QISHG630-52Home Gateway

1 HG630 Home Gateway Quick Start 1Installing the Base When you install the base, ensure that the arrow on the base points to the front panel of the HG630 Home Gateway (HG630 for short). 2Connecting Cables Using the DSL Port If you have subscribed to digital subscriber line (DSL) broadband, you can connect the HG630 to a telephone port for Internet access. Connect your devices in the sequence indicated in the following figure. 1. Telephone wall jack 2. Splitter 3. Telephone 4. Desktop computer 5. Power adapter 6. Laptop computer 7. HG630 1 3 2 4 5 6 a b c 5 7 2 a. LINE port b. PHONE port c. MODEM port When configuring the HG630 for the first time, use an Ethernet cable to connect the HG630 to a computer. 3Powering On the HG630 To power on the HG630, press its power button. After the HG630 is powered on, the HG630 indicator turns on. The following table lists how the indicators behave when the HG630 is operating correctly. If the indicators do not behave as expected, ensure that everything is plugged in correctly. IndicatorExpected State Description Power Steady on The HG630 is powered on. DSLBlinking The HG630 is being activated through DSL. Steady on The HG630 is being activated through DSL. Internet Steady on The HG630 is working in routing mode, but no data is being transmitted. Blinking The HG630 is working in routing mode. And data is being transmitted. LAN1~LAN4 Steady on The HG630 is connected to a device properly. Blinking Data is being transmitted between the HG630 and the device connected. WLANSteady on The WLAN connection is set up, but no data is being transmitted. Blinking The WLAN connection is set up, and data is being transmitted. WPSBlinking A wireless client, such as a computer installed with a wireless network adapter, is connecting to the HG630 using the WPS function. This process lasts for no longer than 120 seconds. 3 4Setting Network Access Parameters By default, the HG630 works in DHCP mode. The HG630 starts to set up a dial-up connection automatically after you power it on. You do not need to install any dial-up software or perform any dial-up operations on your computer. To set up a dial-up connection for Internet access: Step 1 Open a browser. In the address box, enter http://192.168.1.1 . Press Enter . Step 2 Enter the login user name ( user by default) and password ( user by default). Click Login . To protect against unauthorized access, change the user name and password after the first login. For details, see chapter 6 “Maintenance Guide”. Step 3 Click Setup Wizard to display the Wizard tab . And click Next . Step 4 Click Next again. The HG630 works in DHCP mode by default. Your network service provider will assign IP address automatically. You do not need to configure any dial-up parameter on the HG630. If you want to access Internet trough 3G wireless network, please connect a 3G USB modem to the HG630, and enter the APN and Dial numberthat are provided by your 3G service provider. Step 5 In SSID and WPA pre-shared key , set a wireless network name and password, and click Next . To obtain the default SSID and key, check the label on the rear panel. To better secure your WLAN, promptly change the SSID and key. For details, see chapter 6 “Maintenance Guide”. Step 6 Confirm the information you set and then click Submit . Then check the status of the Internet indicator. When the Internet indicator turns green, you can access the Internet. The preceding operations need only be performed once. The next time you power on the computer, you can access the Internet without any other configurations. 5Wireless Connection Setup The wireless configuration software provided by Windows is used as an example to describe how to set up a wireless connection. If the SSID and key have been changed, use the new ones. On Windows 7 Step 1 Choose Start > Control Panel > Network and Internet > Network and Sharing Center > Change adapter settings . Right-click Wireless Network Connection , and select Connect/Disconnect . 4 Step 2 From the wireless network list, select the WLAN provided by the HG630. Click Connect . Step 3 In the displayed dialog box, enter the WLAN password and click OK . Step 4 In the wireless network list, check the WLAN connection status. If the status is Connected , the computer is wirelessly connected to the HG630. On Windows XP Step 1 Choose Start > Control Panel > Network and Internet Connections > Network Connections . Right-click Wireless Network Connection and choose View Available Wireless Networks from the shortcut menu. Step 2 From the wireless network list, select the WLAN provided by the HG630. Click Connect . Step 3 In the displayed dialog box, enter the WLAN password and click Connect . Step 4 In the wireless network list, check the WLAN connection status. If the status is Connected , the computer is wirelessly connected to the HG630. 6Maintenance Guide Changing the Web Management Page User Name and Password The correct user name and password are required to log in to the web management page. Regular changes to the web management page user name and password can effectively prevent unauthorized users from logging in and modifying important parameters. Step 1 Log in to the web management page. Step 2 In the navigation tree, choose Maintenance > Account . Step 3 Enter a new user name, your current password, and a new password. Re-enter the new password to confirm it. Step 4 Click Submit . When modify password successfully, this page will jump to the login page, enter the new user name and password to log in. If you forget the password, you can press and hold the Resetbutton for 6 seconds or more, then the user name and password of the web management page will back to factory value. This operation will make your own configuration data lost, please perform this operation with caution. Changing Your WLAN Name and Password WLAN access requires the WLAN name and password. When the HG630 is delivered, the WLAN name and password are preset. To improve …

Text truncated - open the document above for the full version.

Huawei Technologies Co.,Ltd Declaration of Authorization We Name: Huawei Technologies Co.,Ltd Address: Bantian, Longgang District , Shenzhen, China Declare that: Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification of the following product(s): Product description: Home Gateway Type designation: HG630; HG630-52 Trademark: HUAWEI on our behalf. Date: 2013-5-20 City: Shenzhen Name: Zhang Xinghai Function: EMC Laboratory Manager Signature:

Netronix Inc Model Declaration Letter We, the undersigning company Company Name: Huawei Technologies Co.,Ltd Address: Bantian, Longgang District, Shenzhen Hereby confirm that the following products: Product description: Home Gateway Type designation: HG630; HG630-52 Brand: HUAWEI All versions of the Model HG630-52 and HG630 are electrically equal and only differ in model name because of marketing purpose. Company: Huawei Technologies Co.,Ltd Address: Bantian, Longgang District, Shenzhen Signature: ____________ Name: Zhang Xinghai

CERTIFICATE OF COMPLIANCE Ref No.: NEI-FCCE-1-1305C036 Date of Issue: May. 20, 2013 Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the Neutron EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment Home Gateway Model Name HG630; HG630-52 Brand Name HUAWEI Applicant Huawei Technologies Co., Ltd. Address Bantian, Longgang District, Shenzhen China Standard(s) FCC Part 15, Subpart B: 2012 ANSI C63.4 (2009) The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCE-1-1305C036) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory Neutron Engineering Inc. B1, No.37, Lane 365, Yang Guang St., NeiHu District 114., Taipei, Taiwan TEL：+886-2-2657-3299 FAX：+886-2-2657-3331

Neutron Engineering Inc. Project No.: 1305C036 Page 2 of 11 Neutron Engineering Inc. Project No.: 1305C036 Page 3 of 11 Neutron Engineering Inc. Project No.: 1305C036 Page 4 of 11 Manufacturer: XQ Neutron Engineering Inc. Project No.: 1305C036 Page 5 of 11 Manufacturer: HK Neutron Engineering Inc. Project No.: 1305C036 Page 6 of 11

2013-04-10 2013-04-10 2013-04-10 2013-04-10 GEYAHUI YANGYINGZHI ZHONGGANG LUOXUANYU HG630-52 Pantone Black C 物料底纸必须满足打印要求 红色框中内容由产线打印 DKBA8.807.6788 96651372 HG630-52铭牌_英文版本 D K B A 8 8 0 7 6 7 8 8 . C D R 丝印内容 示意图 7 . 0 m m 6.0 mm Power Rating: Name: Home Gateway Model: HG630 12V ; 1.0A HUAWEI TECHNOLOGIES CO., LTD.MADE IN CHINA C Power Rating: Name: Home Gateway Model: HG630 12V ; 1.0A SN:2153020XXX7S1601 MAC:00E0FCAABBCC SSID：HG630-XXXXXX WLAN Key：XXXXXXXXXX HUAWEI TECHNOLOGIES CO., LTD.MADE IN CHINA 0.2 PET哑白 6 . 4 m m A 5 . 0 m m FCC ID:QISHG630-52 FCC ID:QISHG630-52 US:HAUDL01BHG630-52 US:HAUDL01BHG630-52 This Product Complies With 47CFR PART 68. This Product Complies With 47CFR PART 68. This device complies with Part 15 of the FCC Rules. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: Operation is subject to the following two conditions: (1)this device may not cause harmful interference, (1)this device may not cause harmful interference, and (2)this device must accept any interference received, and (2)this device must accept any interference received, including interference that may cause undesired operation. including interference that may cause undesired operation. 红框不打印，红框中内容仅 作示意，实际内容由产线打印 产线打印区域66x15mm XX FCC ID:QISHG630-52 US:HAUDL01BHG630 Neutron Engineering Inc. Project No.: 1305C036 Page 2 of 11

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: QISHG630-52 Project No. : 1305C036 Equipment : Home Gateway Model Name : HG630; HG630-52 Applicant : Huawei Technologies Co., Ltd. Address : Bantian, Longgang District, Shenzhen China Manufacturer : Huawei Technologies Co., Ltd. Address : Administration Building, Huawei Base, Bantian, Longgang District ,Shenzhen 518129, P.R.China According: : FCC Guidelines for Human Exposure IEEE C92.76 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Ant. Manufacturer Model Name Antenna TypeConnector Gain (dBi) Note 0 Huawei Technologies Co.,Ltd N/A PCB onboardN/A 1 1 Huawei Technologies Co.,Ltd N/A PCB onboardN/A 1 Note: The EUT incorporates a MIMO function. Physically, the EUT provides two completed transmitters and two receivers (2T2R). Operating Mode TX Mode 1TX 2TX 802.11b V (ANT0 or ANT1) - 802.11g V (ANT0 or ANT1) - 802.11n(20MHz) - V (ANT0 & ANT1) 802.11n(40MHz) - V (ANT0 & ANT1) Neutron Engineering Inc. TEST RESULTS EUT： Home Gateway Model Name ： HG630 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX B MODE /CH01, CH06, CH11 Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 15.97 39.5367 0.009907191 Complies 15.92 39.0841 0.009793781 Complies 15.98 39.6278 0.009930031 Complies EUT： Home Gateway Model Name ： HG630 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX G MODE /CH01, CH06, CH11 Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 15.79 37.9315 0.00950496 1 Complies 15.86 38.5478 0.00965940 1 Complies 15.91 38.9942 0.00977126 1 Complies EUT： Home Gateway Model Name ： HG630 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-20M MODE /CH01, CH06, CH11 - ANT 0 Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 12.85 19.2752 0.004830041 Complies 12.93 19.6336 0.004919831 Complies 12.95 19.7242 0.004942541 Complies Neutron Engineering Inc. EUT： Home Gateway Model Name ： HG630 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-20M MODE /CH01, CH06, CH11 - ANT 1 Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 12.78 18.9671 0.004752811 Complies 12.89 19.4536 0.004874731 Complies 12.96 19.7697 0.004953941 Complies EUT： Home Gateway Model Name ： HG630 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-20M MODE /CH01, CH06, CH11 – ANT0+ ANT 1 Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 15.83 38.2825 0.009592911 Complies 15.92 39.0841 0.009793781 Complies 15.97 39.5367 0.009907191 Complies EUT： Home Gateway Model Name ： HG630 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-40M MODE /CH03, CH06, CH09 - ANT 0 Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 12.87 19.3642 0.004852331 Complies 12.91 19.5434 0.004897231 Complies 12.94 19.6789 0.004931171 Complies Neutron Engineering Inc. EUT： Home Gateway Model Name ： HG630 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-40M MODE /CH03, CH06, CH09 - ANT 1 Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 12.82 19.1426 0.004796791 Complies 12.89 19.4536 0.004874731 Complies 12.96 19.7697 0.004953941 Complies EUT： Home Gateway Model Name ： HG630 Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-40M MODE /CH03, CH06, CH09 - ANT 1+ANT 2 Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 15.86 38.5478 0.009659401 Complies 15.91 38.9942 0.009771261 Complies 15.96 39.4457 0.009884401 Complies

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1305C036 Page 1 of 155 FCC Radio Test Report FCC ID: QISHG630-52 This report concerns (check one): Original Grant Class II Change Issued Date : May. 20, 2013 Project No. : 1305C036 Equipment : Home Gateway Model Name : HG630; HG630-52 Applicant : Huawei Technologies Co., Ltd. Address : Bantian, Longgang District, Shenzhen China Manufacturer : Huawei Technologies Co., Ltd. Address : Administration Building, Huawei Base, Bantian, Longgang District ,Shenzhen 518129, P.R. China Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: May. 07, 2013 Date of Test: May. 07, 2013 ~ May. 17, 2013 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory: (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1305C036 Page 2 of 155 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1305C036 Page 3 of 155 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 21 4.2.1 RADIATED EMISSION LIMITS 21 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 22 4.2.3 TEST PROCEDURE 23 4.2.4 DEVIATION FROM TEST STANDARD 23 4.2.5 TEST SETUP 24 4.2.6 EUT OPERATING CONDITIONS 25 4.2.7 TEST RESULTS (9K~ 30MHZ) 26 4.2.8 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 27 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 40 5 . BANDWIDTH TEST 88 5.1 APPLIED PROCEDURES / LIMIT 88 5.1.1 MEASUREMENT INSTRUMENTS LIST 88 5.1.2 TEST PROCEDURE 88 5.1.3 DEVIATION FROM STANDARD 88 5.1.4 TEST SETUP 88 5.1.5 EUT OPERATION CONDITIONS 88 5.1.6 TEST RESULTS 89 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1305C036 Page 4 of 155 Table of Contents Page 6 . MAXIMUM OUTPUT POWER TEST 101 6.1 APPLIED PROCEDURES / LIMIT 101 6.1.1 MEASUREMENT INSTRUMENTS LIST 101 6.1.2 TEST PROCEDURE 101 6.1.3 DEVIATION FROM STANDARD 101 6.1.4 TEST SETUP 101 6.1.5 EUT OPERATION CONDITIONS 101 6.1.6 TEST RESULTS 102 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 105 7.1 APPLIED PROCEDURES / LIMIT 105 7.1.1 MEASUREMENT INSTRUMENTS LIST 105 7.1.2 TEST PROCEDURE 105 7.1.3 DEVIATION FROM STANDARD 105 7.1.4 TEST SETUP 105 7.1.5 EUT OPERATION CONDITIONS 105 7.1.6 TEST RESULTS 106 8 . POWER SPECTRAL DENSITY TEST 136 8.1 APPLIED PROCEDURES / LIMIT 136 8.1.1 MEASUREMENT INSTRUMENTS LIST 136 8.1.2 TEST PROCEDURE 136 8.1.3 DEVIATION FROM STANDARD 136 8.1.4 TEST SETUP 136 8.1.5 EUT OPERATION CONDITIONS 136 8.1.6 TEST RESULTS 137 9 . EUT TEST PHOTO 151 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1305C036 Page 5 of 155 1. CERTIFICATION Equipment : Home Gateway Brand Name : HUAWEI Model Name : HG630; HG630-52 Applicant : HUAWEI Technologies Co., Ltd. Factory : Huawei Technologies Co., Ltd. Address : Huawei Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Date of Test : May. 07, 2013 ~ May. 17, 2013 Test Item : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1305C036) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1305C036 Page 6 of 155 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious Emission PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(b)(3) Peak Output Power PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS 15.…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1305C036 Page 151 of 155 9. EUT TEST PHOTO Conducted Measurement Photos Adapter: XQ Neutron Engineering Inc. Report No.: NEI-FCCP-1-1305C036 Page 152 of 155 Conducted Measurement Photos Adapter: HK Neutron Engineering Inc. Report No.: NEI-FCCP-1-1305C036 Page 153 of 155 Radiated Measurement Photos 9K~30MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1305C036 Page 154 of 155 Radiated Measurement Photos 30~1000MHz Neutron Engineering Inc. Report No.: NEI-FCCP-1-1305C036 Page 155 of 155 Radiated Measurement Photos Above 1000MHz
