QISR2561Indoor Router

IDU R2561 V100R001C00SPC012 User Guide Issue 01 Date 2020-07-06 HUAWEI TECHNOLOGIES CO., LTD. Issue 01 (2019-02-28) Copyright © Huawei Technologies Co., Ltd. i Copyright © Huawei Technologies Co., Ltd. 2019. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks and Permissions and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd. All other trademarks and trade names mentioned in this document are the property of their respective holders. Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS" without warranties, guarantees or representations of any kind, either express or implied. The information in this document is subject to change without notice. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute a warranty of any kind, express or implied. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China Website: http://www.huawei.com Email: [email protected] IDU R2561 User Guide Contents Issue 01 (2019-02-28) Copyright © Huawei Technologies Co., Ltd. ii Contents 1 About this Guide ........................................................................................................................... 1 1.1 Prerequisite Skills and Knowledge ............................................................................................................................... 1 1.2 Conventions Used in this Document ............................................................................................................................. 1 2 Introduction.................................................................................................................................... 2 2.1 Product Overview ......................................................................................................................................................... 2 2.2 Product Package............................................................................................................................................................ 2 2.3 Connectors .................................................................................................................................................................... 2 2.4 LED Indicators.............................................................................................................................................................. 4 2.5 Installation .................................................................................................................................................................... 4 2.5.1 Installing IDU R2561................................................................................................................................................. 4 2.5.2 Connecting the Cable ................................................................................................................................................. 5 3 Web Interface ................................................................................................................................. 6 3.1 Login to Web-GUI ........................................................................................................................................................ 6 3.2 Function Button ............................................................................................................................................................ 8 3.3 Status and device information ....................................................................................................................................... 8 3.3.1 Status > Device Status ............................................................................................................................................... 8 3.3.2 Status > Telephony Status ........................................................................................................................................ 10 3.3.3 Status > Network Status ........................................................................................................................................... 11 3.3.4 Status > About .......................................................................................................................................................... 12 3.4 Menu Structure ........................................................................................................................................................... 13 4 Reference Manual ....................................................................................................................... 15 4.1 Management ............................................................................................................................................................... 15 4.1.1 Management > Setup Wizard ................................................................................................................................... 15 4.1.2 Management > WAN Setup ..................................................................................................................................... 17 4.1.3 Management > LAN Setup ...................................................................................................................................... 18 4.1.4 Management > Telephony...................................................................…

Text truncated - open the document above for the full version.

Project No.: 962401-01 Page No. : 1 of 11 Photographs of EUT Project No.: 962401-01 Page No. : 2 of 11 Project No.: 962401-01 Page No. : 3 of 11 Project No.: 962401-01 Page No. : 4 of 11 Project No.: 962401-01 Page No. : 5 of 11 Project No.: 962401-01 Page No. : 6 of 11

Project No.: 962401-01 Page No. : 7 of 11 Project No.: 962401-01 Page No. : 8 of 11 Project No.: 962401-01 Page No. : 9 of 11 Project No.: 962401-01 Page No. : 10 of 11 Project No.: 962401-01 Page No. : 11 of 11

Report No.: FA962401-01 Page : 1 of 6 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : QISR2561 Equipment : Indoor Router Model No. : R2561 Brand Name : Huawei Applicant : Huawei Technologies Co., Ltd. Address : Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, China. Standard : 47 CFR FCC Part 2.1091 Received Date : Jun. 24, 2019 Tested Date : Jul. 06 ~ Jul. 15, 2019 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any agency of government. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FA962401-01 Page : 2 of 6 Report Version: Rev. 01 Table of Contents 1 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 4 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 4 1.2 MPE EVALUATION FORMULA ............................................................................................................. 4 1.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE ................................... 4 1.4 MEASUREMENT UNCERTAINTY ......................................................................................................... 4 1.5 MPE EVALUATION RESULTS .............................................................................................................. 5 1.6 MPE EVALUATION OF SIMULTANEOUS TRANSMISSION ................................................................ 5 2 TEST LABORATORY INFORMATION ................................................................................................. 6 Report No.: FA962401-01 Page : 3 of 6 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA962401-01 Rev. 01 Initial issue Jul. 07, 2020 Report No.: FA962401-01 Page : 4 of 6 Report Version: Rev. 01 1 MPE EVALUATION OF MOBILE DEVICES 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 1.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance 1.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE None 1.4 MEASUREMENT UNCERTAINTY The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2) Parameters Uncertainty Conducted power ±0.808 dB Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FA962401-01 Page : 5 of 6 Report Version: Rev. 01 1.5 MPE EVALUATION RESULTS Frequency Range (MHz) Maximum Conducted Power (dBm) Rated Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (W/m 2 ) Limit (W/m 2 ) Ratio* Pass / Fail WLAN 2412-2462 21.59 22 2.77 20 0.060 1 0.060 Pass 5180-5240 18.16 18.5 4.28 20 0.038 1 0.038 Pass 5745-5825 22.13 22.5 5.33 20 0.121 1 0.121 Pass *Ratio = Power density / Limit. 1.6 MPE EVALUATION OF SIMULTANEOUS TRANSMISSION Mode Max Ratio of Each Mode WLAN 2.4 GHz 0.060 WLAN 5GHz 0.121 Sum 0.181 Limit 1 Pass / Fail Pass Report No.: FA962401-01 Page : 6 of 6 Report Version: Rev. 01 2 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corp (EMC and Wireless Communication Laboratory), it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff. Our Test sites are located at Linkou District and Kwei Shan District. Location map can be found on our website http://www.icertifi.com.tw. Linkou Kwei Shan Kwei Shan Site II Tel: 886-2-2601-1640 Tel: 886-3-271-8666 Tel: 886-3-271-8640 No. 30-2, Ding Fwu Tsuen, Lin Kou District, New Taipei City, Taiwan, R.O.C. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan District, Tao Yuan City 333, Taiwan, R.O.C. No. 14-1, Lane 19, Wen San 3rd St., Kwei Shan District, Tao Yuan City 333, Taiwan, R.O.C. If you have any suggestion, please feel free to contact us as below information. Tel: 886-3-271-8666 Fax: 886-3-318-0155 Email: [email protected] ══END══

Report No.: FR962401-01AC Page : 1 of 63 Report Version: Rev. 01 FCC Test Report FCC ID : QISR2561 Equipment : Indoor Router Model No. : R2561 Brand Name : Huawei Applicant : Huawei Technologies Co., Ltd. Address : Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, China. Standard : 47 CFR FCC Part 15.247 Received Date : Jun. 24, 2019 Tested Date : Jul. 06 ~ Jul. 15, 2019 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any agency of government. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FR962401-01AC Page : 2 of 63 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 8 1.3 Test Setup Chart .................................................................................................................................... 8 1.4 The Equipment List ................................................................................................................................ 9 1.5 Test Standards ..................................................................................................................................... 10 1.6 Reference Guidance ............................................................................................................................ 10 1.7 Deviation from Test Standard and Measurement Procedure ............................................................... 10 1.8 Measurement Uncertainty .................................................................................................................... 10 2 TEST CONFIGURATION ..................................................................................................................... 11 2.1 Testing Condition ................................................................................................................................. 11 2.2 Testing Facility...................................................................................................................................... 11 2.3 The Worst Test Modes and Channel Details ....................................................................................... 11 3 TRANSMITTER TEST RESULTS ........................................................................................................ 12 3.1 Conducted Emissions ........................................................................................................................... 12 3.2 6dB and Occupied Bandwidth .............................................................................................................. 15 3.3 RF Output Power .................................................................................................................................. 21 3.4 Power Spectral Density ........................................................................................................................ 24 3.5 Unwanted Emissions into Restricted Frequency Bands ...................................................................... 30 3.6 Emissions in Non-Restricted Frequency Bands ................................................................................... 58 4 TEST LABORATORY INFORMATION ............................................................................................... 63 Report No.: FR962401-01AC Page : 3 of 63 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR962401-01AC Rev. 01 Initial issue Jul. 07, 2020 Report No.: FR962401-01AC Page : 4 of 63 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 Conducted Emissions [dBuV]: 0.491MHz 26.64 (Margin -19.50dB) - AV Pass 15.247(d) 15.209 Radiated Emissions [dBuV/m at 3m]: 2483.50MHz 53.00 (Margin -1.00dB) - AV Pass 15.247(b)(3) Maximum Output Power Max Power [dBm]: 26.21 Pass 15.247(a)(2) 6dB Bandwidth Meet the requirement of limit Pass 15.247(e) Power Spectral Density Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FR962401-01AC Page : 5 of 63 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Freq. (MHz) Channel Number Transmit Chains (N TX ) Data Rate / MCS 2400-2483.5 b 2412-2462 1-11 [11] 2 1-11 Mbps 2400-2483.5 g 2412-2462 1-11 [11] 2 6-54 Mbps 2400-2483.5 n (HT20) 2412-2462 1-11 [11] 2 MCS 0-15 2400-2483.5 n (HT40) 2422-2452 3-9 [7] 2 MCS 0-15 Note 1: RF output power specifies that Maximum Peak Conducted Output Power. Note 2: 802.11b uses a combination of DSSS-DBPSK, DQPSK, CCK modulation. Note 3: 802.11g/n…

Text truncated - open the document above for the full version.

Report No.: FR962401-01CO Page : 1 of 16 Report Version: Rev. 01 FCC Co-Location Test Report FCC ID : QISR2561 Equipment : Indoor Router Model No. : R2561 Brand Name : Huawei Applicant : Huawei Technologies Co., Ltd. Address : Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, China. Standard : 47 CFR FCC Part 15.247 47 CFR FCC Part 15.407 Received Date : Jun. 24, 2019 Tested Date : Jul. 09, 2019 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any agency of government. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FR962401-01CO Page : 2 of 16 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 The Equipment List ................................................................................................................................ 6 1.3 Test Standards ....................................................................................................................................... 7 1.4 Reference Guidance .............................................................................................................................. 7 1.5 Deviation from Test Standard and Measurement Procedure ................................................................. 7 1.6 Measurement Uncertainty ...................................................................................................................... 7 2 TEST CONFIGURATION ....................................................................................................................... 8 2.1 Testing Condition ................................................................................................................................... 8 2.2 Testing Facility........................................................................................................................................ 8 2.3 The Worst Test Modes and Channel Details ......................................................................................... 8 3 TRANSMITTER TEST RESULTS .......................................................................................................... 9 3.1 Unwanted Emissions into Restricted Frequency Bands ........................................................................ 9 4 TEST LABORATORY INFORMATION ............................................................................................... 16 Report No.: FR962401-01CO Page : 3 of 16 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR962401-01CO Rev. 01 Initial issue Jul. 07, 2020 Report No.: FR962401-01CO Page : 4 of 16 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.247(d) 15.407(b) 15.209 Radiated Emissions [dBuV/m at 3m]: 45.52MHz 36.28 (Margin -3.72dB) - PK Pass Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FR962401-01CO Page : 5 of 16 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) WLAN Operating Frequency 802.11b/g/n: 2412 MHz ~ 2462 MHz 802.11a/n/ac: 5180 MHz ~ 5240 MHz, 5745 ~ 5825 MHz Modulation Type 802.11b: DSSS (DBPSK / DQPSK / CCK) 802.11a/g/n/ac: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM) 1.1.2 Antenna Details Ant. No. Type Connector Operating Frequencies (MHz) / Antenna Gain (dBi) 2400~2483.5 5150~5250 5725~5850 1 PIFA UFL 2.77 2.88 3.22 2 PIFA UFL 1.94 4.28 5.33 1.1.3 Power Supply Type of Equipment under Test (EUT) Power Supply Type 19Vdc from adapter Report No.: FR962401-01CO Page : 6 of 16 Report Version: Rev. 01 1.2 The Equipment List Test Item Radiated Emission Test Site 966 chamber1 / (03CH01-WS) Instrument Manufacturer Model No. Serial No. Calibration Date Calibration Until Spectrum Analyzer R&S FSV40 101498 Dec. 27, 2018 Dec. 26, 2019 Receiver R&S ESR3 101658 Dec. 11, 2018 Dec. 10, 2019 Bilog Antenna SCHWARZBECK VULB9168 VULB9168-522 Jul. 18, 2018 Jul. 17, 2019 Horn Antenna 1G-18G SCHWARZBECK BBHA 9120 D BBHA 9120 D 1096 Dec. 18, 2018 Dec. 17, 2019 Horn Antenna 18G-40G SCHWARZBECK BBHA 9170 BBHA 9170517 Nov. 15, 2018 Nov. 14, 2019 Loop Antenna R&S HFH2-Z2 100330 Nov. 09, 2018 Nov. 08, 2019 Loop Antenna Cable KOAX KABEL 101354-BW 101354-BW Oct. 08, 2018 Oct. 07, 2019 Preamplifier EMC EMC02325 980225 Jul. 20, 2018 Jul. 19, 2019 Preamplifier Agilent 83017A MY39501308 Oct. 04, 2018 Oct. 03, 2019 Preamplifier EMC EMC184045B 980192 Aug. 09, 2018 Aug. 08, 2019 RF Cable EMC EMC104-SM-SM-80 00 181106 Oct. 08, 2018 Oct. 07, 2019 RF Cable HUBER+SUHNER SUCOFLEX104 MY16019/4 Oct. 08, 2018 Oct. 07, 2019 RF Cable HUBER+SUHNER SUCOFLEX104 MY16014/4 Oct. 08, 2018 Oct. 07, 2019 LF cable 1M EMC EMCCFD400-NM-N M-1000 160502 Oct. 08, 2018 Oct. 07, 2019 LF cable 3M Woken CFD400NL-LW CFD400NL-001 Oct. 08, 2018 Oct. 07, 2019 LF cable 10M Woken CFD400NL-LW CFD400NL-002 Oct. …

Text truncated - open the document above for the full version.

Report No.: FR962401-01 Page: : 1 of 5 Report Version: Rev. 01 Photographs of the Test Configuration Conducted Emission Test Report No.: FR962401-01 Page: : 2 of 5 Report Version: Rev. 01 Radiated Emission Below 1GHz Test Report No.: FR962401-01 Page: : 3 of 5 Report Version: Rev. 01 Radiated Emission Below 1GHz Test Report No.: FR962401-01 Page: : 4 of 5 Report Version: Rev. 01 Radiated Emission Above 1GHz Test Report No.: FR962401-01 Page: : 5 of 5 Report Version: Rev. 01 Radiated Emission Above 1GHz Test
