Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|
| 6 | 24E | 1.85 GHz - 1.91 GHz | 300.00 mW | 4M20F9W | 0.02
ppm |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesOutput power is ERP for Part 22 and EIRP for Part 24
This device contains functions that are not operational in U.S. Territories. This filing is only applicable for US operations.
Device was tested for SAR compliance for use in notebook computers with connector configurations as described in this filing, and can be used with notebook computers with substantially similar physical dimensions, construction, and electrical and RF characteristics. Compliance of this device in all final host configurations is the responsibility of the Grantee.
End-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. The antenna(s) used for this transmitter must not be co located or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product guidelines.
The highest measured SAR values are: Part 22 lap-held: 1.10 W/kg; Part 24 lap-held: 1.13 W/kg
