QISC2281US Cellular Licensed Transmitter

Copyright © 2006 Huawei Technologies Co., Ltd. All Rights Reserved No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Huawei. The information in this manual is subject to change without notice. Every effort has been made in the preparation of this manual to ensure accuracy of the contents, but all statements, information, and recommendations in this manual do not constitute the warranty of any kind, express or implied. Safety Precautions Do not switch on the phone when phone use is prohibited. Do not use the phone while driving. Switch off the phone near medical apparatus. Switch off the phone in an aircraft. Switch off the phone near high-precision electronic devices. Do not attempt to disassemble the phone or its accessories. Do not place the phone or its accessories in containers with strong electromagnetic field. Do not place magnetic storage media near the phone. Do not put the phone in a high-temperature place or use it in a place with flammable gas such as a gas station. Do not allow children to use the phone without guidance. Use approved batteries and chargers only to avoid explosion. Observe the laws or regulations on phone use. Respect others’ privacy and legal rights when using the phone. Agreement Operation Format Meaning Press and hold Press one button for teo to three seconds and release it. Press Press one button and release quickly Interface Language Format Meaning Bold The character displayed on the bottom of the screen corresponding to the right/left soft key, such as “Menu”. > Multi-level menu is separated by “>”. such as “Menu > Messages” means “ Messages” is the submenu under “Menu”. Symbols Symbol DescriptionMeaning Caution Warnings and precautions for operations Note Description and note for operations i Contents 1 Getting to Know Your Phone..................................................................1 Your Phone........................................................................................1 Key and Functions .............................................................................2 Screen Icons......................................................................................3 Interfaces...........................................................................................4 2 Getting Started.........................................................................................5 Installing the Battery ..........................................................................5 Installing the UIM Card ......................................................................5 Charging the Battery..........................................................................5 Powering On/Off the Phone ...............................................................6 Using the Function Menu ...................................................................6 3 Voice Services .........................................................................................7 Making a Call.....................................................................................7 Receiving a Call.................................................................................7 Operations During a Call....................................................................7 4 Text Entry.................................................................................................8 Text Input Mode .................................................................................8 Entering English ................................................................................8 Entering Number................................................................................9 Entering Symbols.............................................................................10 5 Writing and Sending Messages............................................................11 6 Phone Book............................................................................................12 Adding a New Contact .....................................................................12 Searching for a Contact ...................................................................12 ii 7 Alarm Clock ........................................................................................... 13 Activating the Alarm Clock............................................................... 13 Deactivating the Alarm Clock .......................................................... 13 8 Security.................................................................................................. 14 Enabling/Disabling the Phone Lock................................................. 14 Changing the Phone Lock Code......................................................14 Enabling/Disabling the PIN Lock ..................................................... 14 Changing the PIN Code ..................................................................15 9 Menu Commands .................................................................................. 16 10 Warnings and Precautions ................................................................. 24 1 1 Getting to Know Your Phone Your Phone Meeting Mode Key . @ bc d f jkl m n o pq r s tuv wx hi z + Screen Earpiece Arrow Key Left Soft Key Key Guard Key Right Soft Key End/Power Key Talk/Send Key Number Keys 2 Key and Functions Key Function z Power on or off the phone. z End a call. z Return to the home screen. z Make a call. z View dialed calls. z Display the Menu. z Select the highlighted menu option. Returns to the previous menu. z Quick access to: Profiles; Messages (press) and Write Message (press and hold); Scheduler; Ringer volume. z During a call: and to increase volume, and to decrease the volume. + ~ wx z z Enter numbers and characters. z Select a menu item. z Set the meeting mode in the standby mode (by pressing and holding it for two seconds). z Enter the * symbol in the standby mode (press). z Lock the keypad in t…

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: EMCC Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISC2281 to be kept confidential: 1. Schematic diagram & PCB layout. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Turn-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Klaus Knoerig Von: "Klaus Knoerig" <[email protected]> An: "Klaus Knoerig" <[email protected]> Gesendet: Dienstag, 2. Mai 2006 08:59 Betreff: WG: Response to Inquiry to FCC (Tracking Number 518210) Seite 1 von 2 2006-05-02 Von: Generic Office of Engineering Technology [mailto:[email protected]] Gesendet: Fr 2006-04-28 18:48 An: [email protected] Betreff: Response to Inquiry to FCC (Tracking Number 518210) Inquiry: We are a TCB and we have received three applications for mobile phones operating under Part 22H and using CDMA2000 1X RTT technology. The intended FCC ID Numbers are QISC2281, QISC5300 and QISC2280. The current FCC policy requires a TCB to ask for advice from FCC prior to certifying a CDMA 2000 device. We hereby ask for guidance regarding review procedures. Sincerely, EMCC DR. RASEK Klaus Knoerig Response: From October 2005 training 1) TCBs must ask advise from FCC prior to certifying a 3G device. Preferably a KDB correspondence should be used for this communication. 2) Current advise that we will give for CDMA-2000 and UMTS is: to digest preliminary info documents provided by OET/Lab (CDMA-2000 or WCDMA), then perform reviews of tests to the best extent possible according to provided device setup information. TCBs in their review should apply good engineering judgment and current procedures such as Supplement C to the extent applicable. Additional guidance information is under development. Info documents for other technologies have not been developed at present. 3) When unsure how to address a particular point in their review, TCB should again contact OET/Lab for specific advise. 4) Request-for-info correspondence and FCC response must be included as EAS cover-letter exhibit in the filing, to demonstrate that TCB has requested and ! reviewed info prior to certification Do not reply to this message. Please select the Reply to an Inquiry Response link from the OET Inquiry System to add any additional information pertaining to this inquiry. Seite 2 von 2 2006-05-02

Huawei C2281 CDMA Handset SECRET Page1,Total 6 External Photo of Huawei C2281 Huawei C2281 CDMA Handset SECRET Page2,Total 6 Huawei C2281 CDMA Handset SECRET Page3,Total 6 Huawei C2281 CDMA Handset SECRET Page4,Total 6 Huawei C2281 CDMA Handset SECRET Page5,Total 6 Huawei C2281 CDMA Handset SECRET Page6,Total 6

Huawei C2281 CDMA Handset SECRET Page1, Total 1 ID Labe_C2281

Huawei C2281 CDMA Handset SECRET Page1, Total 1 Label Location_C2281

Huawei C2281 CDMA Handset SECRET Page1,Total 4 Internal Photo of Huawei C2281 Huawei C2281 CDMA Handset SECRET Page2,Total 4 Huawei C2281 CDMA Handset SECRET Page3,Total 4 Huawei C2281 CDMA Handset SECRET Page4,Total 4

Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 35 of 68 CDMA 1X Right Cheek High Electronics: DAE3 Sn536 Communication System: CDMA 1X-new Frequency: 848.31 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.51, 6.51, 6.51) Cheek High/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 1.21 mW/g Cheek High/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 28.7 V/m; Power Drift = -0.200 dB Peak SAR (extrapolated) = 1.40 W/kg SAR(1 g) = 0.991 mW/g; SAR(10 g) = 0.660 mW/g Maximum value of SAR (measured) = 1.06 mW/g 0 dB = 1.06mW/g Fig. 13 Right Hand Touch Cheek CDMA 835MHz CH777 Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 36 of 68 Fig. 14 Z-Scan at power reference point (CDMA 835MHz CH777) Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 37 of 68 CDMA 1X Right Cheek Middle Electronics: DAE3 Sn536 Communication System: CDMA 1X-new Frequency: 836.52 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.51, 6.51, 6.51) Cheek Middle/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 1.09 mW/g Cheek Middle/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 27.4 V/m; Power Drift = -0.200 dB Peak SAR (extrapolated) = 1.29 W/kg SAR(1 g) = 0.909 mW/g; SAR(10 g) = 0.603 mW/g Maximum value of SAR (measured) = 0.974 mW/g 0 dB = 0.974mW/g Fig.15 Right Hand Touch Cheek CDMA 835MHz CH384 Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 38 of 68 Fig. 16 Z-Scan at power reference point (CDMA 835MHz CH384) Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 39 of 68 CDMA 1X Right Cheek Low Electronics: DAE3 Sn536 Communication System: CDMA 1X-new Frequency: 824.7 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.51, 6.51, 6.51) Cheek Low/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.559 mW/g Cheek Low/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 19.3 V/m; Power Drift = -0.200 dB Peak SAR (extrapolated) = 0.667 W/kg SAR(1 g) = 0.480 mW/g; SAR(10 g) = 0.323 mW/g Maximum value of SAR (measured) = 0.512 mW/g 0 dB = 0.512mW/g Fig. 17 Right Hand Touch Cheek CDMA 835MHz CH1013 Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 40 of 68 Fig. 18 Z-Scan at power reference point (CDMA 835MHz CH1013) Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 41 of 68 CDMA 1X Right Tilt High Electronics: DAE3 Sn536 Communication System: CDMA 1X-new Frequency: 848.31 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.51, 6.51, 6.51) Tilt High/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.704 mW/g Tilt High/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 25.1 V/m; Power Drift = -0.200 dB Peak SAR (extrapolated) = 0.887 W/kg SAR(1 g) = 0.607 mW/g; SAR(10 g) = 0.394 mW/g Maximum value of SAR (measured) = 0.653 mW/g 0 dB = 0.653mW/g Fig. 19 Right Hand Tilt 15°CDMA 835MHz CH777 Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 42 of 68 Fig. 20 Z-Scan at power reference point (CDMA 835MHz CH777) Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 43 of 68 CDMA 1X Right Tilt Middle Electronics: DAE3 Sn536 Communication System: CDMA 1X-new Frequency: 836.52 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.51, 6.51, 6.51) Tilt Middle/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.630 mW/g Tilt Middle/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 23.3 V/m; Power Drift = -0.200 dB Peak SAR (extrapolated) = 0.797 W/kg SAR(1 g) = 0.541 mW/g; SAR(10 g) = 0.353 mW/g Maximum value of SAR (measured) = 0.582 mW/g 0 dB = 0.582mW/g Fig. 21 Right Hand Tilt 15°CDMA 835MHz CH384 Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 44 of 68 Fig. 22 Z-Scan at power reference point (CDMA 835MHz CH384) Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 45 of 68 CDMA 1X Right Tilt Low Electronics: DAE3 Sn536 Communication System: CDMA 1X-new Frequency: 824.7 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.51, 6.51, 6.51) Tilt Low/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.328 mW/g Tilt Low/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 17.1 V/m; Power Drift = -0.153 dB Peak SAR (extrapolated) = 0.431 W/kg SAR(1 g) = 0.278 mW/g; SAR(10 g) = 0.179 mW/g Maximum value of SAR (measured) = 0.305 mW/g 0 dB = 0.305mW/g Fig. 23 Right Hand Tilt 15°CDMA 835MHz CH1013 Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 46 of 68 Fig. 24 Z-Scan at power reference point (CDMA 835MHz CH1013) Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 47 of 68 CDMA 1X Body Toward Phantom High Electronics: DAE3 Sn536 Communication System: CDMA 1X-new Frequency: 848.31 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.45, 6.45, 6.45) Toward Phantom High/Area Scan (71x121x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.443 mW/g Toward Phantom High/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 21.1 V/m; Power Drift = -0.200 dB Peak SAR (extrapolated) = 0.480 W/kg SAR(1 g) = 0.371 mW/g; SAR(10 g) = 0.265 mW/g Maximum value of SAR (measured) = 0.396 mW/g 0 dB = 0.396mW/g Fig. 25 CDMA 835MHz, Body, Towards Phantom, CH777 Telecommunication Metrology Center of Ministry of Information Industry No. 2…

Text truncated - open the document above for the full version.

Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 2 of 68 Notes 1. . The test report shall be invalid if there is no “specified stamp for the test report” or the stamp of the test organization on it. 2. Copies of the test report shall be invalid if there is no “specified stamp for the test report” or the stamp of the test organization on it. 3. The test report shall be invalid if there are no signatures of the testing person, reviewing person and approving person on it. 4. The test report shall be invalid if it is altered. 5. Any demurral about the test shall be put forward to the testing organization within 15 days after the receiving of the test report. 6. This test report standalone dose not constitute or imply by its own an approval of the product by any Certification Authorities or Competent Bodies. 7. This report is only valid if complete, and test report shall not be reproduced except in full, without written approval of the laboratory. 8. This report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of Telecommunication Metrology Center of MII and the Accreditation Bodies, if it applies. Address: No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China (Telecommunication Metrology Center of MII) Post code: 100083 Telephone: +86 10 62302041 Fax: +86 10 62304793 Web site: http://www.emcite.com E-mail: [email protected] Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 3 of 68 TABLE OF CONTENT 1 COMPETENCE AND WARRANTIES ............................................................................... 5 2 GENERAL CONDITIONS................................................................................................... 5 3 DESCRIPTION OF EUT...................................................................................................... 5 3.1 ADDRESSING INFORMATION RELATED TO EUT...................................................................... 5 3.2 CONSTITUENTS OF EUT ........................................................................................................ 6 3.3 GENERAL DESCRIPTION......................................................................................................... 6 4 OPERATIONAL CONDITIONS DURING TEST ............................................................. 7 4.1 SCHEMATIC TEST CONFIGURATION........................................................................................ 7 4.2 SAR MEASUREMENT SET-UP................................................................................................. 8 4.3 DASY4 E-FIELD PROBE SYSTEM............................................................................................ 8 4.4 E-FIELD PROBE CALIBRATION............................................................................................... 9 4.5 OTHER TEST EQUIPMENT.................................................................................................... 10 4.6 EQUIVALENT TISSUES.......................................................................................................... 10 4.7 SYSTEM SPECIFICATIONS..................................................................................................... 11 5 CHARACTERISTICS OF THE TEST ............................................................................. 11 5.1 APPLICABLE LIMIT REGULATIONS....................................................................................... 11 5.2 APPLICABLE MEASUREMENT STANDARDS........................................................................... 12 6 LABORATORY ENVIRONMENT ................................................................................... 12 7 CONDUCTED OUTPUT POWER MEASUREMENT................................................... 12 7.1 SUMMARY........................................................................................................................... 12 7.2 CONDUCTED POWER........................................................................................................... 12 8 TEST RESULTS ..................................................................................................................13 8.1 DIELECTRIC PERFORMANCE................................................................................................ 13 8.2 SYSTEM VALIDATION........................................................................................................... 13 8.3 SUMMARY OF MEASUREMENT RESULTS.............................................................................. 14 8.4CONCLUSION........................................................................................................................ 15 9 MEASUREMENT UNCERTAINTY ................................................................................. 15 10 MAIN TEST INSTRUMENTS......................................................................................... 16 11 TEST PERIOD................................................................................................................... 16 12 TEST LOCATION............................................................................................................. 17 ANNEX A MEASUREMENT PROCESS ............................................................................ 18 ANNEX B TEST LAYOUT ................................................................................................... 19 ANNEX C GRAPH RESULTS.............................................................................................. 23 ANNEX D SYSTEM VALIDATION RESULTS.................................................................. 59 ANNEX E PROBE CALIBRATION CERTIFICATE........................................................ 60 Telecommunication Metrology Center of Ministry of Information Industry No. 2006E00191 Page 5 of 68 1 COMPETENCE AND WARRANTIES Telecommunication Metrology Center of Ministry of Information Industry…

Text truncated - open the document above for the full version.

FCC ID: QISC2281 Report No: SYBH (R)54022006EB Confidential Information of Huawei. No Distribution without Permission Page1, Total83 Appendix A Effective Radiated Power of Transmitter According to CFR 47 (FCC) part 2.1046 & 22.913 FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page2, Total83 Channel 1013 TM1: FCC ID: QISC2281 Report No: SYBH (R)54022006EB Confidential Information of Huawei. No Distribution without Permission Page3, Total83 TM3: FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page4, Total83 Channel 283 TM1: FCC ID: QISC2281 Report No: SYBH (R)54022006EB Confidential Information of Huawei. No Distribution without Permission Page5, Total83 TM3: FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page6, Total83 Channel 777 TM1: FCC ID: QISC2281 Report No: SYBH (R)54022006EB Confidential Information of Huawei. No Distribution without Permission Page7, Total83 TM3: FCC ID: QISC2281 Report No: SYBH (R)54022006EB Confidential Information of Huawei. No Distribution without Permission Page8, Total83 Appendix B Modulation Characteristic Measurement According to CFR 47 (FCC) part 2.1047 & 22.915 FCC ID: QISC2281 Report No: SYBH (R)54022006EB Confidential Information of Huawei. No Distribution without Permission Page9, Total83 Channel 283（TM1） FCC ID: QISC2281 Report No: SYBH (R)54022006EB Confidential Information of Huawei. No Distribution without Permission Page10, Total83 Channel 283（TM3） FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page11, Total83 Appendix C Occupied Bandwidth Measurement According to CFR 47 (FCC) part 2.1049& 22.917 FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page12, Total83 Channel 1013（TM1） FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page13, Total83 Channel 1013（TM3） FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page14, Total83 Channel 283（TM1） FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page15, Total83 Channel 283（TM3） FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page16, Total83 Channel 777（TM1） FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page17, Total83 Channel 777（TM3） FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page18, Total83 Appendix D Measurement Results Band Edges According to CFR 47 (FCC) part 2.1051 & 22.917(e) FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page19, Total83 TM1 Left Edge (824 MHz) Channel 1013 A Unit dBm RBW 20 kHz VBW 200 kHz 1RM SWT 10 s 11.6 dB Offset RF Att 33 dB Ref Lvl 14.6 dBm Ref Lvl 14.6 dBm Center 824 MHzSpan 10 MHz1 MHz/ 1MAX -80 -70 -60 -50 -40 -30 -20 -10 0 10 -85.4 14.6 1 Marker 1 [T1] -13.42 dBm 824.00000000 MHz D1 -13 dBm FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page20, Total83 Right Edge (849MHz) Channel 777 A Unit dBm RBW 20 kHz VBW 200 kHz 1RM SWT 10 s 11.6 dB Offset RF Att 33 dB Ref Lvl 14.6 dBm Ref Lvl 14.6 dBm Center 849 MHzSpan 10 MHz1 MHz/ 1MAX -80 -70 -60 -50 -40 -30 -20 -10 0 10 -85.4 14.6 1 Marker 1 [T1] -13.45 dBm 849.00000000 MHz D1 -13 dBm FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page21, Total83 TM3 Left Edge (824 MHz) Channel 1013 A Unit dBm RBW 20 kHz VBW 200 kHz 1RM SWT 10 s 11.6 dB Offset RF Att 33 dB Ref Lvl 14.6 dBm Ref Lvl 14.6 dBm Center 824 MHzSpan 10 MHz1 MHz/ 1MAX -80 -70 -60 -50 -40 -30 -20 -10 0 10 -85.4 14.6 1 Marker 1 [T1] -13.13 dBm 824.00000000 MHz D1 -13 dBm FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page22, Total83 Right Edge (849MHz) Channel 777 A Unit dBm RBW 20 kHz VBW 200 kHz 1RM SWT 10 s 11.6 dB Offset RF Att 33 dB Ref Lvl 14.6 dBm Ref Lvl 14.6 dBm 1MAX Center 849 MHzSpan 10 MHz1 MHz/ -80 -70 -60 -50 -40 -30 -20 -10 0 10 -85.4 14.6 1 Marker 1 [T1] -13.16 dBm 849.00000000 MHz D1 -13 dBm FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page23, Total83 Appendix E Spurious Emission at Antenna Terminal According to CFR 47 (FCC) part 2.1051 & 22.917(e) FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page24, Total83 1.1 TM1 Channel 1013 FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page25, Total83 FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page26, Total83 FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page27, Total83 Channel 283 FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page28, Total83 FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page29, Total83 FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without Permission Page30, Total83 Channel 777 FCC ID: QISC2281 Report No: SYBH (R) 54022006EB Confidential Information of Huawei. No Distribution without P…

Text truncated - open the document above for the full version.

Report No: SYBH (R) 54022006EB FCC ID: QISC2281 FCC TEST REPORT OF Huawei 800MHz CDMA Handset M/N: C2281 Mar. 10, 2006 Reliability Laboratory of Huawei Technologies Co., Ltd. All Right Reserved Report No: SYBH(R)54022006EB Confidential Information of Huawei. No Distribution without Permission Page2, Total36 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Committee for Laboratories (CNAL), and accreditation number: L0310. 2. The laboratory has obtained the accreditation of THE AMERICAN ASSOCIATION FOR LABORATORY ACCREDITATION (A2LA), and Accreditation Council Certificate Number: 2174.01. 3. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 4. The laboratory also has been listed by the VCCI to perform EMC measurements. The accreditation number is C1758, R1672, and T153. 5. The test report is invalid if not marked with "exclusive stamp for the test report". 6. Any copy of the test report is invalid if not re-marked with the "exclusive stamp for the test report". 7. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 8. The test report is invalid if there is any evidence of erasure and/or falsification. 9. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 10. Normally, the test report is only responsible for the samples that have undergone the test. 11. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. Report No: SYBH(R)54022006EB Confidential Information of Huawei. No Distribution without Permission Page3, Total36 Huawei Technologies Co Ltd Huawei Industrial Base, Bantian Longgang Shenzhen 518128, P.R China Tel: +86 755 89651014 Fax: +86 755 89652518 REPORT ON FCC Test of Huawei 800MHz CDMA Handset M/N: C2281 Report No: SYBH (R) 54022006EB REGULATION FCC CFR47 Part 2: Subpart J; FCC CFR47 Part 22: Subpart H; FCC CFR47 Part …

Text truncated - open the document above for the full version.
