Quick Start Guide G735 Your phone at a glance Thank you for choosing the Huawei smartphone. Before you start, let's take a look at your new phone. Press and hold the power button to power on your phone. To power off your phone, press and hold the power button, and touch Power off > OK. To forcibly restart your phone, press and hold the power button until your phone vibrates. Headset jack Power button Volume button Micro USB port Front camera Earpiece Return Home Menu Status indicator Microphone Microphone Light sensor Speaker Getting started Caution Your phone's built-in battery is not user-removable. To replace the battery, contact an authorized Huawei service center. Do not attempt to remove it yourself. Follow the instructions in the following figures to install your micro-SIM card, microSD card. Before you insert or remove the micro-SIM card, power off your phone. 1 5VKTZNKHGZZKX_IU\KX 2 /TYKXZZNK3OIXU9/3IGXJ 4 5 5 /TYZGRRZNKHGZZKX_IU\KX )NGXMKZNKVNUTK /TYKXZZNKSOIXU9*IGXJ5VZOUTGR 3 Locking and unlocking the screen Press the power button to lock the screen. After your phone is idle for a specified period of time, its screen automatically locks. If the screen is off, press the power button to turn it on. Slide your finger in any direction to unlock the screen. Flick up from the bottom of the screen to quickly launch commonly used applications without unlocking the screen. Calling and messaging Touch to place a call using the dialer. You can also touch a phone number in a message, email, web page, or other screen to place a call. Touch to send a text or multimedia message. You can save photos, audio clips, or videos from received multimedia messages. Camera Touch . Flick left or right to switch between photo and video capture modes. Frame the scene you want to capture. Let your camera focus automatically or touch the screen to focus on a specific object. Then touch to take a photo. In all focus mode, you can change the focus point on a photo after it's been taken. Internet connection You can access the Internet through Wi-Fi or a mobile network. Flick down from the status bar to open the notification panel. Touch to turn on the mobile network. Touch and hold to go to the Wi-Fi settings screen. Turn on Wi-Fi and follow the onscreen instructions to connect your phone to a Wi-Fi network. Backing up data You can use the Backup app to back up your phone's data and restore it later. Touch Tools > . Select the data you want to back up, such as your contacts, messages, and photos. Then follow the onscreen instructions. Phone Manager Touch . You can scan your phone for potential hazards with one touch. Follow the onscreen instructions to use one-touch optimization or manually clean the system storage or manage your applications. Flick left to view more functions. You can then clear system trash, set the harassment filter, choose a power saving mode, manage your notifications and application permissions, and more. For more information Encounter any issues while using your phone? Touch on your phone to open HiCare. Want to obtain the full user guide? Download the HUAWEI Ascend G735 User Guide from  http://consumer.huawei.com/en. Want to learn more about Huawei EMUI? Go to http://zh.ui.vmall.com for the latest information. Prepare to be amazed by your new phone. Go to http://club.vmall.com and join the Huawei fan club. All pictures and illustrations in this guide, including but not limited to the phone color, size, and display content, are for your reference only. The actual product may vary. Nothing in this guide constitutes a warranty of any kind, express or implied. Personal Information and Data Security The use of some functions or third-party applications on your device could result in your personal information and data being lost or becoming accessible to others. Several measures are recommended to help you protect personal and confidential information. • Place your device in a safe area to prevent it from unauthorized use. • Set your device screen to lock and create a password or unlock pattern to open it. • Periodically back up personal information kept on your SIM card, memory card, or stored in your device memory. If you change to a different device, be sure to move or delete any personal information on your old device. • If you are worried about viruses when you receive messages or emails from a stranger, you can delete them without opening them. • If you use your device to browse the Internet, avoid websites that might pose a security risk to avoid theft of your personal information. • If you use services such as Wi-Fi tether or Bluetooth, set passwords for these services to prevent unauthorized access. When these services are not in use, turn them off. • Install or upgrade device security software and regularly scan for viruses. • Be sure to obtain third-party applications from a legitimate source. Downloaded third-party applications should be scanned for viruses. • Install security software or patches released by Huawei or third-party application providers. • Some applications require and transmit location information. As a result, a third-party may be able to share your location information. • Your device may provide detection and diagnostic information to third-party application providers. Third party vendors use this information to improve their products and services. • If you have concerns about the security of your personal information and data, please contact [email protected]. Safety information This section contains important information about the operation of your device. It also contains information about how to use the device safely. Read this information carefully before using your device. Electronic device Do not use your device if using the device is prohibited. Do not use the device if doing so causes danger or interference with other electronic devices. Interference with medical equipment • Follow rules and regulations set forth by hospitals…

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. Federal Communications Commission 2015-1- 5 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: QISG735-L03 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Operational Description Bom List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until 2015-04-01 External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. Address: Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C E-mail: [email protected] Tel: 0086-0755-28970299 Fax: 0086-0755-89650226

Huawei Technologies Co., Ltd. Date: January 5, 2015 Statement We , Huawei Technologies Co., Ltd, states that our device, FCC ID: QISG735-L03, has a battery, But the battery will be placed in the battery compartment when delivery, it is not visible to the users as they purchase the products For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager Address: Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C E-mail: [email protected] Te l : 0086-0755-28970299 Fax: 0086-0755-89650226

HUAWEI G735-L03 Smart Phone SECRET 1/5/2015 Page1,Total 3 External Photos of HUAWEI G735-L03 HUAWEI G735-L03 Smart Phone SECRET 1/5/2015 Page2,Total 3 HUAWEI G735-L03 Smart Phone SECRET 1/5/2015 Page3,Total 3

HUAWEI G735-L03 Smart Phone SECRET 2015-1-5 Page1, Total1 Label & Label Location：

HUAWEI G735-L03 Smart Phone SECRET 2015-01-05 Page1, Total3 Internal Photos of HUAWEI G735-L03 HUAWEI G735-L03 Smart Phone SECRET 2015-01-05 Page2, Total3 HUAWEI G735-L03 Smart Phone SECRET 2015-01-05 Page3, Total3

FCC RF Test Report Product Name: Smart Phone Model Number: HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 FCC ID：QISG735-L03 Reliability Laboratory of Huawei Technologies Co., Ltd. Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Tel: +86 755 28780808 Fax: +86 755 89652518 RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 2 of 20 Notice 1. The laboratory has Passed the accreditation by China National Accreditation Service for Conformity Assessment (CNAS). The accreditation number is L0310. 2. The laboratory has Passed the accreditation by The American Association for Laboratory Accreditation (A2LA). The accreditation number is 2174.01. 3. The laboratory has been listed by the US Federal Communications Commission to perform electromagnetic emission measurements. The site recognition number is 97456. 4. The laboratory has been listed by Industry Canada to perform electromagnetic emission measurements. The recognition numbers of test site are 6369A-2. 5. The test report is invalid if not marked with the signatures of the persons responsible for preparing and approving the test report. 6. The test report is invalid if there is any evidence of erasure and/or falsification. 7. The test report is only valid for the test samples. 8. Content of the test report, in part or in full, cannot be used for publicity and/or promotional purposes without prior written approval from the laboratory. RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 3 of 20 Approved by Senior Engineer: 2014-12-08 Liu Chunlin Date Name Signature Prepared by: 2014-12-08 maowenli Date Name Signature Applicant: Huawei Technologies Co., Ltd. Address: Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Date of Receipt Sample: 2014-11-28 Start Date of Test: 2014-11-28 End Date of Test: 2014-12-08 Test Result: Pass RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 4 of 20 Modification Record No. Last Report No. Modification Description First report RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 5 of 20 CONTENT 1 General Information ................................................................................................................................................ 6 1.1 Applied Standard ........................................................................................................................................ 6 1.2 Test Location.............................................................................................................................................. 6 1.3 Test Environment Condition ....................................................................................................................... 6 2 Test Summary ........................................................................................................................................................ 7 3 Description of the Equipment under Test (EUT) ..................................................................................................... 8 3.1 General Description ................................................................................................................................... 8 3.2 EUT Identity ............................................................................................................................................... 8 3.3 Technical Description ................................................................................................................................. 9 4 General Test Conditions / Configurations ............................................................................................................. 10 4.1 EUT Configurations .................................................................................................................................. 10 4.2 Test Environments ................................................................................................................................... 11 4.3 Antenna requirements .............................................................................................................................. 11 4.4 Description of tests ................................................................................................................................... 12 4.5 Test Setups .............................................................................................................................................. 15 4.6 Test Conditions ........................................................................................................................................ 18 5 Main Test Instruments .......................................................................................................................................... 20 RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 6 of 20 1 General Information 1.1 Applied Standard Applied Rules: 47 CFR FCC Part 2, Subpart J 2013 47 CFR FCC Part 15, Subpart C 2013 Test Method: FCC PUBLIC NOTICE DA 00-705 Filing and Measurement Guidelines for Frequency Hopping Spread Spectrum Systems (Released March 30, 2000) ANSI C63.4-2003/-2009, American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. ANSI C63.10-2009, American National Standard for Testing Unlicensed Wireless Devices. 1.2 Tes…

Text truncated - open the document above for the full version.

RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 1 of 127 Appendix A: 20dB Emission Bandwidth (EBW) RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 2 of 127 1 Result Table EUT Conf. EBW [MHz] Verdict TM1_DH5_Ch0 1.025 Pass TM1_DH5_Ch39 1.024 Pass TM1_DH5_Ch78 1.024 Pass TM2_2DH5_Ch0 1.347 Pass TM2_2DH5_Ch39 1.348 Pass TM2_2DH5_Ch78 1.348 Pass TM3_3DH5_Ch0 1.322 Pass TM3_3DH5_Ch39 1.324 Pass TM3_3DH5_Ch78 1.325 Pass RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 3 of 127 2 Test Plot 2.1 TM1_DH5_Ch0 RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 4 of 127 2.2 TM1_DH5_Ch39 RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 5 of 127 2.3 TM1_DH5_Ch78 RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 6 of 127 2.4 TM2_2DH5_Ch0 RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 7 of 127 2.5 TM2_2DH5_Ch39 RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 8 of 127 2.6 TM2_2DH5_Ch78 RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 9 of 127 2.7 TM3_3DH5_Ch0 RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 10 of 127 2.8 TM3_3DH5_Ch39 RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 11 of 127 2.9 TM3_3DH5_Ch78 RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 12 of 127 Appendix B: Carrier Frequency Separation RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 13 of 127 1 Result Table EUT Conf. Carrier Frequency Separation [MHz] Verdict TM1_DH5_Hop 1.050 Pass TM2_2DH5_Hop 1.150 Pass TM3_3DH5_Hop 1.050 Pass RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 14 of 127 2 Test Plot 2.1 TM1_DH5_Hop RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 15 of 127 2.2 TM2_2DH5_Hop RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 16 of 127 2.3 TM3_3DH5_Hop RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 17 of 127 Appendix C: Number of Hopping Channel RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 18 of 127 1 Result Table EUT Conf. Number of Hopping Channel Verdict TM1_DH5_Hop 79 Pass TM2_2DH5_Hop 79 Pass TM3_3DH5_Hop 79 Pass RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 19 of 127 2 Test Plot 2.1 TM1_DH5_Hop RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 20 of 127 2.2 TM2_2DH5_Hop RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 21 of 127 2.3 TM3_3DH5_Hop RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 22 of 127 Appendix D: Time of Occupancy (Dwell Time) RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 23 of 127 1 Result Table The Dwell Time = Burst Width * Total Hops. The detailed calculations are showed as follows: - The duration for dwell time calculation: 0.4 [s] * hopping number = 0.4 [s] * 79 [ch] = 31.6 [s*ch]; - The burst width [ms/hop/ch], which is directly measured, refers to the duration on one channel hop. - The hops per second for all channels: The selected EUT Conf uses a slot type of 5-Tx&1-Rx and a hopping rate of 1600 [ch*hop/s] for all channels. So the final hopping rate for all channels is 1600 / 6 = 266.67 [ch*hop/s]; - The hops per second on one channel: 266.67 [ch*hop/s] / 79 [ch] =3.38 [hop/s]; - The total hops for all channels within the dwell time calculation duration: 3.38 [hop/s] * 31.6 [s*ch] = 106.67 [hop*ch]; - The dwell time for all channels hopping: 106.67 [hop*ch] * Burst Width [ms/hop/ch]. EUT Conf. Burst Width [ms/hop/ch] Total Hops [hop*ch] Dwell Time [ms] Verdict TM1_DH5_Ch39 2.900 106.67 0.309 Pass TM2_2DH5_Ch39 2.900 106.67 0.309 Pass TM3_3DH5_Ch39 2.900 106.67 0.309 Pass RF Test Report of HUAWEI G735-L03 Report No: SYBH(Z-RF)045092014-2002 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 24 of 127 2 Test Plot NOTE: The test plots are only for Burst Width measurements. 2.1 TM1_DH5_Ch39 RF Test Repo…

Text truncated - open the document above for the full version.

Photos of Test Setup For GSM&WCDMA&LTE 1．Radiated Spurious Emissions Radiated Spurious Emission (below 3GHz) Radiated Spurious Emission (3GHz to18GHz) Radiated Spurious Emission (18GHz to26.5GHz) For Bluetooth & Wlan 2．Radiated Spurious Emissions Radiated Spurious Emission (below 1GHz) Radiated Spurious Emission (1GHz to18GHz) Radiated Spurious Emission (above 18GHz) Conducted Emissions Conducted Emissions for AC Ports --------------------------------------------The END-------------------------------------------
