QISD51-5HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth

DiscoveryPhone HUAWEI User Guide © [YEAR] Discovery Communications, LLC. Discovery Expedition and related logos are trademarks of Discovery Communications, LLC, used under license. All rights reserved. MADE IN CHINA. Conforms to ASTM F-963 TM & ©[YEAR] Licensee Inc., City, State 00000 U.S.A. All other symbols, marks, logos and designs (collectively “Trademarks”) are Trademarks of and proprietary to their respective owners and used under license by Licensee, Inc. ALL RIGHTS RESERVED. 1 1 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . 1 2 Getting Started . . . . . . . . . . . . . . . . . . . . . . 4 Your Phone at a Glance . . . . . . . . . . . . . . . . . . . . . . . . 4 Keys and Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Removing the Back Cover and the Battery Cover . . . . . 8 Inserting the USIM/SIM Card and the Battery . . . . . . . . 9 Inserting the microSD Card . . . . . . . . . . . . . . . . . . . . . 9 Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3 Text Entry . . . . . . . . . . . . . . . . . . . . . . . . . 13 Entering English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Entering a Digit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Entering a Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 4 Emergency Settings . . . . . . . . . . . . . . . . . . 16 Making an Emergency Call . . . . . . . . . . . . . . . . . . . . . 16 Setting an Emergency Number . . . . . . . . . . . . . . . . . . 16 5 Voice Services. . . . . . . . . . . . . . . . . . . . . . 18 Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 6 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Adding a Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Searching for a Contact . . . . . . . . . . . . . . . . . . . . . . . 20 2 7 Messaging . . . . . . . . . . . . . . . . . . . . . . . . 21 SMS & MMS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Email. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 8 Media Applications . . . . . . . . . . . . . . . . . . 24 Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Playing a Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 FM Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 9 Organizer Applications . . . . . . . . . . . . . . . . 29 Using Compass. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Weather Forecast . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 10 Connectivity . . . . . . . . . . . . . . . . . . . . . . 32 Connecting via USB . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 11 Security . . . . . . . . . . . . . . . . . . . . . . . . . 37 Enabling/Disabling the Phone Lock. . . . . . . . . . . . . . . 37 PIN and PUK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Locking the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . 38 12 Warnings and Precautions . . . . . . . . . . . . . 39 1 1 Copyright Copyright © Huawei Technologies Co., Ltd. 2011. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses. Trademarks and Permissions , HUAWEI, and re trademarks or registered trademarks of Huawei Technologies Co., Ltd. Other trademarks, product, service and company names mentioned are the property of their respective owners. 2 Notice Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. NO WARRANTY THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL 3 DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS. Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein. 4 2 Getting Started Your Phone at a Glance 1Flashlight2 Charger/Data cable connector 3 4 6 7 8 9 10 5 11 12 13 14 15 16 1…

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: CETECOM Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISD51-5 to be kept confidential: 1. Schematic diagram. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Tune-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Huawei Technologies Co., Ltd. Administration Building, Huawei Base, Bantian, Longgang District, Shenzhen 518129 P.R.C. +86 755 28780808 www.huawei.com Huawei internal reference RCT-US-01-01 USA FCC Short Term Confidentiality Request template Effective date: 2007-01-06 Version 1.1 Short Term Confidentiality Request 2011-09-20 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality Request for FCC ID: QISD51-5 Product Name: HSDPA/UMTS/GPRS/GSM/EDGE Mobile Phone with Bluetooth Product Model: D51-5 To whom maybe concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, Huawei Technologies Co., Ltd requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 90 days: 1. External Photos 2. Internal Photos 3. Test Setup Photos 4. Users Manual The applicant also acknowledges that they will also provide appropriate notice to CETECOM should either of the following occur: A) If the applicant requires additional 45 day extension periods they will notify CETECOM with a new request letter at least 7 days prior to the short-term confidentiality expiration date-[Note: up to maximum of 3 extensions only are allowed], or b) Immediately notify CETECOM in the event the information regarding the product of the product is made available to the public. CETECOM will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely,

Zur optimalen Anzeige dieses PDF-Portfolios sollte es in Acrobat oder Adobe Reader ab Version 9 geöffnet werden. Adobe Reader jetzt herunterladen

HUAWEI D51/D51-5 Mobile Phone with Bluetooth SECRET Page1,Total 3 Internal Photos of HUAWEI D51/D51-5 HUAWEI D51/D51-5 Mobile Phone with Bluetooth SECRET Page2,Total 3 HUAWEI D51/D51-5 Mobile Phone with Bluetooth SECRET Page3,Total 3

Report No:SYBH (Z-SAR) 003082011-2 FCC ID:QISD51-5 Appendix C. Calibration Certificate Table of contends Calibration report “D900- SN1d 112” Calibration report “D1900-SN5d018” Calibration report “DAE4-SN1235” Calibration report “Probe EX3DV4-SN3753”

Report No:SYBH (Z-SAR) 003082011-2 FCC ID:QISD51-5 Appendix B. SAR Measurement Plots Table of contents GSM 850 MHz Head GSM 850 MHz Body GSM 1900 MHz Head GSM 1900 MHz Body WCDMA 850 MHz Head WCDMA 850 MHz Body WCDMA 1900 MHz Head WCDMA 1900 MHz Body Date/Time: 2011-8-4 11:59:22, Date/Time: 2011-8-4 12:06:25 Test Laboratory: Huawei SAR Lab D51-5 GSM850 190CH Left hand touch check DUT: D51-5; Type: Mobile Phone ; Serial: L2P2B11162200196 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.908 mho/m; ε r = 41.8; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.06, 9.06, 9.06); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM4; Type: SAM; Serial: TP-1620  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Head/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.840 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 9.39 V/m; Power Drift = 0.037 dB Peak SAR (extrapolated) = 1.15 W/kg SAR(1 g) = 0.851 mW/g; SAR(10 g) = 0.591 mW/g Maximum value of SAR (measured) = 0.905 mW/g 0 dB = 0.905mW/g Date/Time: 2011-8-4 12:25:14, Date/Time: 2011-8-4 12:32:17 Test Laboratory: Huawei SAR Lab D51-5 GSM850 190CH Left hand tilt 15 degree DUT: D51-5; Type: Mobile Phone ; Serial: L2P2B11162200196 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.908 mho/m; ε r = 41.8; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.06, 9.06, 9.06); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM4; Type: SAM; Serial: TP-1620  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Head/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.467 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 13.3 V/m; Power Drift = -0.010 dB Peak SAR (extrapolated) = 0.585 W/kg SAR(1 g) = 0.441 mW/g; SAR(10 g) = 0.319 mW/g Maximum value of SAR (measured) = 0.464 mW/g 0 dB = 0.464mW/g Date/Time: 2011-8-4 14:48:16, Date/Time: 2011-8-4 14:55:17 Test Laboratory: Huawei SAR Lab D51-5 GSM850 190CH Right hand touch check DUT: D51-5; Type: Mobile Phone ; Serial: L2P2B11162200196 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.908 mho/m; ε r = 41.8; ρ = 1000 kg/m 3 Phantom section: Right Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.06, 9.06, 9.06); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM4; Type: SAM; Serial: TP-1620  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Head/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.787 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 7.8 V/m; Power Drift = 0.051 dB Peak SAR (extrapolated) = 1.05 W/kg SAR(1 g) = 0.765 mW/g; SAR(10 g) = 0.527 mW/g Maximum value of SAR (measured) = 0.815 mW/g 0 dB = 0.815mW/g Date/Time: 2011-8-4 15:16:09, Date/Time: 2011-8-4 15:23:09 Test Laboratory: Huawei SAR Lab D51-5 GSM850 190CH Right hand tilt 15 degree DUT: D51-5; Type: Mobile Phone ; Serial: L2P2B11162200196 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.908 mho/m; ε r = 41.8; ρ = 1000 kg/m 3 Phantom section: Right Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.06, 9.06, 9.06); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM4; Type: SAM; Serial: TP-1620  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Head/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.442 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 11.8 V/m; Power Drift = -0.074 dB Peak SAR (extrapolated) = 0.560 W/kg SAR(1 g) = 0.421 mW/g; SAR(10 g) = 0.304 mW/g Maximum value of SAR (measured) = 0.445 mW/g 0 dB = 0.445mW/g Date/Time: 2011-8-4 14:05:48, Date/Time: 2011-8-4 14:12:51 Test Laboratory: Huawei SAR Lab D51-5 GSM850 251CH Left hand touch check DUT: D51-5; Type: Mobile Phone ; Serial: L2P2B11162200196 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 848.8 MHz Medium parameters used: f = 849 MHz; σ = 0.91 mho/m; ε r = 41.6; ρ = 1000 kg/m 3 Phantom section: Left Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.06, 9.06, 9.06); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM4; Type: SAM; Serial: TP-1620  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/Head/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.772 mW/g Configuration/Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 8.95 V/m; Power Drift = 0.028 dB Peak SAR (extrapolated) = 1.06 W/kg SAR(1 g) = 0.785 mW/g; SAR(10 g) = 0.543 mW/g Maximum value of SAR (measured) = 0.835 mW/g 0 dB = 0.835mW/g Date/Time: 2011-8-4 12:59:51, Date/Time: 2011-8-4 13:06:54 Test Laboratory: Huawei SAR Lab D51-5 GSM850 128CH Left hand touch check DUT: D51-5; Type: Mobile Phone ; Serial: L2P2B11162200196 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 824.2 MHz Medium parameters used (interpolated): f = 824.2 MHz; σ = 0.885 mho/m; ε…

Text truncated - open the document above for the full version.

Huawei Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Tel: +86 755 28785513 Fax: +86 755 36834474 HSUPA/HSDPA/UMTS/GSM/GPRS/ED GE Mobile Phone with Bluetooth FCC SAR Compliance Test Report Project Name: _______________________ Model : _______________________ FCC ID : _______________________ Report No. : _______________________ APPROVED CHECKED PREPARED BY DATE 2011-08-18 2011-08-18 2011-08-18 The test results of this test report relate exclusively to the item(s) tested , The HUAWEI does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of HUAWEI. Reliability Laboratory of Huawei Technologies Co., Ltd. HUAWEI Discovery/D51/D51-5 QISD51-5 SYBH (Z-SAR)003082011-2 Report No.: SYBH (Z-SAR)003082011-2 FCC ID:QISD51-5 2011-08-18 Page 2 of 32 Table of Contents 1 General Information ............................................................................................................................................................ 4 1.1 Statement of Compliance .......................................................................................................................................... 4 1.2 RF exposure limits...................................................................................................................................................... 4 1.3 EUT Description.......................................................................................................................................................... 5 1.3.1 General Description ........................................................................................................................................... 5 1.4 Test specification(s) .................................................................................................................................................. 6 1.5 Testing laboratory ....................................................................................................................................................... 6 1.6 Applicant and Manufacturer ...................................................................................................................................... 6 1.7 Application details ...................................................................................................................................................... 6 1.8 Ambient Condition ..................................................................................................................................................... 6 2 SAR Measurement System ............................................................................................................................................. 7 2.1 SAR Measurement Set-up ....................................................................................................................................... 7 2.2 Test environment ........................................................................................................................................................ 8 2.3 Data Acquisition Electronics description ................................................................................................................ 8 2.4 Probe description........................................................................................................................................................ 9 2.5 Phantom description ................................................................................................................................................ 10 2.6 Device holder description ........................................................................................................................................ 10 2.7 Test Equipment List ................................................................................................................................................. 11 3 SAR Measurement Procedure ...................................................................................................................................... 12 3.1 Scanning procedure ................................................................................................................................................. 12 3.2 Spatial Peak SAR Evaluation ................................................................................................................................. 13 3.3 Data Storage and Evaluation .................................................................................................................................. 14 4 System Verification Procedure ........................................................................................................................................ 16 4.1 Tissue Verification .................................................................................................................................................... 16 4.2 System Check ........................................................................................................................................................... 18 4.3 Validation Procedure................................................................................................................................................ 18 5 Measurement Uncertainty Evaluation .......................................................................................................................... 19 5.1 Measurement uncertainty evaluation for SAR test .............................................................................................. 19 5.2 Measurement uncertainty evaluation for system validation ............................................................................... 20 6…

Text truncated - open the document above for the full version.

Report No:SYBH (Z-SAR) 003082011-2 FCC ID:QISD51-5 Appendix A. System Check Plots Table of contens SystemPerformanceCheck-D900-EX-Head SystemPerformanceCheck-D900-EX-Body SystemPerformanceCheck-D900-EX-Body SystemPerformanceCheck-D1900-EX-Head SystemPerformanceCheck-D1900-EX-Body Date/Time: 2011-8-4 2:57:50, Date/Time: 2011-8-4 3:04:45 Test Laboratory: Huawei SAR Lab SystemPerformanceCheck-D900-EX-Head DUT: Dipole 900 MHz D900V2; Type: D900V2; Serial: D900V2 - SN:2d112 Communication System: CW; Frequency: 900 MHz Medium parameters used: f = 900 MHz; σ = 0.936 mho/m; ε r = 41.1; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.06, 9.06, 9.06); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM4; Type: SAM; Serial: TP-1620  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/d=15mm, Pin=250mW/Area Scan (6x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.53 mW/g Configuration/d=15mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 55.5 V/m; Power Drift = -0.033 dB Peak SAR (extrapolated) = 4.08 W/kg SAR(1 g) = 2.65 mW/g; SAR(10 g) = 1.7 mW/g Maximum value of SAR (measured) = 2.87 mW/g 0 dB = 2.87mW/g Date/Time: 2011-8-2 2:53:22, Date/Time: 2011-8-2 3:00:16 Test Laboratory: Huawei SAR Lab SystemPerformanceCheck-D900-EX-Body DUT: Dipole 900 MHz D900V2; Type: D900V2; Serial: D900V2 - SN:1d112 Communication System: CW; Frequency: 900 MHz Medium parameters used: f = 900 MHz; σ = 1 mho/m; ε r = 52.6; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.07, 9.07, 9.07); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM4; Type: SAM; Serial: TP-1620  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/d=15mm, Pin=250mW/Area Scan (6x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.54 mW/g Configuration/d=15mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 53.7 V/m; Power Drift = -0.116 dB Peak SAR (extrapolated) = 3.99 W/kg SAR(1 g) = 2.64 mW/g; SAR(10 g) = 1.71 mW/g Maximum value of SAR (measured) = 2.84 mW/g 0 dB = 2.84mW/g Date/Time: 2011-8-3 2:55:40, Date/Time: 2011-8-3 3:02:34 Test Laboratory: Huawei SAR Lab SystemPerformanceCheck-D900-EX-Body DUT: Dipole 900 MHz D900V2; Type: D900V2; Serial: D900V2 - SN:1d112 Communication System: CW; Frequency: 900 MHz Medium parameters used: f = 900 MHz; σ = 1.01 mho/m; ε r = 54; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(9.07, 9.07, 9.07); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM4; Type: SAM; Serial: TP-1620  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/d=15mm, Pin=250mW/Area Scan (6x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.52 mW/g Configuration/d=15mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 54.6 V/m; Power Drift = -0.157 dB Peak SAR (extrapolated) = 4.16 W/kg SAR(1 g) = 2.73 mW/g; SAR(10 g) = 1.76 mW/g Maximum value of SAR (measured) = 2.95 mW/g 0 dB = 2.95mW/g Date/Time: 2011-8-4 17:28:57, Date/Time: 2011-8-4 17:33:09 Test Laboratory: Huawei SAR Lab SystemPerformanceCheck-D1900-EX-Head DUT: Dipole 1900 MHz D1900V2; Type: D1900V2; Serial: D1900V2 - SN:5d018 Communication System: CW; Frequency: 1900 MHz Medium parameters used: f = 1900 MHz; σ = 1.41 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(7.9, 7.9, 7.9); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/d=10mm, Pin=250mW/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 10.3 mW/g Configuration/d=10mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 84.9 V/m; Power Drift = 0.029 dB Peak SAR (extrapolated) = 18.1 W/kg SAR(1 g) = 9.6 mW/g; SAR(10 g) = 4.95 mW/g Maximum value of SAR (measured) = 10.7 mW/g 0 dB = 10.7mW/g Date/Time: 2011-8-3 11:54:04, Date/Time: 2011-8-3 11:58:15 Test Laboratory: Huawei SAR Lab SystemPerformanceCheck-D1900-EX-Body DUT: Dipole 1900 MHz D1900V2; Type: D1900V2; Serial: D1900V2 - SN:5d018 Communication System: CW; Frequency: 1900 MHz Medium parameters used: f = 1900 MHz; σ = 1.56 mho/m; ε r = 51.2; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration:  Probe: EX3DV4 - SN3753; ConvF(7.17, 7.17, 7.17); Calibrated: 2010-12-13  Sensor-Surface: 4mm (Mechanical Surface Detection)  Electronics: DAE4 Sn1235; Calibrated: 2010-10-22  Phantom: SAM3; Type: SAM; Serial: TP-1597  Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 57 Configuration/d=10mm, Pin=250mW/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 9.01 mW/g Configuration/d=10mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 77.8 V/m; Power Drift = 0.076 dB Peak SAR (extrapolated) = 19.8 W/kg SAR(1 g) = 10.8 mW/g; SAR(10 g) = 5.61 mW/g Maximum value of SAR (measured) = 12.3 mW/g 0 dB = 12.3mW/g

Zur optimalen Anzeige dieses PDF-Portfolios sollte es in Acrobat oder Adobe Reader ab Version 9 geöffnet werden. Adobe Reader jetzt herunterladen

Report No:SYBH (Z-SAR) 003082011-2 FCC ID:QISD51-5 Appendix D. Photo documentation Table of contens Test Facility Test Positions Liquid depth Test Facility Photo 1: Measurement System DASY 5 Test Positions Photo 2: Front View Photo 3: Rear View Photo 4: Left Hand Touched Photo 5: Left Hand Tilt 15° Photo 6: Right Hand Touched Photo 7: Right Hand Tilt 15° Photo 8:Towords Phantom (15mm) Photo 9: Towords Ground (15mm) Photo 10:Towords Ground with Headset (15mm) Photo 11:Towards Ground 0mm with Armband and Headset (0mm) Liquid depth Photo 12: HSL900MHz depth (15.1cm) Photo 13: MSL900depth (15.2cm) Photo 14: HSL1900MHz depth (15.2cm) Photo 15: MSL1900depth (15.1cm)
