QISEC6108V9Huawei STB

LYCA TV Set of Box User Guide 2 Select the TV Signal Source 3 Starting the STB Appearance and Connecting Cables 1 TV AV HDMI Remote Control Connect the , choose the TV or AV Connect the , choose the HDMI. green light: working red light: standby 1 2 3 4 5 6 7 8 * You can select a wireless network. Power switch Power adapter RJ45 cable Home gateway HDMI cable Mini AV cable 1 2 3 4 5 DescriptionItemNo. Switch TV ON/OFF. Study the function of the TV’s Remote control. TV volume UP/DOWN. Select TV input source. Switch STB ON/STANDBY. Audio Mute/Un-Mute. Mouse Mode. Accounts and Profile Management. Refresh. Social Networking. Favorites. Search. Numerals 0 to 9 and associated letters. Enter an asterisk (*).  Enter a number sign (#).  Switch between input methods. 5 6 7 8 DescriptionItemNo. Shortcut to homepage. Go BACK.  Move selection UP, DOWN, LEFT or RIGHT.  In Mouse Mode. move cursor UP, DOWN, LEFT or RIGHT. Confirm an operation. See information about the TV/Movie program. Access application(s) menu. STB Volume UP/DOWN. Video on Demand. Enter Program Guide. Channels UP/DOWN. Media Rewind. Media Fast Forward. Media Play/Pause. Media Stop. Live TV. Movies. Radio Channels. Applications. System Settings. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. 7 Cotrol Remote Study Function Precautions FAQs Overview Your STB remote control is able to study the functions of keys on your TV remote control. This allows you to control both your STB and TV by using your STB remote control. Only the keys on the TV study keypad on your STB remote control are used for studying the functions of keys on your TV remote control. The other keys on your STB remote control are used for controlling the STB. There are four keys on the TV study keypad: : enables your STB remote control to enter the study mode. , , and (red): enable your STB remote control to study the functions of keys on your TV remote control. The functions of all keys on your TV remote control can be studied. It is recommended that the functions of the keys on your TV remote control that have the same names as keys on your STB remote control be studied.     You can repeat steps 2 and 3 to enable your STB remote control to study the functions of the and keys on your TV remote control. Procedure Assume that you want your STB remote control to study the function of the Power key on your TV remote control. The procedure is as follows: Step 1 Hold down on the TV study keypad for 3 seconds. The indicator on your STB remote control is steady on, which indicates that the STB has entered the study mode. Step 2 Hold down (red) on the TV study keypad for 1 second. The indicator on your STB remote control blinks, which indicates that your STB remote control is ready for receiving a signal. Step 3 Aim the emission port of your TV remote control at the emission port of your STB remote control (the distance between the two ports must be less than 3 cm), and hold down the Power key on your TV remote control for 3 seconds to send a signal. Step 4 Press to save the settings and to exit the study mode. After that, you can control your TV by using the (red) key on the TV study keypad. If the indicator on your STB remote control does not respond in the preceding way, your STB remote control has failed to receive the signal. Repeat steps 2 and 3. If the indicator on your STB remote control quickly blinks three times and then is steady on, your STB remote control has received the signal and the study of the Power key function is complete. Release the Power key on your TV remote control.    Items in the Packaging Box Precautions If no signal is received within 10 seconds after your STB remote control enters the study mode, the study mode exits automatically. The keys on the TV study keypad can be used for studying the functions of keys on your TV remote controls of various brands. Only key functions that are last studied are saved. If you have trouble using your STB remote control to control your TV after performing steps 1 to 4, verify that your STB remote control is working properly. Safety Instructions       Maintenance Instructions     Tips on Making Repairs     This product should be operated only from the type of power source indicated on the marking label. Confirm appropriate power and cable connection before powering on the STB. If the STB has been operating for a long time, STB temperature increases. Take measures for heat dissipation. Upon cleaning or long-time unused, disconnect the power cable. Do not pull on the power cable. When disconnecting the power cable, turn off the STB, and then grasp it by the plug. During a lightning storm, disconnect the power cable or network cable to avoid damage to the STB or other accidents caused by lightning strikes. Do not damage the warranty tag when removing the STB cover. Do not allow unqualified personnel to remove the STB cover. This is to avoid damage to the internal circuit. If repair is required, contact the local service center. If parts replacement is required, ensure that service technicians use the parts that are specified by the manufacturer and have the same character- istics as the original parts. Shield the STB from direct sunlight and keep it away from sources of intense heat. Install the STB in a well-ventilated position, and avoid humid and dusty places. Use a soft cloth to clean STB surface. Never use alcohol, gasoline, or other organic solvent. Do not place the STB in any location that is subject to strong pressure, striking, or vibration. 1. Black-and-white images are displayed after STB startup. Possible Cause: The video cable is of poor quality or is not properly connected. Solution: Replace and reconnect the video cable. 2. No video is displayed on the TV screen. Possible Cause: The video cable or network cable is not properly connected.   The STB is powered off. The TV is in an incorrect mode. Solution: …

Text truncated - open the document above for the full version.

FCC ID: QISEC6108V9 +86 755 89650226 Date: DECLARATION LETTER We, , hereby declare that (1) this product will be used for indoor operations; (2) the band from 5600~5650MHz will be disabled by the sofeware during the manufacturing and which cannot be changed by the end-user.. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ----------------------------------- Name: / Title: Tel: Fax: E-mail: HUAWEI TECHNOLOGIES CO., LTD. Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian Longgang District, Shenzhen 518129 China 2015-10-6 Zhangxinghai GCTC Director [email protected] +86 755-28970299 HUAWEI TECHNOLOGIES CO., LTD.

HUAWEI TECHNOLOGIES CO., LTD. Administration Building, Headquarters of Huawei Technologies Co.,Ltd., Bantian, Longgang District, Shenzhen, Guangdong, 518129 China Date: 09-04-2015 Federal Communications Commission Authorization and Evaluation Division FCC ID: QISEC6108V9 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Name：Zhang Xinghai Company name: HUAWEI TECHNOLOGIES CO., LTD. Tel.：( 86)755-28970299 Fax：(86)755-89650226 contact position :GCTC Director

HUAWEI TECHNOLOGIES CO., LTD. Administration Building, Headquarters of Huawei Technologies Co.,Ltd., Bantian, Longgang District, Shenzhen, Guangdong, 518129 China AGENCY AUTHORIZATION LETTER FCC ID: QISEC6108V9 Date: 09-04-2015 To whom it may concern: We, the undersigned, hereby authorize Bureau Veritas Shenzhen Co. Ltd Dongguan Branch., to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by BVDG within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months form original date. If you have any Questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Name：Zhang Xinghai Company name: HUAWEI TECHNOLOGIES CO., LTD. Tel.：( 86)755-28970299 Fax：(86)755-89650226 contact position :GCTC Director

HUAWEI TECHNOLOGIES CO., LTD. Administration Building, Headquarters of Huawei Technologies Co.,Ltd., Bantian, Longgang District, Shenzhen, Guangdong, 518129 China Tel.：( 86)755-28970299 Fax：(86)755-89650226 FCC ID: QISEC6108V9 We hereby declare that our device with the FCC ID above does not initiate and it can not be configured to initiate any transmission on any non-US frequencies or unauthorized frequencies. This includes probes, beacons, and ad-hoc mode transmissions. Our operation is limited to the following frequencies and modes: 2.4G WiFi 802.11b Channel 1 (2412MHz) – Channel 11 (2462MHz) 802.11g Channel 1 (2412MHz) – Channel 11 (2462MHz) 802.11n (20MHz) Channel 1 (2412MHz) – Channel 11 (2462MHz) 802.11n (40MHz) Channel 3 (2422MHz) – Channel 9 (2452MHz) BT 2.1 + EDR Channel 0 (2402MHz) – Channel 78 (2480MHz) BT 4.0 Channel 0 (2402MHz) – Channel 39 (2480MHz) 5G WiFi 802.11a, 802.11n(20MHz) Channel 36 (5180MHz) – Channel 48 (5240MHz) Channel 52 (5260MHz) – Channel 64 (5320MHz) Channel 100 (5500MHz) – Channel 140 (5700MHz) Channel 149 (5745MHz) – Channel 165 (5825MHz) 5G WiFi 802.11n(40MHz) Channel 38 (5190MHz) – Channel 46 (5230MHz) Channel 54 (5270MHz) – Channel 62 (5310MHz) Channel 102 (5510MHz) – Channel 134 (5670MHz) Channel 151 (5755MHz) – Channel 159 (5795MHz) Name : Zhang Xinghai Title : GCTC Director Signature:
