QISC2288CDMA Cellphone

User Manual HUAWEI C2288 Copyright © 2006 Huawei Technologies Co., Ltd. All Rights Reserved No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks and other Huawei trademarks are the trademarks or registered trademarks of Huawei Technologies Co., Ltd. in the People’s Republic of China and certain other countries. All other trademarks mentioned in this manual are the property of their respective holders. Notice The information in this manual is subject to change without notice. Every effort has been made in the preparation of this manual to ensure accuracy of the contents, but all statements, information, and recommendations in this manual do not constitute the warranty of any kind, express or implied. Safety Precautions Before using the phone, please read the safety precautions carefully and instruct your children suitably, so that you can use your phone correctly and safely. For details, see “Warnings and Precautions”. Do not switch on your phone when phone use is prohibited or when phone use may cause interference or danger. Do not use your phone while driving. Follow the rules or regulations in hospitals and health care facilities. Switch off your phone near medical apparatus. Switch off your phone in an aircraft. The phone may cause interference to control signals of the aircraft. Switch off your phone near high-precision electronic devices. The phone may affect the performance of these devices. Do not attempt to disassemble your phone or its accessories. Only qualified personnel are allowed to service or repair the phone. Do not place your phone or its accessories in containers with strong electromagnetic field. Do not place magnetic storage media near your phone. Radiation from the phone may delete the information stored on them. Do not put your phone in a high-temperature place or use it in a place with flammable gas such as a gas station. Keep your phone and its accessories away from children. Do not allow children to use your phone without guidance. Use approved batteries and chargers only to avoid explosion. Observe the laws or regulations on phone use. Respect others’ privacy and legal rights when using your phone. i Table of Contents 1 Getting to Know Your Phone.........................................................................1 2 Getting Started...............................................................................................4 3 Text Entry......................................................................................................8 4 Message........................................................................................................10 5 Phonebook....................................................................................................11 6 Alarm Clock.................................................................................................12 7 Security........................................................................................................13 8 Menu Description.........................................................................................14 9 Safety Precautions........................................................................................20 10 Warnings and Precautions.........................................................................21 1 1 Getting to Know Your Phone Front View of Your Phone 2 Key Description Key Description Send key Press it to make or answer a call. In the standby mode, press it to access the Call Records menu. Power key Press it to power your phone on or off, end a call or reject a call. In the non-standby mode, press it to return to the standby mode. Left soft key In the standby mode, press it to access the main menu. In the non-standby mode, press it to select a corresponding option. Right soft key In the non-standby mode, press it to select a corresponding option. Alphanumeric keys Press them to enter numbers, letters, and symbols. For items with a number prefix, press the numeric key to select a corresponding item. Navigation keys In the standby mode: Up: Create a new message. Left: Display the calendar. Down: Display contacts of the phonebook. Right: Access the inbox. During a call, press the up or down key to adjust the earpiece volume. * key During the editing, press it to display the list of symbols. In the English input mode, press and hold it to switch between the ABC mode and the Predictive Input mode. # key During the editing, press it to switch between input 3 modes. In the English input mode, press and hold it to switch among the upper case, lower case, and sentence caps mode. After the phone lock is enabled, press and hold it to lock the phone. Icon Description Icon Description Icon Description Network signal strength Silence on Phone lock enabled Vibration on New voice mail Alarm clock on Outside the network service area Call privacy enabled Text message received Roaming Urgent message received Battery level High urgent message received Calling 4 2 Getting Started Installing the Battery If your phone is on, press and hold the Power key to power off your phone. Removing the Battery If your phone is on, press and hold the Power key to power off your phone. Charging 1. Install the battery. 2. Connect the charger plug to the charger connector of your phone. 3. Connect the power cord of the travel charger to the power socket. 4. During the charging, the icon scrolls. When the icon stays still, it indicates that the battery is fully charged. 5. Disconnect the travel charger from the power socket and your phone. Caution: l Use the chrager manufactured or approved by Huawei only. l Do not use any damaged or worn out battery or charger. 5 l Charge the battery for at least eight hours at the first time. A new battery can reach its best performance after it is charged and recharged several times. Powering Your Phone On or Off Press and hold the Power key to …

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: ATCB Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISC2288 to be kept confidential: 1. Schematic diagram & PCB layout. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Turn-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base, Bantian, Longgang, Shenzhen, P.R China Post ZIP：518129 Page ：1/1 To: ATCB Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Authorization 2006-09-01 To whom it may concern: We the undersigned, hereby authorize American TCB. Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by American TCB. Inc. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Huawei Technologies Co., Ltd. . Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 14, 2006 RE: Huawei Technologies Co., Ltd. FCC ID: QISC2288 I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) FYI: In the future, kindly provide your application for FCC Certification on AmericanTCB application form. It is much easier to read than the document you presented. 2.) Please provide Internal Photographs for this device. You are reminded that all internal photographs must be clear enough to identify components on the printed wiring boards and must have all RF shielding removed. 3.) Please provide a label for this device as it will be shipped. 4.) Kindly indicate where I may find the voltage and currents through the final radio frequency amplifying device as specified by 2.1033(c)(8). 5.) I accept the fact that there are no user serviceable parts within this device, but it is still a requirement before any testing is initiated that the equipment be set to the upper end of it’s expected power range before testing. Please provide target RF power tune-up values and production tolerance for this device. 6.) Please provide a description of the digital modulation techniques employed as required by 2.1033(c)(13). 7.) Please provide an expanded block diagram of the RF Subsystem. Please refer to your existing block diagram for reference. 8.) Your application form specifies an RF power of 0.141 watts. Please provide units (ERP/EIRP/conducted/etc.). 9.) Your application form is not signed and dated by a responsible party. Who will assume ownership of this filing? 10.) There is no test firm contact, technical contact, or non-technical contact listed on the application form. Please review. 11.) The Manual quotes one body-worn distance on page 28, and a completely different value on page 24. Please correct. 12.) Is this device capable of connecting to a computer using a cable? If so, then either Part 15B Certification or DofC may apply. 13.) Please refer to the SAR report, Section 10 on Test Instrumentation. It appears that some instruments may have been out of calibration on the dates the testing was performed. 14.) The cover page of the SAR report indicates that this is a “Non-Type Approval”. What does this mean? 15.) Looking at the Test Setup photos, it appears that “Conducted Emissions for AC Ports” and “Radiated Disturbance” do not conform to the requirements of ANSI C63.4. Please review your Test Setup procedures and review that data as necessary. 16.) My apologies for being “thick-headed”, but I do not understand how your “Appendix A” corresponds to Effected Radiated Power (ERP). Please elaborate in your description. How do these instrument settings correspond to measurements made using the “Substitution Method”? z Page 2 October 14, 2006 William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

文档名称 文档密级 2006-10-23 华为机密，未经许可不得扩散 第1页, 共4页 1.) FYI: In the future, kindly provide your application for FCC Certification on AmericanTCB application form. It is much easier to read than the document you presented. Re: TUV Rheinland (Shenzhen) will deal with it. 2.) Please provide Internal Photographs for this device. You are reminded that all internal photographs must be clear enough to identify components on the printed wiring boards and must have all RF shielding removed. Re: TUV Rheinland (Shenzhen) will deal with it. 3.) Please provide a label for this device as it will be shipped. Re: TUV Rheinland (Shenzhen) will deal with it. 4.) Kindly indicate where I may find the voltage and currents through the final radio frequency amplifying device as specified by 2.1033(c)(8). Re: Please refer to document《FCC Test Report of HUAWEI CDMA 800MHz Mobile Phone C2288.doc》 on page 9,there has some description on it. Applied DC Voltages and Currents According to CFR (FCC) part 2, subpart 2, section 2.1033(c) (8). The voltage and current in the final RF stage is: Table 1 Applied DC Voltages and Currents Voltage: ＋2.85V Current: 150mA According to CFR (FCC) part 2, subpart 2, section 2.1033(c) (8) 5.) I accept the fact that there are no user serviceable parts within this device, but it is still a requirement before any testing is initiated that the equipment be set to the upper end of it’s expected power range before testing. Please provide target RF power tune-up values and production tolerance for this device. Re: Please refer to document《Tune-up Procedure-C2288.doc》 on page 1,there has 文档名称 文档密级 2006-10-23 华为机密，未经许可不得扩散 第2页, 共4页 some description on this problem. We have renewed the documents, and add the maximum power setting in this section. The CDMA2000 power adjust procedure Function: After the CDMA2000 transmit POWER calibration the C2288 can find the relationship between the TX-AGC and output power. So it can transmit the specific power according to the 3GPP2 protocol. Procedure: step1: The computer sets C2288 to the Factory test mode and works at US cellular band, sets the CMU200 to CDMA2000 Cellular Analyzer mode, connect C2288 with CMU200 using an RF cable. Step2: Tuning the TX-AGC of C2288 from 60 to 460 and measure the output power of the C2288 via CMU200, generally, the power will change from 26dBm to -55dBm, so we can find the relationship between the TX-AGC and output power. Generally, we set the max output power at 24.5+/-1dBm, and the corresponding TX-AGC value is 70+/-10. 6.) Please provide a description of the digital modulation techniques employed as required by 2.1033(c)(13). Re: Please refer to document《Operational_Description-C2288.doc》 on page 2,there has some description you wanted. Description of Digital Modulation Techniques ....... 7.) Please provide an expanded block diagram of the RF Subsystem. Please refer to your existing block diagram for reference. Re: The new detail block diagram has been submitted to you. 8.) Your application form specifies an RF power of 0.141 watts. Please provide units (ERP/EIRP/conducted/etc.). Re: It’s rated as ERP. 9.) Your application form is not signed and dated by a responsible party. Who will assume ownership of this filing? 文档名称 文档密级 2006-10-23 华为机密，未经许可不得扩散 第3页, 共4页 Re: Have been done. 10.) There is no test firm contact, technical contact, or non-technical contact listed on the application form. Please review. Re: Have been done. 11.) The Manual quotes one body-worn distance on page 28, and a completely different value on page 24. Please correct. Re: This is two section of the manual. The page 24 is the advice for the customer, and the page 28 gives the test distance. So that different, and we give more strict requirements for user’s operation. 12.) Is this device capable of connecting to a computer using a cable? If so, then either Part 15B Certification or DofC may apply. Re: The capable of connecting to computer is not the standard function of this mobile phone. So we don’t hope to do the Certification and DOC procedure. 13.) Please refer to the SAR report, Section 10 on Test Instrumentation. It appears that some instruments may have been out of calibration on the dates the testing was performed. Re: Thank you! The error has been modified. 14.) The cover page of the SAR report indicates that this is a “Non-Type Approval”. What does this mean? Re: The test laboratory (Telecommunication Metrology Center of Ministry of Information Industry) is a government laboratory of Ministry of Information Industry of China. They are also responsible for type approval test of Ministry information of China. So they should mark the reports which are not for type approval test of China MII. So they give the mark of “Non-Type Approval”. 15.) Looking at the Test Setup photos, it appears that “Conducted Emissions for AC Ports” and “Radiated Disturbance” do not conform to the requirements of ANSI C63.4. Please review your Test Setup procedures and review that data as necessary. Re: Please kindly give us more information on it. And the full anechoic chamber in section 2 is used for spurious emissions test according to FCC regulation. 文档名称 文档密级 2006-10-23 华为机密，未经许可不得扩散 第4页, 共4页 16.) My apologies for being “thick-headed”, but I do not understand how your “Appendix A” corresponds to Effected Radiated Power (ERP). Please elaborate in your description. How do these instrument settings correspond to measurements made using the “Substitution Method”? Re: The test use the substitution corrections method in the test, and the test result of Appendix A gives the result have been add the substitution corrections in test instrument. And the substitution corrections include the attenuation of the test site (space), cable loss and the gain of substitution antenna. Following gives the detail calculation of the correction factor. The substitution corrections are obtained as described below: A SUBST = PSUBST_TX - PSUBST_RX - LSUBST_CABLES + GSUBST_TX_ANT Where ASUBST is the…

Text truncated - open the document above for the full version.

HUAWEI C2288 CDMA Mobile Phone SECRET Page1,Total 6 External Photos of HUAWEI C2288 HUAWEI C2288 CDMA Mobile Phone SECRET Page2,Total 6 HUAWEI C2288 CDMA Mobile Phone SECRET Page3,Total 6 HUAWEI C2288 CDMA Mobile Phone SECRET Page4,Total 6 HUAWEI C2288 CDMA Mobile Phone SECRET Page5,Total 6 HUAWEI C2288 CDMA Mobile Phone SECRET Page6,Total 6

HUAWEI C2288 CDMA Mobile Station SECRET Page1, Total 1 ID Label Location_C2288

HUAWEI C2288 CDMA Mobile Station SECRET Page1, Total 1 ID Label _C2288

HUAWEI C2288 CDMA Mobile Phone SECRET Page1,Total 6 Internal Photos of HUAWEI C2288 HUAWEI C2288 CDMA Mobile Phone SECRET Page2,Total 6 HUAWEI C2288 CDMA Mobile Phone SECRET Page3,Total 6 HUAWEI C2288 CDMA Mobile Phone SECRET Page4,Total 6 HUAWEI C2288 CDMA Mobile Phone SECRET Page5,Total 6 HUAWEI C2288 CDMA Mobile Phone SECRET Page6,Total 6

Telecommunication Metrology Center of Ministry of Information Industry No. 2006E01417Page 38 of 74 Fig. 16 Z-Scan at power reference point (CDMA 835MHz CH384) Telecommunication Metrology Center of Ministry of Information Industry No. 2006E01417Page 39 of 74 CDMA 1X Right Cheek Low Date/Time: 2006-9-11 14:36:34 Electronics: DAE3 Sn589 Medium: HEAD 835 Medium parameters used (interpolated): f = 835 MHz; ı = 0.92 mho/m; İ r = 41.9; ȡ = 1000 kg/m 3 Ambient Temperature:23.3 o C Liqiud Temperature: 22.5 o C Communication System: CDMA 1X-new Frequency: 824.7 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.51, 6.51, 6.51) Cheek Low/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.579 mW/g Cheek Low/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 20.6 V/m; Power Drift = -0.200 dB Peak SAR (extrapolated) = 0.721 W/kg SAR(1 g) = 0.515 mW/g; SAR(10 g) = 0.347 mW/g Maximum value of SAR (measured) = 0.550 mW/g   0 dB = 0.550mW/g Fig. 17 Right Hand Touch Cheek CDMA 835MHz CH1013 Telecommunication Metrology Center of Ministry of Information Industry No. 2006E01417Page 40 of 74 Fig. 18 Z-Scan at power reference point (CDMA 835MHz CH1013) Telecommunication Metrology Center of Ministry of Information Industry No. 2006E01417Page 41 of 74 CDMA 1X Right Tilt High Date/Time: 2006-9-11 13:54:57 Electronics: DAE3 Sn589 Medium: HEAD 835 Medium parameters used (interpolated): f = 835 MHz; ı = 0.92 mho/m; İ r = 41.9; ȡ = 1000 kg/m 3 Ambient Temperature:23.3 o C Liqiud Temperature: 22.5 o C Communication System: CDMA 1X-new Frequency: 848.31 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.51, 6.51, 6.51) Tilt High/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.597 mW/g Tilt High/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 23.5 V/m; Power Drift = -0.200 dB Peak SAR (extrapolated) = 0.748 W/kg SAR(1 g) = 0.538 mW/g; SAR(10 g) = 0.361 mW/g Maximum value of SAR (measured) = 0.578 mW/g   0 dB = 0.578mW/g Fig. 19 Right Hand Tilt 15°CDMA 835MHz CH777 Telecommunication Metrology Center of Ministry of Information Industry No. 2006E01417Page 42 of 74 Fig. 20 Z-Scan at power reference point (CDMA 835MHz CH777) Telecommunication Metrology Center of Ministry of Information Industry No. 2006E01417Page 43 of 74 CDMA 1X Right Tilt Middle Date/Time: 2006-9-11 14:21:27 Electronics: DAE3 Sn589 Medium: HEAD 835 Medium parameters used (interpolated): f = 835 MHz; ı = 0.92 mho/m; İ r = 41.9; ȡ = 1000 kg/m 3 Ambient Temperature:23.3 o C Liqiud Temperature: 22.5 o C Communication System: CDMA 1X-new Frequency: 836.52 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.51, 6.51, 6.51) Tilt Middle/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.479 mW/g Tilt Middle/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 19.9 V/m; Power Drift = -0.151 dB Peak SAR (extrapolated) = 0.609 W/kg SAR(1 g) = 0.443 mW/g; SAR(10 g) = 0.299 mW/g Maximum value of SAR (measured) = 0.473 mW/g   0 dB = 0.473mW/g Fig. 21 Right Hand Tilt 15°CDMA 835MHz CH384 Telecommunication Metrology Center of Ministry of Information Industry No. 2006E01417Page 44 of 74 Fig. 22 Z-Scan at power reference point (CDMA 835MHz CH384) Telecommunication Metrology Center of Ministry of Information Industry No. 2006E01417Page 45 of 74 CDMA 1X Right Tilt Low Date/Time: 2006-9-11 14:48:32 Electronics: DAE3 Sn589 Medium: HEAD 835 Medium parameters used (interpolated): f = 835 MHz; ı = 0.92 mho/m; İ r = 41.9; ȡ = 1000 kg/m 3 Ambient Temperature:23.3 o C Liqiud Temperature: 22.5 o C Communication System: CDMA 1X-new Frequency: 824.7 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.51, 6.51, 6.51) Tilt Low/Area Scan (51x81x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.315 mW/g Tilt Low/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 16.8 V/m; Power Drift = 0.056 dB Peak SAR (extrapolated) = 0.394 W/kg SAR(1 g) = 0.290 mW/g; SAR(10 g) = 0.198 mW/g Maximum value of SAR (measured) = 0.310 mW/g   0 dB = 0.310mW/g Fig. 23 Right Hand Tilt 15°CDMA 835MHz CH1013 Telecommunication Metrology Center of Ministry of Information Industry No. 2006E01417Page 46 of 74 Fig. 24 Z-Scan at power reference point (CDMA 835MHz CH1013) Telecommunication Metrology Center of Ministry of Information Industry No. 2006E01417Page 47 of 74 CDMA 1X Body Toward Phantom High Date/Time: 2006-9-7 13:51:32 Electronics: DAE3 Sn589 Medium: Body 835 Medium parameters used (interpolated): f = 835 MHz; ı = 0.95 mho/m; İ r = 54.6; ȡ = 1000 kg/m 3 Ambient Temperature:23.3 o C Liqiud Temperature: 22.5 o C Communication System: CDMA 1X-new Frequency: 848.31 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1736 ConvF(6.45, 6.45, 6.45) Toward Phantom High/Area Scan (71x121x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 0.356 mW/g Toward Phantom High/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 19.6 V/m; Power Drift = -0.127 dB Peak SAR (extrapolated) = 0.426 W/kg SAR(1 g) = 0.329 mW/g; SAR(10 g) = 0.231 mW/g Maximum value of SAR (measured) = 0.351 mW/g   0 dB = 0.351mW/g Fig. 25 CDMA 835MHz, Body, Towards Phantom, CH777 Telecommunication Metrology Center of Ministry of Information Industry No. 2006E01417Page 48 of 74 Fig. 26 Z-Scan at power reference point (CDMA 835MHz, Body,Towards Phantom, CH777) Telecommunication Metrology Center of Ministry of Information Industry No. 2006E01417Page 49 of 74 CDMA 1X Body Toward Phantom Middle Date/Time: 2006-9-7 14:33:46 Electronics: DAE3 Sn589 Medium: Body 835 Medium parameters used (interpolated): f = 835 MHz; ı = 0.95 mho/m; İ r = 54.6; ȡ = 1000 kg/m 3 Ambient Temperature:23.3 o C Liqiud Temperature: 22.5 o C Communication System: CDMA 1X-new Frequency: 836.52 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN173…

Text truncated - open the document above for the full version.

Report No: SYBH(E) 06072006 FCC ID: QISC2288 FCC TEST REPORT OF HUAWEI CDMA 800MHz Mobile Phone M/N: C2288 Aug. 02, 2006 Reliability Laboratory of Huawei Technologies Co., Ltd. All Right Reserved Report No: SYBH(E)06072006 Confidential Information of HUAWEI. No Distribution without Permission Page2, Total37 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Committee for Laboratories (CNAL), and accreditation number: L0310. 2. The laboratory has obtained the accreditation of THE AMERICAN ASSOCIATION FOR LABORATORY ACCREDITATION (A2LA), and Accreditation Council Certificate Number: 2174.01. 3. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 4. The laboratory also has been listed by the VCCI to perform EMC measurements. The accreditation number is C1758, R1672, and T153. 5. The test report is invalid if not marked with "exclusive stamp for the test report". 6. Any copy of the test report is invalid if not re-marked with the "exclusive stamp for the test report". 7. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 8. The test report is invalid if there is any evidence of erasure and/or falsification. 9. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 10. Normally, the test report is only responsible for the samples that have undergone the test. 11. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. Report No: SYBH(E)06072006 Confidential Information of HUAWEI. No Distribution without Permission Page3, Total37 Huawei Technologies Co Ltd Huawei Industrial Base, Bantian Longgang Shenzhen 518128, P.R China Tel: +86 755 89651014 Fax: +86 755 89652518 REPORT ON FCC Test of HUAWEI CDMA Mobile Phone M/N: C2288 Report No: SYBH (E) 06072006 REGULATION FCC CFR47 Part 2: Subpart J; FCC CFR47 Part 22: Subpart H; FCC CFR47 Part 15: Subpart B; CONCLUSION There are 9 items need to be tested, 9 items have been tested. The sample of the model completely meets the requirements Final Judgement: Pass General Manager 2006.08.28 Tang Shuanli Date Name signature Technical Responsibility For Area of Testing 2006.08.26 Zhang Xinghai Date Name signature Test Lab Engineer 2006.09.01 Zhu Yongsheng Date Name signature Report No: SYBH(E)06072006 Confidential Information of HUAWEI. No Distribution without Permission Page4, Total37 Contents 1 Summary ..............................................................................................................................................5 2 Product Description.............................................................................................................................6 2.1 PRODUCTION INFORMATION...............................................................................................................6 2.2 MODIFICATION INFORMATION.............................................................................................................6 3 Test Site Description............................................................................................................................7 3.1 TESTING PERIOD..............................................................................................................................7 3.2 GENERAL SET UP DESCRIPTION.........................................................................................................7 4 Product Description .............................................................................................................................8 4.1 TECHNICAL CHARACTERISTICS...........................................................................................................8 4.2 EUT IDENTIFICATION LIST...............................................................................................................10 5 Main Test Instruments........................................................................................................................11 6 Transmitter Measurements.................................................................................................................12 6.1 EFFECTIVE RADIATED POWER OF TRANSMITTER (ERP)......................................................................12 6.2 MODULATION CHARACTERISTICS......................................................................................................15 6.3 OCCUPIED BANDWIDTH...................................................................................................................17 6.4 BAND EDGES COMPLIANCE..............................................................................................................19 6.5 SPURIOUS EMISSION AT ANTENNA TERMINAL.....................................................................................21 6.6 RADIATED SPURIOUS EMISSION.......................................................................................................23 6.7 FREQUENCY STABILITY...................................................................................................................27 7 EMC Test .................................................................................................................................…

Text truncated - open the document above for the full version.
