QISR206Mobile WiFi

1 Thank you for purchasing the Mobile WiFi. This Mobile WiFi brings you a high speed wireless network connection. This document will help you understand your Mobile WiFi so you can start using it right away. Please read this document carefully before using your Mobile WiFi. For detailed information about the functions and configurations of the Mobile WiFi, refer to the online help on the web management page that comes with the Mobile WiFi. For detailed instructions for logging in to the web management page, refer to "Logging In to the Web Management Page". Getting to Know Your Mobile WiFi Note: The Mobile WiFi function descriptions and illustrations in this document are for your reference only. The product you have purchased may vary. Application Scenarios Wi-Fi devices (such as smartphones, tablet computers, and game consoles) or computers can all access the Internet through Mobile WiFi. The specific connection procedure depends on the operating system of the Wi-Fi device or computer. Establish a connection according to your device's specific instructions. To access the Internet through a USB port connection, install the driver according to the instructions. Scenario 1: Connecting multiple devices through Wi-Fi Scenario 2: Connecting a single device through USB Scenario 3: Connecting multiple devices through Wi-Fi and USB simultaneously Appearance No. Item 1 Signal indicator 2 Wi-Fi indicator 3 Battery indicator 4 SMS indicator 5 Power button 6 Strap hole 7 Micro USB port Note: Wi-Fi: Wireless Fidelity 6 12345 7 2 Indicator Icon Indicator Status Signal Green Strong signal Orange Weak signal Red No signal Wi-Fi Green Wi-Fi turned on Battery Green Sufficient battery Blinking greenCharging Red Low battery SMS Green New message Blinking greenInbox full If no operation is performed on the Mobile WiFi within a preset period, the Mobile WiFi enters the standby mode, in which the battery indicator ( ) blinks slowly and the other indicators are off. To turn on the other indicators, press any key. SSID and Wireless Network Encryption Key When a Wi-Fi device establishes a connection to the Mobile WiFi for the first time, you may need to enter the default Service Set Identifier (SSID) and wireless network encryption key. These are printed on the Mobile WiFi label. It is recommended that you can log in to the web management page and change your SSID and wireless network encryption key. Getting Started Installing a SIM Card and the Battery Caution: Use a standard SIM card compatible with the Mobile WiFi, otherwise you will damage your Mobile WiFi. Install the SIM card and the battery according to the illustration. Charging the Battery If the Mobile WiFi has not been used for a long time or if the battery is fully depleted, the Mobile WiFi may not power on immediately after the charger is plugged in. Please charge the battery for a while before attempting to power on the Mobile WiFi. Method 1: Use the power adapter to charge the device Note:  Only use the power adapter compatible with the Mobile WiFi and provided by a designated manufacturer. Use of an incompatible power adapter or one from an unknown manufacturer may cause the Mobile WiFi to malfunction, fail, or could even cause a fire. Such use voids all warranties, whether expressed or implied, on the product.  The power adapter is an optional accessory. If it is not included in the package, you may contact an authorized dealer to buy an adapter compatible with the Mobile WiFi.  The Mobile WiFi’s power adapter model is HW-050100X1W. X represents U, E, B, A, or J, depending on your region. For details about the specific adapter model, contact an authorized dealer. Method 2: Charge the device through a computer connection Use the data cable provided with your device to connect the Mobile WiFi to the computer. 1 2 4 3 1 2 3 Connecting to the Internet via Wi-Fi The Mobile WiFi's management parameters have been preset according to your operator's requirements. You can quickly connect to the Internet by following these steps: Step 1: Turn on the Mobile WiFi Press and hold the button until the screen lights up, indicating that the Mobile WiFi is turned on. You can log in to the web management page and turn the fast boot function on or off. This function greatly reduces the Mobile WiFi's boot-up time. Note:  Press and hold the button to turn off the Mobile WiFi.  If your Mobile WiFi malfunctions or cannot be properly powered off, press and hold the button for at least 10 seconds to forcibly power off your Mobile WiFi.  Please turn the fast boot function off when you are on an airplane. Step 2: Establish a Wi-Fi connection (using a computer running the Windows XP operating system as an example) 1. Ensure that the Mobile WiFi's Wi-Fi function is on. 2. Select Start > Control Panel > Network Connections > Wireless Network Connection. Note: Before establishing a Wi-Fi connection, ensure that the computer is equipped with a wireless network adapter. If the computer indicates a wireless network connection, the wireless network adapter can be used. Otherwise, verify that your wireless network adapter is working properly. 3. Click View available wireless networks to view a list of available wireless networks. 4. Select the wireless network connection with the Mobile WiFi's SSID and click Connect. Note:  If the wireless network connection is encrypted, enter the correct wireless network encryption key.  The default SSID and encryption key are printed on the Mobile WiFi's label. 5. Wait a moment for the wireless network connection icon to appear in the system tray in the lower right corner of the computer screen. The wireless network connection is then established. Step 3: Connect to the Internet If data is transmitted, the Mobile WiFi will automatically connect to the Internet. If data is not transmitted for a period of time, the Mobile WiFi will automatically disconnect from the network connection. Note: You can log in to the web management page and enabl…

Text truncated - open the document above for the full version.

Copyright © Huawei Technologies Co., Ltd. 2013. All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd. and its affiliates ("Huawei"). The product described in this manual may include copyrighted software of Huawei and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders. Trademarks and Permissions , , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd. Other trademarks, product, service and company names mentioned may be the property of their respective owners. Notice Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and therefore may not be activated or may be limited by local network operators or network service providers. Thus, the descriptions herein may not exactly match the product or its accessories which you purchase. Huawei reserves the right to change or modify any information or specifications contained in this manual without prior notice and without any liability. DISCLAIMER ALL CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HUAWEI BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOSS OF PROFITS, BUSINESS, REVENUE, DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS REGARDLESS OF WHETHER SUCH LOSSES ARE FORSEEABLE OR NOT. THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO LIABILITY FOR PERSONAL INJURY TO THE EXTENT APPLICABLE LAW PROHIBITS SUCH A LIMITATION) OF HUAWEI ARISING FROM THE USE OF THE PRODUCT DESCRIBED IN THIS MANUAL SHALL BE LIMITED TO THE AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE OF THIS PRODUCT. Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and be responsible to obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein. Privacy Policy Please refer to our privacy policy on our websites for the information about how we protect your personal information. Safety information This section contains important information about the operation of your device. It also contains information about how to use the device safely. Read this information carefully before using your device. Electronic device Do not use your device if using the device is prohibited. Do not use the device if doing so causes danger or interference with other electronic devices. Interference with medical equipment  Follow rules and regulations set forth by hospitals and health care facilities. Do not use your device where prohibited.  Some wireless devices may affect the performance of hearing aids or pacemakers. Consult your service provider for more information.  Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained between a device and a pacemaker to prevent potential interference with the pacemaker. If using a pacemaker, hold the device on the side opposite the pacemaker and do not carry the device in your front pocket. Areas with flammables and explosives  Do not use the device where flammables or explosives are stored (in a gas station, oil depot, or chemical plant, for example). Using your device in these environments increases the risk of explosion or fire. In addition, follow the instructions indicated in text or symbols.  Do not store or transport the device in containers with flammable liquids, gases, or explosives. Traffic security  Observe local laws and regulations while using the device. To reduce the risk of accidents, do not use your wireless device while driving.  Concentrate on driving. Your first responsibility is to drive safely.  RF signals may affect the electronic systems of motor vehicles. For more information, consult the vehicle manufacturer.  Do not place the device over the air bag or in the air bag deployment area in a motor vehicle. Doing so may hurt you because of the strong force when the air bag inflates.  Do not use your device while flying in an aircraft or immediately before boarding. Using wireless devices in an aircraft may disrupt wireless networks, present a hazard to aircraft operation, or be illegal. Operating environment  Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the device in these environments may result in circuit malfunctions.  Do not use your device during thunderstorms to protect your device against any danger caused by lightning.  Ideal operating temperatures are 0°C to +35°C. Ideal storage temperatures are -10°C to +45°C. Extreme heat or cold may damage your device or accessories.  Keep the device and accessories in a well-ventilated and cool area away from direct sunlight. Do not enclose or cover your device with towels or other objects. Do not place the device in a container with poor heat dissipation, such as a box or bag.  Do not expose your device to direct sunlight (such as on a car dashboard) for prolonged periods.  To protect your device or accessories from fire or electrical shock hazards, avoid rain and moisture.  Keep the device away from sources of heat and fire, such as a heater, microwave oven, stove, water heater, radiator, or candle.  Stop using your device or applications for a while if the device is overheated. If skin is expos…

Text truncated - open the document above for the full version.

Huawei Technologies Co.,Ltd. Federal Communications Commission 2013-03-15 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: QISR206 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Operational Description Bom List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. ***************************************************************************** In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the Commission withholds the following documents from public viewing until 2013-5-15: External Photos Internal Photos Test Setup Photos User Manual ****************************************************************************** It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Zhang Xinghai EMC Laboratory Manager Huawei Technologies Co., Ltd. E-mail: [email protected] Fax: 0086-0755- 28970299

R206 Vodafone Mobile Wi-Fi SECRET Page1，Total 5 External Photos of R206 R206 Vodafone Mobile Wi-Fi SECRET Page2，Total 5 R206 Vodafone Mobile Wi-Fi SECRET Page3，Total 5 R206 Vodafone Mobile Wi-Fi SECRET Page4，Total 5 R206 Vodafone Mobile Wi-Fi SECRET Page5，Total 5

R206 Vodafone Mobile Wi-Fi SECRET Page 1 Total 1 R206 Label & Label Location:

Huawei Technologies Co.,Ltd Bantian, Longgang District, Shenzhen, 518129 Guangdong, P.R.China Tel: +86-755-2878-1879 ; Fax: +86-755-2878-1889 Date: March 19, 2013 Statement We, Huawei Technologies Co.,Ltd, states that our device, FCC ID: QISR206, has a battery, But the battery will not be placed in the battery compartment when delivery, it is visible to the users as they purchase the products and install the battery. For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

R206 Vodafone Mobile Wi-Fi SECRET Page1，Total4 Internal Photos of R206 R206 Vodafone Mobile Wi-Fi SECRET Page2，Total4 R206 Vodafone Mobile Wi-Fi SECRET Page3，Total4 R206 Vodafone Mobile Wi-Fi SECRET Page4，Total4

EMC Test Report Product Name: Vodafone Mobile Wi-Fi Model Number: R206 Report No: SYBH(Z-EMC)020022013-2 FCC ID: QISR206 Reliability Laboratory of Huawei Technologies Co., Ltd. Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Tel: +86 755 28780808 Fax: +86 755 89652518 FCC Test Report of R206 FCC ID: QISR206 Security Level: secret Report No: SYBH(Z-EMC)020022013-2 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total17 Notice 1. The laboratory has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L0310. 2. The laboratory has passed the accreditation by The American Association for Laboratory Accreditation (A2LA). The accreditation number is 2174.01. 3. The laboratory has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 97456. 4. The laboratory has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 6369A-2. 5. The test report is invalid if not marked with "exclusive stamp for the test report". 6. The test report is invalid if not marked with the stamps or the signatures of the persons responsible for performing, revising and approving the test report. 7. The test report is invalid if there is any evidence of erasure and/or falsification. 8. If there is any dissidence for the test report, please file objection to the test centre within 15 days from the date of receiving the test report. 9. Normally, the test report is only responsible for the samples that have undergone the test. 10. Context of the test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of the laboratory. FCC Test Report of R206 FCC ID: QISR206 Security Level: secret Report No: SYBH(Z-EMC)020022013-2 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total17 Applicant: Huawei Technologies Co., Ltd. Address: Administration Building, Headquarters of Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, 518129, P.R.C Date of Receipt Test Item: Mar.13, 2013 Start Date of Test: Mar.13, 2013 End Date of Test: Mar.16, 2013 Test Result: Pass Approved By 2013-03-18 Liu Chunlin (Lab Manager) Date Name Signature Operator 2013-03-18 Xiang Zaiji (Test Engineer) Date Name Signature FCC Test Report of R206 FCC ID: QISR206 Security Level: secret Report No: SYBH(Z-EMC)020022013-2 Confidential Information of Huawei. No Distribution without Written Permission Page4, Total17 Modification Record No. Last Report No. Modification Description 1 NA First Report. FCC Test Report of R206 FCC ID: QISR206 Security Level: secret Report No: SYBH(Z-EMC)020022013-2 Confidential Information of Huawei. No Distribution without Written Permission Page5, Total17 TABLE OF CONTENT 1 General Information ........................................................................................................................... 6 1.1 EUT Description ......................................................................................................................... 6 1.2 Test Site Information .................................................................................................................. 7 1.3 Applied Standards ...................................................................................................................... 7 2 Summary of Results .......................................................................................................................... 8 3 System Configuration during EMC Test ............................................................................................ 9 3.1 Test Mode .................................................................................................................................. 9 3.2 Test System Configuration ......................................................................................................... 9 3.3 Cables Used during Test .......................................................................................................... 10 3.4 Associated Equipment Used during Test ................................................................................. 10 4 Electromagnetic Interference (EMI) ................................................................................................. 11 4.1 Radiated Disturbance 30MHz to 18GHz .................................................................................. 11 4.2 Conducted Disturbance 0.15 MHz to 30MHz .......................................................................... 13 5 Main Test Instruments ..................................................................................................................... 14 6 System Measurement Uncertainty .................................................................................................. 14 7 Test Data and Graph ....................................................................................................................... 15 7.1 Radiated Disturbance ............................................................................................................... 15 7.2 Conducted Disturbance ............................................................................................................ 17 FCC Test Report of R206 FCC ID: QISR206 Security Level: secret Report No: SYBH(Z-EMC)020022013-2 Confidential Information of Huawei. No Distribution without Written Permission Page6, Total17 1 General Information 1.1 EUT Description EUT Description Product Name Vodafone Mobile Wi-Fi Model Number R206 Serials Number J7V5TB9330700231 TX Frequency GSM850: 824MHz To 849MHz GSM1900: 1850MHz To 1910MHz WIFI: 2412MHz To 2462MHz RX Frequency GSM850: 869MHz To 894…

Text truncated - open the document above for the full version.

Test Report of R206 FCC ID: QISR206 Security Level: secret Report No: SYBH(Z-EMC)020022013-2 Confidential Information of Huawei. No Distribution without Permission Page1, Total4 Photos of EUT EUT Appearance Test Report of R206 FCC ID: QISR206 Security Level: secret Report No: SYBH(Z-EMC)020022013-2 Confidential Information of Huawei. No Distribution without Permission Page2, Total4 Photos of Test Setup Test Report of R206 FCC ID: QISR206 Security Level: secret Report No: SYBH(Z-EMC)020022013-2 Confidential Information of Huawei. No Distribution without Permission Page3, Total4 1. Radiated Emissions Radiated Disturbance （30MHz To 1GHz） Radiated Disturbance（1GHz To 18GHz） Test Report of R206 FCC ID: QISR206 Security Level: secret Report No: SYBH(Z-EMC)020022013-2 Confidential Information of Huawei. No Distribution without Permission Page4, Total4 2. Conducted Emissions Conducted Emissions for AC Ports -------------------------------------------END--------------------------------------
