704-03(2) connectBlue ab residence: malmö VAT no. se 556589-0851-01 norra vallgatan 64 3V se-211 22 malmö sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.se page 1 of 1 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: CONFIDENTIALITY REQUEST FOR FCC ID PVH090802 Model name: OWSPA311g To Whom It May Concern: This letter serves as an official request for confidentiality under the FCC Rule Section 0.457 and 0.459 . . We have requested that the block diagram, schematic diagram and E&M datasheet required to be submitted with this application to be withheld from public review. The reason for this request is that these documents are company proprietary information that should never get into the possession of competitors, which would be harmful for our business. The E&M datasheet is a highly technical integration manual addressed to the module integrator and not to the end-user. Please contact me if there is any information you may need. Regards, Mats Andersson, CTO connectBlue

Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page1 of7 70290_g.jpgcB-OWSPA311gx-06(samplefor external antenna), top view Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page2 of7 70290_d.jpgcB-OWSPA311gi-06(samplewith internal antenna), top view Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page3 of7 70290_e.jpgCB-OWSPA311gi-06(s ample with internal antenna), housing removed top view Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page4 of7 70290_f.jpgcB-OWSPA311gx-06/ CB-OWSPA311gi-06 , bottomview Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page5 of7 70290_c.jpgcB-0903 -03, carrier board, top view Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page6 of7 70290_h.jpgcB-0903 -03, carrier boardforcB-OWSPA311gx-06with external antenna, top view Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page7 of7 70290_b.jpgcB-0903-03, carrier board,bottomview

2007-04-27 Reference:cBProject-0704-02 (2) connectBlue ab residence: malmö VAT no. se 556589-0851-01 Norra vallgatan 64 3V se-211 22 malmö sweden tel.+46 (0)40-6307100 fax.+46 (0)40-237137 e-mail: [email protected] http://www.connectBlue.se page 1 of 1 FCC/IC identifier labels for WLAN unit cB-OWSPA311g The FCC/IC identifier marking is situated on the secondary side of the module. The marking is printed in the solder mask. Figure 1 OWSPA311g regulatory information Depending of module version one of the labels below will be attached to the topside of the module. There are four module versions. Serial label S/N:0120-01-###### Batch: ## FW: #.# Date: YY.WW cB-OWSPA311gi-04 S/N:0122-01-###### Batch: ## FW: #.# Date: YY.WW cB-OWSPA311gx-04 Internal antenna External antenna S/N:0121-01-###### Batch: ## FW: #.# Date: YY.WW cB-OWSPA311gi-06 S/N:0123-01-###### Batch: ## FW: #.# Date: YY.WW cB-OWSPA311gx-06 2007-04-27 Page 2 of 2 The label will be located as shown in Figure 2 – Figure 5 below. OWSPA311gi-04, internal antenna, JST shrouded pin header connector NOT mounted Figure 2 OWSPA311gi-04 Serial label OWSPA311gi-06, internal antenna, JST shrouded pin header connector mounted Figure 3 OWSPA311gi-06 Serial label S/N:0120 - 01 - ###### Batch: ## FW: #.# Date: YY.WW cB-OWSPA311gi-04 S/N:0121 - 01 - ###### Batch: ## FW: #.# Date: YY.WW cB-OWSPA311gi-06 2007-04-27 Page 3 of 3 OWSPA311gx-04, external antenna, JST shrouded pin header connector NOT mounted Figure 4 OWSPA311gx-04 Serial label OWSPA311gx-06, external antenna, JST shrouded pin header connector mounted Figure 5 OWSPA311gx-06 Serial label S/N:0122 - 01 - ###### Batch: ## FW: #.# Date: YY.WW cB-OWSPA311gx-04 S/N:0123 - 01 - ###### Batch: ## FW: #.# Date: YY.WW cB-OWSPA311gx-06 2007-04-27 Page 4 of 4 An auxiliary label will be provided for systems using the module where the original label not will be visible when the module is installed. Instructions on how to attach the auxiliary label in compliance with the modular approval guidelines developed by the FCC will be provided. The instructions will call attention to place the auxiliary label on an exterior surface of the device such that it will be visible upon inspection. The auxiliary label will have at least the information as shown in the figure below This device contains FCC ID PVH090802 IC: 5325A-090802

Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page1 of7 70290_g.jpgcB-OWSPA311gx-06(samplefor external antenna), top view Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page2 of7 70290_d.jpgcB-OWSPA311gi-06(samplewith internal antenna), top view Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page3 of7 70290_e.jpgCB-OWSPA311gi-06(s ample with internal antenna), housing removed top view Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page4 of7 70290_f.jpgcB-OWSPA311gx-06/ CB-OWSPA311gi-06 , bottomview Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page5 of7 70290_c.jpgcB-0903 -03, carrier board, top view Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page6 of7 70290_h.jpgcB-0903 -03, carrier boardforcB-OWSPA311gx-06with external antenna, top view Annex B of test report R70290_A Edition 1 EUT:cB-OWSPA311gx-06/ cB-OWSPA311gi-06 Manufacturer: connectBlue AB Examiner: Thomas KÜHNDate of issue: 20 March 2007page7 of7 70290_b.jpgcB-0903-03, carrier board,bottomview

Specifications subject to change without notice. 3425 N.44 th Street, LINCOLN, NE 68504 USA SALES PHONE: 800.228.4563 PHONE: 402.467.4491 • FAX: 402.467.4528 www.centurion.com • [email protected] Copyright  2004 Centurion Wireless Technologies, Inc. All Rights Reserved Specifications: ƒ Versatile and easy to use antenna for 2.4 to 2.5 GHz Bluetooth and IEEE 802.11 devices ƒ Designed for easy connection to radio cards ƒ Utilizes Centurion’s patented PCB Microsphere technology ƒ Has a ground plane incorporated into the resonator structure, therefore no additional ground plane is required to radiate efficiently Frequency Range 2.4 – 2.5 GHz Gain 2 dBi Polarization Linear Impedance 50 ohms VSWR <2.5:1 Dimensions (L x W x H) 1.88" x .5"x .032" Weight 2 g Cable & Connector: Model # Part # Cable Connector NanoBlue-IP04 MAF94045 100mm, Ø 1.13mm IPEX MHF NanoBlue MAF94102 100mm, RG-178 Flying Lead NanoBlue a – 9/05/05 NanoBlue Model Number: NanoBlue Internal Antenna – Embedded Azimuth Plane 2.45 GHz Elevation Plane Phi = 90 2.45 GHz Elevation Plane Phi = 0 2.45 GHz 1.88"

Specifications subject to change without notice. 3425 N.44 th Street, LINCOLN, NE 68504 USA SALES PHONE: 800.228.4563 PHONE: 402.467.4491 • FAX: 402.467.4528 www.centurion.com • [email protected] Copyright  2004 Centurion Wireless Technologies, Inc. All Rights Reserved Specifications: ƒ ½ wave coaxial dipole ƒ Flexible element Frequency 2.4 - 2.5 GHz Polarization Vertical Gain 2.0 dBi Nominal Impedance 50 ohms VSWR 1.5:1 max at resonance RF Power Handling 50 watts Length 7.6 cm (90° Bent) or 10.8 cm (180° Straight) Temperature Range -40° to +80°C Drop Test 1M Cables & Connectors: Model # Part # Cable Connector WCR2400-FL04 MAF94015 100 mm RG-178 Flying Lead WCR2400-IP04 MAF94017 100 mm RG-178 IPEX U.FL WCR Snap-in a – 5/20/04 WCR Model Number: WCR2400-IP WCR2400-FL External Antenna – Snap-in/Captive Azimuth 2.45 GHz Antenna Bent @ 90° Antenna Straight @ 180° Elevation phi=0 2.45 GHz 7.6 cm

The Technology of Nature ® Fractus specialises in enabling effective mobile communications. Using fractal technology, we design and manufacture optimised antennas to make your wireless devices more competitive. Our mission is to help our clients develop innovative products and accelerate their time to market through our expertise in antenna design, testing and manufacturing. Small SMD chip antenna for small high performance wireless headset devices Fractus ® Slim Reach Xtend TM Bluetooth ® Chip Antenna P/N: FR05-S1-N-0-104 The Fractus Slim Reach Xtend BluetoothChip Antenna for wireless headsets is a tiny rectangular 3D- shaped antenna suitable for small headset devices operating at 2.4 GHz where high performance, low-cost and reduced form factor are mandatory. Its broad bandwidth ensures high quality signal reception and transmission across wireless devices, different plastic housing designs and multiple user wearing. Taking advantage of the space-filling properties of fractals, this small monopoleantenna is ideal for use within indoor (highly scattered) environments. The Fractus Slim Reach Xtend Chip Antennaspeeds your time to market by allowing you to easily integrate it within your industrial design (SMD mounting). Product Benefits ƒSmall form factor:Allows integration into space limited areas easily and efficiently with minimum clearance area. ƒBroad bandwidth:Ensures robust performance when considering different plastic housing and close body proximity. ƒHigh performance:Increases signal quality and device range due to a superior radiation efficiency. ƒOmnidirectional pattern:Optimises device usage due to a uniform radiation pattern. Bluetooth ® Frequency range Efficiency Peak Gain 2400-2500 MHz* > 0 dBi > 50 % Dimensions 7 x 3 x 1 mm Temperature-40 to + 85 ºC Impedance 50 ΩUnbalanced Weight 0.20 g VSWR< 2:1 Front view Bottom view Measured results from a standard PCB of 40x20 mm 7 x 3 x 1 mm 22.22.42.62.83 1 1.5 2 2.5 3 3.5 4 4.5 5 VS WR Fre que ncy (GHz) Free Space With Cas ing + He ad Effe c ts (*) Results measured in a reference evaluation board of 40x20 mm with conventional plastic housing and mounted on the user’s ear. Please, contact your sales representative at Richardson Electronics to get additional information on recommended configurations for different devices: RICHARDSON ELECTRONICSwww.rell.com [email protected] Information contained within this document is subject to change without prior notice Ref: DS_FR05-S1-N-0-104_v01 Patent Pending: WO0154225, WO0122528, PCT/EP01/10589, PCT/EP02/07837, US60/613394, US60/627653 and PCT/EP02/07836©FRACTUS S.A. 2005

TEST REPORT REFERENCE: R70290_A Edition 1 Examiner: Thomas KÜHNDate of issue:20March 2007Page6 of105 2 TECHNICAL DATA OF EQUIPMENT 2.1DEVICE UNDER TEST Type of equipment: *802.11b and g Wireless LAN module Type designation: *cB-OWSPA311gi-06(internal antenna)/ cB-OWSPA311gx-06(external antenna) FCC ID: *PVH090802 Antenna type/ gain: *External or internal, refer table below Antenna connector: *With internal antenna, no antenna connector is mounted. Using external antennas, two UFL connectors were used. Power supply: *3.3 V DC to 5.5 V DC Type of modulation: *DSSS/OFDM (CCK / DQPSK,depends on data-rate and the 802.11-mode) Operating frequency range:*2.412 to 2.462 GHz (11 channels with 5 MHz channel separation) Data rate:*1 Mbps to 54 Mbps Number of channels: *11 Temperature range: *-30 °C to +85 °C Highest / lowest internal frequency: * 2.462 GHz / 32 kHz *: declared by the applicant Used antennas: Manufacturer, model name*Antenna typeAntenna locationAntenna gain*Cable length Fractus FR05-01 -N-0-001PatchInternal+1.1dBi- Centurion NanoBlue-IP04, MAF94045 PatchExternal+2.0 dBi100 mm Centurion WCR-2400-IP04, MAF94017 MonopoleExternal+2.0 dBi100 mm Mobile Mark PSTG0-2400HSMonopoleExternal0.0 dBi- Joymax IHF-242MonopoleExternal+2.0 dBi1.5 m Joymax IH-151MonopoleExternal+5.0 dBi0 cm/ 50 cm/ 3 m Joymax IG-103MonopoleExternal+8.5 dBi30 cm / 3 m Huber + Suhner SPA 2400/75/8/0/V PatchExternal+7.5 dBi50 cm / 3 m Huber + Suhner SOA 2400/360/6/20/V MonopoleExternal+6.0 dBi30 cm / 3 m Huber + Suhner SOA 2400/360/4/20/V MonopoleExternal+4.0 dBi0 cm / 30 cm / 1.5 m / 3 m *: declared by the applicant The following external I/O cables were used: CableLengthShieldingConnector DC in(carrier board)2 m *No6.3 mm jack plug RS 232 (carrier board)2 m *Yes9 pole D-Sub connector *: Length during the test if no other specified.

Königswinkel 10 32825 Blomberg Germany Phone+49 5235 9500-0 Fax+49 5235 9500-10 TEST REPORT Test Report Reference: R70290_A Edition 1 Equipment under Test:cB-OWSPA311gi-06 / cB-OWSPA311gx-06 FCC ID: PVH090802 Serial Number:none Applicant: connectBlue AB Manufacturer: connectBlue AB Test Laboratory (CAB) accredited by DATech GmbH in compliance with DIN EN ISO/IEC 17025 under the Reg. No. DAT-P-105/99-21 and FCC Test site registration number 90877 TEST REPORT REFERENCE: R70290_A Edition 1 Examiner: Thomas KÜHNDate of issue:20March 2007Page2 of105 Contents:Page 1 IDENTIFICATION.....................................................................................................................................4 1.1 APPLICANT.....................................................................................................................................4 1.2 MANUFACTURER..........................................................................................................................4 1.3 DATES.............................................................................................................................................4 1.4 TEST LABORATORY......................................................................................................................5 1.5 RESERVATION...............................................................................................................................5 1.6 NORMATIVE REFERENCES..........................................................................................................5 1.7 TEST RESULTS..............................................................................................................................5 2 TECHNICAL DATA OF EQUIPMENT......................................................................................................6 2.1 DEVICE UNDER TEST...................................................................................................................6 2.2 PERIPHERY DEVICES...................................................................................................................7 3 OPERATIONAL STATES AND PHYSICAL BOUNDARIES.....................................................................7 4 APPLICATION OVERVIEW.....................................................................................................................8 5 TEST RESULTS.......................................................................................................................................9 5.1 CONDUCTED EMISSIONS ON POWER SUPPLY LINES (150 kHz to 30 MHz)...........................9 5.1.1 METHOD OF MEASUREMENT..........................................................................................9 5.1.2TEST RESULTS (CONDUCTED EMISSIONS ON POWERSUPPLY LINES) ..................10 5.2 6 dB BANDWIDTH..........................................................................................................................12 5.2.1METHOD OF MEASUREMENT (6 dBBANDWIDTH)........................................................12 5.2.2TEST RESULTS (6 dBBANDWIDTH)................................................................................13 5.3 MAXIMUM PEAK OUTPUT POWER..............................................................................................17 5.3.1 METHOD OF MEASUREMENT (MAXIMUM PEAK OUTPUT POWER)............................17 5.3.2 TEST RESULTS (MAXIMUM PEAK OUTPUT POWER)...................................................18 5.4 POWER SPECTRAL DENSITY......................................................................................................19 5.4.1 METHOD OF MEASUREMENT (POWER SPECTRAL DENSITY).................................... 19 5.4.2 TEST RESULTS (POWER SPECTRAL DENSITY)............................................................20 5.5 BAND-EDGE COMPLIANCE...........................................................................................................24 5.5.1 METHOD OF MEASUREMENT (BAND-EDGE COMPLIANCE)........................................24 5.5.2 TEST RESULT (BAND-EDGECOMPLIANCE (RADIATED)) b-mode...............................25 5.5.3 TEST RESULT (BAND-EDGE COMPLIANCE (RADIATED)) g-mode...............................27 CONTINUED NEXT PAGE TEST REPORT REFERENCE: R70290_A Edition 1 Examiner: Thomas KÜHNDate of issue:20March 2007Page3 of105 Contents:Page 5.6 RADIATED EMISSIONS..................................................................................................................29 5.6.1 METHOD OF MEASUREMENT (RADIATED EMISSIONS)...............................................29 5.6.2TEST RESULTS (TRANSMITTERRADIATED EMISSIONS)............................................35 5.6.2.1 PRELIMINARY MEASUREMENT INTERNAL ANTENNA (30 kHz to 1 GHz)............35 5.6.2.2FINALMEASUREMENTINTERNAL ANTENNA (9 kHz to 30 MHz)..........................38 5.6.2.3 FINALMEASUREMENTINTERNAL ANTENNA (30 MHz to 1 GHz).........................39 5.6.2.4 PRELIMINARY MEASUREMENT INTERNAL ANTENNA (1 GHz to 25 GHz) b-mode.....................................................................................................41 5.6.2.5 FINAL MEASUREMENT INTERNAL ANTENNA (1 GHz to 25 GHz) b mode............48 5.6.2.6 PRELIMINARY MEASUREMENTINTERNAL ANTENNA (1 GHz to 25 GHz) g-mode.....................................................................................................51 5.6.2.7 FINAL MEASUREMENT INTERNAL ANTENNA (1 GHz to 25 GHz) g- mode...........58 5.6.2.8 PRELIMINARY MEASUREMENT EXTERNAL PATCH ANTENNA (1 GHz to 25 GHz) b-mode.....................................................................................................61 5.6.2.9 FINAL MEASUREMENT EXTERNAL PATCH ANTENNA (1 GHz to 25 GHz) b-mode.....................................................................................................68 5.6.2.10 PRELIMINARY MEASUREMENT EXTERNAL PATCH ANTENNA (1 GHz to 25 GHz) g-mode.....................................................................................…
