QISHG630Home Gateway

1 HG630 Home Gateway Quick Start 1 Installing the Base When you install the base, ensure that the arrow on the base points to the front panel of the HG630 Home Gateway (HG630 for short). 2 Connecting Cables Using the DSL Port If there is at least one telephone jack available in your home, you can access the Internet using digital subscriber line (DSL) services. 1 3 2 4 5 6 a b c 5 7 2 1. Telephone wall jack 2. Splitter 3. Telephone 4. Desktop computer 5. Power adapter 6. Laptop computer 7. HG630 a. Splitter LINE port b. Splitter PHONE port c. Splitter MODEM port 3 Powering On the HG630 After you connect the cables, power on the HG630 by pressing the On/Off button on its side panel. After you power on the HG630, the Power indicator lights up,the DSL indicator lights up and starts blinking, indicating that the DSL port is being activated. The blinking may last from 40 seconds to 3 minutes. When the DSL indicator stops blinking and turns steady on, it indicates that the cables are connected correctly and the HG630 has been activated using DSL. 4 Setting Network Access Parameters Configuring a Dial-Up Connection for Internet Access By default, the HG630 works in routing mode. The HG630 starts to set up a dial-up connection automatically after you power it on. You do not need to install any dial-up software or perform any dial-up operations on your computer. To set up a dial-up connection for Internet access: Step 1 Launch a browser on your computer. Enter http://192.168.1.1 in the address box, and press Enter . Step 2 On the login page, enter your user name and password.  By default, the user name is user and password is HuaweiUser.  For security reasons or to make the password easy to remember, you can change the user name and password for login. For details, check the HG630 user guide.  If the user name and password have been changed, use the new ones to log in. Step 3 Click Login . Step 4 Click Setup Wizard to display the Wizard tab . Step 5 Click Next . Step 6 In WAN device , select your ADSL or VDSL WAN device. Step 7 In User name and Password , enter the user name and password that are provided by your service provider, and then click Next . Step 8 In SSID and WPA pre-shared key , set a wireless network name and password, and then click Next . 3  The default wireless network name (SSID) and password ( WLAN Key) which are printed on the label of the HG630's rear panel are preset before delivery. They are unique and safe. If you do not want to modify them, click Next.  For security reasons or to make the password easy to remember, you can change it. For details, see section "Configuring a Wireless Network Name and Password" .  If the default wireless network name and password have been changed, use the new ones. Step 9 Confirm the information you set and then click Submit . Then check the status of the Internet indicator. When the Internet indicator turns green, you can access the Internet. The preceding operations need only be performed once. The next time you power on the computer, you can access the Internet without any other configurations. Configuring a Wireless Network Name and Password When the HG630 is delivered, the wireless network name and password are preset. You can find them on the HG630’s rear panel label. For security reasons or to make the password easier to remember, change the wireless network name and password as follows: (The default wireless network encryption mode WPA-PSK/WPA2-PSK is used as an example) Step 1 Log in to the HG630's web-based configuration utility. Step 2 Choose Basic > WLAN to display the WLAN tab. Step 3 Select Enable WLAN . Step 4 In SSID , enter a new wireless network name. Step 5 For Security , select WPA-PSK/WPA2-PSK . Step 6 In WPA Pre-Shared Key , enter a new password. Use the default settings for other parameters. Step 7 Click Submit . Remember the new wireless network name and password you just set. You will be prompted to enter this password when connecting wireless devices, such as a computer, to the HG630's wireless network. 4 5 Setting Up a Wireless Connection A computer running Windows 7 is used as an example to describe how to set up a wireless connection: Step 1 Start the computer’s wireless configuration service: 1. Click Start, enter services.msc in the search box, and press Enter. 2. In the Services window, right-click WLAN AutoConfig to display a shortcut menu, and choose Properties. 3. Check that Service status is Started. 4. Click OK to close the dialog box, and then close the Services window. Step 2 Find and make note of the wireless network name ( SSID ) and password ( WLAN Key ) printed on the label on the HG630's rear panel. If the wireless network name and password have been changed, use the new ones. Step 3 Configure the wireless network connection on the computer as follows: 1. Choose Start > Control Panel > Network and Sharing Center > Change adapter settings. 2. In the Network Connections window, right-click the Wireless Network Connection to display a shortcut menu, and select Connect/Disconnect. 3. In the Wireless Network Connection dialog box, select the wireless network whose name is the same as the one you recorded in Step 2, and click Connect. 4. In the Connect to Network dialog box, enter the wireless network password you recorded in Step 2, and click OK. After the system verifies the password, Connected appears on the wireless network icon in the wireless network list, indicating that your computer has established a wireless connection to the HG630. For more information, visit http://www.huaweidevice.com to download the HG630 user guide. Enter HG630 in the search box to find the user guide. 6 Warnings and Precautions To use the device properly and safely, read these warnings and precautions carefully and strictly observe them during operation. Unless otherwise specified, the term "device" refers to the device and its accessories. Basic Requirements  During storage, transportation, and operation of the d…

Text truncated - open the document above for the full version.

Part Number: 203197 HG630 Home Gateway Product Description Issue 01 Date 2012-05-20 HUAWEI TECHNOLOGIES CO., LTD. Copyright © Huawei Technologies Co., Ltd. 2012. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks and Permissions and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd. All other trademarks and trad e names mentioned in this document are the property of their respective holders. Notice The purchased products, services and features are stipulated by the commercial contract made between Huawei and the customer. All or partial products, services and features described in this document may not be within the purchased scope or the usage scope. Unless otherwise agreed by the contract, all statements, information, and recommendations in this document are provided “AS IS” without warranties, guarantees or representations of any kind, either express or implied. The information in this document is subject to change without notice. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, a nd recommendations in this document do not constitute the warranty of any kind, express or implied. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China Website: http://www.huaweidevice.com Email: [email protected] HG630 Home Gateway Product Description Issue: 01 (2012-05-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 3 of 16 Contents 1 Overview............................................................................................................................... 4 1.1 Introduction to the HG630 ................................................................................................................... 4 1.2 Hardware Features ............................................................................................................................... 5 1.3 Network Architecture ........................................................................................................................... 8 2 Functional Features ........................................................................................................... 10 2.1 High- bandwidth VDSL2 and HSPA Upstream Link ......................................................................... 10 2.2 Support 802.11n ................................................................................................................................. 10 2.3 WPS Function .................................................................................................................................... 10 2.4 Routing Function ................................................................................................................................ 10 2.5 IPv6 Function ..................................................................................................................................... 10 2.6 Flexible QoS Policies ......................................................................................................................... 11 2.7 Standardized TR-069 Management .................................................................................................... 11 2.8 Convenient and Secure Management and Maintenance ..................................................................... 11 3 Technical Specifications .................................................................................................. 12 3.1 Interface Features ............................................................................................................................... 12 3.2 Security Features ................................................................................................................................ 13 3.3 Routing & Bridged Features .............................................................................................................. 13 3.4 QoS Features ...................................................................................................................................... 14 3.5 Network Management ........................................................................................................................ 14 3.6 Power Supply Specifications .............................................................................................................. 14 3.7 Physical Specifications ....................................................................................................................... 14 3.8 Environmental Specifications ............................................................................................................ 14 4 Acronyms and Abbreviations ......................................................................................... 15 HG630 Home Gateway Product Description Issue: 01 (2012-05-20) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Page 4 of 16 1 Overview 1.1 Introduction to the HG630 Figure 1-1 Appearance of the HG630 HG630 Home Gateway (hereinafter referred to as the HG630) is a type of Very High Speed Digital Subscriber Line (VDSL) terminal. It's also compatible with Asymmetric Digital Subscriber Line (ADSL), ADSL2, ADSL2+. On the network side, the HG630 provides a DSL interface. For users, it provides an 2×2 MIMO 802.11b/g/n interface and four Ethernet interfaces. After connecting to a PC, STB, video phone, or another terminal, users can enjoy data, voice, and a range of other services. The HG630 supports the triple play service completely and provides powerful routing and bridging functions. It supports the IPv4 & IPv6 dual stack mode and the DS-Lite mode, and various access modes such as PPPoE, IPoA and IPoE. Besides, it supports DHCP, DNS, NAT, IGMP Proxy and S…

Text truncated - open the document above for the full version.

Huawei Technologies Co.,Ltd Aug 28, 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd would like the following documents regarding this submission for FCC ID: QISHG630 to be kept confidential. 1. Schematic 2. Block diagram 3. Operational description The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Name: Zhang Xinghai Title: EMC Laboratory Manager

Huawei Technologies Co.,Ltd Aug 28, 2012 To whom it may concern: We the undersigned, hereby authorize EMCCert DR. RAŠEK GmbH and Neutron Engineering, Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by EMCCert DR. RAŠEK GmbH and Neutron Engineering, Inc. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Huawei Technologies Co., Ltd Sincerely, Signature: Name: Zhang Xinghai Title: EMC Laboratory Manager

Huawei Technologies Co.,Ltd Attestation Letter To whom it may concern: We, the undersigned, Name: Huawei Technologies Co.,Ltd Address: Bantian, Longgang District, Shenzhen Declare that: Product description: Home Gateway Model: HG630 Brand Name: HUAWEI Hereby the DoC procedure will be carried out prior to marketing the product in the USA. on our behalf. Date: 2012-08-31 Name: Zhang Xinghai Function: EMC Laboratory Manager Signature:

Neutron Engineering Inc. Project No.: 1208C126 Page 2 of 13 1208C126 1208C126 Neutron Engineering Inc. Project No.: 1208C126 Page 3 of 13 1208C126 1208C126 Neutron Engineering Inc. Project No.: 1208C126 Page 4 of 13 1208C126 1208C126 Neutron Engineering Inc. Project No.: 1208C126 Page 5 of 13 1208C126 1208C126 Neutron Engineering Inc. Project No.: 1208C126 Page 6 of 13 1208C126 1208C126 Neutron Engineering Inc. Project No.: 1208C126 Page 7 of 13 1208C126 1208C126 Neutron Engineering Inc. Project No.: 1208C126 Page 8 of 13 1208C126 1208C126 Neutron Engineering Inc. Project No.: 1208C126 Page 9 of 13 1208C126 1208C12 6

2012-08-15 2012-08-15 2012-08-15 2012-08-15 GEYAHUI YANGYINGZHI ZHONGGANG XUDUJUAN HG630 Pantone Black C 物料底纸必须满足打印要求 红色框中内容由产线打印 DKBA8.807.XXXX 9665XXXX HG630产品铭牌_北美版本 D K B A 8 . 8 0 7 . X X X X 丝印内容 示意图 7 . 0 m m 6.0 mm Power Rating: Name: Home Gateway Model: HG630 12V ; 2.0A HUAWEI TECHNOLOGIES CO., LTD.MADE IN CHINA C Power Rating: Name: Home Gateway Model: HG630 12V ; 2.0A SN:2153020XXX7S1601XXXX MAC:00E0FCAABBCC SSID：HG630-XXXXXX WLAN Key：XXXXXXXX HUAWEI TECHNOLOGIES CO., LTD.MADE IN CHINA MAC和SN打印区域42x12mm WLAN信息打印区域42x6mm 0.2 PET哑白 6 . 4 m m FCC ID:QISHG630 FCC ID:QISHG630 US:HAUDL01BHG630 US:HAUDL01BHG630 This Product Complies With 47CFR PART 68. This Product Complies With 47CFR PART 68. This device complies with Part 15 of the FCC Rules. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: Operation is subject to the following two conditions: (1)this device may not cause harmful interference, (1)this device may not cause harmful interference, and (2)this device must accept any interference received, and (2)this device must accept any interference received, including interference that may cause undesired operation. including interference that may cause undesired operation. 5 . 0 m m Neutron Engineering Inc. Project No.: 1208C126 Page 3 of 13 1208C126 1208C126

Neutron Engineering Inc. Project No.: 1208C126 Page 10 of 13 1208C126 1208C126 Neutron Engineering Inc. Project No.: 1208C126 Page 11 of 13 1208C126 1208C126 Neutron Engineering Inc. Project No.: 1208C126 Page 12 of 13 1208C126 1208C126 Neutron Engineering Inc. Project No.: 1208C126 Page 13 of 13 1208C126 1208C126

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C126 Page 1 of 143 FCC Radio Test Report FCC ID: QISHG630 This report concerns (check one) : Original Grant Class II Change Issued Date : Aug. 30, 2012 Project No. : 1208C126 Equipment : Home Gateway Model Name : HG630 Applicant : Huawei Technologies Co., Ltd. Address : Bantian, Longgang District, Shenzhen China Manufacturer : Huawei Technologies Co., Ltd. Address : Administration Building, Huawei Base, Bantian, Longgang District , Shenzhen 518129, P.R. China Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Aug. 15, 2012 Date of Test: Aug. 15, 2012 ~ Aug. 29, 2012 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C126 Page 2 of 143 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C126 Page 3 of 143 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 15 4.1.3 TEST PROCEDURE 16 4.1.4 DEVIATION FROM TEST STANDARD 16 4.1.5 TEST SETUP 16 4.1.6 EUT OPERATING CONDITIONS 16 4.1.7 TEST RESULTS 17 4.2 RADIATED EMISSION MEASUREMENT 21 4.2.1 RADIATED EMISSION LIMITS 21 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 22 4.2.3 TEST PROCEDURE 23 4.2.4 DEVIATION FROM TEST STANDARD 23 4.2.5 TEST SETUP 24 4.2.6 EUT OPERATING CONDITIONS 25 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 27 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 33 5 . BANDWIDTH TEST 81 5.1 APPLIED PROCEDURES / LIMIT 81 5.1.1 MEASUREMENT INSTRUMENTS LIST 81 5.1.2 TEST PROCEDURE 81 5.1.3 DEVIATION FROM STANDARD 81 5.1.4 TEST SETUP 81 5.1.5 EUT OPERATION CONDITIONS 81 5.1.6 TEST RESULTS 82 6 . MAXIMUM OUTPUT POWER TEST 90 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C126 Page 4 of 143 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 90 6.1.1 MEASUREMENT INSTRUMENTS LIST 90 6.1.2 TEST PROCEDURE 90 6.1.3 DEVIATION FROM STANDARD 90 6.1.4 TEST SETUP 90 6.1.5 EUT OPERATION CONDITIONS 90 6.1.6 TEST RESULTS 91 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 94 7.1 APPLIED PROCEDURES / LIMIT 94 7.1.1 MEASUREMENT INSTRUMENTS LIST 94 7.1.2 TEST PROCEDURE 94 7.1.3 DEVIATION FROM STANDARD 94 7.1.4 TEST SETUP 94 7.1.5 EUT OPERATION CONDITIONS 94 7.1.6 TEST RESULTS 95 8 . POWER SPECTRAL DENSITY TEST 125 8.1 APPLIED PROCEDURES / LIMIT 125 8.1.1 MEASUREMENT INSTRUMENTS LIST 125 8.1.2 TEST PROCEDURE 125 8.1.3 DEVIATION FROM STANDARD 125 8.1.4 TEST SETUP 125 8.1.5 EUT OPERATION CONDITIONS 125 8.1.6 TEST RESULTS 126 9 . EUT TEST PHOTO 140 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C126 Page 5 of 143 1. CERTIFICATION Equipment : Home Gateway Brand Name : HUAWEI Model Name : HG630 Applicant : Huawei Technologies Co., Ltd. Date of Test : Aug. 15, 2012 ~ Aug. 29, 2012 Test Item : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1208C126) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C126 Page 6 of 143 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious EmissionPASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(b)(3) Peak Output Power PASS 15.209/15.205 Radiated Spurious Emission PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this test report (2) The test follows FCC KDB Publication No,558074(Measurement Guideli…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C126 Page 140 of 143 9. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C126 Page 141 of 143 Radiated Measurement Photos 9K~30MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C126 Page 142 of 143 Radiated Measurement Photos 30~1000MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1208C126 Page 143 of 143 Radiated Measurement Photos Above 1000MHz
