QISHG655BHome Gateway

HUAWEI HG655b Home Gateway User Guide HUAWEI TECHNOLOGIES CO., LTD. HUAWEI HG655b Home Gateway V100R001 User Guide Issue 01 Date 2010-02-03 Part Number 202207 Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. For any assistance, please contact our local office or company headquarters. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China Website: http://www.huawei.com Email: [email protected] Copyright © Huawei Technologies Co., Ltd. 2010. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses. Trademarks and Permissions , , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Other trademarks, product, service and company names mentioned are the property of their respective owners. Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. Notice Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. NO WARRANTY THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS. Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein. HUAWEI HG655b Home Gateway User Guide Contents Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. i Contents 1 Warnings and Precautions .................................................................................. 1-1 2 Product Overview ................................................................................................ 2-1 2.1 Network Application ................................................................................................... 2-1 2.2 Indicators, Interfaces and Buttons ............................................................................... 2-2 2.2.1 Indicators.........................................................................................................2-2 2.2.2 Interfaces and Buttons..................................................................................... 2-4 3 Product Installation and Getting Started ......................................................... 3-1 3.1 Connecting the Cables................................................................................................. 3-1 3.2 Getting Started ............................................................................................................3-2 4 Configuring the HG655b ..................................................................................... 4-1 4.1 Accessing the Web Configuration Page ...................................................................... 4-1 4.2 Changing the Administrator Password ........................................................................ 4-1 4.3 Changing the IP Address ............................................................................................. 4-2 4.4 Restoring Default Settings........................................................................................... 4-2 5 Setting the Network-Access Parameters........................................................... 5-1 5.1 Accessing the Network by the Embedded PPP Dial-Up Software on the HG655b ..... 5-1 5.2 Accessing the Network by the PPP Dial-Up Software on Your Computer ................. 5-2 6 Configuring the wireless network..................................................................... 6-1 6.1 Configuring the Wireless Connection by the Web Page.............................................. 6-1 6.2 Configuring the Wireless Connection by the button.................................................... 6-2 7 Configuring the Voice Services ......................................................................... 7-1 7.1 Introduction ................................................................................................................. 7-1 7.2 Configuration Procedure ............................................................................................. 7-1 8 FAQs........................................................................................................................ 8-1 8.1 How can I configure a computer to use a …

Text truncated - open the document above for the full version.

Huawei Technologies Co.,Ltd. Administration Building, Huawei Base, Bantian, Longgang District, Shenzhen 518129 P.R.C. FCC ID: QISHG655B Data: November 12, 2010 We, Huawei Technologies Co.,Ltd. doesn’t provide any controls or software to allow the operation outside of the USA frequency band when we sell this product in USA. Sincerely, Signature: Name/Title: Zhang Xinghai/EMC Manager Company Name: Huawei Technologies Co.,Ltd. Address: Administration Building, Huawei Base, Bantian, Longgang District, Shenzhen 518129 P.R.C. TEL: +86-755-28781879 FAX: +86-755-28781889 Email: [email protected]

Huawei Technologies Co.,Ltd. Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. Attestation for FCC Declaration of Conformity FCC ID: QISHG655B Data: November 12, 2010 Please be notified that we, the undersigned, Huawei Technologies Co.,Ltd declare that the product which bears the above FCC ID is also compliant with the FCC requirements for DoC. The test report number supporting the DoC is 10B07004F. Testing in regards to this report was done by Interocean EMC Technology Corp. located atNo.5-2, Lin 1, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei County 244, Taiwan, R.O.C.., which has been accredited in accordance to all of the requirements of 47CFR 2.948(d) and (e) of the FCC rules and KDB349827 Sincerely, Signature: Name/Title: Zhang Xinghai/EMC Manager Company Name: Huawei Technologies Co.,Ltd. Address: Administration Building,Huawei Base,Bantian,Longgang District, Shenzhen 518129 P.R.C. TEL: +86-755-28781879 FAX: +86-755-28781889 Email: [email protected]

Huawei Technologies Co.,Ltd. Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. AGENCY AUTHORIZATION LETTER FCC ID: QISHG655B Date: November 12, 2010 To whom it may concern: We, the undersigned, hereby authorize Shenzhen Huatongwei International Co.,Ltd of China to act on our behalf, as our agent in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification, Any act carried out by Shenzhen Huatongwei International Co.,Ltd. within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely, Signature: Name/Title: Zhang Xinghai/EMC Manager Company Name: Huawei Technologies Co.,Ltd. Address: Administration Building, Huawei Base, Bantian, Longgang District, Shenzhen 518129 P.R.C. TEL: +86-755-28781879 FAX: +86-755-28781889 Email: [email protected]

Huawei Technologies Co.,Ltd. Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: QISHG655B Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematic Theory of Operation Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, We do not want these documents to be accessible to the general public. Sincerely, Signature: Name/Title: Zhang Xinghai/EMC Manager Company Name: Huawei Technologies Co.,Ltd. Address: Administration Building,Huawei Base,Bantian,Longgang District, Shenzhen 518129 P.R.C. TEL: +86-755-28781879 FAX: +86-755-28781889 Email: [email protected]

External Photos of the EUT

D K B A 8 8 0 7 1 9 5 4 . C D R 4*4 7S 3 8 . 6 90.0 FCC ID:QISHG655B US:HAUXXXXXHG655B This Product Complies With 47CFR PART 68 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos of the EUT

MPE TEST REPORT FCC Part 2.1091(b) Report Reference No......................: FCC ID............................................. : WE10100020 QISHG655B Compiled by ( position+printed name+signature)..: File administrators Wenliang Li Supervised by ( position+printed name+signature)..: Test Engineer Eric Zhang Approved by ( position+printed name+signature)..: Manager Jimmy Li Date of issue.....................................: Dec 14,2010 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: Huawei Technology Co.,Ltd Address ............................................: Administration Building, Huawei Base, Bantian, Longgang District, Shenzhen 518129 P.R.C Test specification: Standard ...........................................: FCC Part 2.1091(b) TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Home Gateway Trade Mark .......................................: Manufacturer ....................................: Huawei Technologies Co.,Ltd. Model/Type reference.......................: HUAWEI HG655b Listed Models ..................................: / Ratings .............................................: DC 12V Adapter From AC 120V/60Hz Frequency Range From 2412 MHz to 2462 MHz Result................................................: Positive V1.0 Page 2 of 7 Report No.: WE10100020 FCC ID: QISHG655B Shenzhen Huatongwei International Inspection Co., Ltd MPE T E S T R E P O R T Test Report No. : WE10100020 Dec 14,2010 ______________________________________________________________________________________________ Date of issue Equipment under Test : Home Gateway Model /Type : HG655b Listed Models : / Applicant : Huawei Technology Co.,Ltd Address : Administration Building, Huawei Base, Bantian, Longgang District, Shenzhen 518129 P.R.C Manufacturer Huawei Technology Co.,Ltd Address : Administration Building, Huawei Base, Bantian, Longgang District, Shenzhen 518129 P.R.C The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 7 Report No.: WE10100020 FCC ID: QISHG655B Shenzhen Huatongwei International Inspection Co., Ltd Contents 1. SUMMARY............................................................................. 4 1.1. EUT configuration 4 1.2. NOTE 4 2. TEST ENVIRONMENT............................................................... 5 2.1. Address of the test laboratory 5 2.2. Environmental conditions 5 2.3. Statement of the measurement uncertainty 5 3. METHOD OF MEASUREMENT .................................................... 5 3.1. Applicable Standard 5 3.2. Limit 6 3.3. MPE Calculation Method 6 4. CONCLUSION ........................................................................ 7 V1.0 Page 4 of 7 Report No.: WE10100020 FCC ID: QISHG655B Shenzhen Huatongwei International Inspection Co., Ltd 1. SUMMARY 1.1. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - supplied by the manufacturer ○ - supplied by the lab ○ Power Cable Length (m) : / Shield : / Detachable : / ○ Multimeter Manufacturer : / Model No. : / ● AC Adapter MODEL: FM120015-MX INPUT: 100-240V～50/60Hz 0.6A OUTPUT: 12.0V 1.5A Power Cable: 150cm ◇ Shield ◆ Unshield 1.2. NOTE 1. The EUT is an 802.11b/g/n Home Gateway, The functions of the EUT listed as below: Test Standards Reference Report WLAN 802.11b/g, 802.11n FCC Part 15 Subpart C (Section15.247) WE10100019 WLAN 802.11b/g, 802.11n FCC Part 2.1091(b) WE10100020 2. The frequency bands used in this EUT are listed as follows: Frequency Band(MHz) 2400-2483.5 5150-5350 5470-5725 5725-5850 802.11b √ － － － 802.11g √ － － － 802.11n(20MHz) √ － － － 802.11n(40MHz) √ － － － 3. The EUT incorporates a MIMO function, Physically, the EUT provides two completed transmitter and two completed receivers. Modulation Mode TX Function 802.11b 1TX 802.11g 1TX 802.11n (20MHz) 2TX 802.11n (40MHz) 2TX V1.0 Page 5 of 7 Report No.: WE10100020 FCC ID: QISHG655B Shenzhen Huatongwei International Inspection Co., Ltd 2. TEST ENVIRONMENT 2.1. Address of the test laboratory Shenzhen Huatongwei International Inspection Co., Ltd Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Phone: 86-755-26715686 Fax: 86-755-26748089 The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 (2009) and CISPR Publication 22. 2.2. Environmental conditions During the measurement the environmental conditions were within the listed ranges: Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressure: 950-1050mbar 2.3. Statement of the measurement uncertainty The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities. The measurement uncertainty was calculated for all measurements listed in this test report acc. to CISPR 16 - 4 „Specification for radio disturbance and immunity measuring apparatus and methods – Part 4: Uncertainty in EMC Measurements“ and is documented in the Shenzhen Huatongwei International Inspection Co., Ltd quality system…

Text truncated - open the document above for the full version.

FCC ID: QISHG655B Shenzhen Huatongwei International Inspection Co., Ltd FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No......................: FCC ID............................................. : WE10100019 QISHG655B Compiled by ( position+printed name+signature)..: File administrators Wenliang Li Supervised by ( position+printed name+signature)..: Test Engineer Eric Zhang Approved by ( position+printed name+signature)..: Manager Jimmy Li Date of issue.....................................: Dec 14,2010 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: Huawei Technologies Co.,Ltd. Address ............................................: Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. Test specification: Standard ...........................................: FCC Part 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz Direct Sequence System TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Home Gateway Trade Mark .......................................: Model/Type reference.......................: HUAWEI HG655b Frequency Range .............................: From 2412 MHz to 2462 MHz Listed Models ..................................: / Result................................................: Positive V1.0 Page 2 of 113 Report No.: WE10100019 FCC ID: QISHG655B Shenzhen Huatongwei International Inspection Co., Ltd T E S T R E P O R T Test Report No. : WE10100019 Dec 14,2010 ______________________________________________________________________________________________ Date of issue Equipment under Test : Home Gateway Model /Type : HUAWEI HG655b Listed Models : / Applicant : Huawei Technologies Co.,Ltd. Address : Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. Manufacturer Huawei Technologies Co.,Ltd. Address : Administration Building,Huawei Base,Bantian,Longgang District,Shenzhen 518129 P.R.C. Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 113 Report No.: WE10100019 FCC ID: QISHG655B Shenzhen Huatongwei International Inspection Co., Ltd Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. EUT configuration 6 2.6. Related Submittal(s) / Grant (s) 6 2.7. Modifications 6 2.8. NOTE 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Test Description 9 3.6. Statement of the measurement uncertainty 10 3.7. Equipments Used during the Test 10 4. TEST CONDITIONS AND RESULTS ............................................ 12 4.1. AC Power Conducted Emission 12 4.2. Radiated Emission 15 4.3. Maximum Peak Output Power 31 4.4. Power Spectral Density 35 4.5. Band Edge Compliance of RF Emission 49 4.6. Spurious RF Conducted Emission 52 4.7. 6dB Bandwidth 52 4.8. Antenna Requirement 52 5. TEST SETUP PHOTOS OF THE EUT .......................................... 52 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 52 V1.0 Page 4 of 113 Report No.: WE10100019 FCC ID: QISHG655B Shenzhen Huatongwei International Inspection Co., Ltd 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2009 : American National Standard for Testing Unlicensed Wireless Devices. V1.0 Page 5 of 113 Report No.: WE10100019 FCC ID: QISHG655B Shenzhen Huatongwei International Inspection Co., Ltd 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Oct 27, 2010 Testing commenced on : Oct 28, 2010 Testing concluded on : Dec 14,2010 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 12V Adapter from AC 120V/60Hz Description of the test mode IEEE 802.11b/g/n: The EUT provided eleven channels used for USA. Channel Frequency(MHz) Channel Frequency(MHz) 1 2412 8 2447 2 2417 9 2452 3 2422 10 2457 4 2427 11 2462 5 2432 6 2437 7 2442 2.3. Short description of the Equipment under Test (EUT) The EUT (HUAWEI HG655b) is a 2.4G wireless home gateway. For more details, refer to the user’s manual of the EUT. Serial number: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition. The Applicant provides AT command to control the EUT for staying in continous transmitting and receiving mode for testing. V1.0 Page 6 of 113 Report No.: WE10100019 FCC ID: QISHG655B Shenzhen Huatongw…

Text truncated - open the document above for the full version.

Test Setup Photos of the EUT
