Thank you for choosing the Mobile Broadband USB Stick. With your USB Stick, you can access a wireless network at high speed. Note: This manual describes the appearance of the USB Stick, as well as the procedures for preparation, installation, and removal. For operation details about the management program, see the online help included in the management program. Getting to Know Your USB Stick The following figure shows the appearance of the USB Stick. It is provided only for your reference. The actual product may be different. 1 2 3 4 5 2  USB Connector It connects the USB Stick to a PC.  Strap Hole You can tie the cap and the USB Stick together by threading a strap through the strap holes, so that the cap will not be easily lost.  Indicator It indicates the status of the USB Stick.  Green, blinking twice every 2s: The USB Stick is powered on.  Green, blinking once every 2s: The USB Stick is registering with a 2G network.  Blue, blinking once every 2s: The USB Stick is registering with a 3G/3G+ network.  Green, solid: The USB Stick is connected to a 2G network.  Blue, solid: The USB Stick is connected to a 3G network.  Cyan, solid: The USB Stick is connected to a 3G+ network.  Off: The USB Stick is removed.  SIM Card Slot It holds a Subscriber Identity Module (SIM) card.  mic roSD Card Slot It holds a microSD card. Getting Your USB Stick Ready 1. Slide the cover to remove it from the USB Stick. 2. Insert the SIM card and the microSD card into the corresponding card slots, as shown in the following figure. 3. Replace the cover and click it into place. Note:  The microSD card is an optional accessory. If it is not provided in the package, you can buy one yourself.  Ensure that the beveled edge of the SIM card is properly aligned with that of the SIM card slot and the microSD card is inserted according to the direction as labeled on the microSD card slot.  Do not remove the microSD or SIM card when the card is in use. Otherwise, the card as well as your USB Stick may get damaged and the data stored on the card may be corrupted. Installation/Removal Guide The procedure for installing the management program depends on the operating system (OS) installed on your PC. The following sections take Windows 7 as an example. Connecting the USB Stick to a PC Plug the USB Stick into the USB port of your PC. Installing the USB Stick Management Program 1. Connect the USB Stick with the PC. 2. The OS automatically detects and recognizes the new hardware and starts the installation wizard. Note: If the auto-run program does not respond, find the AutoRun Application in the driver path. Then double-click AutoRun Application to run the program. 3. Follow the on-screen instructions of the installation wizard. 4. After the program is installed, a shortcut icon for the management program appears on the desktop. Starting the Management Program After being installed, the management program starts automatically. Then every time the USB Stick is connected to the PC, the management program starts automatically. You can also double-click the shortcut icon on the desktop to start the management program. Removing the USB Stick 1. Click in the notification area. 2. Select the corresponding hardware and then click Safely Remove Hardware and Eject Media. 3. Remove the USB Stick after a while. Uninstalling the Management Program 1. Choose Start > Control Panel > Uninstall a program. 2. Find the management program and double-click it to uninstall the management program. Note: Exit the management program before uninstalling it. Version: V100R001_01 Part Number: 3101****

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: TUVPS Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality 2013-8-21 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISE3531S-6 to be kept confidential: 1. Schematic diagram. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Tune-up procedure 6. PCB Layout The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

HUAWEI Technologies Co., Ltd. Date (21/08/2013) BABT TCB Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Huawei Technologies Co., Ltd. Bantian, Longgang District, Shenzhen, 518129, China hereby authorize TUV-SUD China Shenzhen Branch 6/F, H Hall, Century Craftwork Culture Square, No. 4001 Fuqiang Road, Futian District, Shenzhen 518048 P. R. China Bu Cookies Phone: +86-755-88286998 e-mail: [email protected] to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that neither we nor any party to this application are subject to denial of U.S. Federal benefits, which include FCC benefits, pursuant to section 5301 of Anti-Drug Abuse Act of 1988, U.S.C. 862 because of conviction for possession or distribution of controlled substance. This authorization is application to following FCC ID application: Type of equipment: HSPA+ USB Stick Model no.: E3531s-6 FCC ID: QISE3531S-6 This authorization is valid until further written notice from Huawei Technologies Co., Ltd. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhangxinghai EMC Laboratory Manager

Statements Date (29/08/2013) BABT TCB Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Huawei Technologies Co., Ltd. Bantian, Longgang District, Shenzhen, 518129, China Hereby to confirm that our device, HSPA+ USB Stick, Models: E3531s-6, FCC ID: QISE3531S-6, the cover can be removed during package and the FCC ID is readily visible when users open the product box. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhangxinghai EMC Laboratory Manager

E3531s-6 SECRET Page1, Total5 External Photos of E3531s-6 E3531s-6 SECRET Page2, Total5 E3531s-6 SECRET Page3, Total5 E3531s-6 SECRET Page4, Total5 E3531s-6 SECRET Page5, Total5

E3531s-6 SECRET Page 1 Total 1 ID Label E3531s-6

E3531s-6 SECRET Page 1 Total 1 ID Label Location_E3531s-6

,HUAWEI E3531 s-6 SECRET _____________ - — -—————-—----——- .————————— -. 1 1 152 153 154 155 156 157 1ñ8 159 180 ‘6). 16 Page5, TotaI5

E3531s-6 SECRET Page1, Total2 Internal Photos of E3531s-6 E3531s-6 SECRET Page2, Total2

Report No.: SYBH(Z-SAR)004082013-2 FCC ID:QISE3531S-6 Appendix A. System Check Plots Table of contents SystemPerformanceCheck-D835-EX-Body SystemPerformanceCheck-D1900-EX-Body Date: 2013-8- 9 Test Laboratory: HUAWEI SAR/HAC Lab SystemPerformanceCheck-D835-EX-Body DUT: Dipole 835 MHz D835V2; Type: D835V2; Serial: D835V2 - SN:4d059 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.988 S/m; ε r = 55.611; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3898; ConvF(9.58, 9.58, 9.58); Calibrated: 2013-1- 14; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn1236; Calibrated: 2012-11-23 lPhantom: SAM4; Type: SAM; Serial: TP-1620 lDASY52 52.8.4(1052); SEMCAD X 14.6.8(7028) Configuration/d=15mm, Pin=250mW/Area Scan (6x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.56 W/kg Configuration/d=15mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 51.784 V/m; Power Drift = -0.10 dB Peak SAR (extrapolated) = 3.71 W/kg SAR(1 g) = 2.42 W/kg; SAR(10 g) = 1.59 W/kg Maximum value of SAR (measured) = 2.63 W/kg 0 dB = 2.63 W/kg = 4.20 dBW/kg Date: 2013-8-11 Test Laboratory: HUAWEI SAR/HAC Lab SystemPerformanceCheck-D1900-EX-Body DUT: Dipole 1900 MHz D1900V2; Type: D1900V2; Serial: D1900V2 - SN:5d143 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.558 S/m; ε r = 52.286; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3898; ConvF(7.52, 7.52, 7.52); Calibrated: 2013-1- 14; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn1236; Calibrated: 2012-11-23 lPhantom: SAM3; Type: SAM; Serial: TP-1597 lDASY52 52.8.4(1052); SEMCAD X 14.6.8(7028) Configuration/d=10mm, Pin=250mW/Area Scan (7x13x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 11.1 W/kg Configuration/d=10mm, Pin=250mW/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 62.090 V/m; Power Drift = -0.15 dB Peak SAR (extrapolated) = 19.5 W/kg SAR(1 g) = 10.5 W/kg; SAR(10 g) = 5.46 W/kg Maximum value of SAR (measured) = 11.9 W/kg 0 dB = 11.9 W/kg = 10.75 dBW/kg

Report No.: SYBH(Z-SAR)004082013-2 FCC ID: QISE3531S-6 Appendix B. SAR Measurement Plots Table of contents GSM850 B ody GSM1900 Body UMTS Band V Body UMTS Band II Body Date: 2013-8-10 Test Laboratory: HUAWEI SAR/HAC Lab E3531s-6 GSM850 GPRS 2TS 251CH Front side 5mm DUT: E3531s-6; Type: HSPA+ USB Stick; Serial: SAR1 Communication System: HW-GSM\GPRS\EGPRS-2TS; Frequency: 848.8 MHz;Duty Cycle: 1:4.10015 Medium parameters used: f = 849 MHz; σ = 1.002 S/m; ε r = 55.277; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3898; ConvF(9.58, 9.58, 9.58); Calibrated: 2013-1- 14; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn1236; Calibrated: 2012-11-23 lPhantom: SAM4; Type: SAM; Serial: TP-1620 lDASY52 52.8.4(1052); SEMCAD X 14.6.8(7028) Configuration/Body/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.796 W/kg Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.586 V/m; Power Drift = 0.19 dB Peak SAR (extrapolated) = 1.48 W/kg SAR(1 g) = 0.871 W/kg; SAR(10 g) = 0.520 W/kg Maximum value of SAR (measured) = 0.954 W/kg 0 dB = 0.954 W/kg = -0.21 dBW/kg Date: 2013-8-10 Test Laboratory: HUAWEI SAR/HAC Lab E3531s-6 GSM850 GPRS 2TS 251CH Front side 5mm-repeated DUT: E3531s-6; Type: HSPA+ USB Stick; Serial: SAR1 Communication System: HW-GSM\GPRS\EGPRS-2TS; Frequency: 848.8 MHz;Duty Cycle: 1:4.10015 Medium parameters used: f = 849 MHz; σ = 1.002 S/m; ε r = 55.277; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3898; ConvF(9.58, 9.58, 9.58); Calibrated: 2013-1- 14; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn1236; Calibrated: 2012-11-23 lPhantom: SAM4; Type: SAM; Serial: TP-1620 lDASY52 52.8.4(1052); SEMCAD X 14.6.8(7028) Configuration/Body/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.801 W/kg Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.552 V/m; Power Drift = 0.19 dB Peak SAR (extrapolated) = 1.51 W/kg SAR(1 g) = 0.875 W/kg; SAR(10 g) = 0.521 W/kg Maximum value of SAR (measured) = 0.958 W/kg 0 dB = 0.958 W/kg = -0.19 dBW/kg Date: 2013-8-10 Test Laboratory: HUAWEI SAR/HAC Lab E3531s-6 GSM850 GPRS 2TS 190CH Front side 5mm DUT: E3531s-6; Type: HSPA+ USB Stick; Serial: SAR1 Communication System: HW-GSM\GPRS\EGPRS-2TS; Frequency: 836.6 MHz;Duty Cycle: 1:4.10015 Medium parameters used: f = 837 MHz; σ = 0.993 S/m; ε r = 55.388; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3898; ConvF(9.58, 9.58, 9.58); Calibrated: 2013-1- 14; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn1236; Calibrated: 2012-11-23 lPhantom: SAM4; Type: SAM; Serial: TP-1620 lDASY52 52.8.4(1052); SEMCAD X 14.6.8(7028) Configuration/Body/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.671 W/kg Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.022 V/m; Power Drift = 0.14 dB Peak SAR (extrapolated) = 1.25 W/kg SAR(1 g) = 0.730 W/kg; SAR(10 g) = 0.437 W/kg Maximum value of SAR (measured) = 0.799 W/kg 0 dB = 0.799 W/kg = -0.98 dBW/kg Date: 2013-8-10 Test Laboratory: HUAWEI SAR/HAC Lab E3531s-6 GSM850 GPRS 2TS 128CH Front side 5mm DUT: E3531s-6; Type: HSPA+ USB Stick; Serial: SAR1 Communication System: HW-GSM\GPRS\EGPRS-2TS; Frequency: 824.4 MHz;Duty Cycle: 1:4.10015 Medium parameters used (interpolated): f = 824.4 MHz; σ = 0.993 S/m; ε r = 55.644; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3898; ConvF(9.58, 9.58, 9.58); Calibrated: 2013-1- 14; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn1236; Calibrated: 2012-11-23 lPhantom: SAM4; Type: SAM; Serial: TP-1620 lDASY52 52.8.4(1052); SEMCAD X 14.6.8(7028) Configuration/Body/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.563 W/kg Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.597 V/m; Power Drift = 0.13 dB Peak SAR (extrapolated) = 1.02 W/kg SAR(1 g) = 0.602 W/kg; SAR(10 g) = 0.361 W/kg Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.660 W/kg 0 dB = 0.660 W/kg = -1.80 dBW/kg Date: 2013-8-9 Test Laboratory: HUAWEI SAR/HAC Lab E3531s-6 GSM850 GPRS 2TS 251CH Back side 5mm DUT: E3531s-6; Type: HSPA+ USB Stick; Serial: SAR1 Communication System: HW-GSM\GPRS\EGPRS-2TS; Frequency: 848.8 MHz;Duty Cycle: 1:4.10015 Medium parameters used: f = 849 MHz; σ = 1.002 S/m; ε r = 55.277; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: lProbe: EX3DV4 - SN3898; ConvF(9.58, 9.58, 9.58); Calibrated: 2013-1- 14; lSensor-Surface: 4mm (Mechanical Surface Detection), z = 1.0, 31.0 lElectronics: DAE4 Sn1236; Calibrated: 2012-11-23 lPhantom: SAM4; Type: SAM; Serial: TP-1620 lDASY52 52.8.4(1052); SEMCAD X 14.6.8(7028) Configuration/Body/Area Scan (6x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.810 W/kg Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 23.324 V/m; Power Drift = -0.18 dB Peak SAR (extrapolated) = 1.27 W/kg SAR(1 g) = 0.801 W/kg; SAR(10 g) = 0.497 W/kg Maximum value of SAR (measured) = 0.871 W/kg 0 dB = 0.871 W/kg = -0.60 dBW/kg Date: 2013-8-9 Test Laboratory: HUAWEI SAR/HAC Lab E3531s-6 GSM850 GPRS 2TS 190CH Back side 5mm DUT: E3531s-6; Type: HSPA+ USB Stick; Serial: SAR1 Communication System: HW-GSM\GPRS\EGPRS-2TS; Frequency: 836.6 MHz;Duty Cycle: 1:4.10015 Medium parameters used: f = 837 MHz; σ = 0.993 S/m; ε r = 55.388; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: l…

Text truncated - open the document above for the full version.

Justification of the extended calibration of Dipole D1900V2 SN:5d143 Referred to 450824 D02 Dipole SAR Validation Verification v01, Published on Nov 17 2009, Otherwise, according to the IEEE Standard 1528a-2005 recommended annual calibration is expected, when happened as below the following: 1) When the most recent return-loss, measured at least annually, deviates by more than 20% from the previous measurement (i.e. 0.2 of the dB value) or not meeting the required -20 dB return-loss specification; 2) When the most recent measurement of the real or imaginary parts of the impedance, measured at least annually, deviates by more than 5 Ω from the previous measurement. Dipole1900 Head TST Target Value Measured Value Difference Impedance transformed to feed point 53.5Ω+5.8jΩ 50.8Ω+8.57jΩ R=-2.7Ω, X=2.77Ω Return Loss - 23.7dB -24.16dB -1.94% Dipole1900 Body TST Target Value Measured Value Difference Impedance transformed to feed point 48.4Ω+6.1jΩ 45.78Ω+3.17jΩ R=-2.62Ω, X=-2.93Ω Return Loss -23.9dB -25.3dB -5.86% Measure Data 2011-09-26 2012-09-13 -- Impedance Test-Head Return Loss Test-Head Impedance Test-Body Return Loss Test-Body

Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Tel: +86 755 28780808 Fax: +86 755 89652518 FCC SAR Compliance Test Report Product Name:_______________________ Model :_______________________ FCC ID : _______________________ Report No. : _______________________ APPROVED (Lab Manager) PREPARED (Test Engineer) BY DATE 2013-08-20 2013-08-20 The test results of this test report relate exclusively to the item(s) tested , The HUAWEI does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of HUAWEI. Reliability Laboratory of Huawei Technologies Co., Ltd. E3531s-6 QISE3531S-6 SYBH(Z-SAR)004082013-2 HSPA+ USB Stick Report No.: SYBH(Z-SAR)004082013-2 FCC ID: QISE3531S-6 2013-08-20 Page 2 of 33 Table of Contents 1 General Information ............................................................................................................................................................ 4 1.1 Statement of Compliance .......................................................................................................................................... 4 1.2 RF exposure limits...................................................................................................................................................... 4 1.3 EUT Description ......................................................................................................................................................... 5 1.3.1 General Description ........................................................................................................................................... 5 1.4 Test specification(s) .................................................................................................................................................. 6 1.5 Testing laboratory ....................................................................................................................................................... 6 1.6 Applicant and Manufacturer ...................................................................................................................................... 6 1.7 Application details ...................................................................................................................................................... 6 1.8 Ambient Condition ...................................................................................................................................................... 6 2 SAR Measurement System ............................................................................................................................................. 7 2.1 SAR Measurement Set-up ....................................................................................................................................... 7 2.2 Test environment ........................................................................................................................................................ 8 2.3 Data Acquisition Electronics description ................................................................................................................ 8 2.4 Probe description ....................................................................................................................................................... 9 2.5 Phantom description ................................................................................................................................................ 10 2.6 Device holder description ........................................................................................................................................ 10 2.7 Test Equipment List ................................................................................................................................................. 11 3 SAR Measurement Procedure ...................................................................................................................................... 12 3.1 Scanning procedure ................................................................................................................................................. 12 3.2 Spatial Peak SAR Evaluation ................................................................................................................................. 13 3.3 Data Storage and Evaluation .................................................................................................................................. 14 4 System Verification Procedure ........................................................................................................................................ 16 4.1 Tissue Verification .................................................................................................................................................... 16 4.2 System Check ........................................................................................................................................................... 17 4.3 System check Procedure ........................................................................................................................................ 18 5 Measurement Uncertainty Evaluation .......................................................................................................................... 19 5.1 Measurement uncertainty evaluation for SAR test .............................................................................................. 19 5.2 Measurement uncertainty evaluation for system check...................................................................................... …
