QISE5776U-72Mobile Cellular Device with GSM/GPRS/EDGE 1900, WCDMA/HSPA/DC-HSPA FDD II/V, CDMA EVDO BC0.

1 Thank you for choosing HUAWEI Mobile WiFi Supported functions and actual appearance depend on the specific models you purchased. The illustrations are provided for your reference only. For details about the model you selected, consult your service provider. This guide briefly describes the functions of the Mobile WiFi. For more details, see help on the web management page. Copyright © Huawei Technologies Co., Ltd. 2012. All rights reserved. THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY, AND DOES NOT CONSTITUTE ANY KIND OF WARRANTIES. 2 Getting to Know HUAWEI Mobile WiFi Connection Scenario A Wi-Fi device can be connected to the Internet through the Mobile WiFi. The actual connection procedure depends on the operating system of the Wi-Fi device. The connection scenario illustrated here is for your reference. Scenario 1: Multi-device access via Wi-Fi Scenario 2: One-device access via USB 3 Scenario 3: Multi-device access via Wi-Fi and USB at the same time 4 Appearance No. Item 1 Screen 2 Power button 3 micro-SIM card slot 4 Reset button 5 Strap hole 6 WPS button  Press and hold it until a WPS activation animation is displayed to enable the WPS function. 7 USB port 2 34 567 1 5 Screen No. Item 1 Signal strength 2 Network 3 Battery level 4  Wi-Fi enabled  Number of devices connected 5 International roaming state 123 4 5 R 3G 6 SSID and Wireless Network Key To connect a Wi-Fi device to your Mobile WiFi, an SSID and a wireless network key are required. The default SSID and wireless network key can be found in the gift box. Before You Start Installing the micro-SIM Card Caution: Do not use any micro-SIM card that is not standard or is incompatible with the Mobile WiFi. Otherwise, the Mobile WiFi may be damaged. 1. Remove the rubber cap from the micro-SIM card slot. Then insert the micro-SIM card into the slot. Be sure that the micro-SIM card is facing in the right direction. 2. After inserting the micro-SIM card completely, attach the rubber cap. Note:  To remove the micro-SIM card, press in the card gently. The micro-SIM card will pop 7 out for removal.  Do not remove the micro-SIM card when the card is in use. Otherwise, the card as well as your Mobile WiFi may get damaged and the data stored on the card may be corrupted. Charging the Battery Charge your Mobile WiFi the first time you use it or if it has not been used for a long time. Method 1: Using the charger Caution:  Only use chargers compatible with the Mobile WiFi and provided by a designated manufacturer (HW-050200U3W). Use of an incompatible charger or one from an unknown manufacturer may cause the Mobile WiFi to malfunction, fail, or could even cause a fire. Such use voids all warranties, whether expressed or implied, on the product. 8 Method 2: Connecting to a PC for charging Connect the Mobile WiFi to a PC using a compatible data cable. 9 Accessing the Internet via Wi-Fi Connection By default, management parameters are preset on the Mobile WiFi according to the requirements of the service provider. Follow the steps below to quickly access the Internet. Step1: Power on the Mobile WiFi Press and hold until the screen lights up. The Mobile WiFi is powered on. Note: Press and hold to power off the Mobile WiFi. 10 Step2: Establish a Wi-Fi Connection (Take a computer with Windows XP operating system as an example) 1. Make sure that the Wi-Fi is enabled. 2. Select Start > Control Panel > Network Connections > Wireless Network Connection. Note: To set up a Wi-Fi connection, the PC must have a wireless network adapter installed. If Wireless Network Connection is displayed, a wireless network adapter is available. Otherwise, check to make sure you have a wireless network adapter installed. 3. Click View available wireless networks to display a list of wireless networks available. 4. Select a network indicated by the SSID of the Mobile WiFi, and then click Connect. Note:If the encryption parameter is already set for the Mobile WiFi, the Wireless Network Connection dialog box is displayed. Enter the wireless network key in the dialog box. 5. Wait until the wireless connection icon is displayed in the status area in the lower right corner of the PC screen. 11 Step3: Access the Internet After you establish a Wi-Fi connection successfully, you can access the Internet using the following modes. Caution: Please select a proper Internet connection mode based on your service expense. For example, if you are subscribed to the time-based network service, you are recommended to select Manual mode. For details about the service expense, consult your service provider. Mode Operations Auto After the Mobile WiFi is powered on, it will connect to the Internet automatically. If there is no data transmission over a period of time, the Mobile WiFi automatically terminates the Internet connection. Manual Launch the web management page and follow the prompts to connect to or disconnect from the network. 12 Note:  Launch the web management page to select the mode for accessing the Internet.  You can choose whether to enable the Mobile WiFi to connect to the Internet automatically even while you are roaming. If this function is disabled, the Mobile WiFi automatically disconnects from the Internet while you are roaming. To access the Internet, set up a connection manually. Accessing the Web Management Page 1. Make sure that the connection between the Mobile WiFi and the client is a proper one. 2. Start the Internet browser and enter http://192.168.1.1 in the address bar. 3. Enter the password and log in to the web management page. Note: The default password is admin. 13 Daily Use Power Saving Mode If no operation is performed on the Mobile WiFi within a preset period, the screen turns off. Press any key to light up the screen. If the Mobile WiFi is powered by the battery only, choose whether to enable the Mobile WiFi to turn off Wi-Fi automatically. If this function is enabled and no Wi-Fi devices access the Mobile WiFi for a preset period, the Mobile WiF…

Text truncated - open the document above for the full version.

Copyright © Huawei Technologies Co., Ltd. 2012. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd. and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses. Trademarks and Permissions , , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. LTE is a trademark of ETSI. Other trademarks, product, service and company names mentioned are the property of their respective owners. Notice Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd. reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. NO WARRANTY THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD. BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS. Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein. Warnings and Precautions This section contains important information pertaining to the operating instructions of your device. It also contains information about how to use your device safely. Read this information carefully before using the device. Electronic Device Do not use your device if using the device is prohibited. Do not use the device when using the device causes danger or interference with electronic devices. Medical Device  Follow rules and regulations set forth by hospitals and health care facilities. Do not use your device when using the device is prohibited.  Some wireless devices may affect the performance of hearing aids or pacemakers. For any such problems, consult your service provider.  If you are using an electronic medical device, consult the doctor or the device manufacturer to confirm whether radio waves affect the operation of this device. Potentially Explosive Atmosphere Do not use your device in any area with a potentially explosive atmosphere, and comply with all signs and instructions. Areas that may have potentially explosive atmospheres include the areas where you would normally be advised to turn off your vehicle engine. Triggering of sparks in such areas could cause an explosion or a fire, resulting in bodily injuries or even deaths. Do not use your device at refueling points such as service stations. Comply with restrictions on the use of radio equipment in fuel depots, storage, and distribution areas, and chemical plants. In addition, adhere to restrictions in areas where blasting operations are in progress. Before using the device, watch out for areas that have potentially explosive atmospheres that are often, but not always, clearly marked. Such locations include areas below the deck on boats, chemical transfer or storage facilities, and areas where the air contains chemicals or particles such as grain, dust, or metal powders. Ask the manufacturers of vehicles using liquefied petroleum gas (such as propane or butane) whether this device can be safely used in their vicinity. Traffic Security  Observe local laws and regulations while using the device. To prevent accidents, do not use your wireless device while driving.  RF signals may affect electronic systems of motor vehicles. For more information, consult the vehicle manufacturer.  In a motor vehicle, do not place the device over the air bag or in the air bag deployment area. Otherwise, the device may hurt you owing to the strong force when the air bag inflates.  Do not use your device while flying in an aircraft and before boarding an aircraft. Using wireless devices in an aircraft may cause danger to the operation of the aircraft and disrupt the wireless telephone network. It may also be considered illegal. Operating Environment  Do not use or charge the device in dusty, damp, and dirty places or places with magnetic fields. Otherwise, it may result in a malfunction of the circuit.  While using the device, observe the local laws and regulations, and respect others' privacy and legal rights.  Place the device or accessories in well-ventilated, cool, and out-of-direct-sunlight place. Avoid enveloping the device, or covering towels and placing articles on the device. Place the device out of a box or case to avoid poor heat dissipation that results in the damage to the device.  On a stormy day with thunder, do not use your device, to prevent any danger caused by lightning.  Keep the ambient temperature between 0°C to +35°C for using the device. Safety of Children Comply with all precautions with regard to children's safety. Letting the child play with your device or its accessories, which may include parts that can be detached from the …

Text truncated - open the document above for the full version.

Huawei Technologies Co.,Ltd. Federal Communications Commission 2012-08-15 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: QISE5776U-72 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Operational Description Bom List Tune-Up Procedure Lab PBA Inquiry Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. ***************************************************************************** In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until 2012-10-30: External Photos Internal Photos Test Setup Photos User Manual ****************************************************************************** It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. E-mail: [email protected] Fax: 0086-0755- 28970299

Huawei Technologies Co.,Ltd. Federal Communications Commission 2012-08-15 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: QISE5776U-72 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Operational Description Bom List Tune-Up Procedure Lab PBA Inquiry Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. ***************************************************************************** In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until 2012-10-30: External Photos Internal Photos Test Setup Photos User Manual ****************************************************************************** It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. E-mail: [email protected] Fax: 0086-0755- 28970299

CDMA HWD11 Mobile WiFi SECRET Page1，Total 5 External Photos of CDMA HWD11 CDMA HWD11 Mobile WiFi SECRET Page2，Total 5 CDMA HWD11 Mobile WiFi SECRET Page3，Total 5 CDMA HWD11 Mobile WiFi SECRET Page4，Total 5 CDMA HWD11 Mobile WiFi SECRET Page5，Total 5

CDMA HWD11 Mobile WiFi SECRET Page 1 Total 1 CDMA HWD11 Label & Label Location:

CDMA HWD11 Mobile WiFi SECRET Page1，Total5 Internal Photos of CDMA HWD11 CDMA HWD11 Mobile WiFi SECRET Page2，Total5 CDMA HWD11 Mobile WiFi SECRET Page3，Total5 CDMA HWD11 Mobile WiFi SECRET Page4，Total5 CDMA HWD11 Mobile WiFi SECRET Page5，Total5

EMC Test Report Product Name: Mobile WiFi Model Number: CDMA HWD11 Report No: SYBH(Z-EMC)039082012-2 FCC ID：QISE5776U-72 Reliability Laboratory of Huawei Technologies Co., Ltd. Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Tel: +86 755 28780808 Fax: +86 755 89652518 Test Report of CDMA HWD11 FCC ID: QISE5776U-72 Security Level: secret Report No: SYBH(Z-EMC)039082012-2 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total17 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has passed the accreditation by The American Association for Laboratory Accreditation (A2LA). The accreditation number is 2174.01. 3. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 4. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-2. 5. The test report is invalid if not marked with "exclusive stamp for the test report". 6. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 7. The test report is invalid if there is any evidence of erasure and/or falsification. 8. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 9. Normally, the test report is only responsible for the samples that have undergone the test. 10. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. Test Report of CDMA HWD11 FCC ID: QISE5776U-72 Security Level: secret Report No: SYBH(Z-EMC)039082012-2 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total17 Applicant: Huawei Technologies Co., Ltd. Address: Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Date of Receipt Test Item: Jul.23, 2012 Start Date of Test: Jul.23, 2012 End Date of Test: Aug.05, 2012 Test Result: Pass Approved By 2012-08-08 Liu Chunlin (Lab Manager) Date Name Signature Operator 2012-08-08 Xiang Zaiji Date Name Signature Test Report of CDMA HWD11 FCC ID: QISE5776U-72 Security Level: secret Report No: SYBH(Z-EMC)039082012-2 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total17 Modification Record No. Last Report No. Modification Description 1 NA First Report. Test Report of CDMA HWD11 FCC ID: QISE5776U-72 Security Level: secret Report No: SYBH(Z-EMC)039082012-2 Confidential Information of Huawei. No Distribution without Written Permission Page5, Total17 TABLE OF CONTENT 1 General Information ........................................................................................................................... 6 1.1 EUT Description ......................................................................................................................... 6 1.2 Test Site Information .................................................................................................................. 7 1.3 Applied Standards ...................................................................................................................... 7 2 Summary of Results .......................................................................................................................... 8 3 System Configuration during EMC Test ............................................................................................ 9 3.1 Test Mode .................................................................................................................................. 9 3.2 Test System Configuration ......................................................................................................... 9 3.3 Cables Used during Test .......................................................................................................... 10 3.4 Associated Equipment Used during Test ................................................................................. 10 4 Electromagnetic Interference (EMI) ................................................................................................. 11 4.1 Radiated Disturbance 30MHz to 18GHz .................................................................................. 11 4.2 Conducted Disturbance 0.15 MHz to 30MHz .......................................................................... 13 5 Main Test Instruments ..................................................................................................................... 14 6 System Measurement Uncertainty .................................................................................................. 14 7 Test Data and Graph ....................................................................................................................... 15 7.1 Radiated Disturbance ............................................................................................................... 15 7.2 Conducted Disturbance ............................................................................................................ 17 Test Report of CDMA HWD11 FCC ID: QISE5776U-72 Security Level: secret Report No: SYBH(Z-EMC)039082012-2 Confidential Information of Huawei. No Distribution without Written Permission Page6, Total17 1 General Information 1.1 EUT Description EUT Description Product Name Mobile WiFi Model Number CDMA HWD11 Serials Number L4H01A9262100047 TX Frequency GSM1900: 1850MHz To 1910MHz WCDMA Band II: 1850MHz To 1910MHz WCDMA Band V: 824MHz To 849MHz CDMA…

Text truncated - open the document above for the full version.

FCC Test Report of CDMA HWD11 FCC ID: QISE5776U-72 Security Level: secret Report No: SYBH(Z-EMC)039082012-2 Confidential Information of Huawei. No Distribution without Permission Page1, Total6 Photos of EUT FCC Test Report of CDMA HWD11 FCC ID: QISE5776U-72 Security Level: secret Report No: SYBH(Z-EMC)039082012-2 Confidential Information of Huawei. No Distribution without Permission Page2, Total6 EUT Appearance FCC Test Report of CDMA HWD11 FCC ID: QISE5776U-72 Security Level: secret Report No: SYBH(Z-EMC)039082012-2 Confidential Information of Huawei. No Distribution without Permission Page3, Total6 Photos of Test Setup FCC Test Report of CDMA HWD11 FCC ID: QISE5776U-72 Security Level: secret Report No: SYBH(Z-EMC)039082012-2 Confidential Information of Huawei. No Distribution without Permission Page4, Total6 1 Radiated Emissions Radiated Disturbance （30MHz To 1GHz） FCC Test Report of CDMA HWD11 FCC ID: QISE5776U-72 Security Level: secret Report No: SYBH(Z-EMC)039082012-2 Confidential Information of Huawei. No Distribution without Permission Page5, Total6 Radiated Disturbance（1GHz To 18GHz） FCC Test Report of CDMA HWD11 FCC ID: QISE5776U-72 Security Level: secret Report No: SYBH(Z-EMC)039082012-2 Confidential Information of Huawei. No Distribution without Permission Page6, Total6 2 Conducted Emissions Conducted Emissions with AC Port
