QISB890B890-66 is an LTE Wireless Gateway, which with UMTS, LTE & WLAN

B890 LTE Wireless Gateway Quick Start HUAWEI TECHNOLOGIES CO., LTD. 1 Note:  Figures in this guide are only for your reference. For details about the particular model you have chosen, contact your service provider.  Check the information about the product and its accessories when you purchase it. Some accessories are not provided in the product package. If necessary, contact your local dealer to purchase them.  This guide briefly describes the device functions. For details about how to set the management parameters, see the help information on the web management page. 1 Getting to Know Your Device Application Scenarios Scenario 1： With USIM card inserted and work properly in the device, you can connect your computer to the device to access the Internet, and connect your telephone to the device to answering or making a call. Scenario 2： With connecting to the Ethernet, you can connect your computer to the device to access the Internet. 2 Scenario 3： With connecting to the Ethernet and working with a USIM card, you can connect your computer to the device to access the Internet though Ethernet, and answering or making a call thought the USIM card. Appearance 1. Power indicator 2. Network status indicator 3. Wi-Fi/WPS indicator 4. SMS indicator 5. Telephone indicator 6. Wireless dialing indicator 7. LAN indicators 8. WAN indicator 9. USB indicator 10. Wi-Fi/WPS button 11. Dial-up button 12. SIM card slot 13. WAN port 14. LAN ports 15. USB port 16. Telephone port 17. Power port 18. Register button(not supported at this time) 19. Power button 3 Indicators Indicator Status  Steady on: device powered on.  Off: device powered off.  Blinking red fast: Subscriber Identity Module (SIM) card unavailable (SIM card not installed or malfunctioning, or PIN code not verified).  Steady yellow: device registered with the network.  Steady green: device connected to the Internet.  Off: no signal received.  Steady on: Wi-Fi turned on or data transfer in progress.  Blinking: WPS connection being set up.  Off: Wi-Fi turned off.  Steady on: The inbox is already full.  Blinking:you have new SMS(s).  Steady on: At least one handset registered.  Fast blinking: Handset registration in progress.  Slow blinking: Handset paging in progress.  Off: No handsets registered.  Steady on: Wireless dial-up successful.  Blinking slowly: Wireless dial-up in progress.  Blinking fast: Wireless dial-up failed. / /  Steady on: network cable connected.  Blinking: data transfer in progress.  Off: network cable not connected.  Steady on: Ethernet dial-up successful.  Blinking slowly: Ethernet dial-up in progress.  Blinking fast: Ethernet dial-up failed.  Steady on: USB storage device connected.  Off: USB storage device not connected. 4 2 Installation Preparing Internet Connection Yo u r device not only support the mobile data network to access the Internet through USIM card, and also support connected to Ethernet to access to the Internet. Method 1: Installing the USIM Card Step 1 Open and rotate the protective cover, to expose the SIM card slot. Step 2 Insert the USIM card into the card slot. Ensure that the beveled edge of the USIM card aligns with that of the card slot. Step 3 Rotate and close the protective cover. Attention: Before removing the SIM card, ensure that the device is powered off and disconnected from the power outlet. Method 2: Connecting Ethernet cable Step 1 Use a Ethernet cable, insert one of the end into the WAN port of the device. Step 2 Insert another end of the cable into the Ethernet port of the wall. 5 Connecting Cables The following figure shows an example of how to connect the cables. In this example, the device is connected to a desktop computer, a laptop computer, and a telephone. If you do not inserted the USIM card to the device, you will not able to answering or making a call,you can skip to connect the telephone. 1. Power adapter 2. Telephone (Optional) 3. Desktop computer 4. Laptop Note:  Using an incompatible power adapter may damage the device..  Radio signals can interfere with telephone call connection and quality. To eliminate the risk of possible interference, place the telephone at least 1 meter (3.28 feet) away from the device.  Use an Ethernet cable that is not longer than 100 meters (328 feet), to connect a computer to one of the device's LAN ports. 6 (Optional) Installing an External Antenna In areas with poor network coverage, connect an external antenna to the device's external antenna port. Screw the external antenna in fully, as shown in the following figure. Note:  Skip this section if you do not need to connect an external antenna to the device.  Before using an external antenna, log in to the web management page (http://192.168.1.1) and set antenna mode to external. For details, see the help information on the web management page.  Only use the external antenna indoors.  You cannot switch between the internal antenna and the external antenna while using a voice or data service. (Optional) Connecting to a USB device Connect a USB flash drive, portable hard disk drive, or USB printer to the device's USB port, as shown in the following figure. For details, see the help information on the web management page. Note:  Do not connect a computer to the device's USB port.  The device's USB port can supply a maximum current of 500 mA to power connected USB devices. If the current required by a portable hard disk drive (or other peripherals) connected to the device is higher than 500 mA, the device may fail to recognize the hard disk drive. In this case, use an auxiliary power supply for the hard disk drive. For more information, contact your service provider. 7 3 Powering the Device On or Off  After connecting to a power outlet, the device will power on automatically.  To manually power the device on, press and hold until all indicators turn on.  To power the device off, press and hold until all indicators turn off. Note: Keep your device stand placed wh…

Text truncated - open the document above for the full version.

1 Copyright © Huawei Technologies Co., Ltd. 2011. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses. Trademarks and Permissions , , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Other trademarks, product, service and company names mentioned are the property of their respective owners. Notice Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. NO WARRANTY THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED 2 WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS. Safety Information This section contains important information pertaining to the operating instructions of your device. It also contains information about how to use the device safely. Read this information carefully before using your device. Electronic Device Do not use your device if using your device is prohibited. Do not use the device when using your device causes danger or interference with electronic devices. Medical Device  Follow rules and regulations set forth by hospitals and health care facilities. Do not use your device when using the device is prohibited.  Some wireless devices may affect the performance of hearing aids or pacemakers. For any such problems, consult your service provider.  If you are using an electronic medical device, consult the doctor or the device manufacturer to confirm whether radio waves affect the operation of this device. Potentially Explosive Atmosphere Do not use your device in any area with a potentially explosive atmosphere, and comply with all signs and instructions. Areas that may have potentially explosive 3 atmospheres include the areas where you would normally be advised to turn off your vehicle engine. Triggering of sparks in such areas could cause an explosion or a fire, resulting in bodily injuries or even deaths. Do not use your device at refueling points such as service stations. Comply with restrictions on the use of radio equipment in fuel depots, storage, and distribution areas, and chemical plants. In addition, adhere to restrictions in areas where blasting operations are in progress. Before using the device, watch out for areas that have potentially explosive atmospheres that are often, but not always, clearly marked. Such locations include areas below the deck on boats, chemical transfer or storage facilities, and areas where the air contains chemicals or particles such as grain, dust, or metal powders. Ask the manufacturers of vehicles using liquefied petroleum gas (such as propane or butane) whether this device can be safely used in their vicinity. Traffic Security  Observe local laws and regulations while using the device. To prevent accidents, do not use your wireless device while driving.  RF signals may affect electronic systems of motor vehicles. For more information, consult the vehicle manufacturer.  In a motor vehicle, do not place the device over the air bag or in the air bag deployment area. Otherwise, the device may hurt you owing to the strong force when the air bag inflates.  Do not use your device while flying in an aircraft and before boarding an aircraft. Using wireless devices in an aircraft may cause danger to the operation of the aircraft and disrupt the wireless telephone network. It may also be considered illegal. Operating Environment  Do not use or charge the device in dusty, damp, and dirty places or places with magnetic fields. Otherwise, it may result in a malfunction of the circuit.  While using the device, observe the local laws and regulations, and respect others' privacy and legal rights.  Place the device or accessories in well-ventilated, cool, and 4 out-of-direct-sunlight place. Avoid enveloping the device, or covering towels and placing articles on the device. Place the device out of a box or case to avoid poor heat dissipation that results in the damage to the device.  On a stormy day with thunder, do not use your device, to prevent any danger caused by lightning.  Keep the ambient temperature between –10°C to +45°C for using the device.  This device should be installed and operated with a minimum distance of 20 cm between the antenna and all persons. Safety of Children Comply with all precautions with regard to children's safety. Letting the child play with your device or its accessories, which may include parts that can be detached from the device, may be dangerous, as it may present a choking hazard. Ensure that small children are kept away from the device and accessories. Accessories Use the accessories delivered only by the manufacturer. Using a…

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. Date (25/09/2012) BABT TCB Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Huawei Technologies Co., Ltd. Bantian, Longgang District, Shenzhen, 518129, China hereby authorize TUV-SUD China Shenzhen Branch 6/F, H Hall, Century Craftwork Culture Square, No. 4001 Fuqiang Road, Futian District, Shenzhen 518048 P. R. China Louis Lin Phone: +86-755-88286998 e-mail: [email protected] to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that neither we nor any party to this application are subject to denial of U.S. Federal benefits, which include FCC benefits, pursuant to section 5301 of Anti-Drug Abuse Act of 1988, U.S.C. 862 because of conviction for possession or distribution of controlled substance. This authorization is application to following FCC ID application: FCC ID: QISB890 This authorization is valid until further written notice from Huawei Technologies Co., Ltd. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhangxinghai EMC Laboratory Manager

Huawei Technologies Co.,Ltd. Federal Communications Commission 2012-09-26 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: QISB890 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Operational Description Bom List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. ***************************************************************************** In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until 2013-03-25: External Photos Internal Photos Test Setup Photos User Manual ****************************************************************************** It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. E-mail: [email protected] Fax: 0086-0755-89650226

HUAWEI B890-66 LTE Wireless Gateway SECRET Page1 Total6 Photo documentation of external of product HUAWEI B890-66 LTE Wireless Gateway SECRET Page2 Total6 HUAWEI B890-66 LTE Wireless Gateway SECRET Page3 Total6 HUAWEI B890-66 LTE Wireless Gateway SECRET Page4 Total6 HUAWEI B890-66 LTE Wireless Gateway SECRET Page5 Total6 HUAWEI B890-66 LTE Wireless Gateway SECRET Page6 Total6

HUAWEI B890-66 LTE Wireless Gateway SECRET Page1, Total 1

HUAWEI B890-66 LTE Wireless Gateway SECRET Page1, Total 1 B890-66 Label location

HUAWEI B890-66 LTE Wireless Gateway SECRET Page1,Total 6 Photo documentation of interior of product HUAWEI B890-66 LTE Wireless Gateway SECRET Page2,Total 6 HUAWEI B890-66 LTE Wireless Gateway SECRET Page3,Total 6 HUAWEI B890-66 LTE Wireless Gateway SECRET Page4,Total 6 HUAWEI B890-66 LTE Wireless Gateway SECRET Page5,Total 6 HUAWEI B890-66 LTE Wireless Gateway SECRET Page6,Total 6

EMC Test Report Product Name: LTE Wireless Gateway Model Number: B890-66 Report No: SYBH(Z-EMC)109082012-2 FCC ID：QISB890 Reliability Laboratory of Huawei Technologies Co., Ltd. Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Tel: +86 755 28780808 Fax: +86 755 89652518 Test Report of Wireless Gateway FCC ID: QISB890 Security Level: secret Report No: SYBH(Z-EMC)109082012-2 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total18 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has passed the accreditation by The American Association for Laboratory Accreditation (A2LA). The accreditation number is 2174.01. 3. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 4. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-2. 5. The test report is invalid if not marked with "exclusive stamp for the test report". 6. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 7. The test report is invalid if there is any evidence of erasure and/or falsification. 8. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 9. Normally, the test report is only responsible for the samples that have undergone the test. 10. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. Test Report of Wireless Gateway FCC ID: QISB890 Security Level: secret Report No: SYBH(Z-EMC)109082012-2 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total18 Applicant: Huawei Technologies Co., Ltd. Address: Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Date of Receipt Test Item: Aug.21, 2012 Start Date of Test: Aug.23, 2012 End Date of Test: Aug.31, 2012 Test Result: Pass Approved By 2012-09-03 Liuchunlin (Lab Manager) Date Name Signature Operator 2012-09-03 Caozhimin Date Name Signature Test Report of Wireless Gateway FCC ID: QISB890 Security Level: secret Report No: SYBH(Z-EMC)109082012-2 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total18 Modification Record No. Last Report No. Modification Description 1 NA First report Test Report of Wireless Gateway FCC ID: QISB890 Security Level: secret Report No: SYBH(Z-EMC)109082012-2 Confidential Information of Huawei. No Distribution without Written Permission Page5, Total18 TABLE OF CONTENT 1 General Information ............................................................................................................................. 6 1.1 EUT Description ........................................................................................................................... 6 1.2 Test Site Information .................................................................................................................... 7 1.3 Applied Standards ........................................................................................................................ 7 2 Summary of Results ............................................................................................................................. 8 3 System Configuration during EMC Test .............................................................................................. 9 3.1 Test Mode ..................................................................................................................................... 9 3.2 Test System Configuration ........................................................................................................... 9 3.3 Cables Used during Test ............................................................................................................ 10 3.4 Associated Equipment Used during Test .................................................................................. 10 4 Electromagnetic Interference (EMI) ................................................................................................... 11 4.1 Radiated Disturbance 30MHz to 18GHz ................................................................................... 11 4.2 Conducted Disturbance 0.15 MHz to 30MHz ............................................................................ 13 5 Main Test Instruments ........................................................................................................................ 14 6 System Measurement Uncertainty .................................................................................................... 14 7 Test Data and Graph .......................................................................................................................... 15 7.1 Radiated Disturbance ................................................................................................................. 15 7.2 Conducted Disturbance .............................................................................................................. 17 Test Report of Wireless Gateway FCC ID: QISB890 Security Level: secret Report No: SYBH(Z-EMC)109082012-2 Confidential Information of Huawei. No Distribution without Written Permission Page6, Total18 1 General Information 1.1 EUT Description EUT Description Product Name LTE Wireless Gateway Model Number B890-66 Serials Number N/A Working Voltage 12Vdc TX Frequency WCDMA Band II: 1850MHz To 1910MHz WCDMA Ba…

Text truncated - open the document above for the full version.

FCC Test Report of HUAWEI B890-66 FCC ID: QISB890 Security Level: secret Report No: SYBH(Z-EMC)109082012-2 Confidential Information of Huawei. No Distribution without Permission Page1, Total6 Photos of EUT FCC Test Report of HUAWEI B890-66 FCC ID: QISB890 Security Level: secret Report No: SYBH(Z-EMC)109082012-2 Confidential Information of Huawei. No Distribution without Permission Page2, Total6 Figure1 EUT Appearance FCC Test Report of HUAWEI B890-66 FCC ID: QISB890 Security Level: secret Report No: SYBH(Z-EMC)109082012-2 Confidential Information of Huawei. No Distribution without Permission Page3, Total6 Photos of Test Setup FCC Test Report of HUAWEI B890-66 FCC ID: QISB890 Security Level: secret Report No: SYBH(Z-EMC)109082012-2 Confidential Information of Huawei. No Distribution without Permission Page4, Total6 1 Radiated Emissions Radiated Disturbance Emissions (below 1GHz) FCC Test Report of HUAWEI B890-66 FCC ID: QISB890 Security Level: secret Report No: SYBH(Z-EMC)109082012-2 Confidential Information of Huawei. No Distribution without Permission Page5, Total6 Radiated Disturbance Emissions (1GHz to18GHz) FCC Test Report of HUAWEI B890-66 FCC ID: QISB890 Security Level: secret Report No: SYBH(Z-EMC)109082012-2 Confidential Information of Huawei. No Distribution without Permission Page6, Total6 2 Conducted Emissions Conducted Emissions with AC Ports ----------------------------------------------------------- END-----------------------------------------------------------
