QISH1512Smart Phone

Safety + Warranty 1 1.1 Safety & regulatory details Please read all of the safety information carefully before using your d evice to ensure its s afe and proper operation and to learn how to dispose of your device properly. Online safety information To read the complete safety and regulatory information for this product: 1. Visit http://consumer.huawei.com/en/. 2. Search for "Nexus 6P". 3. Download the document titled Safety, Regulatory and Legal Information for your phone. Electronic labels To view regulatory marks and related information on your phone, go to Settings > About phone > Regulatory information. 2 1.2 Safety guidelines Operation and safety • To prevent possible hearing damage, do not listen at high volume levels for long periods. • Using a headset at high volumes may damage your hearing. To reduce this risk, lower the headset volume to a safe and comfortable level. • Using an unapproved or incompatible power adapter, charger or battery may damage your device, shorten its lifespan or cause a fire, explosion or other hazards. • Use only approved accessories. The use of unapproved accessories may void the warranty, may violate local regulations and laws, and may be dangerous. For information about the availability of approved accessories in your area, contact your retailer. • Ideal operating temperatures are 0 °C to 35 °C. Ideal storage temperatures are -20 °C to 60 °C. • Pacemaker manufacturers recommend maintaining a minimum distance of 15 cm between a pacemaker and a wireless device to prevent potential interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your front pocket. • Keep the device and the battery away from excessive heat and direct sunlight. Do not place them on or in heating devices, such as microwave ovens, stoves or radiators. 3 • Adhere to local laws and regulations while using the device. To reduce the risk of accidents, do not use your device while driving. • While flying in an aircraft or immediately before boarding, ensure that you use your device according to the instructions provided. Using a wireless device in an aircraft may disrupt wireless networks, present a hazard to aircraft operations or be illegal under law. • To prevent damage to your device's parts or internal circuits, do not use it in dusty, smoky, damp or dirty environments or near magnetic fields. • When charging the device, make sure the power adapter is plugged into a socket near the devices and is easily accessible. • Unplug the charger from the electric socket and from the device when not in use. • If the device has a built-in, non-removable battery, do not attempt to remove it. Doing so may damage the device. To replace the battery, take the device to an authorised service centre. • Do not use, store or transport the device where flammables or explosives are stored (e.g. in a petrol station, oil depot or chemical plant). Using your device in these environments increases the risk of explosion or fire. • Do not use chemical detergents, powders, or other agents (such as alcohol or benzene) to clean the device or accessories. These substances may cause damage to parts or present a fire hazard. Use a clean, soft, and dry cloth to clean the device and accessories. • Dispose of this device, the battery and accessories according to local regulations. They should not be disposed of in normal household waste. Improper battery use may lead to fire, explosion or other hazards. 4 1.3 Regulatory information EU regulatory conformance Body worn operation The device complies with RF specifications when used near your ear or at a distance of 1.5 cm from your body. Ensure that the device accessories, such as a device case and device holster, are not composed of metal components. Keep the device away from your body to meet the distance requirement. The highest SAR value reported for this device type when tested at the ear is 1.17 W/kg, and when properly worn on the body is 0.54 W/kg. Statement Huawei Technologies Co., Ltd. hereby declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC and 2009/ 125/EC. For the latest declaration of conformity, visit the website http://consumer.huawei.com/certification. The following marking is included in the product: This device may be operated in all member states of the EU. Adhere to national and local regulations where the device is used. This device may be restricted for use, depending on the local network. Restrictions in the 5 GHz band: WLAN function of this device is restricted only to indoor use when operating in the 5150 to 5350 MHz frequency range. 5 FCC Regulatory Compliance Body worn operation The device complies with RF specifications when used near your ear or at a distance of 1.5 cm from your body. Ensure that the device accessories, such as a device case and device holster, are not composed of metal components. Keep the device away from your body to meet the distance requirement. Certification information (SAR) This device is also designed to meet the requirements for exposure to radio waves established by the Federal Communications Commission (USA). The SAR limit adopted by the USA is 1.6 W/kg averaged over one gram of tissue. The highest SAR value reported to the FCC for this device type complies with this limit. The highest SAR value reported to the FCC for this device type when using at the ear is 1.49 W/kg, and when properly worn on the body is 0.81 W/kg, and when using the Wi-Fi hotspot function is 1.43 W/Kg. FCC statement This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc…

Text truncated - open the document above for the full version.

Huawei Technologies Co.,Ltd. Federal Communications Commission 2015-9-11 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: QISH1512 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Operational Description Bom List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. ***************************************************************************** In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until 2015-12-26: External Photos Internal Photos Test Setup Photos User Manual ****************************************************************************** It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. E-mail: [email protected] Fax: 0086-0755-89650226

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base, Bantian, Longgang, Shenzhen, P.R China Post ZIP：518129 Page ：1/1 To: TUVPS Fax : NULL From:Zhang Xinghai Fax:0086-0755-89650226 Tel:0086-0755-28970299 Email address: [email protected] Http: www.huawei.com Subject：Letter of Authorization 2015-09-15 To whom it may concern: We the undersigned, hereby authorize TUVPS to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by TUVPS on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Huawei Technologies Co., Ltd. . Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

11_2.4G Wi-Fi Declaration Letter V1.0 Huawei Technologies Co.,Ltd. Federal Communications Commission 2015-09-15 Oakland Mills Road Columbia MD 21046 Subject: Statement for 2.4G Wi-Fi TM FCC ID: QISH1512 To Whom It May Concern: We, Huawei Technologies Co., Ltd., states that our product---H1512 comply with the requirement in KDB 594280 D01 Software Configuration Control v02r01. For 2.4G Wi-Fi part, only support channels 1-11, the channel 12 and channel 13 are disabled by software in the factory, this setting is not accessible and can’t active by the user or any other third-party. If have any questions concerning the above, please contact the undersigned. Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. E-mail: [email protected] Tel: 0086-0755-28970299 Fax: 0086-0755-89650226 **Wi-Fi is a trademark of Wi-Fi Alliance

12_5G Wi-Fi Declaration Letter V1.0 Huawei Technologies Co.,Ltd. Statement Federal Communications Commission 2015-09-14 Oakland Mills Road Columbia MD 21046 Subject: Statement for 5G Wi-Fi TM The information within this section of the Operational Description is to show compliance against the Software Security Requirements laid out within KDB 594280 D02 U-NII Device Security v01r02. The information below describes how we maintain the overall security measures and systems so that only: 1. Authenticated software is loaded and operating on the device 2. The device is not easily modified to operate with RF parameters outside of the authorization General Description 1. Describe how any software /firmware update will be obtained, downloaded, and installed. There are two methods of updating the software/firmware on the device and these are either Firmware Over the Air (FOTA) from the User’s Service Provider or via a hardware connection to a computer supporting the download client. The download client is a software tool that has to be downloaded from the Huawei web site. Via OTA, the device has to be powered on and in Idle mode, registered with the Users Service provider. The User is informed that there is a new software/firmware version available, the option to update the software/firmware is selected then the download commences without any user intervention as all authentication is done directly between the device and the Service Provider. The user is then requested to power cycle the device to active the newly installed SW. Via the download client, the device is to be initially recognized by the download client as being an authentic device via the correct authentication certificates held on the device. The User is then advised of the Software/Firmware updates that are available for download to their device. The User requests the necessary updates and the Software/Firmware is downloaded to the device without any further User intervention as all authentications is carried out between the 12_5G Wi-Fi Declaration Letter V1.0 certificates held on the device and the download client. As part of the Software/Firmware update, the device power cycles so that is ready for the User to disconnect from the download Client and continue using. 2. Describe all the radio frequency parameters that are modified by any software/firmware without any hardware changes. Are these parameters in some way limited, such that, it will not exceed the authorized parameters? The Software/Firmware in the device, controls the following RF parameters: 1. Transmitter Frequency 2. Transmitter Output Power 3. Receiver Frequency 4. Channel Bandwidth 5. RSSI calibration The Software/Firmware controls the RF parameters listed above so as to comply with the specific set of regulatory limits in accordance with the FCC grants issued for this device. Yes. The RF parameters are limited to comply with FCC rules and requirements during calibration of the device in the factory. Security keys (certification certificates) are in place to ensure that these parameters cannot be access by the User and/or a 3rd party 3. Are there any authentication protocols in place to ensure that the source of the software/ firmware is legitimate? If so, describe in details; if not, explain how the software is secured from modification 。 All software images are digitally signed with public key cryptography. Images are signed by private key stored in securely merged server, and verified by public key stored in a device when they are flashed into the device. Some SW images are verified with the public key when they are executed. 4. Are there any verification protocols in place to ensure that the software/firmware is legitimate? If so, describe in details The same as General Description Q3 5. Describe, if any, encryption methods used? Software/firmware is not encrypted. 6. For a device that can be configured as a master and client (with active or passive scanning), explain how the device ensures compliance for each mode? In particular if the device acts as master in some band of operation and client in another; how is compliance ensured in each band of operation? This handset will only operate as a master device in hot spot mode and in Wi-Fi direct mode, both of which are limited to the 2.4GHz band on channels 1 – 11 only. This device can only be configured as a client in all UNII bands where it operates using passive scanning techniques. 3rd Party Access Control 1. How is any unauthorized software/firmware change prevented? The same as General Description Q3 2. Is it possible for third parties to load device drivers that could modify the RF parameters, country of operation or other parameters which No 12_5G Wi-Fi Declaration Letter V1.0 impact device compliance? If so, describe procedures to ensure that only approved drivers are loaded. 3. Explain if any third parties have the capability to operate a US sold device on any other regulatory domain, frequencies, or in any manner that is in violation of the certification 3rd party does not have the capability 4. What prevents third parties from loading non-US versions of the software/firmware on the device? 3rd party cannot access SW/FW 5. For modular devices, describe how authentication is achieved when used with different hosts. Not applicable – this is not a modular device SOFTWARE CONFIGURATION DESCRIPTION 1. To whom is the UI accessible? (Professional installer, end user, other.) NA a) What parameters are viewable to the professional installer/end-user?6 NA b) What parameters are accessible or modifiable to the professional installer? NA i) Are the parameters in some way limited, so that the installers will not enter parameters that exceed those authorized? NA ii) What controls exist that the user cannot operate the device outside its authorization in the U.S.? NA c) What configuration options are available to the end-user? NA i) Are the parameters in some way limited, so that the installers will not enter paramet…

Text truncated - open the document above for the full version.

23_Electronic Label Letter V1.0 Huawei Technologies Co.,Ltd. Federal Communications Commission 2015-09-14 Oakland Mills Road Columbia MD 21046 Subject: Electronic Label Letter FCC ID:QISH1512 To Whom It May Concern: Pursuant to the provisions of KDB 784748 D02 e labeling v01, we hereby provide the following statement: This device have a integrated display screen can present the required label information electronically (e-label) in lieu of a physical label or nameplate. The end user can access the electronic label with three steps. The information of electronic label is programmed by Huawei, any can’t be modified by any third party. If have any questions concerning the above, please contact the undersigned. Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. E-mail: [email protected] Tel: 0086-0755-28970299 Fax: 0086-0755-89650226

Justification Letter Date (21/09/2015) BABT TCB Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Huawei Technologies Co., Ltd. Bantian, Longgang District, Shenzhen, 518129, China hereby to do the Justification on FCC application: Smart Phone, H1512, FCC ID: QISH1512 as following: H1512 is a smart phone. It is supporting GSM, WCDMA, CDMA, LTE, 2.4G Wi-Fi, 5 G Wi-Fi, Bluetooth, BLE and NFC function. H1511(Smart Phone, FCC ID: QISH1511) is a smart phone. It is also supporting GSM, WCDMA, CDMA, LTE, 2.4G Wi-Fi, 5 G Wi-Fi, Bluetooth, BLE and NFC function. The detailed difference between H1512 (FCC ID: QISH1512) and H1511 (FCC ID: QISH1511) as below: The different bands are controlled by the software and the hardware is the same. H1511 H1512 LTE bands B2/4/5/7/12/13/17/25/26/29/30/41 B2/4/5/7/17/38/41 WCDMA bands B2/B4/B5 B2/B4/B5 CDMA Bands BC0/1/10 BC0/1 GSM four bands the same the same NFC mode the same the same camera the same the same FLASH the same the same Main board the same the same PCB layout the same the same Appearance the same the same Bluetooth mode the same the same WLAN mode the same the same BT/ WLAN antenna the same the same GSM/ WCDMA /LTE antenna the same the same Battery the same the same Chipset the same the same Memory the same the same RF Parameter The same RF Parameter in the same band The same RF Parameter in the same band Dimension the same the same HAC Support Not support So in this FCC application for H1512(FCC ID: QISH1512): New Test report and data I15N00996-EMC for FCC Part 15B have been submitted, and this report according to Part 15B is valid and applicable and they are representative of the compliance of H1512. Test report and data ( except for spurious emission ) for Bluetooth(DSS part) refer to report “SYBH(Z- RF)011072015-2005” in FCC application for H1511(FCC ID: QISH1511), and this data according to Part 15C remains valid and applicable and they are representative of the compliance of H1512(FCC ID: QISH1512). Spurious emission test data refer to new report I15Z42367-SRD02 Test report and data ( except for spurious emission) for Bluetooth 4.0(DTS part) refer to report “SYBH(Z-RF)011072015-2002” in FCC application for H1511(FCC ID: QISH1511), and this data according to Part 15C remains valid and applicable and they are representative of the compliance of H1512(FCC ID: QISH1512) Spurious emission test data refer to new report I15Z42367-SRD03. Test report and data( except for spurious emission) for 2.4GHz WLAN(DTS part) refer to report “SYBH(Z-RF)011072015-2004” in FCC application for H1511(FCC ID: QISH1511), and this data according to Part 15C remains valid and applicable and they are representative of the compliance of H1512(FCC ID: QISH1512).Spurious emission test data refer to new report I15Z42367-SRD04. Test report and data( except for spurious emission and DFS) for 5GHz WLAN refer to report “SYBH(Z-RF)011072015-2002” in FCC application for H1511(FCC ID: QISH1511). and this data according to Part 15E remains valid and applicable and they are representative of the compliance of H1512(FCC ID: QISH1512). Spurious emission test data refer to new report I15Z42367-EMC01 and I15Z42367-EMC02, DFS test data refer to new report I15Z42367-SRD01. Test report of GSM 850/1900, WCDMA band2/4/5, CDMA BC0/ BC01 and LTE band 2/4/5/7/17/38/41( PCE part) please refer to new test report “SYBH(Z-RF)012082015-2001”. But test data of GSM 850/1900, WCDMA band2/4/5,CDMA BC0/ BC01 and LTE band 2/4/5/7/17/41 refer to report “SYBH(Z-RF)011072015-2001” in FCC application for H1511(FCC ID: QISH1511), and this data according to Part 22, 24 ,27 and 90 remains valid and applicable and they are representative of the compliance of H1512(FCC ID: QISH1512) Test report and data for NFC(NXX part) refer to report “SYBH(Z-RF)011072015-2006” in FCC application for H1511(FCC ID: QISH1511), and this data according to Part 15C remains valid and applicable and they are representative of the compliance of H1512(FCC ID: QISH1512) SAR test report of GSM 850/1900, WCDMA band2/4/5, CDMA BC0/ BC01 and LTE band 2/4/5/7/17/38/41( PCE part) please refer to new test report “SYBH(Z-SAR)019082015-2”. But test data of GSM 850/1900, WCDMA band2/4/5,CDMA BC0/ BC01 and LTE band 2/4/5/7/17/41 refer to report “SYBH(Z-SAR)011072015-2” in FCC application for H1511(FCC ID: QISH1511), and this remains valid and applicable and they are representative of the compliance of H1512(FCC ID: QISH1512). Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhangxinghai EMC Laboratory Manager

H1512 Smart Phone; SECRET Page1,Total 5 External Photos of H1512 H1512 Smart Phone; SECRET Page2,Total 5 H1512 Smart Phone; SECRET Page3,Total 5 H1512 Smart Phone; SECRET Page4,Total 5 H1512 Smart Phone; SECRET Page5,Total 5

H1512 Smart Phone; SECRET Page1, Total 4 H1512 H1512 Smart Phone; SECRET Page2, Total 4 H1512 Smart Phone; SECRET Page3, Total 4 Setting-About phone-certification

H1512 Smart Phone; SECRET Page1,Total 5 Internal Photos of H1512 H1512 Smart Phone; SECRET Page2,Total 5 H1512 Smart Phone; SECRET Page3,Total 5 H1512 Smart Phone; SECRET Page4,Total 5 H1512 Smart Phone; SECRET Page5,Total 5

Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Tel: +86 755 28780808 Fax: +86 755 89652518 FCC SAR Compliance Test Report Product Name: Smart Phone Model: H1512 Report No.: SYBH(Z-SAR)019082015-2 FCC ID: QISH1512 APPROVED (Lab Manager) PREPARED (Test Engineer) BY DATE 2015-09-15 2015-09-15 The test results of this test report relate exclusively to the item(s) tested . The HUAWEI does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of HUAWEI. Reliability Laboratory of Huawei Technologies Co., Ltd. Report No.: SYBH(Z-SAR)019082015-2 FCC ID: QISH1512 2015-09-15 Page 2 of 235 Table of Contents 1 General Information ............................................................................................................................................... 5 1.1 Statement of Compliance .............................................................................................................................. 5 1.2 RF exposure limits ......................................................................................................................................... 6 1.3 EUT Description ............................................................................................................................................ 7 1.3.1 General Description ............................................................................................................................... 9 1.3.2 TDD LTE additional specification ......................................................................................................... 11 1.3.3 Power reduction specification .............................................................................................................. 11 1.3.4 Downlink LTE CA additional specification ........................................................................................... 13 1.3.5 Dynamic antenna switching specification ............................................................................................ 16 1.3.6 802.11g/a Wi-Fi CDD and 802.11 n/ac Wi-Fi MIMO specification ...................................................... 16 1.4 Test specification(s) .................................................................................................................................... 17 1.5 Testing laboratory ........................................................................................................................................ 17 1.6 Applicant and Manufacturer ........................................................................................................................ 17 1.7 Application details ........................................................................................................................................ 17 1.8 Ambient Condition ...................................................................................................................................... 17 2 SAR Measurement System ................................................................................................................................. 18 2.1 SAR Measurement Set-up .......................................................................................................................... 18 2.2 Test environment ......................................................................................................................................... 19 2.3 Data Acquisition Electronics description .................................................................................................... 19 2.4 Probe description ......................................................................................................................................... 20 2.5 Phantom description .................................................................................................................................... 21 2.6 Device holder description ............................................................................................................................ 22 2.7 Test Equipment List ..................................................................................................................................... 23 3 SAR Measurement Procedure ............................................................................................................................ 24 3.1 Scanning procedure .................................................................................................................................... 24 3.2 Spatial Peak SAR Evaluation ...................................................................................................................... 25 3.3 Data Storage and Evaluation ...................................................................................................................... 26 4 System Verification Procedure ............................................................................................................................ 28 4.1 Tissue Verification ....................................................................................................................................... 28 4.2 System Check ............................................................................................................................................. 35 4.3 System check Procedure............................................................................................................................. 37 5 SAR measurement variability and uncertainty .................................................................................................... 38 5.1 SAR measurement variability…
