EchoLife HG556 Home Gateway User Guide HUAWEI TECHNOLOGIES CO., LTD. EchoLife HG556 Home Gateway V100R001 User Guide Issue 01 Date 2009-08-26 Part Number 202157 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. For any assistance, please contact our local office or company headquarters. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China Website: http://www.huawei.com Email: [email protected] Copyright © Huawei Technologies Co., Ltd. 2009. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses. Trademarks and Permissions , HUAWEI, and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Other trademarks, product, service and company names mentioned are the property of their respective owners. Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Notice Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. NO WARRANTY THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS. Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein. EchoLife HG556 Home Gateway User Guide Contents Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. i Contents 1 Safety Precautions ................................................................................................ 1-1 2 Product Overview................................................................................................. 2-1 2.1 Product Features.......................................................................................................... 2-1 2.2 Network Application................................................................................................... 2-2 2.3 Indicators, Interfaces and Buttons............................................................................... 2-3 2.3.1 Indicators......................................................................................................... 2-3 2.3.2 Interfaces and Buttons..................................................................................... 2-2 2.4 System Requirements.................................................................................................. 2-3 3 Product Installation.............................................................................................. 3-1 3.1 Selecting the Installation Position............................................................................... 3-1 3.2 Connecting the Cables................................................................................................. 3-1 4 Configuring the HG556....................................................................................... 4-1 4.1 Accessing the Web Configuration Page...................................................................... 4-1 4.2 Changing the Administrator Password........................................................................ 4-1 5 Data Services......................................................................................................... 5-1 5.1 Introduction................................................................................................................. 5-1 5.2 Configuring the HSPA uplink..................................................................................... 5-1 5.3 Configuring the ADSL uplink..................................................................................... 5-2 5.3.2 Configuring the PPPoE Mode......................................................................... 5-2 Configuring the PPPoE Mode for the WAN Interface............................................. 5-3 Configuring the Work Parameters of the LAN Interface......................................... 5-3 5.3.3 Configuring the Bridge Mode......................................................................... 5-4 6 Voice Services........................................................................................................ 6-1 6.1 Introduction.....................................................................…

Text truncated - open the document above for the full version.

Huawei Technologies Co. Ltd 2009-09-08 HUAWEI Confidential Page1, Total3 APPENDIX A Lettery of Agency "I, an officer of Huawei Technologies Co. Ltd. do hereby authorize Rico Deng, who is Senior Engineer in Intertek Testing Services Taiwan Ltd. to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and Part 18 of the FCC Rules until further notice." I further certify that no party (as defined in §1.2002(b) of CFR 47, 1992) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,853(a). By: Xinghai Zhang Signature Printed Title: EMC manager Date: 2009-9-8

Huawei Technologies Co. Ltd 2009-09-08 HUAWEI Confidential Page2, Total3 APPENDIX B Confidentility Letter (Permanent) Attention: Application Examiner Re: Request for confidentiality Applicant: Huawei Technologies Co. Ltd. FCC ID: QISHG556 To whom it may concern, Request is hereby submitted by Huawei Technologies Co. Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: [Select one or more of items below, as appropriate] • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description Rationale for request for confidentiality: Huawei Technologies Co. Ltd. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Huawei Technologies Co. Ltd 2009-09-08 HUAWEI Confidential Page3, Total3 Sincerely, Title: EMC Manager Company name: Huawei Technologies Co. Ltd. Date: 2009-9-8

Photo 1: External photo of EUT Photo 2: External photo of EUT EchoLife HG556 EchoLife HG556 Photo 3: External photo of EUT Photo 4: External photo of Adapter EchoLife HG556 EchoLife HG556 Photo 5: External photo of Adapter Photo 6: External photo of Adapter EchoLife HG556 EchoLife HG556

FCC ID Label Location 90*30mm

Photo 1: Internal photo of EUT Photo 2: Internal photo of EUT EchoLife HG556 EchoLife HG556 Photo 3: Internal photo of EUT Photo 4: Internal photo of EUT EchoLife HG556 EchoLife HG556 Photo 5: Internal photo of EUT Photo 6: Internal photo of EUT PCB Antenna 2 EchoLife HG556 EchoLife HG556 PCB Antenna 1 Photo 7: Internal photo of EUT EchoLife HG556 PCB Antenna 2

FCC ID. : QISHG556 Report No.: TS09080099-EME Page 1 of 7 Maximum Permissible Exposure (MPE) Evaluation Report Report No. : TS09080099-EME Model No. : EchoLife HG556 Issued Date : Jan. 12, 2010 Applicant: Huawei Technologies Co. Ltd. Administration Building, Huawei Base, Bantian. Longgang District, Shenzhen Test Method/ Standard: FCC 1.1310 and Safety Code 6 Test By: Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result(s) in this report only applies to the tested sample(s). The test report was prepared by: Sign on File Julie Liu/ Assistant These measurements were taken by: Sign on File Rex Liao/ Engineer The test report was reviewed by: Name Jacky Chen Title Engineer FCC ID. : QISHG556 Report No.: TS09080099-EME Page 2 of 7 Table of Contents Summary of Tests ............................................................................................................. 3 1. Introduction .................................................................................................................. 4 2. RF Exposure Limit ....................................................................................................... 4 3. RF Exposure calculations ............................................................................................. 5 4 Description of EUT ....................................................................................................... 6 5 Test results ..................................................................................................................... 7 FCC ID. : QISHG556 Report No.: TS09080099-EME Page 3 of 7 Summary of Tests MPE Evaluation meet FCC OET No. 65: 1997, IEEE C95.1-2005 and IC Safety Code 6 Home Gateway-Model: EchoLife HG556 FCC ID: QISHG556 Test Reference Results MPE Evaluation FCC Guidelines for Human Exposure IEEE C95.1 and IC Safety Code 6 Complies FCC ID. : QISHG556 Report No.: TS09080099-EME Page 4 of 7 1. Introduction The EUT operates in the 2.4 GHz ISM band. Due to the EUT (include antenna) at its normal operation distance is at least 20 cm from the human body, the EUT was defined as a Mobile Device. The reason to do the MPE Evaluation is to avoid the RF hazard to human body. The maximum output power and gain of the antenna were used to calculate the limited Power density (S) at 20 cm distance away from the product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 and Safety Code 6 are followed. According to 1.1307 (b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. 2. RF Exposure Limit For FCC: According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A) Limits for Occupational / Control Exposures 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 (B) Limits for General Population / Uncontrolled Exposure 30-300 27.5 0.073 0.2 30 300-1500 - - F/1500 30 1500-100,000 - - 1.0 30 F= Frequency in MHz FCC ID. : QISHG556 Report No.: TS09080099-EME Page 5 of 7 For IC: Exposure Limits for Persons Not Classed As RF and Microwave Exposed Workers (Including the General Public) Frequency Range (MHz) Electric Field Strength; rms (V/m) Magnetic Field Strength; rms (A/m) Power Density (W/m 2 ) Average Time (minutes) 0.003-1 280 2.19 - 6 1-10 280/f 2.19/f - 6 10-30 28 2.19/f - 6 30-300 28 0.073 2 * 30 300-1500 1.585 f 0.5 0.0042 f 0.5 F/150 30 1500-15000 61.4 0.163 10 30 15000-150000 61.4 0.163 10 616000/f 1.2 150000-300000 0.158 f 0.5 4.21 × 10 -4 f 0.5 6.67 × 10 -5 f 616000/f 1.2 * Power density limit is applicable at frequencies greater than 100 MHz. Notes: 1. Frequency, f, is in MHz. 2. A power density of 10 W/m 2 is equivalent to 1 mW/cm 2 . 3. A magnetic field strength of 1 A/m corresponds to 1.257 microtesla (μT) or 12.57 milligauss (mG). 3. RF Exposure calculations From §FCC 1.1310 table 1 and §Safety Code 6 table 5, the maximum permissible RF exposure for an uncontrolled environment is 1 mW/(cm 2 ) (or 10 W/m 2 )* * 10 W/m 2 = 1 mW/ (cm 2 ) Power density (S) is calculated by the following formula: S = (P * G)/4πR 2 where, S = Power density (mW/cm 2 ) P = Output power to antenna (mW) R = Distance between radiating structure and observation point (cm) G = Gain of antenna in numeric π = 3.1416 Example: Assume a mobile device operates at 2412MHz and its maximum output power is 50mW, and the maximum gain of antenna is 1 (numeric) /0dBi. then the power density (S) = (50 * 1)/4*π*20 2 = 0.00995 (mW/cm 2 ) (or = 0.0995 W/m 2 ) FCC ID. : QISHG556 Report No.: TS09080099-EME Page 6 of 7 4 Description of EUT The EUT is a Home Gateway, which is an 802.11b/g/n MIMO product with dual transmitters and dual receivers and was defined as information technology equipment. The EUT has 802.11b/g/n function which can transmitter independently and simultaneous transmit 4.1 Antenna description Antenna 1 The EUT uses a permanently connected antenna. Antenna Gain: 2dBi max Antenna Type: PCB Printed Connector Type: N/A Antenna 2 The EUT uses a permanently connected antenna. Antenna Gain: 2dBi max Antenna Type: PCB Printed Connector Type: N/A FCC ID. : QISHG556 Report No.: TS09080099-EME Page 7 of 7 5 Test results 2 Tx Mode Channel Frequency (MHz) Antenna Gain (numeric) Output power to antenna (mW) Power density (mW/cm2) Limit of power density (mW/cm2) Distance (cm) 1 2412 1.58 125.25…

Text truncated - open the document above for the full version.

FCC ID. : QISHG556 Report No.: TS09080100-EME Page 1 of 112 EMC TEST REPORT Report No. : TS09080100-EME Model No. : EchoLife HG556 Issued Date : Jan. 07, 2010 Applicant: Huawei Technologies Co. Ltd. Administration Building, Huawei Base, Bantian. Longgang District, Shenzhen Test Method/ Standard: 47 CFR FCC Part 15.247 & ANSI C63.4 2003 Test By: Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result(s) in this report only applies to the tested sample(s). The test report was prepared by: Sign on File Julie Liu/ Assistant These measurements were taken by: Sign on File Rex Liao/ Engineer The test report was reviewed by: Name Jacky Chen Title Engineer FCC ID. : QISHG556 Report No.: TS09080100-EME Page 2 of 112 Table of Contents 1. Summary of Test Data................................................................................................. 3 2. General Information .................................................................................................... 4 3. Maximum 6 dB Bandwidth .......................................................................................... 7 4. 99 % Occupied Bandwidth ........................................................................................ 21 5. Maximum Output Power............................................................................................ 35 6. Power Spectral Density ............................................................................................. 37 7. RF Antenna conducted Spurious............................................................................... 51 8. Radiated Spurious Emission..................................................................................... 88 9. Emission on Band Edge............................................................................................ 97 Appendix A: Test Equipment List..................................................................................112 FCC ID. : QISHG556 Report No.: TS09080100-EME Page 3 of 112 1. Summary of Test Data Test/Requirement Description Applicable Rule Result Minimum 6 dB Bandwidth 15.247(a)(2) Pass Maximum Output Power 15.247(b) Pass Power Spectral Density 15.247(e) Pass RF Antenna Conducted Spurious 15.247(d) Pass Radiated Spurious Emission 15.247(d), 15.205, 15.209 Pass Emission on the Band Edge 15.247(d) Pass AC Power Line Conducted Emission 15.207 Pass FCC ID. : QISHG556 Report No.: TS09080100-EME Page 4 of 112 2. General Information Identification of the EUT Product: Home Gateway Model No.: HG556 FCC ID.: QISHG556 Frequency Range: 1. 2412 MHz to 2462 MHz for 802.11b/g/n HT20 2. 2422 MHz to 2452 MHz for 802.11n HT40 Channel Number: 1. 11 channels for 802.11b/g/n HT20 2. 7 channels for 802.11n HT40 Rated Power: DC 12 V from adapter model: FM120015-US I/P Voltage: 100-240 Vac, 50/60Hz Power Cord: N/A Data Cable: RJ-45 UTP Cat.5 10meter × 1 Sample Received: Aug. 25, 2009 Test Date(s): Aug. 27, 2009 ~ Sep. 03, 2009 Note 1: This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Note 2: When determining the test conclusion, the Measurement Uncertainty of test has been considered. FCC ID. : QISHG556 Report No.: TS09080100-EME Page 5 of 112 Description of EUT The EUT is a Home Gateway, which is an 802.11b/g/n MIMO product with dual transmitters and dual receivers and was defined as information technology equipment. The EUT has 802.11b/g/n function which can transmitter independently and simultaneous transmit For more detail features, please refer to User's manual as file name “Installation guide.pdf” Antenna description Antenna 1 The EUT uses a permanently connected antenna. Antenna Gain: 2dBi max Antenna Type: PCB Printed Connector Type: N/A Antenna 2 The EUT uses a permanently connected antenna. Antenna Gain: 2dBi max Antenna Type: PCB Printed Connector Type: N/A FCC ID. : QISHG556 Report No.: TS09080100-EME Page 6 of 112 Operation mode The EUT was supplied with DC 12 V from adapter (Test voltage: 120 Vac, 60 Hz). The EUT was transmitted continuously during the test. With individual verifying, the maximum output power was found at 1 Mbps data rate for 802.11b mode, 6 Mbps data rate for 802.11g mode, 6.5 Mbps data rate for 802.11n HT20 mode and 13.5 Mbps data rate for 802.11n HT40 mode. The final tests were executed under these conditions and recorded in this report individually. 802.11b ch6 chain0 802.11n HT20 ch6 chain0 Data rate(MHz)PK(dBm) Data rate(MHz) PK(dBm) 1 17.87 6.5 21.56 2 17.65 13 21.37 5.5 17.5 19.5 21.27 11 17.38 26 21.11 39 20.94 802.11g ch6 chain0 52 20.84 Data rate(MHz)PK(dBm) 58.5 20.73 6 22.71 65 20.72 9 22.6 12 22.46 802.11n HT40 ch6 chain0 18 22.36 Data rate(MHz) PK(dBm) 24 22.29 13.5 20.76 36 22.11 27 20.63 48 22.03 40.5 20.62 54 21.96 54 20.48 81 20.3 108 20.18 121.5 20.06 135 20.05 FCC ID. : QISHG556 Report No.: TS09080100-EME Page 7 of 112 3. Maximum 6 dB Bandwidth Name of Test Maximum 6 …

Text truncated - open the document above for the full version.

Photo 1: Conducted Emission Test Set-up photo Photo 2: Conducted Emission Test Set-up photo EchoLife HG556 EchoLife HG556

Photo 1: Radiated Emission Test set-up photo Photo 2: Radiated Emission Test set-up photo EchoLife HG556 EchoLife HG556 Photo 3: Radiated Emission Test set-up photo Photo 4: Radiated Emission Test set-up photo EchoLife HG556 EchoLife HG556
