QISF201Fixed Wireless Terminal

Huawei Technologies Co.,Ltd

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Jun 28, 2011
Application Purpose: Original Equipment
Date of Application: Jun 28, 2011
Equipment Note: Fixed Wireless Terminal
Frequency Range: 824.00000000 - 849.00000000
Company: Huawei Technologies Co.,Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Copyright © Huawei Technologies Co., Ltd. 2011. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses. Trademarks and Permissions , HUAWEI, and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Other trademarks, product, service and company names mentioned are the property of their respective owners. Notice Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers. Thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. NO WARRANTY THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS. Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein. 1 Appearance  Note: The figures in this guide are provided for your reference only. Front View No. Keys/Indicators Description 1 Left function key Select the option displayed in the lower left corner of the screen. 2 Navigation keys  Access the main menu by pressing the OK key in standby mode.  Access a shortcut menu by pressing the corresponding navigation key in standby mode.  Adjust the volume by pressing the navigation keys during a call. 3 Right function key Select the option displayed in the lower right corner of the screen. 4 Number and symbol keys  Enter numbers, letters, and symbols.  Number keys (2–9): Speed-dial a phone number by pressing and holding a key in standby mode.  # key: Switch between text input methods in editing mode.  * key: Display the symbol list in editing mode. 5 Speaker indicator When the hands-free mode is activated, the speaker indicator is on. 2 No. Keys/Indicators Description 6 Power indicator When the power adapter is connected, this indicator is on. 7 Call/Send key  Make or answer a call.  View the call log in standby mode. 8 Speaker key Activate the hands-free mode to dial a number already entered or answer an incoming call. 9 End key  End or cancel a call.  Power the phone on or off by pressing and holding the key.  Turn the backlight on or off in standby mode.  Return to the standby mode. 10 Speed dial keys Speed-dial a defined phone number in standby mode. 11 Shortcut keys Each shortcut key carries a specific function. Screen Icons Icon Description Icon Description Signal strength Battery level Alarm clock Hands-free mode Call in progress No network available Unread message Unopened voicemail message Phone powered by the power adapter Roaming Installation (Optional) Installing a UIM Card Ensure that the phone is powered off and disconnected from the power adapter. When installing a User Identity Module (UIM) card, ensure that the golden contacts of the UIM card are facing downward and that the beveled edge of the UIM card is properly aligned with that of the UIM card slot. Then check that the UIM card is completely inserted.  Note: Do not frequently remove the UIM card when using the phone. 3 Installing the Battery Before using the phone, install the battery properly. When installing the battery, ensure that the phone is powered off and is disconnected from the power adapter; ensure that the golden contacts of the battery mate securely with those in the battery slot. c  Note: If the phone will not be used for a long time, remove the battery from the phone. Charging the Battery  Note:  When the phone is delivered, the batter power is lower. Therefore, charge the phone for a while and then power on the phone the first time you use it.  When you use the phone, it is recommended that you connect the power adapter to the phone. When using the battery to power the phone, ensure that the battery power is sufficient.  I/O connects can only support charging. It can’t support USB with PC for data transfer. Powering On the Phone To power on the phone, press and hold the End key until the screen lights up.  Note: Press and hold the End key to power off the phone. Call Functions Making a Call 1. In standby mode, press the number keys to enter a phone number. 2. Press the Call key to dial the number. 3. Press the End key to end the call or cancel the dialing. 4  Note:  In standby mode, press the Call key to view the call log. Find the desired number in the call log, and then press the Call key dial the number.  Find the desired number in the phonebook, and then press the Call key to dial the number. Answering or Rejecting a Call When there is an incoming call, press the Call key to answer the call; press the …

Text truncated - open the document above for the full version.

Cover Letter(s)

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base, Bantian, Longgang, Shenzhen, P.R China Post ZIP：518129 Page ：1/1 To: INTERTEK Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Authorization 2011-05-18 To whom it may concern: We the undersigned, hereby authorize INTERTEK to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by INTERTEK on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Huawei Technologies Co., Ltd. . Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Cover Letter(s)

22____day of__J_une_ , 2011__ F201 Letter of Agency I appoint Intertek Testing Services Hong Kong Limited. to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under the FCC rules until further notice. I further certify that no party (as defined in 1.2002 of CFR 47, 1995) to this application, including myself, is subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,853A. Equipment: ____ Dated this _ _____________________________________ Signature ZhangXinghai _____________________________________ Name EMC manager _____________________________________ Title Huawei Technologies Co., Ltd. _____________________________________ Company _______8675528781879___________________ Telephone

Cover Letter(s)

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: INTERTEK Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISF201 to be kept confidential: 1. Schematic diagram. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Turn-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

External Photos

HUAWEI F201 Fixed Wireless Terminal SECRET Page1, Total6 Photo documentation of external of product HUAWEI F201 Fixed Wireless Terminal SECRET Page2, Total6 HUAWEI F201 Fixed Wireless Terminal SECRET Page3, Total6 HUAWEI F201 Fixed Wireless Terminal SECRET Page4, Total6 HUAWEI F201 Fixed Wireless Terminal SECRET Page5, Total6 HUAWEI F201 Fixed Wireless Terminal SECRET Page6, Total6

ID Label/Location Info

Huawei F201 Fixed Wireless Terminal SECRET Page1, Total 1 F201 Label Location

ID Label/Location Info

HUAWEI F201 Fixed Wireless Terminal Secret Page1,Total1 F201 Lable:

Internal Photos

Huawei F201 Fixed Wireless Terminal SECRET Page1, Total7 Photo documentation of interior of product Huawei F201 Fixed Wireless Terminal SECRET Page2, Total7 Huawei F201 Fixed Wireless Terminal SECRET Page3, Total7 Huawei F201 Fixed Wireless Terminal SECRET Page4, Total7 Huawei F201 Fixed Wireless Terminal SECRET Page5, Total7 Huawei F201 Fixed Wireless Terminal SECRET Page6, Total7 Huawei F201 Fixed Wireless Terminal SECRET Page7, Total7

RF Exposure Info

HUAWEI F201 Electromagnetic Radiation Exposure Estimation 1 Maximum Permissible Exposure (MPE) Estimation for F201 1 Introduction HUAWEI F201 is Wireless Fixed Terminal equipment in the CDMA system, The frequency band is US Cellular. The Fixed Wireless Terminal implements such functions as RF signal receiving / Transmitting, CDMA protocol processing, voice and SMS service etc. The Fixed Wireless Terminal uses QSC1100 chipset and Zero-IF technologies. 2 Limits and Guidelines on Exposure to Electromagnetic Fields According to the FCC Part 2.1091, we know: mobile device (transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitters radiating structure(s) and the body of the user or nearby persons). And the Cellular radiotelephone service and PCS services are subject to routine environmental evaluation for RF exposure prior to equipment authorization or use if they operate at frequencies of 1.5 GHz or below and their effective radiated power (ERP) is 1.5 watts or more, or if they operate at frequencies above 1.5 GHz and their ERP is 3 watts or more. The radiated power of 800MHz for F201 is 20.84dBm, so the F201 is excluded from routine environmental evaluation for RF exposure according to the requirement of FCC Part 2.1091. The present document is given just only for reference. Uncontrolled limits are used for general public. General population/uncontrolled exposure apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. The exposure levels can be expressed in terms of power density, electric field strength, or magnetic field strength, as averaged over 30 minutes for the general public and 6 minutes for trained personnel. The exposure criterion is frequency dependent, and a chart covering the range from 3 kHz to 100 GHz can be found in NCRP No.86 (references IEEE C95.1-1999). Below are the limits. Limits for Occupational/Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm2) HUAWEI F201 Electromagnetic Radiation Exposure Estimation 2 0.3-3.0 3.0-30 30-300 300-1500 15,00-100,000 614 1842/f 61.4 -- -- 16.3/f 16.3/f 0.163 -- -- (100)* (900/f2)* 1.0 f/300 5 Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm2) 0.3-1.34 1.34-30 30-300 300-15,00 15,00-100,000 614 824/f 27.5 -- -- 1.63 2.19/f 0.073 -- -- (100)* (180/f2)* 0.2 f/1500 1.0 Power density S [mW/cm2] for controlled area at 800 MHz 75.2 300 248 300 )(  MHzf S mW/cm 2 Power density S [mW/cm2] for uncontrolled area at 800 MHz 55.0 1500 248 1500 )(  MHzf S mW/cm 2 S= 0.55 mW/cm 2 = 5.5 W/m 2 for uncontrolled exposure Reference levels are provided for exposure assessment to determine whether the basic restrictions on exposure of humans to electromagnetic fields are exceeded. The basic restrictions on exposure to electromagnetic fields are based directly on established health effects and biological considerations. 3 Location of EUT The EUT uses one monopole antenna. The source of the radiation is mounted on terminal; generally the direction of the antenna position is uprightness tabletop. The highest level of emission would be expected in close vicinity of the antenna and in line of sight to the antenna. HUAWEI F201 Electromagnetic Radiation Exposure Estimation 3 4 Prediction of the Exposure to Electromagnetic Fields Calculations can be made on a site by site basis to ensure the power density is below the limits given above, or guidelines can be done beforehand to ensure the minimum distances from the antenna is maintained through the site planning. The calculations are based on FCC OET 65 Appendix B. 4.1 Calculation of the Safe Distance Below method describes a theoretical approach to calculate possible exposure to electromagnetic radiation around a base station transceiver antenna. Precise statements are basically only possible either with measurements or complex calculations considering the complexity of the environment (e.g. soil conditions, near buildings and other obstacles) which causes reflections, scattering of electromagnetic fields. The maximum output power (given in EIRP) of a base station is usually limited by license conditions of the network operator. A rough estimation of the expected exposure in power flux density on a given point can be made with the following equation. The calculations are based on FCC OET 65 Appendix B.    )(4 )( 2 mr GWP S numeric Whereas: P = Maximum output power in W of the site G numeric = Numeric gain of the antenna relative to isotropic antenna R = distance between the antenna and the point of exposure in meters 4.2 Technical Description F201 Technical Specification: Output power: 0.13W (20.84dBm) for CDMA800MHz Transmitter frequency band CDMA800 Number of antenna ports: 1 Frequency range: 800M： Uplink:824 M~849M； HUAWEI F201 Electromagnetic Radiation Exposure Estimation 4 Downlink:869 M~894M Gain: -2 dBi Mechanical specification (Height) 185.25 mm 4.3 Estimation of compliance boundary for indoor antenna CDMA 800: For the final determination of the compliance boundary the model for far-field calculation is used since this overestimates the field strength in the near-field region. Thus the calculated compliance boundary should be rather more conservative and on the safe side. For EUT the following compliance boundary is calculated: Power at antenna connector BTS: 20.84 dBm（0.13W） Antenna-cable attenuation: 0 dB Antenna gain: -2dBi (0.63) Compliance boundary For CDMA 800MHz band: When r=20cm    )(4 )( 2 mr GWP S numeric    2 2.04 63.013.0 S =0.17W/m 2 < 5.5 W/m 2 …

Text truncated - open the document above for the full version.

Test Report

FCC Test Report of F201 FCC ID：QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page1, Total3 Appendix A Modulation Characteristics According to FCC Part 2.1047 & Part 22 Subpart H FCC Test Report of F201 FCC ID：QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page2, Total3 Channel 283(TM1) FCC Test Report of F201 FCC ID：QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page3, Total3 Channel 283(TM3)

Test Report

FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page1, Total25 Appendix D Spurious Emission at Antenna Terminal According to FCC Part 2.1051 & 22.917 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page2, Total25 Channel 1013（TM1） A Offset 6.9 dB LVL Ref 35 dBmAtt 55 dB 14.1 kHz/Start9 kHzStop150 kHz 3DB RBW 1 kHz SWT 145 ms * VBW 10 kHz* 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -37.87 dBm 9.451923077 kHz D1 -13 dBm Date: 23.MAY.2011 13:41:43 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page3, Total25 Ref 35 dBmAtt 55 dB Offset 6.9 dB A LVL Start150 kHzStop30 MHz2.985 MHz/ * 3DB RBW 10 kHz SWT 300 ms *VBW 30 kHz 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -32.76 dBm 150.000000000 kHz D1 -13 dBm Date: 23.MAY.2011 13:42:08 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page4, Total25 Ref 35 dBmAtt 55 dB Offset 7.1 dB A LVL Start30 MHzStop1 GHz97 MHz/ * 3DB RBW 100 kHz *VBW 300 kHz SWT 100 ms 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] 22.66 dBm 825.897435897 MHz D1 -13 dBm Date: 23.MAY.2011 13:42:34 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page5, Total25 Ref 35 dBmAtt 55 dB Offset 7.4 dB A LVL Start1 GHzStop12.75 GHz1.175 GHz/ * 3DB RBW 1 MHz SWT 70 ms *VBW 3 MHz 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -15.96 dBm 2.600560897 GHz D1 -13 dBm Date: 23.MAY.2011 13:43:00 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page6, Total25 Channel 283（TM1） A Offset 6.9 dB LVL Ref 35 dBmAtt 55 dB 14.1 kHz/Start9 kHzStop150 kHz 3DB RBW 1 kHz SWT 145 ms * VBW 10 kHz* 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -38.39 dBm 10.129807692 kHz D1 -13 dBm Date: 23.MAY.2011 13:41:51 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page7, Total25 Ref 35 dBmAtt 55 dB Offset 6.9 dB A LVL Start150 kHzStop30 MHz2.985 MHz/ * 3DB RBW 10 kHz SWT 300 ms *VBW 30 kHz 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -32.27 dBm 197.836538462 kHz D1 -13 dBm Date: 23.MAY.2011 13:42:17 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page8, Total25 Ref 35 dBmAtt 55 dB Offset 7.1 dB A LVL Start30 MHzStop1 GHz97 MHz/ * 3DB RBW 100 kHz *VBW 300 kHz SWT 100 ms 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] 21.99 dBm 833.669871795 MHz D1 -13 dBm Date: 23.MAY.2011 13:42:42 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page9, Total25 Ref 35 dBmAtt 55 dB Offset 7.4 dB A LVL Start1 GHzStop12.75 GHz1.175 GHz/ * 3DB RBW 1 MHz SWT 70 ms *VBW 3 MHz 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -15.88 dBm 2.657051282 GHz D1 -13 dBm Date: 23.MAY.2011 13:43:08 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page10, Total25 Channel 777（TM1） A Offset 6.9 dB LVL Ref 35 dBmAtt 55 dB 14.1 kHz/Start9 kHzStop150 kHz 3DB RBW 1 kHz SWT 145 ms * VBW 10 kHz* 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -37.67 dBm 10.581730769 kHz D1 -13 dBm Date: 23.MAY.2011 13:41:59 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page11, Total25 Ref 35 dBmAtt 55 dB Offset 6.9 dB A LVL Start150 kHzStop30 MHz2.985 MHz/ * 3DB RBW 10 kHz SWT 300 ms *VBW 30 kHz 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -31.90 dBm 150.000000000 kHz D1 -13 dBm Date: 23.MAY.2011 13:42:25 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page12, Total25 Ref 35 dBmAtt 55 dB Offset 7.1 dB A LVL Start30 MHzStop1 GHz97 MHz/ * 3DB RBW 100 kHz *VBW 300 kHz SWT 100 ms 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] 22.99 dBm 849.214743590 MHz D1 -13 dBm Date: 23.MAY.2011 13:42:51 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page13, Total25 Ref 35 dBmAtt 55 dB Offset 7.4 dB A LVL Start1 GHzStop12.75 GHz1.175 GHz/ * 3DB RBW 1 MHz SWT 70 ms *VBW 3 MHz 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -15.55 dBm 2.544070513 GHz D1 -13 dBm Date: 23.MAY.2011 13:43:16 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without Permission Page14, Total25 Channel 1013（TM3） Att 55 dB A Offset 6.9 dB LVL Ref 35 dBm Start9 kHzStop150 kHz14.1 kHz/ * 3DB RBW 1 kHz SWT 145 ms *VBW 10 kHz 1 PK MAXH -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -37.67 dBm 9.451923077 kHz D1 -13 dBm Date: 23.MAY.2011 13:43:27 FCC Test Report of F201 FCC ID:QISF201 Security Level: Public Report No: SYBH(Z-RF)025052011-2001 Confidential Information of Huawei. No Distribution without…

Text truncated - open the document above for the full version.

Test Report

Report No: SYBH(Z-EMC)063052011-2 Confidential Information of Huawei. No Distribution without Written Permission Page1, Total21 EMC Test Report Product Name: Fixed Wireless Terminal Model Number: F201 Report No: SYBH(Z-EMC)063052011-2 FCC ID:QISF201 Reliability Laboratory of Huawei Technologies Co., Ltd. Huawei Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Tel: +86 755 28780808 Fax: +86 755 89652518 FCC Test Report of Fixed Wireless Terminal FCC ID: QISF201 Report No: SYBH(Z-EMC)063052011-2 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total21 Notice 1 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 3. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-2. 4. The test report is invalid if not marked with "exclusive stamp for the test report". 5. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 6. The test report is invalid if there is any evidence of erasure and/or falsification. 7. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 8. Normally, the test report is only responsible for the samples that have undergone the test. 9. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. FCC Test Report of Fixed Wireless Terminal FCC ID: QISF201 Report No: SYBH(Z-EMC)063052011-2 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total21 Notice 2 Modification Information: Modification Information Modification Information 1 2 3 4 5 6 7 FCC Test Report of Fixed Wireless Terminal FCC ID: QISF201 Report No: SYBH(Z-EMC)063052011-2 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total21 REPORT ON Fixed Wireless Terminal F201 REGULATION FCC CFR47 Part 15: Subpart B; FCC CFR47 Part 22: Subpart H; ANSI/TIA-603-C START OF TEST May.6,2011 END OF TEST May.10,2011 Final Judgement: Pass Approved By 2011-06-3 Liuchunlin Date Name Signature Reviewed By 2011-06-3 Dailinjun Date Name Signature Operator 2011-06-3 Heyong Date Name Signature FCC Test Report of Fixed Wireless Terminal FCC ID: QISF201 Report No: SYBH(Z-EMC)063052011-2 Confidential Information of Huawei. No Distribution without Written Permission Page5, Total21 REPORT BODY CONTENT 1 Status ............................................................................................................................................... 6 1.1 Product Information ......................................................................................................................... 6 1.2 Test Site ........................................................................................................................................... 6 1.3 Test environment condition ............................................................................................................. 6 2 Summary of Results ........................................................................................................................ 7 3 Equipment Specification ................................................................................................................. 8 3.1 General Description......................................................................................................................... 8 4 System Configuration during EMC Test ........................................................................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Zhang Xinghai

[email protected]+86-755-2897-0299Fax: +86-755-8965-0226

Technical Contact

Intertek Testing Service Hong Kong LtdKen Sit

[email protected]2173-8888

Flat D 5/F Garment Centre · Kowloon · Hong Kong

Non-Technical Contact

Intertek Testing Services Hong Kong LtdKen Sit

[email protected]2173-8888

Test Firm

Huawei Technologies Co., LTDZhou Fengyum

[email protected]86-755-28782917Fax: 86-755-89650226

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	22H	824 MHz - 849 MHz	120.00 mW	1M25F9W	18.0000000000 Hz

Confidentiality

Long Term

Grant Notes

Power is ERP. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
