QISE3251S-6DC-HSPA+ USB Stick

Thank you for choosing the Mobile Broadband USB Stick. With your USB Stick, you can access a wireless network at high speed. Note: This manual describes the appearance of the USB Stick, as well as the procedures for preparation, connection steps. For details about how to set the management parameters, see help information on the web management page. Getting to Know Your USB Stick The following figure shows the appearance of the USB Stick. It is provided only for your reference. The actual product may be different. 1 3 2 2 5 4  USB Connector It connects the USB Stick to a PC.  Strap Hole You can tie the cap and the USB Stick together by threading a strap through the strap holes, so that the cap will not be easily lost.  Indicator It indicates the status of the USB Stick.  Green, blinking twice every 3s: The USB Stick is powered on.  Green, blinking once every 3s: The USB Stick is registering with a 2G network.  Blue, blinking once every 3s: The USB Stick is registering with a 3G/3G+ network.  Green, solid: The USB Stick is connected to a 2G network.  Blue, solid: The USB Stick is connected to a 3G network.  Cyan, solid: The USB Stick is connected to a 3G+ network.  Off: The USB Stick is removed.  microSD Card Slot It holds a microSD card.  SIM/USIM Card Slot It holds a Subscriber Identity Module (SIM)/Universal Subscriber Identity Module (USIM) card. Getting Your USB Stick Ready 1. Slide the cover to remove it from the USB Stick. 2. Insert the SIM/USIM card and the microSD card into the corresponding card slots, as shown in the following figure. 3. Replace the cover and slide it into place. Note:  The microSD card is an optional accessory. If it is not provided in the package, you can buy one yourself.  Ensure that the beveled edge of the SIM/USIM card is properly aligned with that of the SIM/USIM card slot and the microSD card is inserted according to the direction as labeled on the microSD card slot.  Do not remove the microSD or SIM/USIM card when the card is in use. Otherwise, the card as well as your USB Stick may get damaged and the data stored on the card may be corrupted. Using Your USB Stick The procedure for installing the management program depends on your computer's operating system. The following sections are based on Windows XP. Connecting to a Network 1. Insert the USB Stick into one of your computer's USB ports. The computer identifies the new hardware and starts its installation automatically. 2. When the installation is complete, the USB Stick's web management page is displayed and the USB Stick connects to the network automatically. The USB Stick's web management page will be automatically displayed every time the USB Stick is inserted into the co mp uter. Note:  If the computer does not start the USB Stick's installation automatically, find the AutoRun.exe file in the USB Stick's root directory, and double-click the file to run it.  If you are not connected to the network, access http://192.168.1.1 to check the device status.  If you cannot access http://192.168.1.1, disconnect other network connections, such as an Ethernet or Wireless Fidelity (Wi-Fi) connection, remove and then insert the USB Stick, or restart the computer. Disconnecting from a Network Remove the USB Stick from the computer. Note: If you do not need to connect to a network, it is recommended that you remove the USB Stick from your computer to eliminate unwanted data traffic. Viewing Service Information Visit http://192.168.1.1 to view your service information. Version: V100R001_01 Part Number: 31010***

Copyright © Huawei Technologies Co., Ltd. 2012. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd. and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses. Trademarks and Permissions , , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Other trademarks, product, service and company names mentioned are the property of their respective owners. Notice Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd. reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. NO WARRANTY THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, I NCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXI MUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD. BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS. Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein. Warnings and Precautions This section contains important information pertaining to the operating instructions of your device. It also contains information about how to use your device safely. Read this information carefully before using the device. Electronic Device Do not use your device if using the device is prohibited. Do not use the device when using the device causes danger or interference with electronic devices. Medical Device  Follow rules and regulations set forth by hospitals and health care f acilities. Do not use your device when using the device is prohibited.  Some wireless devices may affect the performance of hearing aids or pacemakers. For any such problems, consult your service provider.  If you are using an electronic medical device, consult the doctor or the device manufacturer to confirm whether radio waves affect the operation of this device. Potentially Explosive Atmosphere Do not use your device in any area with a potentially explosive atmosphere, and comply with all signs and instructions. Areas that may have potentially explosive atmospheres include the areas where you would normally be advised to turn off your vehicle engine. Triggering of sparks in such areas could cause an explosion or a fire, resulting in bodily injuries or even deaths. Do not use your device at refueling points such as service stations. Comply with restrictions on the use of radio equipment in fuel depots, storage, and distribution areas, and chemical plants. In addition, adhere to restrictions in areas where blasting operations are in progress. Before using the device, watch out for areas that have potentially explosive atmospheres that are often, but not always, clearly marked. Such locations include areas below the deck on boats, chemical transfer or storage facilities, and areas where the air contains chemicals or particles such as grain, dust, or metal powders. Ask the manufacturers of vehicles using liquefied petroleum gas (such as propane or butane) whether this device can be safely used in their vicinity. Traffic Security  Observe local laws and regulations while using the device. To prevent accidents, do not use your wireless device while driving.  RF signals may affect electronic systems of motor vehicles. For more information, consult the vehicle manufacturer.  In a motor vehicle, do not place the device over the air bag or in the air bag deployment area. Otherwise, the device may hurt you owing to the strong force when the air bag inflates.  Do not use your device while flying in an aircraft and before boarding an aircraft. Using wireless devices in an aircraft may cause danger to the operation of the aircraft and disrupt the wireless telephone network. It may also be considered illegal. Operating Environment  Do not use the device in dusty, damp, and dirty places or places with magnetic fields. Otherwise, it may result in malfunction of the circuit.  On a stormy day with thunder, do not use your device when it is being charged, to prevent any danger caused by lightning.  While using the device, observe the local laws and regulations, and respect others' privacy and legal rights.  Keep the ambient temperature between -10°C to +45°C for using the device. Safety of Children Comply with all precautions with regard to children's safety. Letting the child play with your device or its accessories, which may include parts that can be detached from the device, may be dangerous, as it may present a choking hazard. Ensure that small children are kept away from the device and accessories. Accessories Use the accessories delivered only by the manufacturer. Using accessories of other manufacturers or vendors with this device model may invalidate any a…

Text truncated - open the document above for the full version.

the difference of E3251s-6(RF in) and E3251s-6(RF side) SECRET 2012-7-10 E3251s-6 has two modalities, the one is RF switch in the middle and the other is RF switch in the side. The difference is that: E3251s-6（RF in） with straight switch E3251s-6（RF side） with angle switch Straight Switch Angle Switch

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: CETECOM Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISE3251S-6 to be kept confidential: 1. Schematic diagram . 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Tune-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. W e do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

E3251s-6 SECRET Page1, Total5 External Photos of E3251s-6 E3251s-6 SECRET Page2, Total5 E3251s-6 SECRET Page3, Total5 E3251s-6 SECRET Page4, Total5 E3251s-6 SECRET Page5, Total5

E3251s-6 SECRET Page1, Total5 External Photos of E3251s-6 E3251s-6 SECRET Page2, Total5 E3251s-6 SECRET Page3, Total5 E3251s-6 SECRET Page4, Total5 E3251s-6 SECRET Page5, Total5

E3251s-6 SECRET Page 1 Total 1 ID Label Location_ E3251s-6

E3251s-6 SECRET Page 1 Total 1 ID Label E3251s-6：

E3251s-6 SECRET Page1, Total3 Internal Photos of E3251s-6 E3251s-6 SECRET Page2, Total3 E3251s-6 SECRET Page3, Total3

E3251s-6 SECRET Page1, Total3 Internal Photos of E3251s-6 E3251s-6 SECRET Page2, Total3 E3251s-6 SECRET Page3, Total3

Report No.: SYBH(Z-SAR)019062012-2 FCC ID:QISE3251S-6 Appendix A. System Check Plots Table of contents SystemPerformanceCheck-D835-EX-Body SystemPerformanceCheck-D1900-EX-Body Date/Time: 6/21/2012 8:02:38 Test Laboratory: HUAWEI SAR Lab SystemPerformanceCheck-D835-EX-Body DUT: Dipole 835 MHz D835V2; Type: D835V2; Serial: D835V2 - SN:4d126 Communication System: CW; Frequency: 835 MHz Medium parameters used: f = 835 MHz; σ = 0.987 mho/m; ε r = 53.523; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(8.98, 8.98, 8.98); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM 2; Type: SAM; Serial: TP-1474 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/d=15mm,pin=250mW/Area Scan (6x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.75 mW/g Configuration/d=15mm,pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 53.553 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 3.822 mW/g SAR(1 g) = 2.58 mW/g; SAR(10 g) = 1.69 mW/g Maximum value of SAR (measured) = 2.79 mW/g 0 dB = 2.75 mW/g = 8.78 dB mW/g Date/Time: 6/19/2012 10:58:24 Test Laboratory: HUAWEI SAR Lab SystemPerformanceCheck-D1900-EX-Body DUT: Dipole 1900 MHz D1900V2; Type: D1900V2; Serial: D1900V2 - SN:5d143 Communication System: CW; Frequency: 1900 MHz Medium parameters used: f = 1900 MHz; σ = 1.564 mho/m; ε r = 53.065; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(7.14, 7.14, 7.14); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM 1; Type: SAM; Serial: TP-1475 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/d=10mm, Pin=250mW/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 11.4 mW/g Configuration/d=10mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 88.651 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 19.641 mW/g SAR(1 g) = 10.8 mW/g; SAR(10 g) = 5.55 mW/g Maximum value of SAR (measured) = 12.2 mW/g 0 dB = 11.4 mW/g = 21.13 dB mW/g

Report No.: SYBH(Z-SAR)019062012-2 FCC ID:QISE3251S-6 Appendix B. SAR Measurement Plots Table of contents GSM 850MHz Body GSM 1900MHz Body WCDMA 850MHz Body WCDMA 1900MHz Body Date/Time: 6/21/2012 10:07:51 Test Laboratory: HUAWEI SAR Lab E3251s-6 GSM850 GPRS 1TS 128CH Front side 5mm DUT: E3251s-6; Type: DC-HSPA+ USB Stick; Serial: SAR1 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 824.2 MHz Medium parameters used (interpolated): f = 824.2 MHz; σ = 0.975 mho/m; ε r = 53.699; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(8.98, 8.98, 8.98); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM 2; Type: SAM; Serial: TP-1474 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/Body/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 1.06 mW/g Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.785 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 1.577 mW/g SAR(1 g) = 1.04 mW/g; SAR(10 g) = 0.652 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 1.14 mW/g 0 dB = 1.06 mW/g = 0.47 dB mW/g Date/Time: 6/21/2012 8:33:07 Test Laboratory: HUAWEI SAR Lab E3251s-6 GSM850 GPRS 1TS 190CH Front side 5mm DUT: E3251s-6; Type: DC-HSPA+ USB Stick; Serial: SAR1 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.989 mho/m; ε r = 53.478; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(8.98, 8.98, 8.98); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM 2; Type: SAM; Serial: TP-1474 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/Body/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 1.08 mW/g Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.890 V/m; Power Drift = 0.07 dB Peak SAR (extrapolated) = 1.562 mW/g SAR(1 g) = 1.05 mW/g; SAR(10 g) = 0.659 mW/g Maximum value of SAR (measured) = 1.15 mW/g 0 dB = 1.08 mW/g = 0.70 dB mW/g Date/Time: 6/21/2012 10:31:11 Test Laboratory: HUAWEI SAR Lab E3251s-6 GSM850 GPRS 1TS 251CH Front side 5mm DUT: E3251s-6; Type: DC-HSPA+ USB Stick; Serial: SAR1 Communication System: HW-GSM/GPRS/EDGE 1TS; Frequency: 848.8 MHz Medium parameters used: f = 849 MHz; σ = 1.003 mho/m; ε r = 53.277; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(8.98, 8.98, 8.98); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM 2; Type: SAM; Serial: TP-1474 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/Body/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 1.14 mW/g Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 7.163 V/m; Power Drift = -0.12 dB Peak SAR (extrapolated) = 1.663 mW/g SAR(1 g) = 1.1 mW/g; SAR(10 g) = 0.685 mW/g Maximum value of SAR (measured) = 1.19 mW/g 0 dB = 1.19 mW/g = 1.51 dB mW/g Date/Time: 6/21/2012 10:54:29 Test Laboratory: HUAWEI SAR Lab E3251s-6 GSM850 GPRS 2TS 128CH Front side 5mm DUT: E3251s-6; Type: DC-HSPA+ USB Stick; Serial: SAR1 Communication System: HW-GSM/GPRS/EDGE 2TS; Frequency: 824.2 MHz Medium parameters used (interpolated): f = 824.2 MHz; σ = 0.975 mho/m; ε r = 53.699; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(8.98, 8.98, 8.98); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM 2; Type: SAM; Serial: TP-1474 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/Body/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.976 mW/g Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.375 V/m; Power Drift = 0.14 dB Peak SAR (extrapolated) = 1.488 mW/g SAR(1 g) = 0.955 mW/g; SAR(10 g) = 0.591 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 1.05 mW/g 0 dB = 0.976 mW/g = -0.22 dB mW/g Date/Time: 6/21/2012 9:00:18 Test Laboratory: HUAWEI SAR Lab E3251s-6 GSM850 GPRS 2TS 190CH Front side 5mm DUT: E3251s-6; Type: DC-HSPA+ USB Stick; Serial: SAR1 Communication System: HW-GSM/GPRS/EDGE 2TS; Frequency: 836.6 MHz Medium parameters used: f = 837 MHz; σ = 0.989 mho/m; ε r = 53.478; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3736; ConvF(8.98, 8.98, 8.98); Calibrated: 4/26/2012; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn852; Calibrated: 11/16/2011 lPhantom: SAM 2; Type: SAM; Serial: TP-1474 lDASY52 52.8.1(838); SEMCAD X 14.6.5(6469) Configuration/Body/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.997 mW/g Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.498 V/m; Power Drift = 0.15 dB Peak SAR (extrapolated) = 1.480 mW/g SAR(1 g) = 0.965 mW/g; SAR(10 g) = 0.595 mW/g Maximum value of SAR (measured) = 1.06 mW/g 0 dB = 0.997 mW/g = -0.02 dB mW/g Date/Time: 6/21/2012 11:16:48 Test Laboratory: HUAWEI SAR Lab E3251s-6 GSM850 GPRS 2TS 251CH Front side 5mm DUT: E3251s-6; Type: DC-HSPA+ USB Stick; Serial: SAR1 Communication System: HW-GSM/GPRS/EDGE 2TS; Frequency: 848.8 MHz Medium parameters used: f = 849 MHz; σ = 1.003 mho/m; ε r …

Text truncated - open the document above for the full version.

Zur optimalen Anzeige dieses PDF-Portfolios sollte es in Acrobat oder Adobe Reader ab Version 9 geöffnet werden. Adobe Reader jetzt herunterladen

Report No.: SYBH(Z-SAR)019062012-2 FCC ID: QISE3251S-6 Appendix D.Photo documentation Table of contents Test Facility Test Positions Liquid depth Test Facility Photo 1: Measurement System DASY 5 Test Positions Photo 2:Front View Photo 3:Rear View Photo 4: Front Side 5mm Photo 5: Rear Side 5mm Photo 6: Left Side 5mm Photo 7: Right Side 5mm Liquid depth Photo 8:MSL835MHz depth (15.1cm) Photo 9: MSL1900MHz depth (15.1cm)

Huawei Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Tel: +86 755 28785513 Fax: +86 755 36834474 FCC SAR Compliance Test Report Project Name:_______________________ Model :_______________________ FCC ID : _______________________ Report No. : _______________________ APPROVED CHECKED PREPARED BY DATE 2012-08-10 2012-08-10 2012-08-10 The test results of this test report relate exclusively to the item(s) tested , The HUAWEI does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of HUAWEI. Reliability Laboratory of Huawei Technologies Co., Ltd. E3251s-6 QISE3251S-6 SYBH(Z-SAR)019062012-2 DC-HSPA+ USB Stick Report No.: SYBH(Z-SAR)019062012-2 FCC ID:QISE3251S-6 2012-08-10 Page 2 of 34 Table of Contents 1 General Information ............................................................................................................................................................ 4 1.1 Statement of Compliance .......................................................................................................................................... 4 1.2 RF exposure limits...................................................................................................................................................... 4 1.3 EUT Description ......................................................................................................................................................... 5 1.3.1 General Description ........................................................................................................................................... 6 1.4 Test specification(s) .................................................................................................................................................. 7 1.5 Testing laboratory ....................................................................................................................................................... 7 1.6 Applicant and Manufacturer ...................................................................................................................................... 7 1.7 Application details ...................................................................................................................................................... 7 1.8 Ambient Condition ...................................................................................................................................................... 7 2 SAR Measurement System ............................................................................................................................................. 8 2.1 SAR Measurement Set-up ....................................................................................................................................... 8 2.2 Test environment ........................................................................................................................................................ 9 2.3 Data Acquisition Electronics description ................................................................................................................ 9 2.4 Probe description ..................................................................................................................................................... 10 2.5 Phantom description ................................................................................................................................................ 11 2.6 Device holder description ........................................................................................................................................ 11 2.7 Test Equipment List ................................................................................................................................................. 12 3 SAR Measurement Procedure ...................................................................................................................................... 13 3.1 Scanning procedure ................................................................................................................................................. 13 3.2 Spatial Peak SAR Evaluation ................................................................................................................................. 14 3.3 Data Storage and Evaluation .................................................................................................................................. 15 4 System Verification Procedure ........................................................................................................................................ 17 4.1 Tissue Verification .................................................................................................................................................... 17 4.2 System Check ........................................................................................................................................................... 18 4.3 Validation Procedure................................................................................................................................................ 19 5 Measurement Uncertainty Evaluation .......................................................................................................................... 20 5.1 Measurement uncertainty evaluation for SAR test .............................................................................................. 20 5.2 Measurement uncertainty evaluation for system validation ............................................................................... 21 6 SAR Test Configuration .................................…

Text truncated - open the document above for the full version.

Zur optimalen Anzeige dieses PDF-Portfolios sollte es in Acrobat oder Adobe Reader ab Version 9 geöffnet werden. Adobe Reader jetzt herunterladen

FCC RF Test Report Product Name: DC-HSPA+ USB Stick Model Number: E3251s-6 Report No: SYBH(Z-RF)006062012-2001 FCC ID: QISE3251S-6 Reliability Laboratory of Huawei Technologies Co., Ltd. Huawei Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Tel: +86 755 28780808 Fax: +86 755 89652518 FCC Test Report of E3251s-6 FCC ID: QISE3251S-6 Report No: SYBH(Z-RF)006062012-2001 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total17 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 3. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-2. 4. The test report is invalid if not marked with "exclusive stamp for the test report". 5. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 6. The test report is invalid if there is any evidence of erasure and/or falsification. 7. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 8. Normally, the test report is only responsible for the samples that have undergone the test. 9. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. FCC Test Report of E3251s-6 FCC ID: QISE3251S-6 Report No: SYBH(Z-RF)006062012-2001 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total17 Applicant: Huawei Technologies Co., Ltd. Address: Huawei Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Date of Receipt Test Item: Jun. 08, 2012 Start Date of Test: Jun. 11, 2012 End Date of Test: Jun. 18, 2012 Test Result: Pass Approved By Senior Engineer Jun. 25, 2012 Dai Linjun Date Name Signature Reviewed By Jun. 25, 2012 Cousy Xu Date Name Signature Operated By Jun. 25, 2012 Huang Qiuliang Date Name Signature FCC Test Report of E3251s-6 FCC ID: QISE3251S-6 Report No: SYBH(Z-RF)006062012-2001 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total17 Contents 1 General Information ............................................................................................................................. 5 1.1 APPLIED STANDARD ......................................................................................................................... 5 1.2 TEST LOCATION ............................................................................................................................... 5 1.3 TEST ENVIRONMENTAL CONDITION..................................................................................................... 5 2 Summary ............................................................................................................................................. 6 3 Product Description .......................................................…
