QISH881Ccdma2000 Digital Mobile Phone

Quick Start Guide Welcome to HUAWEI HUAWEI Ascend Y300 Model:H881C TracFone part number: XXXXXXXX 1 Phone at a Glance All the pictures in this guide are for your reference only. Your phone's actual display features may be different to those described here, depending on its software version. Key Functions at Your Fingertips • Press and hold to power on your mobile phone. • When your mobile phone is powered on, press and hold this button to display the options menu. You can then choose to power off the phone or perform shortcut operations. • Press to lock the screen when your mobile phone is active. Touch to open the menu on an active screen. • Touch to return to the Home screen. • Touch and hold to display recently used applications. Earpiece Camera Volume key Headset jack Charger/ Data port Power key Back Home Menu 2 Installing the microSD Card If you want to expand your phone memory, you can also insert a microSD card. 1. Remove the battery cover. 2. Insert the microSD card into the card slot as shown in the diagram. Installing the Battery 1. Angle the edge labeled a (with the contacts) into the bottom end of the battery compartment. 2. Push the edge labeled b into the compartment until the battery clicks firmly into place. • Touch to return to the previous screen or exit the application you are running. • Touch to hide the keyboard. 12 a b 3 Charging the Battery Before charging the battery, ensure that it has been properly installed on your phone. 1. Connect the USB cable that came with your mobile phone to the charger. 2. Connect the other end of the USB cable to your mobile phone. Then, to start charging, plug the charger into an electrical outlet. If you charge your mobile phone while it is powered on, the battery icon on the notification bar indicates the charging status. When the battery icon changes to , your mobile phone is fully charged. Status Indicator The color of the status indicator tells you the status of your mobile phone's battery. Status Indicator Green: Fully charged (when connected to charger). Orange: Charging in progress (when connected to charger). Red: Battery low. 4 Touchscreen Actions Using your finger on the touchscreen, you can operate your phone conveniently. Home Screen You can set up the Home screen according to your own preferences, for example by adding a shortcut or a widget to your Home screen, changing the wallpaper, or setting the number of Home screen extensions. To return to the Home screen from any of its extensions, press . Touch & hold TouchDouble touch RotateFlickDrag 10:23 10:23 Flick your finger left or right across the Home screen. Touch to view thumbnails of the Home screen and its extensions. Touch a thumbnail to open the screen. 5 When a new notification icon appears on the notification bar, place your finger on the notification bar and flick down to open the notification panel. Adding a New Home Screen Item 1. On the Home screen, touch to display the application list. 2. Press and hold an application icon, and then drag the icon to a blank area on the Home screen. Removing an Icon from the Home Screen 1. Touch and hold an item on the Home screen that you want to remove until your mobile phone vibrates. 2. Without lifting your finger, drag the item to the trash can. Wait until the item and the trash can turn red. 3. Release the item. Adding a Contact 1. In the contact list, touch . 2. From the screen displayed, create a contact in your mobile phone, SIM card or your account. Add a new account if you do not have one. 3. Enter the contact's name, and then add detailed information such as phone numbers and address. 4. Touch Done to save the contact information. To save a contact from your call log, touch and hold the desired phone number to display the options menu, and then touch Add to contacts. 6 Making a Call with the Phone Application 1. On the Home screen, touch > Phone. If the dialer is not displayed, touch . 2. Enter the phone number. 3. Touch to initiate the call. Creating and Sending a Multimedia Message You can use multimedia messages to make everyday communications very special. You can record a message and send it as an audio file, for example, sing "Happy Birthday" and send it to a friend, or send a slideshow of photographs of a special event. The possibilities are enormous. 1. Touch > Messaging, then . 2. Enter a phone number in the To field, or touch to select a contact from People. 3. Touch the composition text box to start composing your message. 4. When you are ready to send the message, touch . 7 Connecting Internet Get online using your phone's Wi-Fi to save your money. Turning On Wi-Fi 1. Touch > Settings. 2. Under WIRELESS & NETWORKS, touch the button next to Wi-Fi. Basic Operations Touch > Browser to open the home page. When known or open Wi-Fi networks and mobile data networks are available at the same time, your phone will preferably select a Wi-Fi network for Internet access. Touch on the upper section of the screen, and all web pages currently open are displayed. You can: • Touch one page to enlarge it. • Touch the cross sign (×) to close that page. • Touch (+) to open a new browser window. 10:23 8 Opening a Webpage 1. In a browser window, touch the URL field at the top of the screen. 2. Use the keyboard to enter a webpage address. 3. As you enter the address, matching webpage addresses will appear on the screen. If you see the address you want, touch it and go directly to that webpage or complete entering your desired webpage. Turning Off Your Data Service When you are not using your data service, to eliminate unwanted data traffic, you can turn it off quickly. 1. Open the notification bar. 2. Touch at the top of the screen to switch data services on or off. Play Store Android Play Store provides direct access to applications and games which you can download and install on your phone. Opening Play Store 1. On the Home screen, touch > Play Store. 2. When you open Play Store for the first time, the Google Play Term…

Text truncated - open the document above for the full version.

Secret 2012-11-26 华为保密信息,未经授权禁止扩散 第1页, 共1页 Huawei Technologies Co.,Ltd Bantian, Longgang District, Shenzhen, 518129 Guangdong, P.R.China Tel: +86-755-2878-1879 ; Fax: +86-755-2878-1889 Date: November 26, 2012 Statement We, Huawei Technologies Co.,Ltd, states that our device, FCC ID: QISH881C use Broadcom’s chip BCM4330, though BCM4330 support BT4.0+HS and 5.0G Wi-Fi., but H881C doesn’t support BLE, 5 GHz client, ad-hoc, Wi-Fi Direct function. H881C only support BT2.1+EDR and 2.4G Wi-Fi. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Huawei Technologies Co.,Ltd Bantian, Longgang District, Shenzhen, 518129 Guangdong, P.R.China Tel: +86-755-2878-1879 ; Fax: +86-755-2878-1889 Date: November 26, 2012 Statement We, Huawei Technologies Co.,Ltd, states that our device, FCC ID: QISH881C, has a battery, But the battery will not be placed in the battery compartment when delivery, it is visible to the users as they purchase the products and install the battery. For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Huawei Technologies Co.,Ltd. Federal Communications Commission 2012-11-28 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: QISH881C To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Operational Description Bom List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. ***************************************************************************** In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until 2013-3-30: External Photos Internal Photos Test Setup Photos User Manual ****************************************************************************** It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. E-mail: [email protected] Fax: 0086-0755-89650226

HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page1,Total 6 External Photos of HUAWEI H881C, H881C HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page2,Total 6 HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page3,Total 6 HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page4,Total 6 HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page5,Total 6 HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page6,Total 6

HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page1, Total 4 Label Location HUAWEI H881C, H881C HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page2, Total 4 HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page3, Total 4 HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page4, Total 4

HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page1,Total 6 Internal Photos of HUAWEI H881C, H881C HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page2,Total 6 HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page3,Total 6 HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page4,Total 6 HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page5,Total 6 HUAWEI H881C, H881C cdma2000 Digital Mobile Phone; Asura SECRET Page6,Total 6

FCC Test Report - EDR Product Name: cdma2000 Digital Mobile Phone; Asura Model Number: HUAWEI H881C, H881C Report No: SYBH(Z-RF)003112012-2004 FCC ID：QISH881C Reliability Laboratory of Huawei Technologies Co., Ltd. Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Tel: +86 755 28780808 Fax: +86 755 89652518 FCC Test Report of HUAWEI H881C, H881C FCC ID: QISH881C Security Level: Public Report No: SYBH(Z-RF)003112012-2004 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total31 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 3. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-2. 4. The test report is invalid if not marked with "exclusive stamp for the test report". 5. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 6. The test report is invalid if there is any evidence of erasure and/or falsification. 7. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 8. Normally, the test report is only responsible for the samples that have undergone the test. 9. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. FCC Test Report of HUAWEI H881C, H881C FCC ID: QISH881C Security Level: Public Report No: SYBH(Z-RF)003112012-2004 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total31 REGULATION FCC CFR47 Part 2:2011: Subpart J; FCC CFR47 Part 15:2011: Subpart C; ANSI C63.10:2009 START OF TEST Nov., 07, 2012 END OF TEST Nov., 12, 2012 Final Judgement: Pass Approved By Senior Engineer Nov., 19, 2012 Dai Linjun Date Name Signature Reviewed By Nov., 19, 2012 Cousy Xu Date Name Signature Operated By Nov., 19, 2012 Huang Qiuliang Date Name Signature FCC Test Report of HUAWEI H881C, H881C FCC ID: QISH881C Security Level: Public Report No: SYBH(Z-RF)003112012-2004 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total31 Contents 1 Summary .................................................................................................................................................... 5 2 Product Description .................................................................................................................................. 6 2.1 PRODUCTION INFORMATION ................................................................................................................... 6 2.2 MODIFICATION INFORMATION .................................................................................................................. 6 3 Test Site Description ................................................................................................................................. 7 4 General Setup Description ........................................................................................................................ 7 5 Product Description .................................................................................................................................. 8 5.1 TECHNICAL CHARACTERISTICS ............................................................................................................... 8 5.2 EUT IDENTIFICATION LIST .................................................................................................................... 10 6 Main Test Instruments ............................................................................................................................. 11 7 Transmitter Measurements ..................................................................................................................... 12 7.1 BANDWIDTH MEASUREMENT ................................................................................................................. 12 7.2 CARRIER FREQUENCY SEPARATION MEASUREMENT ............................................................................... 14 7.3 NUMBER OF HOPPING CHANNEL ............................................................................................................ 16 7.4 TIME OF OCCUPANCY ........................................................................................................................... 18 7.5 PEAK OUTPUT POWER .......................................................................................................................... 20 7.6 BAND EDGE SPURIOUS EMISSION .......................................................................................................... 22 7.7 CONDUCTED RF SPURIOUS ................................................................................................................. 24 7.8 RADIATED SPURIOUS EMISSION & SPURIOUS IN RESTRICTED BAND ......................................................... 26 7.9 CONDUCTED EMISSION AT POWER PORT .............................................................................................. 28 8 System Measurement Uncertainty ......................................................................................................... 30 9 Appendices List ....................................................................................................................................... 31 FCC Test Report of HUAWEI H881C, H881C FCC ID: QISH881C Security Level: Public Report No: SYBH(Z-RF)003112012-2004 Confidential Information of Huawei.…

Text truncated - open the document above for the full version.

FCC Test Report Product Name: cdma2000 Digital Mobile Phone; Asura Model Number: HUAWEI H881C, H881C Report No: SYBH(Z-RF)003112012-2003 FCC ID：QISH881C Reliability Laboratory of Huawei Technologies Co., Ltd. Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Tel: +86 755 28780808 Fax: +86 755 89652518 FCC Test Report of HUAWEI H881C, H881C FCC ID: QISH881C Security Level: Public Report No: SYBH(Z-RF)003112012-2003 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total33 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 3. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-2. 4. The test report is invalid if not marked with "exclusive stamp for the test report". 5. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 6. The test report is invalid if there is any evidence of erasure and/or falsification. 7. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 8. Normally, the test report is only responsible for the samples that have undergone the test. 9. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. FCC Test Report of HUAWEI H881C, H881C FCC ID: QISH881C Security Level: Public Report No: SYBH(Z-RF)003112012-2003 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total33 REGULATION FCC CFR47 Part 2:2011: Subpart J; FCC CFR47 Part 15:2011: Subpart C; ANSI C63.10:2009 START OF TEST Nov., 07, 2012 END OF TEST Nov., 12, 2012 Final Judgement Pass Approved By Senior Engineer Nov., 19, 2012 Dai Linjun Date Name Signature Reviewed By Nov., 19, 2012 Cousy Xu Date Name Signature Operated By Nov., 19, 2012 Huang Qiuliang Date Name Signature FCC Test Report of HUAWEI H881C, H881C FCC ID: QISH881C Security Level: Public Report No: SYBH(Z-RF)003112012-2003 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total33 Contents 1 Summary .................................................................................................................................................... 5 2 Product Description .................................................................................................................................. 6 2.1 PRODUCTION INFORMATION ................................................................................................................... 6 2.2 MODIFICATION INFORMATION ................................................................................................................. 6 3 Test Site Description ................................................................................................................................. 6 4 General Setup Description ........................................................................................................................ 7 5 Product Description .................................................................................................................................. 8 5.1 TECHNICAL CHARACTERISTICS ............................................................................................................... 8 5.2 EUT IDENTIFICATION LIST .................................................................................................................... 10 6 Main Test Instruments ............................................................................................................................ 11 7 Transmitter Measurements ..................................................................................................................... 12 7.1 BANDWIDTH MEASUREMENT ................................................................................................................. 12 7.2 CARRIER FREQUENCY SEPARATION MEASUREMENT ............................................................................... 14 7.3 NUMBER OF HOPPING CHANNEL ............................................................................................................ 16 7.4 TIME OF OCCUPANCY ........................................................................................................................... 18 7.5 PEAK OUTPUT POWER .......................................................................................................................... 20 7.6 BAND EDGE SPURIOUS EMISSION .......................................................................................................... 22 7.7 CONDUCTED RF SPURIOUS ................................................................................................................. 24 7.8 RADIATED SPURIOUS EMISSION & SPURIOUS IN RESTRICTED BAND ......................................................... 26 7.9 CONDUCTED EMISSION AT POWER PORT .............................................................................................. 29 8 System Measurement Uncertainty ......................................................................................................... 32 9 Appendices List ....................................................................................................................................... 33 FCC Test Report of HUAWEI H881C, H881C FCC ID: QISH881C Security Level: Public Report No: SYBH(Z-RF)003112012-2003 Confidential Information of Huawei. No Distr…

Text truncated - open the document above for the full version.

FCC Test Report of HUAWEI H881C, H881C FCC ID: QISH881C Security Level: Public Report No: SYBH(Z-RF)003112012-2003 Confidential Information of Huawei. No Distribution without Written Permission Page1, Total4 Appendix J Photos of Test Setup FCC Test Report of HUAWEI H881C, H881C FCC ID: QISH881C Security Level: Public Report No: SYBH(Z-RF)003112012-2003 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total4 1 Radiated Spurious Emissions Radiated Spurious Emission (below 1GHz) Radiated Spurious Emission (1GHz to18GHz) FCC Test Report of HUAWEI H881C, H881C FCC ID: QISH881C Security Level: Public Report No: SYBH(Z-RF)003112012-2003 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total4 Radiated Spurious Emission (above 18GHz) FCC Test Report of HUAWEI H881C, H881C FCC ID: QISH881C Security Level: Public Report No: SYBH(Z-RF)003112012-2003 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total4 2 Conducted Emissions Conducted Emissions for AC Ports
