Huawei Technologies Co.,Ltd Bantian, Longgang District,Shenzhen, China Tel: +86-755-2878-1879, Fax: +86-755-2878-1889 Date: June 9, 2011 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for FCC ID: QISG3620 To Whom It May Concern: We, Huawei Technologies Co.,ltd. hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Sincerely yours, Zhang Xinghai

Rev. 1/1/03 Huawei Technologies Co.,Ltd Bantian, Longgang District,Shenzhen, China Tel: +86-755-2878-1879, Fax: +86-755-2878-1889 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: QISG3620 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics (file: HUAWEI G3620_Schem.pdf) Block Diagram (file: HUAWEI G3620_BlkDia.pdf) Parts List (file: HUAWEI G3620_PartsLst.pdf) Operation Description (file: HUAWEI G3620_OpDes.doc) Tune Up Procedure (file: HUAWEI G3620_TunPro.doc) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Zhang Xinghai

Huawei Technologies Co.,Ltd Bantian, Longgang District,Shenzhen, China Tel: +86-755-2878-1879, Fax: +86-755-2878-1889 Date: June 9, 2011 Power of Attorney To whom it may concern, Please be notified that we, Huawei Technologies Co.,Ltd., have designated Jones Tsai in Sporton International Inc. as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Jones Tsai in Sporton International Inc. on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is limited to the product of as following: FCC ID: QISG3620 If you have any acknowledgement and response, please send it to Sporton International Inc. directly. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, Contact Person: Zhang Xinghai Company: Huawei Technologies Co.,Ltd TEL: +86-755-2878-1879 FAX: +86-755-2878-1889 E-mail: [email protected]

Huawei Technologies Co.,Ltd Bantian, Longgang District,Shenzhen, China Tel: +86-755-2878-1879, Fax: +86-755-2878-1889 Date: June 9, 2011 Statement We, Huawei Technologies Co.,ltd. , states that our device, FCC ID: QISG3620, has no space to put the label except the battery compartment of this device. The label will put under the battery compartment and it is visible to the users as they purchase the products and install the battery. Sincerely yours, _______________ Zhang Xinghai

Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 1 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 1. External Photograph of EUT Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 2 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 3 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 4 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 5 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 6 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 7 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 List of Accessory: Specification of Accessory AC Adapter Brand Name HUAWEI Model Name ASTC20-050065 Battery Brand Name HUAWEI Model Name HBG3511 Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 8 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 9 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 10 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 11 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 12 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 13 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 14 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 15 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 16 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。

Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 17 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 3. Internal Photograph of EUT Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 18 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 19 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 20 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 21 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 22 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 BT Antenna Photographs of EUT Report No.: EP152003 Brand Name: HUAWEI / Model Name: HUAWEI G3620 SPORTON INTERNATIONAL (KUNSHAN) INC. Page Number : 23 of 23 TEL : 86-0512-5790-0158 Report Issued Date : Jun. 11, 2011 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : 错误!未找到引用源。 WWAN Antenna

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-6-4 System Check_Head_835MHz_110604 DUT: Dipole 835 MHz Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL_835_110604 Medium parameters used: f = 835 MHz; σ = 0.908 mho/m; ε r = 41.7; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: ET3DV6 - SN1788; ConvF(6.23, 6.23, 6.23); Calibrated: 2010-9-21 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 59 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.63 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 55.9 V/m; Power Drift = -0.00634 dB Peak SAR (extrapolated) = 3.55 W/kg SAR(1 g) = 2.43 mW/g; SAR(10 g) = 1.6 mW/g Maximum value of SAR (measured) = 2.63 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-6-4 System Check_Body_835MHz_110604 DUT: Dipole 835 MHz Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: MSL_835_110604 Medium parameters used: f = 835 MHz; σ = 0.977 mho/m; ε r = 54.4; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: ET3DV6 - SN1788; ConvF(5.99, 5.99, 5.99); Calibrated: 2010-9-21 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM1; Type: SAM; Serial: TP-1479 - Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 59 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.76 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 55.3 V/m; Power Drift = -0.00623 dB Peak SAR (extrapolated) = 3.61 W/kg SAR(1 g) = 2.54 mW/g; SAR(10 g) = 1.69 mW/g Maximum value of SAR (measured) = 2.76 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-6-4 System Check_Head_1900MHz_110604 DUT: Dipole 1900 MHz Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: HSL_1900_110604 Medium parameters used: f = 1900 MHz; σ = 1.44 mho/m; ε r = 39.7; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.3 °C DASY5 Configuration: - Probe: ET3DV6 - SN1788; ConvF(5.03, 5.03, 5.03); Calibrated: 2010-9-21 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 59 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 12.2 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 95.2 V/m; Power Drift = -0.131 dB Peak SAR (extrapolated) = 17.7 W/kg SAR(1 g) = 10.3 mW/g; SAR(10 g) = 5.44 mW/g Maximum value of SAR (measured) = 11.6 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-6-4 System Check_Body_1900MHz_110604 DUT: Dipole 1900 MHz Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: MSL_1900_110604 Medium parameters used: f = 1900 MHz; σ = 1.53 mho/m; ε r = 52.4; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.4 °C DASY5 Configuration: - Probe: ET3DV6 - SN1788; ConvF(4.39, 4.39, 4.39); Calibrated: 2010-9-21 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM1; Type: SAM; Serial: TP-1479 - Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 59 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 12.8 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 94.7 V/m; Power Drift = 0.042 dB Peak SAR (extrapolated) = 16.7 W/kg SAR(1 g) = 10.8 mW/g; SAR(10 g) = 5.8 mW/g Maximum value of SAR (measured) = 12.4 mW/g

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-6-4 #05 GSM850_Right Cheek_Ch251 DUT: 152003 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_110604 Medium parameters used: f = 849 MHz; σ = 0.922 mho/m; ε r = 41.5; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: ET3DV6 - SN1788; ConvF(6.23, 6.23, 6.23); Calibrated: 2010-9-21 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 59 Ch251/Area Scan (51x91x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.807 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 14.9 V/m; Power Drift = -0.112 dB Peak SAR (extrapolated) = 0.912 W/kg SAR(1 g) = 0.720 mW/g; SAR(10 g) = 0.527 mW/g Maximum value of SAR (measured) = 0.777 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-6-4 #05 GSM850_Right Cheek_Ch251_2D DUT: 152003 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_110604 Medium parameters used: f = 849 MHz; σ = 0.922 mho/m; ε r = 41.5; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: ET3DV6 - SN1788; ConvF(6.23, 6.23, 6.23); Calibrated: 2010-9-21 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 59 Ch251/Area Scan (51x91x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.807 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 14.9 V/m; Power Drift = -0.112 dB Peak SAR (extrapolated) = 0.912 W/kg SAR(1 g) = 0.720 mW/g; SAR(10 g) = 0.527 mW/g Maximum value of SAR (measured) = 0.777 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-6-4 #06 GSM850_Right Tilted_Ch251 DUT: 152003 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_110604 Medium parameters used: f = 849 MHz; σ = 0.922 mho/m; ε r = 41.5; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: ET3DV6 - SN1788; ConvF(6.23, 6.23, 6.23); Calibrated: 2010-9-21 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 59 Ch251/Area Scan (51x91x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.433 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 17.1 V/m; Power Drift = -0.108 dB Peak SAR (extrapolated) = 0.516 W/kg SAR(1 g) = 0.408 mW/g; SAR(10 g) = 0.302 mW/g Maximum value of SAR (measured) = 0.429 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-6-4 #07 GSM850_Left Cheek_Ch251 DUT: 152003 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_110604 Medium parameters used: f = 849 MHz; σ = 0.922 mho/m; ε r = 41.5; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: ET3DV6 - SN1788; ConvF(6.23, 6.23, 6.23); Calibrated: 2010-9-21 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 59 Ch251/Area Scan (51x91x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.743 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 13.3 V/m; Power Drift = 0.102 dB Peak SAR (extrapolated) = 0.860 W/kg SAR(1 g) = 0.686 mW/g; SAR(10 g) = 0.502 mW/g Maximum value of SAR (measured) = 0.723 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-6-4 #08 GSM850_Left Tilted_Ch251 DUT: 152003 Communication System: Generic GSM; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_835_110604 Medium parameters used: f = 849 MHz; σ = 0.922 mho/m; ε r = 41.5; ρ = 1000 kg/m 3 Ambient Temperature：23.4 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: ET3DV6 - SN1788; ConvF(6.23, 6.23, 6.23); Calibrated: 2010-9-21 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 59 Ch251/Area Scan (51x91x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.406 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 15.5 V/m; Power Drift = -0.107 dB Peak SAR (extrapolated) = 0.479 W/kg SAR(1 g) = 0.374 mW/g; SAR(10 g) = 0.277 mW/g Maximum value of SAR (measured) = 0.399 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2011-6-4 #01 GSM1900_Right Cheek_Ch810 DUT: 152003 Communication System: Generic GSM; Frequency: 1909.8 MHz;Duty Cycle: 1:8.3 Medium: HSL_1900_110604 Medium parameters used: f = 1910 MHz; σ = 1.45 mho/m; ε r = 39.6; ρ = 1000 kg/m 3 Ambient Temperature：23.3 °C; Liquid Temperature：21.3 °C DASY5 Configuration: - Probe: ET3DV6 - SN1788; ConvF(5.03, 5.03, 5.03); Calibrated: 2010-9-21 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1210; Calibrated: 2010-11-18 - Phantom: SAM3; Type: SAM; Serial: TP-1477 - Measurement SW: DASY5, V5.2 Build 157; SEMCAD X Version 14.0 Build 59 Ch810/Area Scan (51x91x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.234 mW/g Ch810/Zoom Scan (5x5x7)/Cube 0: Measurement grid: …
