HUAWEI ® Airbridge cBTS3612-800 12-carrier CDMA Base Station User Manual V100R001 Airbridge cBTS3612-800 12-carrier CDMA Base Station User Manual Manual Version T2-030160-20020720-C-1.20 Product Version V100R001 BOM 31013260 Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. Please feel free to contact our local office, customer care center or company headquarters. Huawei Technologies Co., Ltd. Address: Huawei Customer Service Building, Kefa Road, Science-based Industrial Park, Shenzhen, P. R. China Postal Code: 518057 Website: http://www.huawei.com Phone: +86-755-26540036 Fax: +86-755-26540035 Email: [email protected] © 2002 Huawei Technologies Co., Ltd. All Rights Reserved No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks ® , HUAWEI ® , C&C08, EAST8000, HONET, ViewPoint, INtess, ETS, DMC, SBS, TELLIN, InfoLink, Netkey, Quidway, SYNLOCK, Radium, , M900/M1800, TELESIGHT, Quidview, NETENGINE, Musa, OptiX, Airbridge, Tellwin, Inmedia, VRP, DOPRA, iTELLIN, C&C08 iNET, iBill and infox are trademarks of Huawei Technologies Co., Ltd. Notice The information in this document is subject to change without notice. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document don't constitute the warranty of any kind, express or implied. Feedback Form Huawei Technologies Co., Ltd. welcomes your feedback on this document. Your comments can be of great value in helping us improve our documentation. Please fax this form to +86-755-26540035 , Attn: Information Development Department , or email to [email protected]. Airbridge cBTS3612-800 12-carrier CDMA Base Station User Manual Version: T2-030160-20020720-C-1.20 1. Please rate the effectiveness of this document by checking the appropriate columns: Excellent Good Fair Poor Ease of Use Clarity Completeness Accuracy Organization Illustrations Appearance Overall Satisfaction 2. Please check the ways you feel we could improve this document: r Improve the organization r Add more details r Improve the table of contents r Make it more concise/brief r Include more figures r Make it less technical r Add more examples r Improve the index r Add more/better quick reference r Add more step-by-step procedures Please provide details for the suggested improvement: 3. What did you like most about this document? 4. Feel free to write any comments below or on an attached sheet. If we may contact you concerning your comments, please complete the following: Name: ________________Title:______________ Phone: _______________ Company: __________________________________ Email: _______________ Address: __________________________________ Date: _______________ About This Manual Contents The manual introduces the insulation methods and procedure of cBTS3612-800. It is divided into three modules: l Module 1: System Description 1. System Overview 2 Hardware Architecture 3 Software Architecture 4 System Function 5 System Configuration Appendix A Technical Indices of Receiver and Transmitter Appendix B EMC Indices Appendix C Environment Indices Appendix D Standard Compliance Appendix E Abbreviation l Module 2: BTS Maintenance Sub Module 1 Routine Maintenance Instructions Sub Module 2 Common Fault Analysis and Locating Sub Module 3 Board and Part Replacement Sub Module 4 Board Indicators and DIP Switches Target Readers The manual is intended for the following readers: l Engineers & technicians l Operation & maintenance personnel Conventions This document uses the following conventions: I. General conventions Convention Description Arial Normal paragraphs are in Arial. Arial Narrow Warnings, cautions, notes and tips are in Arial Narrow. Terminal Display Terminal Display is in Courier New ; message input by the user via the terminal is in boldface. II. Command conventions Convention Description boldface font Command keywords (which must be input unchanged) are in boldface. italic font Command arguments for which you supply values are in italics. [ ] Elements in square brackets [ ] are optional. { x | y | ... } Alternative keywords are grouped in braces and separated by vertical bars. One is selected. [ x | y | ... ] Optional alternative keywords are grouped in square brackets and separated by vertical bars. One (or none) is selected. { x | y | ... } * Alternative keywords are grouped in braces and separated by vertical bars. A minimum of one and maximum of all can be selected. [ x | y | ... ] * Optional alternative keywords are grouped in square brackets and separated by vertical bars. Many (or none) are selected. ! A line starting with an exclamation mark is comments. III. GUI conventions Convention Description < > Message entered via the terminal is within angle brackets. [ ] MMIs, menu items, data table and field names are inside square brackets [ ]. / Multi-level menus are separated by forward slashes (/). Menu items are in boldface. For example, [File/Create/Folder]. IV. Keyboard operation Format Description <Key> Press the key with key name expressed with a pointed bracket, e.g. <Enter>, <Tab>, <Backspace>, or<A>. <Key1+Key2> Press the keys concurrently; e.g. <Ctrl+Alt+A>means the three keys should be pressed concurrently. <Key1, Key2> Press the keys in turn, e.g. <Alt, A>means the two keys should be pressed in turn. [Menu Option] The item with a square bracket indicates the menu option, e.g. [System] option on the main menu. The item with a pointed bracket indicates the functional button option, e.g. <OK> button on some interface. [Menu1/Menu2/Menu3] Multi-level menu options, e.g. [System/Option/Color setup] on the main menu indicates [Color Setup] on the menu option of [Option], which is on the menu option of [System]. V. Mouse operation Action Description Click Press the left button or right button quickly (left button by…

Text truncated - open the document above for the full version.

User Manual Airbridge cBTS3612-800 12-carrier CDMA Base Station Table of Contents 03Q-0112-20020720-120 i Table of Contents 1 Overview......................................................................................................................................1-1 1.1 Purposes of cBTS3612-800 Routine Maintenance............................................................1-1 1.2 Classification of cBTS3612-800 Routine Maintenance Operations...................................1-1 1.2.1 Classification According to Implementing Methods.................................................1-1 1.2.2 Classification by Period Length...............................................................................1-1 1.3 Guide to the Usage of cBTS3612-800 Routine Maintenance records and cBTS3612-800 Routine Maintenance Instructions............................................................................................1-2 1.3.1 cBTS3612-800 Daily Unexpected Fault Handling Record......................................1-3 1.3.2 cBTS3612-800 Monthly Maintenance Record.........................................................1-4 1.3.3 cBTS3612-800 Quarterly Maintenance Record......................................................1-5 1.3.4 cBTS3612-800 Yearly Maintenance Record...........................................................1-6 2 cBTS3612-800 Monthly Maintenance Instructions..................................................................2-1 3 Quarterly Maintenance Instructions.........................................................................................3-1 4 cBTS3612-800 Yearly Maintenance Instructions.....................................................................4-1 5 Return Loss, VSWR and Reflection Coefficient......................................................................5-1 User Manual Airbridge cBTS3612-800 12-carrier CDMA Base Station 1 Overview 03Q-0112-20020720-120 1-1 1 Overview cBTS3612-800 Routine Maintenance Instructions describes in details the contents and methods of cBTS3612-800 routine maintenance operations. It serves as a reference in determining the routine maintenance schedule of a particular site. cBTS3612-800 Routine Maintenance consists of: 1) Purpose of cBTS3612-800 routine maintenance; 2) Classification of cBTS3612-800 routine maintenance operations; 3) Logging of routine maintenance operations. 1.1 Purposes of cBTS3612-800 Routine Maintenance Normal system operation of cBTS3612-800 in different running environment depends on effective routine maintenance. cBTS3612-800 routine maintenance is intended to detect and solve problems in due time to prevent trouble. 1.2 Classification of cBTS3612-800 Routine Maintenance Operations 1.2.1 Classification According to Implementing Methods I. Conventional maintenance To observe the operation of the system, and test and analyze equipment performance during system operation. II. Unconventional maintenance To test if the performance of system equipment has degraded by artificially creating some faults and observe system performance with these faults. For example, maintenance personnel may artificially create some faults and test if the alarm system reports alarm correctly. 1.2.2 Classification by Period Length I. Unscheduled maintenance Maintenance operations incurred by equipment fault or network adjustment. For example, maintenance tasks triggered by user complaint, damage of equipment and User Manual Airbridge cBTS3612-800 12-carrier CDMA Base Station 1 Overview 03Q-0112-20020720-120 1-2 line fault. Solving of problems left over by daily maintenance operations is also regarded as unscheduled maintenance operation. II. Daily maintenance Maintenance tasks conducted daily. cBTS3612-800 Daily maintenance helps maintenance personnel keep track of the operating conditions of the equipment at any moment so that problems can be solved in time. When a problem is detected in daily maintenance, record it in detail to help eliminate it in time. III. Periodical maintenance Maintenance tasks conducted regularly. Periodical maintenance helps maintenance personnel keep track of the long-term performance of the equipment. Periodical maintenance includes: monthly maintenance, quarterly maintenance and yearly maintenance. 1.3 Guide to the Usage of cBTS3612-800 Routine Maintenance records and cBTS3612-800 Routine Maintenance Instructions 1) Note down in details the unexpected faults occurred in cBTS3612-800 daily maintenance operations in cBTS3612-800 Daily Unexpected Fault Handling Record for future reference. The user may modify the record according to the actual needs, or compile the records into manuals. 2) Note down in details the actual maintenance operations carried out during cBTS3612-800 monthly maintenance in cBTS3612-800 Monthly Maintenance Record. For details, see cBTS 3612 Monthly Maintenance Operation Instruction. 3) Note down in details the actual maintenance operations carried out during cBTS3612-800 quarterly maintenance in cBTS Quarterly Maintenance Record. For details, see cBTS 3612 Quarterly Maintenance Operation Instruction. 4) Note down in details the actual maintenance operations carried out during cBTS3612-800 yearly maintenance in cBTS3612-800 Yearly Maintenance Record. For details, see cBTS 3612 Yearly Maintenance Operation Instruction. User Manual Airbridge cBTS3612-800 12-carrier CDMA Base Station 1 Overview 03Q-0112-20020720-120 1-3 1.3.1 cBTS3612-800 Daily Unexpected Fault Handling Record Site Belong-to BSC Time when fault occurred: Time when fault is solved: Person on duty: Handled by: Classification of fault: € Primary power supply € Secondary power supply € Base Band Subrack € RF Subrack € CDU/DFU/RLDU Subrack € Antenna & Feeder System € Others Fault detected: ? With user complaint ? From the alarm system ? In Daily maintenance ? From other sources Description of fault: Alarm Handling & Result: User Manual Airbridge cBTS3612-800 12-carrier CDMA Base Station 1 Overview 03Q-0112-20020720-120 1…

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 1 von 37 Page 1 of 37 Auftraggeber: Client: Huawei Technologies Co., Ltd. Kefa Rd. Science–Based Industrial Park Nanshan District Shenzhen 518057 P.R. China Gegenstand der Prüfung: Test item: CDMA Base Station Bezeichnung: Identification: cBTS3612-800 Serien-Nr.: Serial No. Pre-production Model Wareneingangs-Nr.: Receipt No.: 63004686 Eingangsdatum: Date of receipt: 01.07.2002 Prüfort: Testing location: Huawei EMC Laboratory FCC registered test site number 97456 as of October 10. 2000. Prüfgrundlage: Test specification: FCC Part 22, subpart H, §22.901(d) FCC Part 2, subpart J, §2.1033 - §2.1057 Prüfergebnis: Test Result Der vorstehend beschriebene Prüfgegenstand wurde geprüft und entspricht oben genannter Prüfgrundlage. The a. m. test item passed. geprüft / tested by: Yu Huichun kontrolliert / reviewed by: Zhang Xinghai 2002-07-25 Yu Huichun Datum Name Unterschrift Date Name Signature 2002 –08-06 Zhang Xinghai Datum Name Unterschrift Date Name Signature Sonstiges / Other Aspects: Abkürzungen: OK, Pass = entspricht Prüfgrundlage Fail = entspricht nicht Prüfgrundlage N/A = nicht anwendbar Abbreviations: OK, Pass = passed Fail = failed N/A = not applicable Dieser Prüfbericht bezieht sich nur auf den o.g. Prüfgegenstand und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report relates to the a. m. test item. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark on this or similar products. Authorized format 16.12.1996, R.M. Huawei Technologies Co., Ltd. Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 2 von 37 Page 2 of 37 1. SUMMARY Below table summarizes the measurements and results for the CDMA base station. Detailed results and descriptions are shown in the following pages. FCC Measurement Specification FCC Limits Part(s) Description Result 2.1046 22.913 RF Output Power PASS 2.1047 22.901 Modulation Characteristics PASS 2.1049 22.917 Occupied Bandwidth PASS 2.1051 22.917(e) Spurious Emission at Antenna Terminals PASS 2.1053 22.917(e) Field Strength of Spurious Emissions PASS 2.1055 22.355 Frequency Stability PASS The base station is intended for use in the licensed domestic public cellular radio service and is designed to be placed and operated under the conditions of FCC rules part 22 subpart H, section 22.901 (d). Huawei Technologies Co., Ltd. Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 3 von 37 Page 3 of 37 2. TABLE OF CONTENT 1. SUMMARY........................................................................................................................................... 2 2. TABLE OF CONTENT ......................................................................................................................... 3 3. PRODUCT DESCRIPTION.................................................................................................................. 5 4. TEST SITE DESCRIPTION ................................................................................................................. 6 4.1. T ESTING P ERIOD ................................................................................................................................. 6 4.2. G ENERAL S ET UP D ESCRIPTION ........................................................................................................... 6 5. PRODUCT DESCRIPTION.................................................................................................................. 7 5.1. T ECHNICAL C HARACTERISTICS ............................................................................................................ 7 5.1.1. Frequency Range...................................................................................................................... 7 5.1.2. Transmitter Power Rating.......................................................................................................... 7 5.1.3. Channel Spacing / Separation .................................................................................................. 7 5.1.4. Type of Emission ....................................................................................................................... 7 5.1.5. Environmental Conditions for Base station ............................................................................... 8 5.1.6. Power Source ............................................................................................................................ 8 5.1.7. Tune-up Procedure ................................................................................................................... 8 5.1.8. Applied DC Voltages and Currents ........................................................................................... 8 5.2. EUT I DENTIFICATION L IST ................................................................................................................... 9 5.2.1. FCC Identification .................................................................................................................... 12 6. TRANSMITTER MEASUREMENTS.................................................................................................. 13 6.1. RF O UTPUT P OWER ......................................................................................................................... 13 6.1.1. Test Conditions ....................................................................................................................... 13 6.1.2. Test Specifications and Limits.................................................................................................13 6.1.2.1. Specification ................................................................................................................................... 13 6.1.2.2. Limits .......…

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. Appendix A Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 1 von 3 Page 1 of 3 Appendix A Channel Power Measurement According to CFR 47 (FCC) part 2.1046 Co., Ltd. Appendix A Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 2 von 3 Page 2 of 3 Channel 1 Co., Ltd. Appendix A Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 3 von 3 Page 3 of 3 Channel 2

Huawei Technologies Co., Ltd. Appendix B Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 1 von 3 Page 1 of 3 Appendix B Modulation Characteristic Measurement According to CFR 47 (FCC) part 2.1047 Huawei Technologies Co., Ltd. Appendix B Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 2 von 3 Page 2 of 3 Channel 1 Huawei Technologies Co., Ltd. Appendix B Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 3 von 3 Page 3 of 3 Channel 2

Huawei Technologies Co., Ltd. Appendix C Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 1 von 3 Page 1 of 3 Appendix C Occupied Bandwidth Measurement According to CFR 47 (FCC) part 2.1049 Huawei Technologies Co., Ltd. Appendix C Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 2 von 3 Page 2 of 3 Channel 1 Huawei Technologies Co., Ltd. Appendix C Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 3 von 3 Page 3 of 3 Channel 2

Huawei Technologies Co., Ltd. Appendix D Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 1 von 9 Page 1 of 9 Appendix D Spurious Emission at Antenna Terminal Measurements According to CFR 47 (FCC) part 2.1051 Huawei Technologies Co., Ltd. Appendix D Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 2 von 9 Page 2 of 9 Huawei Technologies Co., Ltd. Appendix D Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 3 von 9 Page 3 of 9 Huawei Technologies Co., Ltd. Appendix D Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 4 von 9 Page 4 of 9 Huawei Technologies Co., Ltd. Appendix D Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 5 von 9 Page 5 of 9 Huawei Technologies Co., Ltd. Appendix D Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 6 von 9 Page 6 of 9 Huawei Technologies Co., Ltd. Appendix D Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 7 von 9 Page 7 of 9 Huawei Technologies Co., Ltd. Appendix D Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 8 von 9 Page 8 of 9 Huawei Technologies Co., Ltd. Appendix D Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 9 von 9 Page 9 of 9

Huawei Technologies Co., Ltd. Appendix E Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 1 von 28 Page 1 of 28 Appendix E Field Strength of Spurious Radiation Measurements According to CFR 47 (FCC) part 2.1053 Huawei Technologies Co., Ltd. Appendix E Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 2 von 27 Page 2 of 27 MEASUREMENT RESULT: "CBTS3612_pre PK" 7/17/02 4:40PM Frequency Level Height Azimuth Polarisation MHz dBm cm deg 30.000000 -60.12 100.0 0.00 VERTICAL 31.077778 -60.79 100.0 270.00 VERTICAL 32.155556 -51.38 400.0 270.00 HORIZONTAL 33.233333 -64.43 100.0 270.00 VERTICAL 34.311111 -60.47 100.0 0.00 HORIZONTAL 35.388889 -64.60 100.0 0.00 VERTICAL 36.466667 -66.28 100.0 270.00 HORIZONTAL 37.544444 -69.96 200.0 180.00 VERTICAL 38.622222 -69.10 400.0 0.00 VERTICAL 39.700000 -66.53 100.0 180.00 HORIZONTAL 40.777778 -68.26 100.0 90.00 HORIZONTAL 41.855556 -65.75 200.0 90.00 HORIZONTAL 42.933333 -68.97 200.0 90.00 HORIZONTAL 44.011111 -69.40 400.0 270.00 VERTICAL 45.088889 -72.18 300.0 180.00 VERTICAL 46.166667 -74.13 200.0 90.00 HORIZONTAL 47.244444 -78.20 300.0 270.00 VERTICAL 48.322222 -76.37 100.0 0.00 HORIZONTAL 49.400000 -78.81 200.0 90.00 HORIZONTAL 50.477778 -74.82 100.0 270.00 VERTICAL 51.555556 -72.10 100.0 90.00 VERTICAL 52.633333 -73.89 100.0 0.00 VERTICAL 53.711111 -78.17 100.0 270.00 VERTICAL 54.788889 -77.14 200.0 90.00 HORIZONTAL 55.866667 -73.54 300.0 90.00 HORIZONTAL 56.944444 -72.88 300.0 90.00 HORIZONTAL 58.022222 -75.25 300.0 270.00 HORIZONTAL 59.100000 -77.69 300.0 270.00 HORIZONTAL 60.177778 -78.45 100.0 90.00 VERTICAL 61.255556 -78.48 300.0 270.00 HORIZONTAL 62.333333 -76.30 300.0 270.00 HORIZONTAL 63.411111 -70.85 100.0 180.00 VERTICAL 64.488889 -76.01 200.0 270.00 HORIZONTAL 65.566667 -76.76 300.0 270.00 HORIZONTAL 66.644444 -77.42 300.0 90.00 HORIZONTAL 67.722222 -79.18 300.0 90.00 HORIZONTAL 68.800000 -78.68 300.0 90.00 HORIZONTAL 69.877778 -78.53 300.0 270.00 HORIZONTAL 70.955556 -79.68 200.0 270.00 HORIZONTAL 72.033333 -79.12 200.0 270.00 HORIZONTAL 73.111111 -78.75 300.0 270.00 HORIZONTAL 74.188889 -79.13 100.0 0.00 VERTICAL 75.266667 -79.32 200.0 270.00 VERTICAL 76.344444 -78.71 200.0 270.00 VERTICAL 77.422222 -76.55 200.0 270.00 VERTICAL Huawei Technologies Co., Ltd. Appendix E Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 3 von 27 Page 3 of 27 MEASUREMENT RESULT: "CBTS3612_pre PK" (continued) Frequency Level Height Azimuth Polarisation MHz dBm cm deg 78.500000 -76.61 300.0 270.00 HORIZONTAL 79.577778 -74.79 200.0 90.00 HORIZONTAL 80.655556 -76.39 200.0 90.00 HORIZONTAL 81.733333 -76.63 200.0 90.00 HORIZONTAL 82.811111 -76.56 300.0 270.00 HORIZONTAL 83.888889 -75.81 200.0 270.00 HORIZONTAL 84.966667 -76.41 300.0 90.00 VERTICAL 86.044444 -75.64 100.0 90.00 VERTICAL 87.122222 -74.35 200.0 180.00 HORIZONTAL 88.200000 -74.56 200.0 0.00 HORIZONTAL 89.277778 -68.19 400.0 0.00 HORIZONTAL 90.355556 -72.87 200.0 0.00 HORIZONTAL 91.433333 -71.91 300.0 180.00 HORIZONTAL 92.511111 -70.82 400.0 180.00 HORIZONTAL 93.588889 -72.42 200.0 0.00 HORIZONTAL 94.666667 -73.47 300.0 180.00 HORIZONTAL 95.744444 -74.20 200.0 180.00 HORIZONTAL 96.822222 -70.66 100.0 180.00 HORIZONTAL 97.900000 -74.58 200.0 180.00 HORIZONTAL 98.977778 -72.32 300.0 90.00 HORIZONTAL 100.055556 -73.11 200.0 0.00 HORIZONTAL 101.133333 -72.27 200.0 0.00 HORIZONTAL 102.211111 -72.93 200.0 90.00 HORIZONTAL 103.288889 -71.67 200.0 0.00 HORIZONTAL 104.366667 -70.94 200.0 0.00 HORIZONTAL 105.444444 -71.12 300.0 0.00 HORIZONTAL 106.522222 -69.49 200.0 0.00 HORIZONTAL 107.600000 -70.12 200.0 0.00 HORIZONTAL 108.677778 -70.25 300.0 90.00 HORIZONTAL 109.755556 -70.89 300.0 0.00 VERTICAL 110.833333 -69.03 100.0 0.00 VERTICAL 111.911111 -71.43 300.0 0.00 VERTICAL 112.988889 -69.33 100.0 0.00 HORIZONTAL 114.066667 -71.45 200.0 180.00 HORIZONTAL 115.144444 -71.10 400.0 90.00 HORIZONTAL 116.222222 -70.85 300.0 0.00 HORIZONTAL 117.300000 -70.51 400.0 0.00 HORIZONTAL 118.377778 -63.72 100.0 0.00 HORIZONTAL 119.455556 -71.15 100.0 90.00 HORIZONTAL 120.533333 -62.23 300.0 0.00 VERTICAL 121.611111 -72.17 200.0 270.00 HORIZONTAL 122.688889 -72.36 100.0 270.00 HORIZONTAL 123.766667 -72.37 100.0 270.00 HORIZONTAL 124.844444 -72.15 300.0 180.00 HORIZONTAL 125.922222 -71.47 100.0 180.00 HORIZONTAL Huawei Technologies Co., Ltd. Appendix E Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 4 von 27 Page 4 of 27 MEASUREMENT RESULT: "CBTS3612_pre PK" (continued) Frequency Level Height Azimuth Polarisation MHz dBm cm deg 127.000000 -73.51 100.0 90.00 VERTICAL 128.077778 -73.98 100.0 180.00 VERTICAL 129.155556 -73.87 100.0 270.00 VERTICAL 130.233333 -73.57 200.0 180.00 HORIZONTAL 131.311111 -72.90 400.0 0.00 HORIZONTAL 132.388889 -75.27 400.0 180.00 VERTICAL 133.466667 -73.05 300.0 0.00 VERTICAL 134.544444 -72.60 300.0 180.00 VERTICAL 135.622222 -72.25 100.0 90.00 VERTICAL 136.700000 -72.21 400.0 270.00 HORIZONTAL 137.777778 -75.58 100.0 270.00 HORIZONTAL 138.855556 -75.02 300.0 0.00 HORIZONTAL 139.933333 -75.62 400.0 270.00 HORIZONTAL 141.011111 -75.90 300.0 270.00 HORIZONTAL 142.088889 -75.48 400.0 180.00 VERTICAL 143.166667 -75.42 200.0 90.00 HORIZONTAL 144.244444 -74.65 300.0 180.00 HORIZONTAL 145.322222 -73.77 100.0 180.00 VERTICAL 146.400000 -76.65 400.0 90.00 HORIZONTAL 147.477778 -75.52 400.0 0.00 VERTICAL 148.555556 -76.40 400.0 90.00 HORIZONTAL 149.633333 -77.05 300.0 270.00 HORIZONTAL 150.711111 -77.63 300.0 270.00 HORIZONTAL 151.788889 -78.00 400.0 270.00 VERTICAL 152.866667 -77.13 300.0 0.00 HORIZONTAL 153.944444 -76.22 300.0 90.00 VERTICAL 155.022222 -76.77 400.0 90.00 HORIZONTAL 156.100000 -77.15 100.0 180.00 VERTICAL 157.177778 -77.90 100.0 90.00 VERTICAL 158.255556 -76.25 100.0 180.00 VERTICAL 159.333333 -78.48 300.0 0.00 VERTICAL 160.411111 -77.33 200.0 90.00 VERTICAL 161.488889 -77.56 100.0 0.00 HORIZONTAL 162.566667 -77.51 100.0 0.00 HORIZONTAL 163.644444 -77.14 300.0 270.00 VERTICAL 164.722222 -77.90 300.0 180.00 HORIZONTAL 165.800000 -77.59 200.0 0.00 VERTICAL 166.877778 -77.33 200.0 …

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. Appendix F Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 1 von 8 Page 1 of 8 Appendix F Frequency Stability Measurements According to CFR 47 (FCC) part 2.1055 Huawei Technologies Co., Ltd. Appendix F Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 2 von 8 Page 2 of 8 Frequency Stability versus Voltage Huawei Technologies Co., Ltd. Appendix F Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 3 von 8 Page 3 of 8 Huawei Technologies Co., Ltd. Appendix F Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 4 von 8 Page 4 of 8 Huawei Technologies Co., Ltd. Appendix F Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 5 von 8 Page 5 of 8 Frequency Stability versus Temperature Huawei Technologies Co., Ltd. Appendix F Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 6 von 8 Page 6 of 8 Huawei Technologies Co., Ltd. Appendix F Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 7 von 8 Page 7 of 8 Huawei Technologies Co., Ltd. Appendix F Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 8 von 8 Page 8 of 8 Huawei Technologies Co., Ltd. Appendix F Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 9 von 8 Page 9 of 8

Huawei Technologies Co., Ltd. Appendix G Prüfbericht - Nr.: Test Report No. 17000535 001 Seite 1 von 4 Page 1 of 4 Appendix G Conducted Emission Measurements According to CFR 47 (FCC) part 15.207 Test Report No. Page 2 of 4 Conducted Emission Test FCC PART 22 POWER-LINE EUT: BTS3612-800 Manufacturer: Huawei Technologies Co., Ltd. Operating Condition: 24.5degree 43%huminity Test Site: Shielding room Operator: YuHuichun Test Specification: FCC PART22/15 Comment: DC PORT Start of Test: 7/5/02 / 9:20:51PM SCAN TABLE: "FCC15 CE" Short Description: FCC ClassA Voltage Test Start Stop Step Detector Meas. IF Transducer Frequency Frequency Width Time Bandw. 450.0 kHz 30.0 MHz 4.5 kHz MaxPeak 20.0 ms 9 kHz NNLK8121 416 Average Test Report No. Page 3 of 4 -5 0 10 20 30 40 50 60 65 Level [dBμV] 450k700k1M2M3M4M5M6M8M10M20M30M Frequency [Hz] + + + + + + x x x x x Marker: 679.5 kHz 41.24 dBμVL3 x xMES bts3612-800_fin QP + +MES bts3612-800_fin AV MES bts3612-800_pre PK MES bts3612-800_pre AV Test Report No. Page 4 of 4 MEASUREMENT RESULT: "bts3612-800_fin QP" 7/5/02 9:39PM Frequency Level Transd Limit Margin Line PE MHz dBμV dB dBμV dB 0.508500 37.80 0.5 48 10.1 N GND 0.594000 34.90 0.4 48 13.0 L3 GND 0.679500 38.70 0.3 48 9.2 N GND 0.850500 37.00 0.2 48 10.9 L3 GND 1.021500 36.20 0.2 48 11.7 L3 GND MEASUREMENT RESULT: "bts3612-800_fin AV" 7/5/02 9:39PM Frequency Level Transd Limit Margin Line PE MHz dBμV dB dBμV dB 0.513000 38.80 0.5 48 9.1 N GND 0.598500 34.20 0.4 48 13.7 L3 GND 0.679500 38.60 0.3 48 9.3 N GND 0.850500 36.80 0.2 48 11.1 N GND 1.021500 35.40 0.2 48 12.5 N GND 1.192500 32.80 0.2 48 15.1 N GND
