QISF203Fixed Wireless Terminal

HUAWEI F203 Fixed Wireless Terminal USER GUIDE Copyright © Huawei Technologies Co., Ltd. 2011. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses. Trademarks and Permissions , HUAWEI, and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Other trademarks, product, service and company names mentioned are the property of their respective owners. Notice Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. NO WARRANTY THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS. Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein. 1 Your Fixed Wireless Terminal 1 2 3 4 5 6 7 8910 Note: The figures of the FWT (Fixed Wireless Terminal) are only for your reference, please refer color and shape to product. No. Item Description 1 Left soft key Select the option displayed on the lower left corner of the screen. 2 Scroll keys y Access the shortcut screen in standby mode. y Adjust the microphone and the earpiece volume during a call. 3 Right soft key Select the option displayed on the lower right corner of the screen. 4 OK key y Access the main menu in standby mode. y Select the option displayed on the lower left corner of the display screen. 5 End key y End a call or reject an incoming call. y Power on or off the FWT in standby mode (by pressing and holding it). y Return to the standby mode. 2 No. Item Description 6 Call/Redial key y Make or answer a call. y View the call history in standby mode. 7 Hands-free key y Activate/deactivate the hands-free mode in standby mode. y Cancel the dialing, when dialing a number in the hands-free mode. y End the current call during a call in the hands-free mode. 8 # key y Lock the keypad in standby mode (by pressing and holding it). y Switch between different input modes in editing mode. 9 * key y Activate/deactivate the quiet profile in standby mode (by pressing and holding it). y Access the symbol screen in editing mode. 10 Number keys y Number keys from 0 to 9: Enter numbers and characters. y Number keys from 1 to 9: Press and hold a key to speed dial a phone number in standby mode. Screen Icons Icon Description Icon Description Network signal strength / Calling / No service Alarm clock is on Hands-free mode Message received Powered by the power adapter Voice message received Battery power level 1 Menu Tree Phone Book Messages CallHistory 1. Search 2. Add New 3. Groups 4. Speed Dial 5. Copy All（Optional） 6. Delete All 7. My Phone Num 8. Memory Status 1. Write Message 2. Inbox 3. Outbox 4. Draft 5. Voice Mail 6. Message Settings 7. Delete All 1. Missed Calls 2. Received Calls 3. Dialed Calls 4. Call Duration 5. Delete All Recorder (Optional) Fun&Utility Profiles 1. Guest Announcements 2. Recorder Settings 1. Alarm 2. Schedule 3. Calculator 4. Stopwatch 5. World Clock 6. Line Game 7. Smash Game 1. General 2. Outdoor 3. Quiet Settings FM Radio (Optional) 1. Display 2. Call Settings 3. Phone Settings 4. Security Installing the UIM Card (Optional) Consult the service provider whether the UIM card is needed. Power off the FWT and remove the power supply cable, and install the UIM card as shown. Make sure that the golden contact on the UIM card is facing downwards. 2 Installing the Battery Power off the FWT and remove the power supply cable, and install the battery as shown. Make sure that the battery cord plug matches the battery jack. Do not insert the battery reversely. Using the Power Adapter and Charging the Battery Connect one end of the power adapter cable to the FWT and the other to the power socket. Note: y Remove the battery if the FWT is left unused for a long period. y If the battery has not been used for a long time or the battery is exhausted, the screen of the FWT may not function when you charge the battery again. This is normal. After the battery is being charged for a while, you can power on the FWT for use. y In normal conditions, the FWT depends on the power adapter for power supply and will use the battery only in the case that the electricity has failed and the power adapter is unavailable. As the battery can supply power only for a limited period, you must make sure that the battery has been fully charged before putting it into use. Using the Menu 1. In standby mode, press Left soft key to d…

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. We, HUAWEI TECHNOLOGIES CO., LTD., declare on our sole responsibility that the product (variant) FCC ID: QISF203, model: F203 This is to advise and officially, that we, HUAWEI TECHNOLOGIES CO., LTD., declare that F203 I/O connects can only support charging. It can’t support USB with PC for data transfer. Sincerely, Wang Dongjie For and Behalf of: Huawei Technologies Co., Ltd. Fifth Street 9# Kuike Building, Shangdi-information Road, Haidian Beijing 0086-10-82836618

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: TUVPS Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISF203 to be kept confidential: 1. Schematic diagram. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Turn-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base, Bantian, Longgang, Shenzhen, P.R China Post ZIP：518129 Page ：1/1 To: Jiangsu TÜV Product Service Ltd. – Shenzhen Branch Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Authorization 2011-02-28 FCC ID:QISF203 To whom it may concern: We the undersigned, hereby authorize Louis Lin of Jiangsu TÜV Product Service Ltd. – Shenzhen Branch to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Louis Lin of Jiangsu TÜV Product Service Ltd. – Shenzhen Branch on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Huawei Technologies Co., Ltd. . Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

HUAWEI F203 Fixed Wireless Terminal SECRET Page1, Total6 Photo documentation of external of product HUAWEI F203 Fixed Wireless Terminal SECRET Page2, Total6 HUAWEI F203 Fixed Wireless Terminal SECRET Page3, Total6 HUAWEI F203 Fixed Wireless Terminal SECRET Page4, Total6 HUAWEI F203 Fixed Wireless Terminal SECRET Page5, Total6 HUAWEI F203 Fixed Wireless Terminal SECRET Page6, Total6

HUAWEI F203 Fixed Wireless Terminal SECRET Page1,Total1 F203 Lable:

Huawei F203 Fixed Wireless Terminal SECRET Page1, Total 1 F203 Label Location

Huawei F203 Fixed Wireless Terminal SECRET Page1, Total6 Photo documentation of interior of product Huawei F203 Fixed Wireless Terminal SECRET Page2, Total6 Huawei F203 Fixed Wireless Terminal SECRET Page3, Total6 Huawei F203 Fixed Wireless Terminal SECRET Page4, Total6 Huawei F203 Fixed Wireless Terminal SECRET Page5, Total6 Huawei F203 Fixed Wireless Terminal SECRET Page6, Total6

HUAWEI F203 Electromagnetic Radiation Exposure Estimation 1 EMF Exposure Estimation for F203 1 About Electromagnetic Radiation Field Exposure 1.1 Introduction CDMA fixed wireless terminal emits RF radiation (Radiation Hazard). Although there is no scientific evidence of possible health risks to persons living near to CDMA fixed terminal, some recommendations are giving below for the installation and operation of CDMA fixed terminal. Operators of CDMA fixed terminal are required to obey the local regulation for erecting CDMA fixed terminal. 1.2 Limits and Guidelines on Exposure to Electromagnetic Fields There are a number of international and national regulations, standards and guidelines for exposure to electromagnetic fields. Several European countries have adapted the recommendation of the council of the European Union published on 12. July 1999 on the limitation of exposure of the general public to electromagnetic fields (1999/519/EC), the recommendation is based on the guideline published by the International Commission on Non-Ionizing Radiation protection (ICNIRP). Below table shows a comparison between different regulations and applied reference levels of some countries. Country Limit 824-849MHz E electric field strength Limit 824-849MHz S power flux density ICNIRP International 39.47 V/m(824MHz) 4.12 W/m 2 (824MHz) Europe (1999/519/EC) 39.47 V/m(824MHz) 4.12W/m2(824MHz) Note: the limit in 824MHz is most rigorous in the band 824MHz~849MHz. Reference levels are provided for exposure assessment to determine whether the basic restrictions on exposure of humans to electromagnetic fields are exceeded. The basic restrictions on exposure to electromagnetic fields are based directly on established health effects and biological considerations. HUAWEI F203 Electromagnetic Radiation Exposure Estimation 2 1.3 Location of CDMA Fixed Wireless Terminal antennas CDMA fixed wireless terminal antennas, the source of the radiation, are usually mounted on FWT with TNC converter, Generally the height of the antenna position does not fall below 20 cm. The Indoor omni antennas generally parameter is: omni-2.0dBi-vertical-50W-or-TNC/MALE; The direction of the antenna position is uprightness tabletop , you can adjust the direction of the antenna position basis view the signal strength on the display screen of the FWT; The power usually is focused into a horizontal main beam and slightly downward tilted. The remaining power goes into the weaker beams on both side of the main beam. The highest level of emission would be expected in close vicinity of the antenna and in line of sight to the antenna. 1.4 Calculation of Compliance Boundary for CDMA fixed wireless terminal according to EN 50385 Below method describes a theoretical approach to calculate the compliance boundary according to EN 50383:2002 based on a typical configuration of the CDMA fixed wireless terminal. Compliance is declared with EN 50385:2002. Below method applies only to a site with the configurations described below, should the site include other transmitters namely from other CDMA network operators then those transmitters will affect the compliance boundaries for the antenna site. The method used for assessment is based on equations for far-field electromagnetic field calculation according to clause 8 of EN 50383. Those equations are accurate in the far-field of antennas but will over-predict in the near field, however it can be used for “worst case” or conservative prediction of electromagnetic fields or power densities radiated by antennas. CDMA fixed wireless terminal use the omni indoor antenna, are usually mounted on FWT with TNC converter, so the estimation of compliance boundary is based on this omni antenna here. HUAWEI F203 Electromagnetic Radiation Exposure Estimation 3 1.4.1 Typical Configuration of the CDMA Fixed Wireless Terminal The CDMA fixed wireless terminal is subscriber equipments in the CDMA system. The frequency band is Band Class 0. It implements such functions as RF signal receiving/sending，CDMA1x protocol processing, audio signal in/output, etc. Externally it RS232 interface (to computers), antenna interface, and power interface, in addition to the charging interface. Maximum output power is 250 mW. 1.4.2 Technical Description F203 Technical Specification: Output power: 250mW (24 dBm) / TRX Transmitter frequency band 824-894 MHz (CDMA Band Class 0) Number of antenna ports: 1 Antenna system and type (typical) TLB-800-2H indoor aerial Omnioriental Frequency range: 824-894MHz Gain: 2.0dBi Mechanical specification (Height) 178mm 1.4.4 Estimation of compliance boundary for indoor antenna The wavelength for 824 MHz to 849 MHz is 0.162m to 0.157m. Above calculations is accurate when the point of investigation is in the far-field region and over-estimates in the radiating near-field. The far-field region is determined by:  2 2D r =0.437 m(D=0.18525m，λ＝0.157) Whereas: frequency ngtransmitti of wavelength antenna of length D ioninvestigat of point theto antenna the from distance r     The radiating near-field region is determined by:   2 2 4 D r = 0.039<r  0.437 m HUAWEI F203 Electromagnetic Radiation Exposure Estimation 4 For the final determination of the compliance boundary the model for far-field calculation is used since this overestimates the field strength in the near-field region. Thus the calculated compliance boundary should be rather more conservative and on the safe side. For above CDMA fixed wireless terminal the following compliance boundary is calculated: Power at antenna connector BTS: 24 dBm Antenna-cable attenuation: 0 dB Input power to antenna: 24 dBm (250mW) Antenna gain: 2.0 dBi (1.59) Reference level for 450 MHz based on recommendation 1999/519/EC: 39.47 V/m For any further assessment the value of 39.47 V/m is used. Compliance boundary For CDMA 824MHz band:  2 , 2 **30 E GP r   = 2 2 47.39 59.1*25.0*30 r r = 0.086 m for CDMA 824 MHz The compliance boundary distance is close enough; the co…
