QISHG658HOME GATEWAY

1 HG658 Home Gateway Quick Start 1 Connecting Cables 1 Telephone wall jack 2 Power adapter 3 Splitter 4 HG658 5 Telephone 6 Set-top box 7 Laptop computer 8 Desktop computer a LINE port b MODEM port c PHONE port 2 Powering On the HG658 Press the On/Off button on the side panel to power on the HG658. After you power on the HG658, the WAN indicator light blinks (for less than three minutes), indicating that the HG658 is being activated. Once activated, the WAN indicator light stops blinking and remains steady on. The Power indicator light also remains steady on, indicating that the HG658 is working properly. 2 3 Accessing the Internet To set up network access for the HG658 and your computer: Step 1 Open a web browser on your computer. Enter http://192.168.1.1 in the address box, and then press Enter. Step 2 On the login page, enter the user name (user by default) and password (HuaweiUser by default). Step 3 Click Login. After the system verifies your account, the web-based configuration utility is displayed. The first time you log in to the web-based configuration utility, a setup wizard is displayed. To skip the wizard and go immediately to the HG658 configuration page, click Advance. Step 4 In the displayed setup wizard, click Next. If you have configured the HG658 before and you log in to the web-based configuration utility, the setup wizard page will not be displayed. However, you can still click Setup Wizard in the upper right corner to display the setup wizard page. Step 5 Set WAN device based on your network type, and then enter the user name and password that are provided by your Internet Service Provider (ISP) in the User name and Password text boxes. Step 6 Click Next. Step 7 Set SSID and WPA pre-shared key, and then click Next. Check the label on the HG658's rear panel for SSID and WPA pre-shared key. Step 8 Click Submit. After you complete the preceding settings, you can start surfing the Internet. You need to perform the preceding operations on a computer only once. The next time you power on your computer, you can start surfing the Internet without any further configurations. 3 4 Setting Up a Wireless Connection The following example uses a computer running the Windows 7 operating system to describe how to set up a wireless connection: Step 1 Start the wireless configuration service of the Windows 7 operating system as follows: 1. Click Start, enter services.msc in the search box, and then press Enter. 2. In the Services window, right-click WLAN AutoConfig to display a shortcut menu, and then choose Properties. 3. Check that Service status is Started. If Service status is not Started, click Start. 4. Click OK to close the dialog box. Then close the Services window. Step 2 Find WLAN Name and WLAN Key printed on the label of the HG658's rear panel. Step 3 Configure the wireless network connection on the computer as follows: 1. Choose Start > Control Panel > Network and Sharing Center > Change adapter settings. 2. In the Network Connections window, right-click the wireless network you created to display a shortcut menu, and then choose Connect/Disconnect. 3. In the Wireless Network Connection dialog box, select the wireless network whose name is the same as the one you recorded in Step 2, and then click Connect. 4. n the Connect to Network dialog box, enter WLAN Key that you recorded in Step 2, and then click OK. After the system verifies the password, Connected appears on the wireless network icon in the wireless network list, indicating that your computer has established a wireless connection to the HG658. For more information, visit http://www.huaweidevice.com to download the HG658 user guide. Enter HG658 in the search box to find the user guide. 4 5 Warnings and Precautions To use the device properly and safely, read these warnings and precautions carefully and strictly observe them during operation. Unless otherwise specified, the term "device" refers to the device and its accessories. Basic Requirements  During storage, transportation, and operation of the device, keep it dry and prevent it from colliding with other objects.  Do not dismantle the device. In case of any fault, contact an authorized service center for assistance or repair.  Without authorization, no organization or individual can change the mechanical, safety, or performance design of the device.  When using the device, observe all applicable laws and regulations and respect the legal rights of other people. Environmental Requirements for Using the Device  Before connecting and disconnecting cables, stop using the device, and then disconnect it from the power supply. Ensure that your hands are dry during operation.  Keep the device far from sources of heat and fire, such as a heater or a candle.  Keep the device far from electronic appliances that generate strong magnetic or electric fields, such as a microwave oven or a refrigerator.  Place the device on a stable surface.  Place the device in a cool and well-ventilated indoor area. Do not expose the device to direct sunlight.  Use the device in an area with a temperature ranging from 0°C to 40°C.  Do not block the openings on the device with any object. Reserve a minimum space of 10 cm around the device for heat dissipation.  Do not place any object (such as a candle or a water container) on the device. If any foreign object or liquid enters the device, stop using the device immediately, power it off, remove all the cables connected to it, and then contact an authorized service center.  During thunderstorms, power off the device, and then remove all the cables connected to it to prevent it from getting damaged due to lightning strikes. Precautions for Using Wireless Devices  When using the device, ensure that the antenna of the device is at least 20 cm away from all persons.  Do not use the device where using wireless devices is prohibited or may cause interference or danger.  The radio waves generated by the device may interfere with the ope…

Text truncated - open the document above for the full version.

Huawei Technologies Co.,Ltd Declaration of Authorization We Name: Huawei Technologies Co.,Ltd Address: Bantian, Longgang District , Shenzhen, China Declare that: Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification of the following product(s): Product description: HomeGateway Type designation: HG658 Trademark: HUAWEI on our behalf. Date: 2011-11-14 City: Shenzhen Name: Zhang Xinghai Function: EMC Laboratory Manager Signature:

CERTIFICATE OF COMPLIANCE Ref No.: NEI-FCCE-1-1211C017 Date of Issue: Nov. 15, 2012 Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the Neutron EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment Home Gateway Model Name HG658 Brand Name HUAWEI Applicant Huawei Technologies Co., Ltd. Address Bantian, Longgang District, Shenzhen China Measurement ANSI C63.4 (2009) Method The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCE-1-1211C017) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory Neutron Engineering Inc. B1, No.37, Lane 365, Yang Guang St., NeiHu District 114., Taipei, Taiwan TEL：+886-2-2657-3299 FAX：+886-2-2657-3331

Neutron Engineering Inc. Project No.: 1211C017 Page 2 of 16 1211C017 1211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 3 of 16 1211C017 1211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 4 of 16 1211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 5 of 16 1211C017 1211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 6 of 16 1211C017 1211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 7 of 16 1211C017 1211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 8 of 16 1211C017 1211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 9 of 16 1211C017 1211C017

6.4 mm8.7 mm 7.3 mm 示意图 zhangjunjie houzhiming xiahonghua guoda 2012-11-19 2012-11-19 2012-11-19 2012-11-19 DKBA8.807.6476 A DKBA 8.807.6476 51655004 FCC ID:QISHG658 US:HAUDL01BHG658 This Product Complies With 47CFR PART 68. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation. FCC ID:QISHG658 US:HAUDL01BHG658 This Product Complies With 47CFR PART 68. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation. HAUDL01BHG658

Neutron Engineering Inc. Project No.: 1211C017 Page 10 of 16 1211C017 1211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 11 of 16 1211C017 1211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 12 of 16 1211C017 1211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 13 of 16 Common Mode Choke: MingPu 1211C017 1211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 14 of 16 Common Mode Choke: HaiGuang 1211C017 1211C0171211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 15 of 16 1211C017 1211C017 Neutron Engineering Inc. Project No.: 1211C017 Page 16 of 16 1211C017 1211C017

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1211C017 Page 1 of 160 FCC Radio Test Report FCC ID: QISHG658 This report concerns (check one) : Original Grant Class II Change Issued Date : Nov. 15, 2012 Project No. : 1211C017 Equipment : Home Gateway Model Name : HG658 Applicant : Huawei Technologies Co., Ltd. Address : Bantian, Longgang District, Shenzhen China Manufacturer : Huawei Technologies Co., Ltd. Address : Administration Building, Huawei Base, Bantian, Longgang District , Shenzhen 518129, P.R. China Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Nov. 01, 2012 Date of Test: Nov. 01, 2012 ~ Nov. 14, 2012 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1211C017 Page 2 of 160 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1211C017 Page 3 of 160 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 15 4.1.3 TEST PROCEDURE 16 4.1.4 DEVIATION FROM TEST STANDARD 16 4.1.5 TEST SETUP 16 4.1.6 EUT OPERATING CONDITIONS 16 4.1.7 TEST RESULTS 17 4.2 RADIATED EMISSION MEASUREMENT 25 4.2.1 RADIATED EMISSION LIMITS 25 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 26 4.2.3 TEST PROCEDURE 27 4.2.4 DEVIATION FROM TEST STANDARD 27 4.2.5 TEST SETUP 28 4.2.6 EUT OPERATING CONDITIONS 29 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 34 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 46 5 . BANDWIDTH TEST 94 5.1 APPLIED PROCEDURES / LIMIT 94 5.1.1 MEASUREMENT INSTRUMENTS LIST 94 5.1.2 TEST PROCEDURE 94 5.1.3 DEVIATION FROM STANDARD 94 5.1.4 TEST SETUP 94 5.1.5 EUT OPERATION CONDITIONS 94 5.1.6 TEST RESULTS 95 6 . MAXIMUM OUTPUT POWER TEST 107 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1211C017 Page 4 of 160 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 107 6.1.1 MEASUREMENT INSTRUMENTS LIST 107 6.1.2 TEST PROCEDURE 107 6.1.3 DEVIATION FROM STANDARD 107 6.1.4 TEST SETUP 107 6.1.5 EUT OPERATION CONDITIONS 107 6.1.6 TEST RESULTS 108 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 111 7.1 APPLIED PROCEDURES / LIMIT 111 7.1.1 MEASUREMENT INSTRUMENTS LIST 111 7.1.2 TEST PROCEDURE 111 7.1.3 DEVIATION FROM STANDARD 111 7.1.4 TEST SETUP 111 7.1.5 EUT OPERATION CONDITIONS 111 7.1.6 TEST RESULTS 112 8 . POWER SPECTRAL DENSITY TEST 142 8.1 APPLIED PROCEDURES / LIMIT 142 8.1.1 MEASUREMENT INSTRUMENTS LIST 142 8.1.2 TEST PROCEDURE 142 8.1.3 DEVIATION FROM STANDARD 142 8.1.4 TEST SETUP 142 8.1.5 EUT OPERATION CONDITIONS 142 8.1.6 TEST RESULTS 143 9 . EUT TEST PHOTO 157 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1211C017 Page 5 of 160 1. CERTIFICATION Equipment : Home Gateway Brand Name : HUAWEI Model Name : HG658 Applicant : Huawei Technologies Co., Ltd. Date of Test : Nov. 01, 2012 ~ Nov. 14, 2012 Test Item : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1211C017) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1211C017 Page 6 of 160 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious EmissionPASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(b)(3) Peak Output Power PASS 15.209/15.205 Radiated Spurious Emission PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this test report (2) The test follows FCC KDB Publication No,558074(Mea…
