Technical Manual Airbridge BTS3606 CDMA Base Station System Description Chapter 1 Introduction 1-1 Chapter 1 Introduction The mobile communication system has experienced the first generation (analog system) and the second generation (digital system). As one of the main development trends of the second generation, the Code Division Multiple Access 1X (CDMA 1X) technology, advocated by the 3rd Generation Partnership Project 2 (3GPP2), has been widely used for commercial purpose. The CDMA 1X technology complies with IS-95A and IS-95B standards. The capacity of the CDMA 1X system has increased substantially because it adopts such technologies as reverse pilot, fast power control and transmit diversity. This chapter first introduces the network solution of Huawei CDMA 1X mobile communication system, and then the market position of Huawei indoor BTS3606. 1.1 Network Solution of Huawei CDMA 1X System The Huawei CDMA 1X mobile communication system comprises the Base Station Subsystem (BSS) and the Core Network (CN). Users can operate and maintain the system through an integrated mobile network management system. Figure 1-1 shows the network of Huawei CDMA 1X system. This manual aims to introduce the Base Transceiver Station (BTS) of the BSS, thus, the following figure emphasizes the network structure of BSS. Technical Manual Airbridge BTS3606 CDMA Base Station System Description Chapter 1 Introduction 1-2 Internet PSTN/ISDN PLMN A3/A7 A1/A2 A10/A11 Abis A1/A2 BSC/PCF BSC/PCF MS A10/A11 Abis Abis BSSCN BTS Abis BTS BTS BTS BTS BTS ODU ODU ODU ODU MS BTS3601C/ODU3601CBTS3606cBTS3612BTS3612A Optical fiber MS Mobile Network Management System Packet Domain Network Equipment Circuit Domain Network Equipment Internet PSTN/ISDN PLMNPLMNPLMN A3/A7 A1/A2 A10/A11 Abis A1/A2 BSC/PCF BSC/PCF MSMS A10/A11 Abis Abis BSSCN BTS Abis BTSBTS BTSBTS BTSBTS BTSBTS BTSBTS ODUODU ODUODU ODUODU ODUODU MSMS BTS3601C/ODU3601CBTS3606cBTS3612BTS3612A Optical fiber MSMS Mobile Network Management System Packet Domain Network Equipment Circuit Domain Network Equipment MS: Mobile Station BTS: Base Transceiver Station BSC: Base Station Controller ODU: Out Door Unit PCF: Packet Control Function BSS: Base Station Subsystem CN: Core Network PLMN: Public Land Mobile Network PSTN: Public Service Telephone Network ISDN: Integrated Service Digital Network Figure 1-1 Network structure of Huawei CDMA 1X system & Note: The appearance of the BTS3601C cabinet is the same as that of the ODU3601C cabinet. 1.1.1 Brief Introduction to BSS The BSS consists of the BTS, Base Station Controller (BSC), and Packet Control Function (PCF). The PCF is usually integrated with the BSC. The ODU3601C, a soft site, is also a part of the Huawei BSS. I. BTS The BTS transmits and receives radio signals to enable the communication between the radio network system and the Mobile Station (MS). Huawei provides a series of BTS products, including: l cBTS3612: Indoor BTS equipment. The maximum capacity of a single cabinet is 4 carriers and 3 sectors or 2 carriers and 6 sectors. Technical Manual Airbridge BTS3606 CDMA Base Station System Description Chapter 1 Introduction 1-3 l BTS3606: Indoor BTS equipment developed based on the cBTS3612. The maximum capacity of a single cabinet is 2 carriers and 3 sectors. l BTS3612A: Outdoor BTS equipment developed based on the cBTS3612. The maximum capacity of a single cabinet is 2 carriers and 3 sectors. l BTS3601C: Outdoor one-carrier BTS equipment. l ODU3601C: Outdoor one-carrier Soft equipment. It shares the baseband processing resource of its upper-level BTS. It also transmits and receives the radio signal together with the upper-level BTS. II. BSC/PCF The BSC performs the following functions: l BTS control and management l Call connection and disconnection l Mobility management l Power control l Radio resource management l Provision of stable and reliable radio connections for the upper-level services through soft/hard handoff The PCF manages the Radio-Packet (R-P) connection. As radio resources are limited, they should be released when subscribers are not sending or receiving information. But the Peer-Peer Protocol (PPP) connection must be maintained. The PCF shields the radio mobility from the upper-level services through the handoff function. III. MS The MS is the equipment used by the mobile subscriber. It can originate and receive calls, and communicate with the BSS. 1.1.2 Brief Introduction to CN The CN comprises the packet domain network and the circuit domain network. I. Packet domain network equipment The packet domain network equipment covers: l Packet Data Service Node (PDSN) l Mobile Internet Protocol Home Agent (MIP HA) l Authorization, Authentication and Accounting (AAA) They connect and communicate with the Internet. Technical Manual Airbridge BTS3606 CDMA Base Station System Description Chapter 1 Introduction 1-4 II. Circuit domain network equipment The circuit domain network equipment includes: l Mobile Switching Center (MSC) l Home Location Register (HLR) l Gateway Mobile-services Switching Center (GMSC) They connect and communicate with the conventional Public Land Mobile Network (PLMN) and Public Switched Telephone Network/Integrated Services Digital Network (PSTN/ISDN). 1.2 Position of BTS3606 The following presents the position of the BTS3606. I. Position in the network The BTS3606 is located between the BSC and the MS in the CDMA 1X system. Under the control of the BSC, the BTS3606 is the radio transceiver equipment serving one cell or multiple logical sectors. Connecting with the BSC through the Abis interface, the BTS3606 helps the BSC manage radio resources, radio parameters and interfaces. It also implements, over the Um interface, the radio transmission between the BTS and the MS, as well as related control functions. II. Position in the application The indoor BTS3606 supports multi-cell configuration. A single cabinet can supports three sectors, each of which can support at most two carriers. Th…

Text truncated - open the document above for the full version.

Huawei Technologies Bantian Longgang District Shenzhen 518129 P.R.C. Date 200-- Pages 1 To NULL FaxNULL FromZhangXinghai Fax 755 8965 1014 Tel 755 8965 3384 Email: [email protected] Http: www.huawei.com Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISBTS3606-1900 to be kept confidential. 1. Circuits, Schematic Diagrams 2. PCB Layout 3. Block diagrams 4. Tune up information 5. User operational description The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page1, Total4 Photo documentation of appearance of product Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page2, Total4 A. Appearance of product a. Photo of BTS3606 Front side of cabinet Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page3, Total4 Back side of cabinet Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page4, Total4 Side face of cabinet

FCC ID QISBTS306-1900 This device complies with Part 15 of the FCC Rules. Operation is subject to the two following conditions : (1) This device may not cause harmful interference , and (2) this device must accept any interference received , including interference that may cause undesired operations.

Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page1, Total15 Photo documentation of interior of product Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page2, Total15 Main construct - Front View Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page3, Total15 Main construct - Back View Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page4, Total15 Board - BCIM Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page5, Total15 Board - BCKM Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page6, Total15 Board - BCPM Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page7, Total15 Board - CTRM Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page8, Total15 Board - CHPA Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page9, Total15 Module - CDDU Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page10, Total15 Module – Fan box Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page11, Total15 Module – DC power distribution 1(Common module) Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page12, Total15 Module – DC power distribution 1 of BTS3606A Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page13, Total15 Module – DC power distribution 2 of BTS3606A Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page14, Total15 Module – DC to DC power module( Common module) Report on RF Test of 6-carrier 1900MHz CDMA Base Station BTS3606-1900 Secret Confidential Information of Huawei. No Distribution without Permission Page15, Total15 Module – AC to DC power module of BTS3606A

Huawei Technologies Co., Ltd. Prüfbericht - Nr.: Test Report No. 17002244 001 Seite 2 von 39 Page 2 of 39 Below table summarizes the measurements and results for the CDMA base station. Detailed results and descriptions are shown in the following pages. FCC Measurement Specification FCC Limits Part(s) Description Result 2.1046 24.232 RF Output Power PASS 2.1047 Modulation Characteristics PASS 2.1049 Occupied Bandwidth PASS 2.1051 24.238 Spurious Emission at Antenna Terminals PASS 2.1053 24.238 Field Strength of Spurious Emissions PASS 2.1055 24.235 Frequency Stability PASS The base station is intended for use in the licensed domestic public cellular radio service and is designed to be placed and operated under the conditions of FCC rules part 24 subpart E. Huawei Technologies Co., Ltd. Prüfbericht - Nr.: Test Report No. 17002244 001 Seite 3 von 39 Page 3 of 39 4.1. T ESTING P ERIOD ................................................................................................................................. 4 4.2. G ENERAL S ET UP D ESCRIPTION ........................................................................................................... 4 5.1. T ECHNICAL C HARACTERISTICS ............................................................................................................ 4 5.1.1. Frequency Range...................................................................................................................... 4 5.1.2. Transmitter Power Rating.......................................................................................................... 4 5.1.3. Channel Spacing / Separation .................................................................................................. 4 5.1.4. Type of Emission ....................................................................................................................... 4 5.1.5. Environmental Conditions for Base station ............................................................................... 4 5.1.6. Power Source ............................................................................................................................ 4 5.1.7. Tune-up Procedure ................................................................................................................... 4 5.1.8. Applied DC Voltages and Currents ........................................................................................... 4 5.2. EUT I DENTIFICATION L IST ................................................................................................................... 4 5.2.1. FCC Identification ...................................................................................................................... 4 6.1. RF O UTPUT P OWER ............................................................................................................................ 4 6.1.1. Test Conditions ......................................................................................................................... 4 6.1.2. Test Specifications and Limits................................................................................................... 4 6.1.2.1. Specification ..................................................................................................................................... 4 6.1.2.2. Limits ................................................................................................................................................ 4 6.1.3. Test Method and Setup ............................................................................................................. 4 6.1.4. Measurement Results ............................................................................................................... 4 6.1.4.1. Conclusion ........................................................................................................................................ 4 6.1.4.2. Equipment List .................................................................................................................................. 4 6.2. M ODULATION C HARACTERISTICS ......................................................................................................... 4 6.2.1. Test Conditions ......................................................................................................................... 4 6.2.2. Test Specifications and Limits................................................................................................... 4 6.2.2.1. Specification ..................................................................................................................................... 4 6.2.2.2. Limits ................................................................................................................................................ 4 6.2.3. Test Method and Setup ............................................................................................................. 4 6.2.4. Measurement Results ............................................................................................................... 4 6.2.4.1. Conclusion ........................................................................................................................................ 4 6.2.4.2. Equipment List .................................................................................................................................. 4 6.3. O CCUPIED B ANDWIDTH ....................................................................................................................... 4 6.3.1. Test Conditions ......................................................................................................................... 4 6.3.2. Test Specifications and Limits................................................................................................... 4 6.3.2.1. Specification ...........................................................................................................…
