HG658d Home Gateway User Guide HU AWEI TECHNOLOGIES CO., LTD. HG658d Home Gateway V100R001 User Guide Issue 01 Date 2013- 07-23 Part Number 202633 Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. Please feel free to contact our local office or company headquarters. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China Website: http://www.huawei.com Email: [email protected] Copyright © Huawei Technologies Co., Ltd. 2013. All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. and its affiliates ("Huawei"). The product described in this manual may include copyrighted software of Huawei and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders. Trademarks and Permissions , , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Other trademarks, product, service and company names mentioned may be the property of their respective owners. Notice Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and therefore may not be activated or may be limited by local network operators or network service providers. Thus, the descriptions herein may not exactly match the product or its accessories which you purchase. Huawei reserves the right to change or modify any information or specifications contained in this manual without prior notice and without any liability. DISCLAIMER ALL CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HUAWEI BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOSS OF PROFITS, BUSINESS, REVENUE, DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS REGARDLESS OF WHETHER SUCH LOSSES ARE FORSEEABLE OR NOT. THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO LIABILITY FOR PERSONAL INJURY TO THE EXTENT APPLICABLE LAW PROHIBITS SUCH A LIMITATION) OF HUAWEI ARISING FROM THE USE OF THE PRODUCT DESCRIBED IN THIS MANUAL SHALL BE LIMITED TO THE AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE OF THIS PRODUCT. Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and be responsible to obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein. Privacy Policy To better understand how we protect your personal information, please see the privacy policy at http://consumer.huawei.com/en/privacy-policy/index.htm. i Contents Contents ........................................................................................ i 1 Connecting Cables and Getting Started .................................. 1 1.1 Connecting Cables Using the WAN Port ................................... 1 1.2 Connecting Cables Using the DSL Port ..................................... 2 2 Setting Network Access Parameters ....................................... 4 2.1 Logging in to the Web-based Configuration Utility ..................... 4 2.2 Configuring Internet Access Parameters ................................... 4 3 Setting Up a Wireless Connection ........................................... 5 3.1 Setting up a Wireless Connection Using the WPS Button ......... 5 3.2 Setting up a Wireless Connection Manually .............................. 6 4 Voice Services ........................................................................... 7 5 Configuring the HG658d ........................................................... 7 5.1 Accessing Mobile Storage Devices Using the FTP Client .......... 7 5.2 Changing the User Name and Password for the Web-based Configuration Utility .......................................................................... 8 5.3 Changing the Login IP Address ................................................. 9 5.4 Enabling or Disabling the Wireless Network Function ............. 10 5.5 Changing the Wireless Network Name and Password ............ 10 5.6 Configuring the Firewall ........................................................... 11 5.7 Restoring Default Settings ....................................................... 12 5.8 Restarting the HG658d ............................................................ 12 6 FAQs ......................................................................................... 13 7 Technical Specifications ......................................................... 19 7.1 Indicators .................................................................................. 19 7.2 Ports and Buttons ..................................................................... 22 ii 7.3 Default Settings ........................................................................ 24 7.4 Product Specifications .............................................................. 24 1 1 Connecting Cables and Getting Started Thank you for purchasing the HG658d (HG658d for short). You can go online using the Ethernet and DSL modem services. However, you can only use one type of service at one time. 1.1 Connecting Cables Using the WAN Port Connecting Cables If there is at least one Ethernet wall jack available in your home, you can access the Internet using the Ethernet. 1 2 3 5 4 DSL US…

Text truncated - open the document above for the full version.

1 HG658d Home Gateway Quick Start 1 Connecting Cables Using the WAN Port If there is at least one Ethernet wall jack available in your home, you can access the Internet using the Ethernet. 1 2 3 5 4 DSL USB Reset Power LAN4 LAN3 LAN 2 LAN1 WAN PHONE2 PHONE1 1 Power adapter 2 Ethernet wall jack 3 Desktop computer 4 Laptop computer 5 HG658d Using the DSL Port If there is at least one telephone jack available in your home, you can access the Internet using digital subscriber line (DSL) services. 2 1 Telephone wall jack 2 HG658d 3 Power adapter 4 Laptop computer 5 Telephone 6 Desktop computer 7 Splitter a LINE port b MODEM port c PHONE port 2 Powering On the HG658d Press the On/Off button on the side panel to power on the HG658d. After you power on the HG658d, the Power indicator light remains steady on indicating that the HG658d is working properly.  When you connect the cables to access the Internet using the WAN port. The INTERNET indicator lights up, indicating that the HG658d is working properly. When the INTERNET indicator starts blinking, data is being transmitted between the HG658d and the connected device.  When you connect the cables to access the internet using the DSL port, the WAN indicator lights up and starts blinking, indicating that the DSL port is being activated. The blinking may last from 40 seconds to 3 minutes. When the WAN indicator stops blinking and turns steady on, it indicates that the cables are connected correctly and the HG658d has been activated using DSL. 3 3 Accessing the Internet To set up network access for the HG658d and your computer: Step 1 Open a web browser on your computer. Enter http://192.168.1.1 in the address box, and then press Enter . Step 2 On the login page, enter the user name and password. By default, the user name is admin and password is admin . Click Login . For security reasons or to make the password easy to remember, you can change the user name and password. For details, refer to the HG658d user guide. Step 3 Click Setup Wizard . Step 4 Click Next . Step 5 In User name and Password , enter the user name and password that are provided by your service provider, and then click Next . Step 6 Click Next . Step 7 Set SSID and WPA pre-shared key , and then click Next . Check the label on the HG658d's rear panel for SSID and WPA pre-shared key. Step 8 Click Submit . Then check the status of the Internet indicator. When the Internet indicator turns green, you can access the Internet. You need to perform the preceding operations on a computer only once. The next time you power on your computer, you can start surfing the Internet without any further configurations. 4 Setting Up a Wireless Connection The following example uses a computer running the Windows 7 operating system to describe how to set up a wireless connection: Step 1 Find wireless network name ( SSID ) and password ( WLAN Key ) printed on the label of the HG658d's rear panel. For security reasons or to make the password easy to remember, you can change the wireless network name and password. For details, refer to the HG658d user guide. Step 2 Configure the wireless network connection on the computer as follows: 4 1. Choose Start > Control Panel > Network and Sharing Center > Change adapter settings. 2. In the Network Connections window, right-click the Wireless Network Connection to display a shortcut menu, and then choose Connect/Disconnect. 3. In the Wireless Network Connection dialog box, select the wireless network whose name is the same as the one you recorded in Step 1 , and then click Connect. 4. In the Connect to Network dialog box, enter WLAN Key that you recorded in Step 1 , and then click OK. After the system verifies the password, Connected appears on the wireless network icon in the wireless network list, indicating that your computer has established a wireless connection to the HG658d. For more information, visit http://www.huaweidevice.com to download the HG658d user guide. Enter HG658d in the search box to find the user guide. 5 Safety information This section contains important information about the operation of your device. It also contains information about how to use the device safely. Read this information carefully before using your device. Electronic device Do not use your device if using the device is prohibited. Do not use the device if doing so causes danger or interference with other electronic devices. Interference with medical equipment  Follow rules and regulations set forth by hospitals and health care facilities. Do not use your device where prohibited.  Some wireless devices may affect the performance of hearing aids or pacemakers. Consult your service provider for more information.  Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained between a device and a pacemaker to prevent potential interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your front pocket. Areas with flammables and explosives  Do not use the device where flammables or explosives are stored (in a gas station, oil depot, or chemical plant, for example). Using your device in these environments increases the risk of explosion or fire. In addition, follow the instructions indicated in text or symbols.  Do not store or transport the device in containers with flammable liquids, gases, or explosives. 96722339_01 5 Operating environment  Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the device in these environments may result in circuit malfunctions.  Before connecting and disconnecting cables, stop using the device and disconnect it from the power supply. Ensure that your hands are dry during operation.  Place the device on a stable surface.  Keep the device away from electronic appliances that generate strong magnetic or electric fields, such as a microwave oven or refrigerator.  During thunderstorms, power off your device and remove all cab…

Text truncated - open the document above for the full version.
