QISMG323Wireless Module

Copyright © 2010 Huawei Technologies Co., Ltd. All Rights Reserved No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. Trademarks and Permissions and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd. All other trademarks and trade names mentioned in this document are the property of their respective holders. Notice The information in this document is subject to change without notice. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute the warranty of any kind, express or implied. i Table of Contents Getting to Know the MG323..................................................................... 1 Installing and Using an MG323 Module...................................................... 2 Removing an MG323 Module from a Development Board.............................. 4 Safety Information...........................................................错误！未定义书签。 1 Thank you for purchasing Huawei MG323 Wireless Module. Note: „ This manual briefly describes the preparation, the process for installing/uninstalling, and safety precautions for using Huawei MG323 Wireless Module (hereinafter referred to as the MG323). „ You are recommended to read the manual before using the MG323. „ The signal strength and the transmission rate are affected by the actual environment. Getting to Know the MG323 The following figure shows the appearance of the MG323. The actual product may differ. 1 2 2 3 2 n Antenna interface It is used to connect and fix an antenna. „ The antenna gain：850M<4.28dBi，1900M<3.0dBi o Fixing hole A screw, metal fastener, and nut are used to fix an MG323 module on a development board through this fixing hole. p Board-to-board (B2B) connector (male) It is connected to the B2B connector (female) on the development board. Installing and Using an MG323 Module 1. Connect an antenna connector to the antenna interface of an MG323. 3 Connect the antenna connector vertically to the antenna interface of the MG323. Ensure that the antenna is placed normally. 2. Fasten the male B2B connector on the MG323 module with the female B2B connector of a development board to fix the MG323 module on the development board. 3. Place a metal fastener between the MG323 module and the development board, and put a screw through the fixing hole of the MG323, metal fastener, and fixing hole of the development board in turn. After putting the screw through the fixing hole of the development board, fasten a nut on the screw. 4. Insert a SIM card into the SIM card slot. 5. Use a serial cable to connect a PC with the MG323 module through the RS-232 serial port for software communication. 4 6. To use the MG323 module normally, put jumper caps on the right two pins of the three pins within the red box shown in the following figure to form a short circuit. 7. Connect a handset to the handset interface for testing voice-related functions. 8. Connect an external 5 V power adapter to the MG323 module through the power interface. 9. Turn the switch towards the power interface to supply power to the MG323 module. If you turn the power switch towards the USB interface, the MG323 can charge external batteries. 10. After you press and hold the power button for about one second, the MG323 module is powered on. To power off the module, press and hold this button for two seconds. 11. After you press and hold the reset button for about one second, the MG323 module is reset. Removing an MG323 Module from a Development Board 1. Perform the following steps to remove the peripheral: 1) If the MG323 module is powered on, press and hold the power button for two seconds to power off the module. Then remove the external 5 V power adapter. 2) Remove the serial cable. 3) Remove the SIM card from the SIM card slot. 5 2. Remove the screw on the MG323 module. 3. Remove the MG323 module from the development board. 4. Remove the antenna from the MG323 module. 6 Safety Information Read the safety information carefully to ensure the correct and safe use of your wireless device. Interference Do not use your wireless device if using the device is prohibited or when it causes danger or interference with electric devices. Medical Device „ Do not use your wireless device and follow the rules and regulations set forth by the hospitals and health care facilities. „ Some wireless devices may affect the performance of the hearing aids. For any such problems, consult your service provider. „ If you are using an electronic medical device, consult the doctor or device manufacturer to confirm whether the radio wave affects the operation of this device. Area with Inflammables and Explosives To prevent explosions and fires in areas that are stored with inflammable and explosive devices, do not use your wireless device and observe the rules. Areas stored with inflammables and explosives include but are not limited to the following: „ Gas station „ Fuel depot (such as the bunk below the deck of a ship) „ Container/Vehicle for storing or transporting fuels or chemical products 7 „ Area where the air contains chemical substances and particles (such as granule, dust, or metal powder) „ Area indicated with the "Explosives" sign „ Area indicated with the "Power off bi-direction wireless equipment" sign „ Area where you are generally suggested to stop the engine of a vehicle Traffic Security „ Observe local laws and regulations while using the wireless device. To prevent accidents, do not use your wireless device while driving. „ RF signals may affect electronic systems of motor vehicles. For more information, consult the vehicle manufacturer. „ In a motor vehicle, do not place the wireless device over the air bag or in the air bag deployment area. Otherwise, the wireless device may hurt you owing to the strong force when the air ba…

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: CETECOM Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISMG323 to be kept confidential: 1. Schematic diagram. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Tune-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

Huawei Technologies Co., Ltd. Administration Building, Huawei Base, Bantian, Longgang District, Shenzhen 518129 P.R.C. +86 755 28780808 www.huawei.com Huawei internal reference RCT-US-01-01 USA FCC Short Term Confidentiality Request template Effective date: 2007-01-06 Version 1.1 Short Term Confidentiality Request 2010-06-03 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality Request for FCC ID: QISMG323 Product Name: Wireless Module Product Model: MG323 To whom maybe concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, Huawei Technologies Co., Ltd requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 90 days: 1. External Photos 2. Internal Photos 3. Test Setup Photos 4. Users Manual The applicant also acknowledges that they will also provide appropriate notice to CETECOM should either of the following occur: A) If the applicant requires additional 45 day extension periods they will notify CETECOM with a new request letter at least 7 days prior to the short-term confidentiality expiration date-[Note: up to maximum of 3 extensions only are allowed], or b) Immediately notify CETECOM in the event the information regarding the product of the product is made available to the public. CETECOM will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely,

MG323 SECRET Page1,Total 4 External Photos of MG323 MG323 SECRET Page2,Total 4 MG323 SECRET Page3,Total 4 MG323 SECRET Page4,Total 4

MG323 SECRET Page1, Total 1 ID Label Location MG323

MG323 SECRET Page1,Total 2 Internal Photos of MG323 MG323 SECRET Page2,Total 2

MG323 Electromagnetic Radiation Exposure Estimation 1 Maximum Permissible Exposure (MPE) Estimation for MG323 1 Introduction MG323 GSM/GPRS M2M Module is subscriber equipment in the GSM/GPRS system.The GSM/GPRS frequency bands include EGSM850 and PCS1900. MG323 implement such functions as RF signal receiving / transmitting, GPRS/GSM protocol processing, data service etc. Externally they provide 50pin B2B interface. 2 Limits and Guidelines on Exposure to Electromagnetic Fields According to the FCC Part 2.1091( which reference the part1.1310), we know: mobile device (transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitters radiating structure(s) and the body of the user or nearby persons). And the Cellular radiotelephone service and PCS services are subject to routine environmental evaluation for RF exposure prior to equipment authorization or use if they operate at frequencies of 1.5 GHz or below and their effective radiated power (ERP) is 1.5 watts or more, or if they operate at frequencies above 1.5 GHz and their ERP is 3 watts or more. Uncontrolled limits are used for general public. General population/uncontrolled exposure apply in situations is which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. The exposure levels can be expressed in terms of power density, electric field strength, or magnetic field strength, as averaged over 30 minutes for the general public and 6 minutes for trained personnel. The exposure criterion is frequency dependent, and a chart covering the range from 3 kHz to 100 GHz can be found in NCRP No.86 (references IEEE C95.1-1999). Below are the limits. Limits for Occupational/Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) 0.3-3.0 3.0-30 30-300 300-1500 15,00-100,000 614 1842/f 61.4 -- -- 16.3/f 16.3/f 0.163 -- -- (100)* (900/f 2 )* 1.0 f/300 5 MG323 Electromagnetic Radiation Exposure Estimation 2 Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) 0.3-1.34 1.34-30.0 30-300 300-1500 15,00-100,000 614 824/f 27.5 -- -- 1.63 2.19/f 0.073 -- -- (100)* (180/f 2 )* 0.2 f/1500 1 Power density S [mW/cm2] for controlled area at 850 MHz ，(TX: 824MHz – 849MHz) 75.2 300 824 300 )( === MHzf S mW/cm 2 Power density S [mW/cm2] for uncontrolled area at 824 MHz 55.0 1500 824 1500 )( === MHzf S mW/cm 2 Power density S [mW/cm2] for uncontrolled area at 1900 MHz S=1 mW/cm 2 Reference levels are provided for exposure assessment to determine whether the basic restrictions on exposure of humans to electromagnetic fields are exceeded. The basic restrictions on exposure to electromagnetic fields are based directly on established health effects and biological considerations. 3 Location of EUT The source of the radiation is mounted on terminal; generally the direction of the antenna position is uprightness tabletop. The highest level of emission would be expected in close vicinity of the antenna and in line of sight to the antenna. 4 Prediction of the Exposure to Electromagnetic Fields Calculations can be made on a site by site basis to ensure the power density is below the limits given above, or guidelines can be done beforehand to ensure the minimum distances from the antenna is maintained through the site planning. The calculations are based on FCC OET 65 Appendix B. MG323 Electromagnetic Radiation Exposure Estimation 3 4.1 Calculation of the Safe Distance Below method describes a theoretical approach to calculate possible exposure to electromagnetic radiation around a base station transceiver antenna. Precise statements are basically only possible either with measurements or complex calculations considering the complexity of the environment (e.g. soil conditions, near buildings and other obstacles) which causes reflections, scattering of electromagnetic fields. The maximum output power (given in EIRP) of a base station is usually limited by license conditions of the network operator. A rough estimation of the expected exposure in power flux density on a given point can be made with the following equation. The calculations are based on FCC OET 65 Appendix B. π∗∗ ∗ = )(4 )( 2 mr GWP S numeric Whereas: P = Maximum output power in W of the site G numeric = Numeric gain of the antenna relative to isotropic antenna R = distance between the antenna and the point of exposure in meters 4.2 Technical Description MG323 Technical Specification: Cellular Band Power at antenna connector BTS: 31.3 dBm (GSM850) Antenna-cable attenuation: 0 dB Input power to antenna: 31.3 dBm（1.35W）(GSM850) Antenna gain: 4.28 dBi (2.68) MG323 Electromagnetic Radiation Exposure Estimation 4 PCS Band Power at antenna connector BTS: 29.87 dBm (PCS1900) Antenna-cable attenuation: 0 dB Input power to antenna: 29.87 dBm （0.97W）(PCS1900) Antenna gain: 3 dBi (2.0W) 4.3 Estimation of compliance boundary for indoor antenna 1) Cellular Band : GSM850 For the final determination of the compliance boundary the model for far-field calculation is used since this overestimates the field strength in the near-field region. Thus the calculated compliance boundary should be rather more conservative and on the safe side. For EUT the following compliance boundary is calculated: Compliance boundary For GSM 850MHz band: When r=20cm and GSM only use one timeslot, so π∗∗ ∗ = )(4*8 )( 2 timeslotone mr GWP S numeric π∗∗ = 2 timeslotone 204*8 68.2*1350 S =0.090 mW/cm 2 For GPRS, the transmitter support multi-timeslot, but the conducted ERP will decrease 2dB when add one uplink timeslot, so we can get the following conclusion: The …

Text truncated - open the document above for the full version.

Zur optimalen Anzeige dieses PDF-Portfolios sollte es in Acrobat oder Adobe Reader ab Version 9 geöffnet werden. Adobe Reader jetzt herunterladen

Zur optimalen Anzeige dieses PDF-Portfolios sollte es in Acrobat oder Adobe Reader ab Version 9 geöffnet werden. Adobe Reader jetzt herunterladen

FCC Test Report Product Name: Wireless Module Model Number: MG323 Report No: SYBHZ(R)E013052010EB-3 FCC ID: QISMG323 Reliability Laboratory of Huawei Technologies Co., Ltd. Huawei Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Tel: +86 755 28780808 Fax: +86 755 89652518 FCC Test Report of MG323 FCC ID: QISMG323 Security Level: Public Report No: SYBHZ(R)E013052010EB-3 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total29 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has obtained the accreditation of THE AMERICAN ASSOCIATION FOR LABORATORY ACCREDITATION (A2LA), and Accreditation Council Certificate Number: 2174.01. 3. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 4. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-1. 5. The laboratory also has been listed by the VCCI to perform EMC measurements. The accreditation number is R2364, C2583, and T256. 6. The test report is invalid if not marked with "exclusive stamp for the test report". 7. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 8. The test report is invalid if there is any evidence of erasure and/or falsification. 9. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 10. Normally, the test report is only responsible for the samples that have undergone the test. 11. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. FCC Test Report of MG323 FCC ID: QISMG323 Security Level: Public Report No: SYBHZ(R)E013052010EB-3 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total29 Huawei Technologies Co Ltd Huawei Industrial Base, Bantian Longgang Shenzhen 518128, P.R China Tel: +86 755 89651014 Fax: +86 755 89652518 REPORT ON FCC Test of Wireless Module M/N: MG323 Report No: SYBHZ(R)E013052010EB-3 REGULATION FCC CFR47 Part 2: Subpart J; FCC CFR47 Part 24: Subpart E; CONCLUSION Pass General Manager May.30, 2010 张 兴海 Date Name signature Technical Responsibility For Area of Testing May.30, 2010 余 辉 Date Name signature Test Lab Engineer May.30, 2010 胡 俊 Date Name signature FCC Test Report of MG323 FCC ID: QISMG323 Security Level: Public Report No: SYBHZ(R)E013052010EB-3 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total29 Contents 1 Summary................................................................................................................................................. 5 2 Product Description................................................................................................................................6 2.1 PRODUCTION INFORMATION................................................................................................................... 6 2.2 MODIFICATION INFORMATION.................................................................................................................. 6 3 Test Site Description................................................................................................................................7 3.1 TESTING PERIOD................................................................................................................................... 7 3.2 GENERAL SET UP DESCRIPTION............................................................................................................. 7 4 Product Description.................................................................................................................................. 8 4.1 TECHNICAL CHARACTERISTICS............................................................................................................... 8 4.2 EUT IDENTIFICATION LIST.................................................................................................................... 10 5 Main Test Instruments............................................................................................................................ 11 6 Transmitter Measurements..................................................................................................................... 12 6.1 EFFECTIVE ISOTROPIC RADIATED POWER OF TRANSMITTER (EIRP)........................................................ 12 6.2 CONDUCTED POWER OF TRANSMITTER................................................................................................. 15 6.3 MODULATION CHARACTERISTICS.......................................................................................................... 17 6.4 OCCUPIED BANDWIDTH........................................................................................................................ 19 6.5 BAND EDGES COMPLIANCE.................................................................................................................. 21 6.6 SPURIOUS EMISSION AT ANTENNA TERMINAL........................................................................................ 23 6.7 FREQUENCY STABILITY........................................................................................................................ 25 7 System Measurement Uncertainty.......................................................................................................... 28 8 Appendices............................................................................................................................................ 29 FCC Test Report of MG323 …

Text truncated - open the document above for the full version.

Report No: SYBHZ(R)E012052010EB-1 Confidential Information of Huawei. No Distribution without Written Permission Page1, Total25 EMC Test Report Product Name: Wireless Module Model Number: MG323 Report No: SYBHZ(R)E012052010EB-1 FCC ID: QISMG323 Reliability Laboratory of Huawei Technologies Co., Ltd. Huawei Base, Bantian, Longgang District, Shenzhen 518129, P.R. China Tel: +86 755 28780808 Fax: +86 755 89652518 FCC Test Report of MG323 FCC ID: QIS MG323 Report No: SYBHZ(R) E012052010EB-1 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total25 Notice 1 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has obtained the accreditation of THE AMERICAN ASSOCIATION FOR LABORATORY ACCREDITATION (A2LA), and Accreditation Council Certificate Number: 2174.01. 3. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 4. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-1. 5. The laboratory also has been listed by the VCCI to perform EMC measurements. The accreditation number is R2364, C2583, and T256. 6. The test report is invalid if not marked with "exclusive stamp for the test report". 7. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 8. The test report is invalid if there is any evidence of erasure and/or falsification. 9. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 10. Normally, the test report is only responsible for the samples that have undergone the test. 11. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. FCC Test Report of MG323 FCC ID: QIS MG323 Report No: SYBHZ(R) E012052010EB-1 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total25 Notice 2 Modification Information: Table 1 Modification Information 1 2 3 4 5 6 Modification Information 7 FCC Test Report of MG323 FCC ID: QIS MG323 Report No: SYBHZ(R) E012052010EB-1 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total25 REPORT ON Wireless Module M/N: MG323 REGULATION FCC CFR47 Part 15: Subpart B; FCC CFR47 Part 22:Subpart H; FCC CFR47 Part 24: Subpart E; START OF TEST May.20, 2010 END OF TEST May.30, 2010 Final Judgement: Pass Approver 2010-05-31 张兴海 Date Name Signature Operator 2010-05-31 廖小平 Date Name Signature FCC Test Report of MG323 FCC ID: QIS MG323 Report No: SYBHZ(R) E012052010EB-1 Confidential Information of Huawei. No Distribution without Written Permission Page5, Total25 REPORT BODY CONTENT 1 Status ............................................................................................................................................6 1.1 Product Information.......................................................................................................................6 1.2 Applied Standard ..........................................................................................................................6 1.3 Test Site ........................................................................................................................................7 1.4 Test environment condition...........................................................................................................7 2 Summary of Results......................................................................................................................8 3 Equipment Specification ...............................................................................................................9 3.1 General Description ......................................................................................................................9 3.2 Sub-Assembly Identity ..................................................................................................................9 4 System Configuration during EMC Test .......................................................................................9 4.1 Cables Used during Test ..............................................................................................................9 4.2 Associated Equipment Used during Test .....................................................................................9 4.3 Test Configurations and Test Mode............................................................................................10 4.4 Test conditions and test Connections.........................................................................................10 5 Electromagnetic Interference (EMI) ............................................................................................12 5.1 Radiated Disturbance 30MHz to18000MHz...............................................................................12 5.2 Conducted Disturbance 0.15 MHz to 30MHz.............................................................................13 5.3 Radiated Spurious Emissions.....................................................................................................14 6 Main Test Instruments ................................................................................................................17 7 System Measurement Uncertainty..............................................................................................18 8 Graph and Data of Emission Test...............................................................................................19 8.1 Radiated Disturbance ......................…

Text truncated - open the document above for the full version.

FCC Test Report of MG323 FCC ID: QISMG323 Security Level: secret Report No: SYBHZ(R)E012052010EB-1 Confidential Information of Huawei. No Distribution without Permission Page1, Total7 Photos of EUT FCC Test Report of MG323 FCC ID: QISMG323 Security Level: secret Report No: SYBHZ(R)E012052010EB-1 Confidential Information of Huawei. No Distribution without Permission Page2, Total7 MG323 Appearance FCC Test Report of MG323 FCC ID: QISMG323 Security Level: secret Report No: SYBHZ(R)E012052010EB-1 Confidential Information of Huawei. No Distribution without Permission Page3, Total7 Photos of Test Setup FCC Test Report of MG323 FCC ID: QISMG323 Security Level: secret Report No: SYBHZ(R)E012052010EB-1 Confidential Information of Huawei. No Distribution without Permission Page4, Total7 1 Radiated Emissions Radiated Disturbance (30MHZ-1GHZ) Radiated Disturbance (1GHZ-18GHZ) FCC Test Report of MG323 FCC ID: QISMG323 Security Level: secret Report No: SYBHZ(R)E012052010EB-1 Confidential Information of Huawei. No Distribution without Permission Page5, Total7 2 Radiated Spurious Emissions Radiated Spurious Emission (below 2GHz) Radiated Spurious Emission (2GHz to18GHz) FCC Test Report of MG323 FCC ID: QISMG323 Security Level: secret Report No: SYBHZ(R)E012052010EB-1 Confidential Information of Huawei. No Distribution without Permission Page6, Total7 Radiated Spurious Emission 18G~26.5GHz FCC Test Report of MG323 FCC ID: QISMG323 Security Level: secret Report No: SYBHZ(R)E012052010EB-1 Confidential Information of Huawei. No Distribution without Permission Page7, Total7 3 Conducted Emissions Conducted Emissions for AC Power
