Quick Start WS329 300Mbps Wireless Router 1 1 Obtaining More Information Thanks for purchasing the WS329 300Mbps Wireless Router (WS329 for short). This quick start will show you how to connect your WS329 to a network and access the Internet. The figures in this guide are for reference only. The appearance and display features may vary slightly depending on the actual product version. For the full user guide, visit http://www.huaweidevice.com. Enter WS329 in the website search box and press Enter . Please visit www.huaweidevice.com/worldwide/support/hotline for recently updated hotline and email address in your country or region. 2 Connecting Cables Connect your devices in the sequence indicated in the following figure. Packing list: 1 x WS329, 1 x power adapter, 1 x network cable, 1 x Quick Start and 1 x Warranty Card. When configuring the WS329 for the first time, use an Ethernet cable to connect the WS329 to a computer. 1 2 3 WS329 2 3 Powering On To power on the WS329, press its On/Off button. After the WS329 is powered on, the WS329 indicator turns on. The following table lists how the indicators behave when the WS329 is operating correctly. If the indicators do not behave as expected, ensure that everything is plugged in correctly. IndicatorExpected State PowerSteady on (On/Off button pressed ) InternetBlinking (WAN port connected to a network) WLANBlinking (WLAN enabled) WPS • Steady off (WPS disabled) • Blinking (WPS enabled) LAN1~LAN4Steady on (indicator of the connected LAN port) 4 Setting the Computer IP Address 1. Choose Start > Control Panel > Network and Internet > Network and Sharing Center . 2. Choose Change adapter settings . Right-click Local Area Connection and choose Properties . The following example uses Windows 7 to describe how to set the computer IP address: 3 1. Open a browser. In the address box, enter 192.168.3.1 . Press Enter . Enter the login user name ( admin by default) and password ( admin by default). Click Login . 2. On the Home tab, click Connect to internet . Then select a network connection type and set network parameters based on the network provided by your Internet service provider. To protect against unauthorized access, change your user name and password after the first login. 5 Quick Setup 3. Double-click Internet Protocol Version 4 (TCP/IPv4) . 4. S e l e c t Obtain an IP address automatically and Obtain DNS server address automatically . Click OK . 4 The following example uses Windows 7 to describe how to set up a wireless connection: 6 Wireless Connection Setup The default WLAN key is printed on the router's rear label. To protect your wireless network from unauthorized access, change the key promptly after setup. 1. Choose Start > Control Panel > Network and Internet > Network and Sharing Center > Change adapter settings . Right-click Local Area Connection , a n d c h o o s e Connect / Disconnect . 2. From the wireless network list, select the WLAN provided by the WS329. Click Connect . 3. In the displayed dialog box, enter the WLAN key and click OK . 4. In the wireless network list, check t h e W L A N c o n n e c t i o n s t a t u s . I f t h e s t a t u s i s Connected , t h e computer is wirelessly connected to the WS329. 5 7 Safety information This section contains important information about the operation of your device. It also contains information about how to use the device safely. Read this information carefully before using your device. Electronic device Do not use your device if using the device is prohibited. Do not use the device if doing so causes danger or interference with other electronic devices. Interference with medical equipment >Follow rules and regulations set forth by hospitals and health care facilities.Do not use your device where prohibited. >Some wireless devices may affect the performance of hearing aids orpacemakers. Consult your service provider for more information. >Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained between a device and a pacemaker to prevent potential interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your front pocket. Areas with flammables and explosives >Do not use the device where flammables or explosives are stored (in a gas station, oil depot, or chemical plant, for example). Using your device in these environments increases the risk of explosion or fire. In addition, follow the instructions indicated in text or symbols. >Do not store or transport the device in containers with flammable liquids, gases, or explosives. Operating environment >Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the device in these environments may result in circuit malfunctions. >Before connecting and disconnecting cables, stop using the device and disconnect it from the power supply. Ensure that your hands are dry during operation. >Place the device on a stable surface. >Keep the device away from electronic appliances that generate strong magnetic or electric fields, such as a microwave oven or refrigerator. >During thunderstorms, power off your device and remove all cables connected to it to protect against lightning strikes. >Do not use your device during thunderstorms to protect your device against any danger caused by lightning. >Ideal operating temperatures are 0°C to 40°C. Ideal storage temperatures are 0°C to 40°C. Extreme heat or cold may damage your device or accessories. >Keep the device and accessories in a well-ventilated and cool area away from direct sunlight. Do not enclose or cover your device with towels or other objects. Do not place the device in a container with poor heat dissipation, such as a box or bag. >To protect your device or accessories from fire or electrical shock hazards, avoid rain and moisture. >Keep the device away from sources of heat and fire, such as a heater, microwave oven, stove, water heater, radiator, or candle. >Do not place any…
