QISHG530XHome Gateway

HUAWEI HG530 Home Gateway User Guide HUAWEI TECHNOLOGIES CO., LTD. HUAWEI HG530 Home Gateway V100R001 User Guide Issue 01 Date 2010-03-23 Part Number 202168 Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. Please feel free to contact our local office or company headquarters. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China Website: http://www.huawei.com Email: [email protected] Copyright © Huawei Technologies Co., Ltd. 2010. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses. Trademarks and Permissions , , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Other trademarks, product, service and company names mentioned are the property of their respective owners. Notice Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers. Thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. NO WARRANTY THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS. Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein. Contents 1 Warnings and Precautions....................................................................... 2 2 Getting Started.......................................................................................... 8 3 Setting the Network-Access Parameters................................................. 8 3.1 Accessing the Network Through the Embedded PPP Dial-Up Software on the HG530...........................................................................................................8 3.2 Accessing the Network Through the PPP Dial-Up Software on Your Computer.............................................................................................................9 4 Configuring the Wireless Network Connection.................................... 10 5 Configuring the HG530.......................................................................... 12 5.1 Changing the Administrator Password Used for Logging In to the Web-Based Configuration Utility......................................................................12 5.2 Enabling or Disabling the Wireless Network Function..............................13 5.3 Changing the Wireless Network Name and the Access Password.............13 5.4 Changing the IP Address Used for Logging In to the Web-Based Configuration Utility.........................................................................................14 5.5 Restoring Default Settings..........................................................................14 6 FAQs......................................................................................................... 16 7 Appendix.................................................................................................. 19 7.1 Indicators....................................................................................................19 7.2 Interfaces and Buttons................................................................................20 7.3 Default Settings..........................................................................................21 7.4 Technical Specifications.............................................................................21 i 1 Warnings and Precautions Thank you for purchasing the HUAWEI HG530 Home Gateway (hereinafter referred to as the HG530). To use the device properly and safely, read these warnings and precautions carefully and strictly observe them during operation. Unless otherwise specified, the term "device" refers to the device and its accessories. Basic Requirements z During storage, transportation, and operation of the device, keep it dry and prevent it from colliding with other objects. z Do not dismantle the device. In case of any fault, contact an authorized service center for assistance or repair. z Without authorization, no organization or individual can change the mechanical, safety, or performance design of the device. z When using the device, observe all applicable laws and regulations and respect the legal rights of other people. Environmental Requirements for Using the Device z Before connecting and disconnecting cables, stop using the device, and then disconnect it from the power supply. Ensure that your hands are dry during operation. z K…

Text truncated - open the document above for the full version.

Huawei Technologies Co.,Ltd. Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. FCC ID: QISHG530X Date: July,29 2010 We, Huawei Technologies Co.,Ltd. doesn’t provide any controls or software to allow the operation outside of the USA frequency band when we sell this product in USA Sincerely, Signature: Name/Title: Zhang Xinghai/EMC Manager Company Name: Huawei Technologies Co.,Ltd. Address: Administration Building,Huawei Base,Bantian,Longgang District, Shenzhen 518129 P.R.C. TEL: +86-755-28781879 FAX: +86-755-28781889 Email: [email protected]

Huawei Technologies Co.,Ltd. Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. Attestation for FCC Declaration of Conformity FCC ID:QISHG530X Data: July 23,2010 Please be notified that we, the undersigned, Huawei Technologies Co.,Ltd declare that the product which bears the above FCC ID is also compliant with the FCC requirements for DoC. The test report number supporting the DoC is 10B07004F. Testing in regards to this report was done by Interocean EMC Technology Corp. located atNo.5-2, Lin 1, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County 244, Taiwan, R.O.C.., which has been accredited in accordance to all of the requirements of 47CFR 2.948(d) and (e) of the FCC rules and KDB349827 Sincerely, Signature: Name/Title: Zhang Xinghai/EMC Manager Company Name: Huawei Technologies Co.,Ltd. Address: Administration Building,Huawei Base,Bantian,Longgang District, Shenzhen 518129 P.R.C. TEL: +86-755-89650288 FAX: +86-755-89650226 Email: [email protected]

Huawei Technologies Co.,Ltd. Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129, People's Republic of China Tel: +86-755-2878-1879 ; Fax: +86-755-2878-1889 Date: July 23, 2010 Power of Attorney To whom it may concern, Please be notified that I, Zhang Xinghai, have designated Shenzhen Huatongwei International Co.,Ltd as the persons being responsible for this project and to sign the form 731 and below documents: -External Photos -Lable & Location Info -Internal Photos -RF Exposure Info -Test Report -Test setup photos -User's manual -Short Term Confidentiality Any and all acts carried out by Shenzhen Huatongwei International Co.,Ltd on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is limited to the product of as following: FCC ID: QISHG530X Any changes or modifications of FCC ID must be allowed by HUAWEI. If you have any acknowledgement and response, please send it to Shenzhen Huatongwei International Co.,Ltd directly. Should you have any questions or comments regarding this matter, please have my best attention. The authorization shall become effective on 2010-7-23, and expired on 2011.1.19. Sincerely yours, Contact Person: Zhang Xinghai Company: Huawei Technologies Co.,Ltd. TEL: +86-755-2878-1879 FAX: +86-755-2878-1889 E-mail: [email protected]

Huawei Technologies Co.,Ltd. Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: QISHG530X Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematic Theory of Operation Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, We do not want these documents to be accessible to the general public. Sincerely, Signature: Name/Title: Zhang Xinghai/EMC Manager Company Name: Huawei Technologies Co.,Ltd. Address: Administration Building,Huawei Base,Bantian,Longgang District, Shenzhen 518129 P.R.C. TEL: +86-755-89650288 FAX: +86-755-89650226 Email: [email protected]

V1.0 Page 80 of 85 Report No.: WE10060027 6. External and Internal Photos of the EUT External Photos Label location V1.0 Page 81 of 85 Report No.: WE10060027 Label location V1.0 Page 82 of 85 Report No.: WE10060027 #1 AC Adapter #2 AC Adapter V1.0 Page 83 of 85 Report No.: WE10060027

铭牌生产是铭牌区域是空白的, 此处条码仅用于规定条码所处位置, 实际打印内容以制造所提供为准! 红框是S/N.MAC打印区域， 大小48*12mm, 铭牌生产时此区域留空， 红框只是示意边界，不能印制出来, 条码内容由生产线在线打印。 DKBA8.807.3392 6.00 mm MODEL: HG530 NAME: Home Gateway 12 V; 0.5 A POWER RATING: FCC ID:QISHG531X US:HAUDL01BHG53X This Product Complies With 47CFR PARTu68. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation. 0678 0678 tanyan 53030331 亚白PET过亚膜 亚白PET过亚膜 S/N.MAC码区域 9 . 0 0 m m FCC ID:QISHG530X US:HAUDL01BHG530X This Product Complies With 47CFR PART 68. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation.

Label location

V1.0 Page 84 of 85 Report No.: WE10060027 Internal Photos V1.0 Page 85 of 85 Report No.: WE10060027 .......................End of Report.........................

MPE TEST REPORT FCC Per 47 CFR 2.1091(b) FCC ID .............................................: QISHG530X Compiled by ( position+printed name+signature)..: File administrators Wenliang Li Supervised by ( position+printed name+signature)..: Test Engineer Eric Zhang Approved by ( position+printed name+signature)..: Manager Jimmy Li Date of issue.....................................: July 12, 2010 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address.............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: HUAWEI TECHNOLOGIES CO.,LTD. Address.............................................: Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. Test specification: Standard ...........................................: FCC Per 47 CFR 2.1091(b) TRF Originator ..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Home Gateway Trade Mark .......................................: Model/Type reference.......................: HG530 Listed Models ..................................: / Result................................................: Positive V1.0 Page 2 of 7 FCC ID: QISHG530X MPE T E S T R E P O R T FCC ID : QISHG530X July 12, 2010 ______________________________________________________________________________________________ Date of issue Equipment under Test : Home Gateway Model /Type : HG530 Listed Models : / Applicant : HUAWEI TECHNOLOGIES CO.,LTD. Address : Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. Manufacturer HUAWEI TECHNOLOGIES CO.,LTD. Address : Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 7 FCC ID: QISHG530X Contents 1. SUMMARY............................................................................. 4 1.1. EUT configuration 4 1.2. NOTE 4 2. TEST ENVIRONMENT............................................................... 5 2.1. Address of the test laboratory 5 2.2. Environmental conditions 5 2.3. Statement of the measurement uncertainty 5 3. METHOD OF MEASUREMENT .................................................... 5 3.1. Applicable Standard 5 3.2. Limit 6 3.3. MPE Calculation Method 6 4. CONCLUSION ........................................................................ 7 V1.0 Page 4 of 7 FCC ID: QISHG530X 1. SUMMARY 1.1. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - supplied by the manufacturer ○ - supplied by the lab ○ Power Cable Length (m) : / Shield : / Detachable : / ○ Multimeter Manufacturer : / Model No. : / ● #1 AC Adapter MODEL:FPS005USA-120050 INPUT:100-240V～50/60Hz 300mA OUTPUT:12.0V DC 0.5A Power Cable:150cm ◇ Shield ◆ Unshield ● #2 AC Adapter MODEL:UE06L4-120050SPAU INPUT:100-240V～50/60Hz 0.2A OUTPUT:12.0V DC 0.5A Power Cable:150cm ◇ Shield ◆ Unshield 1.2. NOTE 1. The EUT is an 802.11b/g/n Home Gateway,The functions of the EUT listed as below: Test Standards Reference Report WLAN 802.11b/g, 802.11n FCC Part 15 Subpart C (Section15.247) WE10060027 WLAN 802.11b/g, 802.11n FCC Part 15 Subpart B SQE10060042 2. The frequency bands used in this EUT are listed as follows: Frequency Band(MHz) 2400-2483.5 5150-5350 5470-5725 5725-5850 802.11b √ － － － 802.11g √ － － － 802.11n(20MHz) √ － － － 802.11n(40MHz) √ － － － 3. The EUT incorporates a SISO function, Physically, the EUT provides one completed transmitter and one completed receivers. Modulation Mode TX Function 802.11b 1TX 802.11g 1TX 802.11n (20MHz) 1TX 802.11n (40MHz) 1TX V1.0 Page 5 of 7 FCC ID: QISHG530X 2. TEST ENVIRONMENT 2.1. Address of the test laboratory Shenzhen Huatongwei International Inspection Co., Ltd Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Phone: 86-755-26715686 Fax: 86-755-26748089 The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 (2009) and CISPR Publication 22. 2.2. Environmental conditions During the measurement the environmental conditions were within the listed ranges: Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressure: 950-1050mbar 2.3. Statement of the measurement uncertainty The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities. The measurement uncertainty was calculated for all measurements listed in this test report acc. to CISPR 16 - 4 „Specification for radio disturbance and immunity measuring apparatus and methods – Part 4: Uncertainty in EMC Measurements“ and is documented in the Shenzhen Huatongwei International Inspection Co., Ltd quality system acc. to DIN EN ISO/IEC 17025. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. The manufacturer has the sole responsibility of continued compliance of the device. Hereafter the best measurement capability for Shenzhen Huatongwei laboratory is reported: Test Range Measurement Uncertainty Notes Radiated Emission 30~1000MHz 4.24 dB (1) Radiated Emission 1~18GHz 5.16 d…

Text truncated - open the document above for the full version.

FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No......................: FCC ID............................................. : WE10060027 QISHG530X Compiled by ( position+printed name+signature)..: File administrators Wenliang Li Supervised by ( position+printed name+signature)..: Test Engineer Eric Zhang Approved by ( position+printed name+signature)..: Manager Jimmy Li Date of issue.....................................: July 12, 2010 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: HUAWEI TECHNOLOGIES CO.,LTD. Address ............................................: Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. Test specification: Standard ...........................................: FCC Part 15.247: Operation within the bands 920-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz Direct Sequence System TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Home Gateway Trade Mark .......................................: Model/Type reference.......................: HG530 Listed Models ..................................: / Result................................................: Positive V1.0 Page 2 of 80 Report No.: WE10060027 T E S T R E P O R T Test Report No. : WE10060027 July 12, 2010 ______________________________________________________________________________________________ Date of issue Equipment under Test : Home Gateway Model /Type : HG530 Listed Models : / Applicant : HUAWEI TECHNOLOGIES CO.,LTD. Address : Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. Manufacturer HUAWEI TECHNOLOGIES CO.,LTD. Address : Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 80 Report No.: WE10060027 Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. EUT configuration 5 2.6. Related Submittal(s) / Grant (s) 6 2.7. Modifications 6 2.8. NOTE 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Test Description 9 3.6. Statement of the measurement uncertainty 10 3.7. Equipments Used during the Test 10 4. TEST CONDITIONS AND RESULTS ............................................ 12 4.1. AC Power Conducted Emission 12 4.2. Radiated Emission 17 4.3. Maximum Peak Output Power 35 4.4. Power Spectral Density 38 4.5. Band Edge Compliance of RF Emission 46 4.6. Spurious RF Conducted Emission 51 4.7. 6dB Bandwidth 58 4.8. Antenna Requirement 72 5. TEST SETUP PHOTOS OF THE EUT .......................................... 73 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 75 V1.0 Page 4 of 80 Report No.: WE10060027 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.4-2009: American National Standard for Methods of Measurement of Radio-Noise Emissions From Low Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz. ANSI C63.10 : American National Standard for Testing Unlicensed Wireless Devices V1.0 Page 5 of 80 Report No.: WE10060027 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Jun 27, 2010 Testing commenced on : Jun 27, 2010 Testing concluded on : July 12, 2010 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 12V Adapter from AC 120V/60Hz Description of the test mode IEEE 802.11b/g/n: Thirteen channels are provided to the EUT,but only eleventh channels used for USA. Channel Frequency(MHz) Channel Frequency(MHz) 1 2412 8 2447 2 2417 9 2452 3 2422 10 2457 4 2427 11 2462 5 2432 12 2467 6 2437 13 2472 7 2442 2.3. Short description of the Equipment under Test (EUT) 2.4GHz (Home Gateway (HG530)) For more details, refer to the user’s manual of the EUT. The product has two kinds of patterns: Including the WPS function and non-WPS function.Two kinds of the patterns both have the outer coverings of picture frame and waterfall. Serial number: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition. The Applicant provides AT command to control the EUT for staying in continous transmitting and receiving mode for testing. 2.5. EUT configuration The following peripheral devices and interface cables were connected during the measurement: V1.0 Page 6 of 80 Report No.: WE10…

Text truncated - open the document above for the full version.

V1.0 Page 77 of 84 Report No.: WE10060027 5. Test Setup Photos of the EUT V1.0 Page 78 of 84 Report No.: WE10060027
