QCVR0610400Controllable Outlet

Part No R0610401 Description: Installing a Budderfly adapter transforms your building’s existing wiring into the “Budderfly Open Network” and allows the adapter to monitor energy consumption and communicate the data to a facility controller. Budderfly adaptors use the existing power line for communication and thus require no re‐wiring. Using our Budderfly software, you can visualize consumption data and manage each individual adapter. As a component of Budderfly system, the Budderfly Controllable Outlet is designed to work with all other Budderfl y adapters. It is a plug‐and‐play replacement for your existing duplex outlet, and it provides control on one of its two sockets. Once installed, The Budderfly Controllable Outlet also acts as a repeater to extend the range of the network and increase efficiency. Installation: The Budderfly Controllable Outlet may be used in new installations or to replace an existing Outlet. The wiring schematic will be as per below: 1. At the circuit breaker or fuse panel, disconnect the power for all of the circuits in the switch junction box. 2. Double Check that the power is OFF to the Outlet by trying to turn on a device connected to the plug before continuing. 3. Remove the wall plate from the outletyou are replacing. Then, unscrew the outlet itself and pull it out from the junction box. 4. Disconnect the wires from the outlet you are replacing. 5. Follow the Wiring information provided below and connect the wires a s follows: ‐ Connect the GROUND wire (usually Bare Copper or Green) to the Ground wire of Budderfly Controllable Outlet (Yellow & Green). ‐ Connect the LINE wire (usually Black) that comes from the electrical service panel to the HOT wire of Budderfly Controllable Outlet (Black). ‐ Connect the NEUTRAL wire (usually White) to th e Neutral wire of Budderfly Controllable Outlet (White). 6. After you have connected all of the wires, ensure that all of the wire connectors are firmly attached and that there is no exposed copper excep t for the GROUND wire. 7. Gently place Budderfly Controllable Outlet into the junction box. Then, screw the Outlet into place. 8. Reinstall the wall plate 9. Enable power to the Outlet from the circuit breaker or fuse panel 10. Add the device address to the Budderfly software. WARNING: If you are not sure ab out any part of the above instructions, consult a qualified electrician. WARNING –ELECTRICAL SHOCK HAZARD • The Budderfly Controllable Outlet is intended for installation in accordance with the National Electric Code and local regulations in the United States. • If you are not knowledgeable or comfortable with electrical circuitry, you should have a qualified electrician install the Budderfly Controllable Outlet for you. Warning • Install the Budderfly Controllable Outlets indoor only. • Never use the Budderfly Outlets to power medical and/or life support equipment. WARNING –ELECTRICAL SHOCK HAZARD • Turn OFF the power to the branch circuit for the Outlet at the service panel. • All wiring connections must be made with the POWER OFF to avoid personal injury and/or damage to the Outlet. Wiring Information • Important: Budderfly Controllable Outlet is rated for and intended to only be used with copper wire. • Use 12 AWG or larger wires suitable for 80 o. • Remove 3/4" (1.9 cm) of insulation from each wire. Connect as follows: Twist strands of each end tightly together. Hold bare ends of wires together and push firmly into wire Nut. Screw Nut clockwise making sure that no bare conductor shows below the connector Features: ‐ Remote On/Off control ‐ Manual On/Off control ‐ Ability to create a group of devices ‐ Ability to monitor power consumption ‐ LED indicator to show the state of the Outlet Device Grouping: ‐ Using the Budderfly software, it is possible to create a Group of Outlets. Power consumption: The Budderfly Controllable Outlets will measure the current, the voltage and the power consumed by the connected load, and will store energy consumption. The data can be accessed at any time thru the Budderfly software. The user can generate reports, monitor the consumption or check expenses. LED Indicators: The Budderfly Controllable Outlets are equipped with 1 bi‐color LED (Status), and 1 mono‐color LED that will indicate the state of the device (Control). Status LED Control LED LED is Off : The Outlet is not powered up. LED is OFF: The Upper Outlet is turned OFF. LED is Red: The Outlet is On and not member of a group. LED is Red: The Upper Outlet is turned ON. LED is Green : The Outlet is On and is member of a group. Reset: If the device stops responding, it can be restarted by pushing the Reset Button. A non‐metallic pin should be used to push the reset button. None of the stored parameters are affected. Specifications: Power: 120VAC/ 60Hz Maximum Loads: Operating Temperature: 0°C to +40°C Non‐Controllable Outlet: 20A (max), 1.0 HP. Certification: UL and FCC Certifications are in progress. For indoor use only. Controllable Outlet: 15A (resistive), ½ HP. Specifications subject to change without notice due to continuing product improvement. Communication: The Budderfly Controllable Outlets use the power line and radio frequency to communicate with the “Facility Controller”. The outlets can reply to the following commands: • Direct Turn On/Off command: The Top Outlet will turn the connected load On/Off. • Join/Disjoin group “X”: The outlet will Join/Disjoin the group “X”. Each outlet can be a me mber of several groups at the same time. • Direct RTC synchronization: The outlet can receive a command to synchronize its “Real Time Clock” • Get Actual Measurement: When the outlet receives a “Ge t Measurement” command, it will send back to the facility controller a string of data that contains: ‐ The Current in Amps “A”. ‐ The Power in Watts “W”. ‐ A Timestamp. • Get Stored Measurement: The outlet will send back to the Facility Controller the stored electrical measurements. • Direct Reset Commands: The outlet can receive 3 t…

Text truncated - open the document above for the full version.

Budderfly LLC 2 Trap Falls Rd., Suite 507 Shelton, CT 06484 203-513-8634 www.Budderfly.com April 08, 2013 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for Budderfly LLC (FRN# 0022045272) 2 Trap Falls Road, Suite 507 Shelton, CT 06484 for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Budderfly product: Controllable Outlet under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part l5 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither Budderfly nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti-Drug-Abuse act of 1988,21 U.S.C. 853(a). In addition, Budderfly will notify the Federal Communications Commission if, at any time, the situation changes causing Budderfly to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 714-921-1210. Sincerely, Daniel Riscalla Vice-President Engineering, Budderfly (714)921-1210

Budderfly LLC 2 Trap Falls Rd., Suite 507 Shelton, CT 06484 203-513-8634 www.Budderfly.com April 08, 2013 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Budderfly, would like to declare that the application being submitted for the Controllable Outlet with FCC ID: QCVR0610400 has not been submitted to another TCB or FCC for certification. If you have any further questions or need additional information, please feel free to give me a call at 714-921-1210. Sincerely, Daniel Riscalla Vice-President of Engineering (714)921-1210

February 06, 2013 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematics, block diagrams, and operational description pursuant to an application for certification Gentlemen: We, Budderfly LLC, would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457 (d) of the Commission’s Rules, and Section 552 (b)(4) of the Freedom of Information Act. These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any questions, please do not hesitate to contact us at (714)921-1210 or at (203)513-8634. Sincerely, Sincerely, Daniel Riscalla Vice-President of Engineering Budderfly LLC 2 Trap Falls Rd., Suite 507 Shelton, CT 06484 203-513-8634 www.Budderfly.com

12345678 12345678 A B C D E F A B C D E F ANY DISCREPANCIES BETWEEN THE DRAWING AND THE ASSOCIATED MODEL WHEN SUPPLIED TO BE DISCUSSED WITH BNUDDERFLY DENOTES UL QUALITY CHECK U L - 35 1 21 1 15 5 A3 BUDDERFLY 1 OF 1 SHEET NO: THE INFORMATION DISCLOSED IN THIS DOCUMENT IS PROPRIETARY TO BUDDERFLY AND MAY NOT BE USED FOR MANUFACTURE OR ANY OTHER PURPOSE WITHOUT THE WRITTEN CONSENT OF BUDDERFLY. NA HPGL FILE NAME: NA ALL RIGHTS RESERVED CAD FILE NAME: SWITCH + PLUG LABEL NA DWG NO: NADWG REPL:TITLE: NASURFACE AREA:MASS:NA FREE TOLERANCE NASURFACE FINISH:NA TY868-125MATL DESCP:APVD BY: NATOOL SERNO:MATL NO:CHK BY: DIMENSIONS ARE IN mm INCLUDING FINISH A.Olleik07-Feb-13DWN BY: SCALE:NAMEDATE A.Olleik07-Feb-13NADRAWING RELEASED00ANA DOC NAMEDATESPRTAMENDMENTSIDXZONE LABEL SPECIFICATIONS - MANUFACTURER: FOSHAN SHUNDE TIAN YUE PACKING PRINTING CO LTD - MATERIAL NUMBER: TY868-125 - MAX TEMPERATURE ON POLY CARBONATE (PC): 80C - INDOOR USE ONLY - UL NUMBER: MH25987 - UL CATEGORY: PGDQ2 BUDDERFLY LABEL FCC ID: QCVR0610400 FOR INDOOR USE ONLYVERSION 1.32 Part No R0610400 Controllable Outlet Rated: www.budderfly.com Made in China 03 Dec 2012 - 120VAC, 60 Hertz - Non-Controllable: 20A, 2400W - Controllable: 1600W Tungsten, 1/2HP Patent No.: US 8,140,279 US 8,396,608 Dual Band

Budderfly LLC 2 Trap Falls Rd., Suite 507 Shelton, CT 06484 203-513-8634 www.Budderfly.com September 05, 2013 CETCB 114 Olinda Drive Brea, CA 92823 Subject: SAR TEST EXCLUSION Gentlemen: The Budderfly Controllable Outlet, FCC ID: QCVR0610400, is excluded from SAR testing by the following justification. The maximum power that the transmitter IC is capable of is 5.01 mW. By using the following formula from section 4.3.1 of KDB 447498: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]*[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR Using the maximum conducted power capable (7.0 dBm) and the minimum test separation (5 mm), the resulting calculated SAR value is: (5.01 mW)/5 mm) * (√0.915 GHz) = 0.958 This value is below the exclusion threshold for both the 1-g SAR and 10-g extremity SAR requirements. If you have any further questions or need additional information, please feel free to give me a call at 714-921-1210. Sincerely, Daniel Riscalla Vice-President of Engineering (714)921-1210

Report Number: D30423P1 FCC ID: QCVR0610400 FCC Part 15 Subpart C Section 15.249 Test Report 20621 PASCAL WAY, LAKE FOREST, CALIFORNIA, 92630  PH: (949) 587-0400 FX: (949) 587-0476 Page 1 of 18 FCC PART 15, SUBPART B & SUBPART C SECTION 15.249 TEST REPORT For CONTROLLABLE OUTLET Model: R0610400 Prepared for BUDDERFLY LLC 2 TRAP FALLS RD., SUITE 507 SHELTON, CT 06484 Prepared by: _____________________ MATT HARRISON Approved by: ____________________ JOSH HANSEN COMPATIBLE ELECTRONICS INC. 20621 PASCAL WAY LAKE FOREST, CALIFORNIA 92630 (949) 587-0400 DATE: MAY 13, 2013 REPORT APPENDICES TOTAL BODY A B C D E PAGES 18 2 2 2 13 23 60 This report shall not be reproduced, except in full, without the written approval of Compatible Electronics. Report Number: D30423P1 FCC ID: QCVR0610400 FCC Part 15 Subpart C Section 15.249 Test Report 20621 PASCAL WAY, LAKE FOREST, CALIFORNIA, 92630  PH: (949) 587-0400 FX: (949) 587-0476 Page 2 of 18 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration - EMI 8 4.1.1 Photograph of Test Configuration - EMI 8 4.1.2 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 5.3 Test Software 12 6. TEST SITE DESCRIPTION 13 6.1 Test Facility Description 13 6.2 EUT Mounting, Bonding and Grounding 13 6.3 Facility Environmental Characteristics 13 7. CHARACTERISTICS OF THE TRANSMITTER 14 7.1 Channel Number and Frequencies 14 7.2 Antenna 14 8. TEST PROCEDURES 15 8.1 RF Emissions 15 8.1.1 Conducted Emissions Test 15 8.1.2 Radiated Emissions (Spurious and Harmonics) Test 16 8.1.3 Fundamental Field Strength 17 8.1.4 Emissions Radiated Outside of the Fundamental Frequency Band 17 8.1.5 Voltage Fluctuations 17 8.1.6 Duty Cycle 17 9. TEST PROCEDURE DEVIATIONS 18 10. CONCLUSIONS 18 Report Number: D30423P1 FCC ID: QCVR0610400 FCC Part 15 Subpart C Section 15.249 Test Report 20621 PASCAL WAY, LAKE FOREST, CALIFORNIA, 92630  PH: (949) 587-0400 FX: (949) 587-0476 Page 3 of 18 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts and Photos  Test Setup Diagrams  Antenna and Amplifier Gain Factors  Radiated and Conducted Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Test Site 3 Plot Map And Layout of Test Site above 1 GHz Report Number: D30423P1 FCC ID: QCVR0610400 FCC Part 15 Subpart C Section 15.249 Test Report 20621 PASCAL WAY, LAKE FOREST, CALIFORNIA, 92630  PH: (949) 587-0400 FX: (949) 587-0476 Page 4 of 18 GENERAL REPORT SUMMARY This electromagnetic emission report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced in any form except in full, without the written permission of Compatible Electronics. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: CONTROLLABLE OUTLET Model: R0610400 S/N: None Product Description: The EUT is a replacement outlet that is capable of sensing the current/voltage on the Power Line. This device also supports both power-line and RF communication using the INSTEON Protocol Modifications: The EUT was not modified during the testing. Manufacturer: Budderfly LLC 2 Trap Falls Rd., Suite 507 Shelton, CT 06484 Test Dates: April 22-23, September 25, 2013 Test Specifications: EMI requirements CFR Title 47, Part 15 Subpart B section 15.107 and 15.109 CFR Title 47, Part 15 Subpart C Sections 15.205, 15.207, 15.209 and 15.249 Test Procedure: ANSI C63.4 and ANSI 63.10 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz. Complies with the limits of CFR Title 47 Part 15 subpart B section 15.107. 2 Radiated RF Emissions & Harmonics, 9 kHz – 10GHz. Complies with the limits of CFR Title 47 Part 15 subpart B section 15.109 and subpart C Section 15.205, 15.209 and 3 Fundamental Field Strength Complies with CFR Title 47 Part 15 Subpart C Section 15.249(a) 4 Emissions Radiated Outside of the Fundamental Frequency Band Complies with CFR Title 47 Part 15 Subpart C Section 15.249(d) and 15.205 5 Voltage Variation Complies with CFR Title 47 Part 15 Subpart C Section 15.31(e) Report Number: D30423P1 FCC ID: QCVR0610400 FCC Part 15 Subpart C Section 15.249 Test Report 20621 PASCAL WAY, LAKE FOREST, CALIFORNIA, 92630  PH: (949) 587-0400 FX: (949) 587-0476 Page 5 of 18 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Controllable Outlet Model: R0610400. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4 and C63.10. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the specification limits defined by the Code of Federal Regulations Title 47, Part 15 Subpart B section 15.107, 15.109, Subpart C sections 15.207, 15.205, 15.209 and 15.249. The power line carrier emissions tests were not performed by Compatible Electronics. Report Number: D30423P1 FCC ID: QCVR0610400 FCC Part 15 Subpart C Section 15.249 Test Report 20621 PASCAL WAY, LA…
