QISG5510AGSM Mobile Phone

RF_160, Issue 02 Huawei Technologies Co.,Ltd. Declaration of Authorization We Name: Huawei Technologies Co.,Ltd. Address: Bantian, Longgang District, Shenzhen, 518129 Guangdong, P. R. China City:  SHENZHEN . Country:China . Declare that: Name Representative of agent: Gene Chang (1) Agent Company name: QuieTek Corp. Address: Fl.2, No.345, Xin-hu 2 nd Rd., Nei-hu District City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s): Product description: GSM Mobile Phone Type designation: HUAWEI G5510 on our behalf. Date: 2012-2-28 City: SHENZHEN Name: Zhang Xinghai (2) Function: Manager Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Huawei Technologies Co.,Ltd Administration Building, Huawei Base, Bantian, Longgang District, Shenzhen China Attestation for FCC Declaration of Conformity FCC ID: QISG5510A Date: 2012/02/28 Please be notified that we, the undersigned, Huawei Technologies Co.,Ltd declares that the product which bears the above FCC ID is also compliant with the FCC requirements for DOC. The test report number supporting the DOC is 122S074R-ITUSP01V02 Testing in regards to this report was done by QuieTek Corp., located at No.5-22, Rueishu Keng, Rueiping Tsuen, Linkou Shiang, Taipei County 244, Taiwan, which has been accredited in accordance to all of the requirements of 47CFR 2.948 (d) and (e) of the FCC rules and KDB349827. Sincerely, Zhang Xinghai/manager Huawei Technologies Co.,Ltd

Huawei Technologies Co.,Ltd. Date: 2012-2-28 Federal Communications Commission Authorization and Evaluation Division FCC ID: QISG5510A ATTESTATION FCC ID: QISG5510A Product: GSM Mobile Phone Model: HUAWEI G5510 We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA. Sincerely, __________________ Zhang Xinghai/manager Huawei Technologies Co.,Ltd.

Huawei Technologies Co.,Ltd. Date: 2012-2-28 Federal Communications Commission Authorization and Evaluation Division FCC ID: QISG5510A Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1 Schematics 2 Block Diagram 3 Operational Description 4 BOM List 5 Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________________________ Zhang Xinghai/manager Huawei Technologies Co.,Ltd.

1. EUT Photograph (1) EUT Photo (2) EUT Photo Report No.: 122S074R-RF-US-P06V01 Page: 2 of 4 (3) EUT Photo (4) EUT Photo Report No.: 122S074R-RF-US-P06V01 Page: 3 of 4 (5) EUT Photo Report No.: 122S074R-RF-US-P06V01 Page: 4 of 4 (6) EUT Photo

(1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo (9) EUT Photo (10) EUT Photo (11) EUT Photo (12) EUT Photo

FCC Part15.247 Test Report Product Name : GSM Mobile Phone Model No. : HUAWEI G5510 FCC ID : QISG5510A Applicant : HUAWEI TECHNOLOGIES CO., LTD. Address : Bantian, Longgang District, Shenzhen, 518129 Guangdong, P. R. China Date of Receipt : 21/02/2012 Test Date : 22/02/2012~24/02/2012 Issued Date : 27/02/2012 Report No. : 122S074R-RF-US-P06V01 Report Version : V 1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, NVLAP or any agency of the Government. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No.: 122S074R-RF-US-P06V01 Page: 2 of 119 Test Report Certification Issued Date : 27/02/2012 Report No. : 122S074R-RF-US-P06V01 Product Name : GSM Mobile Phone Applicant : HUAWEI TECHNOLOGIES CO., LTD. Address : Bantian, Longgang District, Shenzhen, 518129 Guangdong, P. R. China Manufacturer : HUAWEI TECHNOLOGIES CO., LTD. Address : Bantian, Longgang District, Shenzhen, 518129 Guangdong, P. R. China Model No. : HUAWEI G5510 FCC ID : QISG5510A EUT Voltage : DC: 3.7V Trade Name : HUAWEI Applicable Standard : FCC CFR Title 47 Part 15 Subpart C: 2008 ANSI C63.4: 2009 ANSI C63.10: 2009 Test Result : Complied Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392 Documented By : (Engineering ADM: Alice Ni) Reviewed By : (Engineering Supervisor: Robin Wu) Approved By : (Engineering Manager: Marlin Chen) Report No.: 122S074R-RF-US-P06V01 Page: 3 of 119 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site : http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No. 5-22, Ruei-Shu Valley, Ruei-Ping Tsuen, Lin-Kou Shiang, Taipei, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou (China) Testing Laboratory : No. 99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou,China. TEL : +86-512-6251-5088 / FAX : +86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC, NVLAP Japan :VCCI Report No.: 122S074R-RF-US-P06V01 Page: 4 of 119 TABLE OF CONTENTS Description Page 1. General Information....................................................................................................7 1.1. EUT Description .........................................................................................................7 1.2. Mode of Operation .....................................................................................................9 1.3. Tested System Details..............................................................................................10 1.4. Configuration of Tested Systerm .............................................................................. 11 1.5. EUT Exercise Software ............................................................................................12 2. Technical Test...........................................................................................................13 2.1. Summary of Test Result ...........................................................................................13 2.2. Test Environment.....................................................................................................14 3. Conducted Emission................................................................................................15 3.1. Test Equipment ........................................................................................................15 3.2. Test Setup ................................................................................................................15 3.3. Limit..........................................................................................................................16 3.4. Test Procedure.........................................................................................................16 3.5. Uncertainty ...............................................................................................................16 3.6. Test Result...............................................................................................................17 4. Radiated Emission...................................................................................................17 4.1. Test Equipment ........................................................................................................19 4.2. Test Setup ................................................................................................................20 4.3. Limit..........................................................................................................................21 4.4. Test Procedure..............................................................................................…

Text truncated - open the document above for the full version.

SAR-Test Setup Photographs Test Setup Photographs Left-Cheek Touch Left-Tilt 15° Right-Cheek Touch Right-Tilt 15° Body SAR Back 15mm Body SAR Front 15mm Body SAR Back 15mm with Headset Depth of the liquid in the phantom – Zoom in Note: The position used in the measurements were according to IEEE 1528 - 2003 Part22&24-Test Photograph Description: ERP Test Setup Description: Substitution Antenna for ERP Test Description: EIRP Test Setup Description: Substitution Antenna for EIRP Test Part 15C-Test Setup Photograph Description: Conducted Emission Test Setup Description: Radiated Emission Test Setup for Below 1GHz Description: Radiated Emission Test Setup for 1~18GHz Description: Radiated Emission Test Setup for Above 18GHz
