QISE226HSDPA USB Modem

Copyright © 2007 Huawei Technologies Co., Ltd. All Rights Reserved No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks and HUAWEI are trademarks of Huawei Technologies Co., Ltd. All other trademarks mentioned in this manual are the property of their respective holders. Notice The information in this manual is subject to change without notice. Every effort has been made in the preparation of this manual to ensure accuracy of the contents, but all statements, information, and recommendations in this manual do not constitute the warranty of any kind, expressed or implied. i Table of Contents Getting Started .........................................................................................................1 Preparing E226 ........................................................................................................2 Installation Instructions ...........................................................................................2 Safety Information ...................................................................................................5 1 Thank you for choosing E226 HSDPA USB Modem (hereinafter referred to as the E226) from Huawei. Note : This manual briefs the profile of the E226, and the preparation, and installation process. For the operation of the management program, see User Manual.. Getting Started 1. Getting to Know the E226 The following figure shows the E226 profile. USB interface USIM/SIM card slot Indicator 2. Indicator This indicator indicates the status of E226. y Off: The E226 is powered off. y Green, Blinking twice every 2.7 seconds: The E226 is searching for a network or no network is available. y Green, Blinking twice every 2.9 seconds: The GSM network is normal. y Blue, Blinking once every 2.9 seconds: The WCDMA network is normal. y Green: GPRS data service is established. y Cyan: HSDPA data service is established. y Blue: WCDMA data service is established. 3. Computer Configuration Requirements To use the E226, configure a computer according to the following items: y Central processing unit (CPU): Pentium 4, 1 GHz or above y Memory: 128 MB RAM or above y Hard disk: 50 MB or above y Operating system (OS): Windows XP, Windows 2000, or Windows Vista y Universal serial bus (USB) modem interface: USB 2.0 full speed y Display resolution: 800 % 600 or above (1024 % 768 is recommended) Note: y Improper configuration may degrade the computer performance. 2 y For Windows XP, it is recommended to install patches such as Service Pack 2 or above. y For Windows 2000, it is recommended to install patches such as Service Pack 4 or above. Preparing E226 1) Remove the UMTS subscriber identity module/subscriber identity module (USIM/SIM) card slot from the E226. Then insert the USIM/SIM card into the card slot, as shown in the following figure. Make sure that the USIM/SIM card is fully in place. 2) Insert the card slot into the E226, as shown in the following figure. Installation Instructions The installation procedures of the E226 Manager vary with operating systems (OSs). Refer to the actual installation instructions during the installation process. 1. Connecting the E226 with a Computer Note : First, power on a computer. Then connect the E226 with the computer. Otherwise, the normal installation of the E226 can be affected. The following figure is the sketch map of the data cable. Auxiliary USBdata cable Mini-USBConnector Mini-USBdata cable 3 1) Plug the mini-universal series bus (USB) connector into the E226. 2) Plug the connectors of the main USB data cable and the auxiliary USB data cable into the USB interfaces of the computer. P C 3) The OS automatically detects and recognizes the new hardware and displays on the status area of the desktop, indicating that the E226 is connected to the computer successfully. P C 2. Installing the E226 Manager 1) Connect the E226 to a computer. 2) The installation wizard automatically starts. If the installation wizard does not respond, double-click the AutoRun.exe file in the driver path to manually install the E226 Manager. 3) Follow the instructions to install the E226 Manager. Note: Do not disconnect the E226 during the installation process. 4) If the installation succeeds, the shortcut icon of the Manager appears on the desktop. 4 3. Removing the E226 To remove the E226, use the hardware deleting function of Windows. 1) Double-click on the status area of the desktop; the "Safely Remove Hardware" prompt is displayed. 2) Select "Huawei Mass Storage USB Device" to stop. 3) At the prompt, remove the E226. 5 Safety Information Please read the safety information carefully to ensure the correct and safe use of your wireless device. General Recommendations for Use Always handle your wireless device with care and keep it in a clean and dust-free place. Do not expose your wireless device to open flames or lit tobacco products. y Always keep your wireless device dry. y Do not drop, throw or try to bend your wireless device. y Do not paint or scratch your wireless device. y Do not attempt to disassemble your wireless device. Doing so will void warranty. Only authorized personnel are allowed to do so. y A separation distance of at least 20 cm must be kept between the antenna used for this transmitter and all persons. y Keep your wireless device in normal temperature. Your wireless device can only operate between -5ºC and +55 ºC. y Use approved accessories only. Do not connect your wireless device to any incompatible products. Obey Laws and Regulations y Do not operate your wireless device where it may be unsafe to do so or where you are required not to do so. y To deactivate your wireless device, close all applications using the wireless device first and then remove the wireless device from your PC. y Obey all local laws, regulations, rules, orders, signs and notices while using the wireless device. Signs about the use of mob…

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. AddressHuawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP518129 Page 1/1 To: CETECOM Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com SubjectLetter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISE226 to be kept confidential: 1. Schematic diagram & PCB layout. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Tune-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

E226 SECRET Page1,Total 5 External Photos of HUAWEI E226 E226 SECRET Page2,Total 5 E226 SECRET Page3,Total 5 E226 SECRET Page4,Total 5 E226 SECRET Page5,Total 5

E226 Page1, Total 1 ID Label Location_E226

E226 SECRET Page1,Total 5 Internal Photos of HUAWEI E226 E226 SECRET Page2,Total 5 E226 SECRET Page3,Total 5 E226 SECRET Page4,Total 5 E226 SECRET Page5,Total 5

FCC ID: QISE226 Report No: SYBH(R)18072007EB-1 Confidential Information of Huawei. No Distribution without Permission Page1, Total2 Appendix F Radiated Emission of Enclosure in Idle Mode According to FCC Part 15.109 FCC ID: QISE226 Report No: SYBH(R)18072007EB-1 Confidential Information of Huawei. No Distribution without Permission Page2, Total2 1GPRS850 MEASUREMENT RESULT: QP DECTER Frequency MHz Level dBμV/m Transd dB Limit dBμV/m Margin dB Height cm Azimuth deg Polarisation 38.700000 23.90 -8.9 40.0 16.1 100.0 281.00 VERTICAL 92.040000 23.60 -12.4 43.5 19.9 234.0 0.00 HORIZONTAL 108.180000 24.60 -10.0 43.5 18.9 287.0 257.00 HORIZONTAL 225.120000 23.40 -10.8 46.0 22.6 133.0 272.00 HORIZONTAL 378.180000 28.90 -5.1 46.0 17.1 154.0 0.00 VERTICAL 596.760000 30.30 -1.9 46.0 15.7 100.0 134.00 VERTICAL 0 10 20 30 40 50 60 70 80 Level 3050701002003005007001G Frequency [Hz] x x x x x x FCC ID: QISE226 Report No: SYBH(R)18072007EB-1 Confidential Information of Huawei. No Distribution without Permission Page1, Total2 Appendix G Conducted Emission at Power Port According to FCC Part 15.107 FCC ID: QISE226 Report No: SYBH(R)18072007EB-1 Confidential Information of Huawei. No Distribution without Permission Page2, Total2 MEASUREMENT RESULT: QP DECTER Frequency MHz Level dBμV Transd dB Limit dBμV Margin dB Line PE 0.1995 49.6 10.5 64 14 N FLO 0.3795 44.1 10.1 58 14.2 L3 FLO 0.8205 41.3 9.9 56 14.7 L3 FLO 2.3955 40.5 10.1 56 15.5 L3 FLO 5.172 24.7 10.1 60 35.3 N FLO 14.9235 23.7 11.2 60 36.3 L3 FLO MEASUREMENT RESULT: “AV DECTER” Frequency MHz Level dBμV Transd dB Limit dBμV Margin dB Line PE 0.195 30.8 10.5 54 23 L3 FLO 0.8205 26.8 9.9 46 19.2 L3 FLO 0.3795 27.1 9.9 46 18.9 L3 FLO 2.5215 28.4 10.1 46 17.6 L3 FLO 5.172 21.3 10.1 50 28.7 L3 FLO 15.5175 11.8 11.4 50 38.2 L3 FLO 0 10 20 30 40 50 60 70 80 Level [dBμV] 150k 300k 500k 123571030 Frequency [Hz] + + + + + + x x x x x x

FCC ID: QISE226 Report No: SYBH(R)18072007EB-1 Confidential Information of Huawei. No Distribution without Permission Page1, Total4 Appendix H Photos of Test Setup FCC ID: QISE226 Report No: SYBH(R)18072007EB-1 Confidential Information of Huawei. No Distribution without Permission Page2, Total4 1Radiated Emissions Radiated Disturbance FCC ID: QISE226 Report No: SYBH(R)18072007EB-1 Confidential Information of Huawei. No Distribution without Permission Page3, Total4 2conducted Emissions Conducted Disturbance FCC ID: QISE226 Report No: SYBH(R)18072007EB-1 Confidential Information of Huawei. No Distribution without Permission Page4, Total4 3Radiated Spurious Emissions Radiated Spurious Emission (below 2GHz) Radiated Spurious Emission (2GHz to18GHz)
