QISS7-303UHUAWEI MediaPad

Quick Start HUAWEI MediaPad 1 1 For More Help For more help, go to http://www.huaweidevice.com to download the User Guide. To find the User Guide of your tablet quickly, enter MediaPad in the webpage search box. The figures in this guide are provided for your reference only. The appearance and display features may vary slightly depending on the actual product version. 2 MediaPad at a Glance 1 Volum e key 7 Speaker 2 Power button 8 Main camera 3 Light sensor 9 Microphone 4 Front camera 10 Micro-USB port 5 Headphone jack 11 HDMI port 6 Spea ker 12 Charger port 2 3 Installing the SIM and microSD Cards b a b 21 34 1. Remove the back cover. 2. Install the SIM card. When installing the SIM card, insert the card gently until it clicks firmly into place. 3. Install the microSD card. 4. Replace the back cover. 3 Do not remove the cover for the main camera. When charging your MediaPad's battery for the first time, charge it for at least 6 hours to ensure that your MediaPad displays the battery information correctly. 4 Switching Your MediaPad On or Off Press and hold the Power button until your MediaPad vibrates to switch on your MediaPad. The first time you switch on the tablet, complete the setup by following the on-screen instructions. To switch off your MediaPad, press and hold the Power button until the screen displays a dialog box, and then touch OK in the dialog box. When the MediaPad is switched on or malfunctions, press and hold the Power button for 10 seconds. After release, press and hold the Power button again until your MediaPad vibrates, indicating that it is restarting. 5 Locking the Screen When your MediaPad is turned on, press the Power button to lock the screen. If your MediaPad is idle for a preset period of time, the screen will lock automatically. 4 6 Unlocking the Screen 1. Press the Power button to wake up the screen. 2. Drag the unlock icon to any point of the circle that is around the icon. 7 Navigation Icons The following icons are commonly used on the Home screen or other application screens. Touch the icons to perform more operations. Touch... To... Return to the previous screen. Return to the Home screen. Open the list of recently used applications. 8 Warnings and Precautions To use the device properly and safely, read these warnings and precautions carefully and strictly observe them during operation. Unless otherwise specified, the term "device" refers to the device and its accessories. Basic Requirements During storage, transportation, and operation of the device, keep it dry and prevent it from colliding with other objects. Do not dismantle the device. In case of any fault, contact an authorized service center for assistance or repair. 5 Without authorization, no organization or individual can change the mechanical, safety, or performance design of the device. When using the device, observe all applicable laws and regulations and respect the legal rights of other people. Environmental Requirements for Using the Device Keep the device far from sources of heat and fire, such as a heater or a candle. Keep the device far from electronic appliances that generate strong magnetic or electric fields, such as a microwave oven or a refrigerator. Keep the ambient temperature between 0°C and 35°C while the device is being charged. Keep the ambient temperature between 0°C to 35°C for using the device powered by a battery. Do not place any object (such as a candle or a water container) on the device. If any foreign object or liquid enters the device, stop using the device immediately, power it off, remove all the cables connected to it, and then contact an authorized service center. During thunderstorms, power off the device, and then remove all the cables connected to it to prevent it from getting damaged due to lightning strikes. Precautions for Using Wireless Devices The device complies with the RF specifications when the device is used in portable exposure conditions or at a distance of 0 cm from your body. Do not use the device where using wireless devices is prohibited or may cause interference or danger. The radio waves generated by the device may interfere with the operation of electronic medical devices. If you are using any electrical medical device, contact its manufacturer for the restrictions on the use of the device. Do not take the device into operating rooms, intensive care units (ICUs), or coronary care units (CCUs). 6 Areas with Inflammables and Explosives Do not use the device where inflammables or explosives are stored, for example, in a gas station, oil depot, or chemical plant. Otherwise, explosions or fires may occur. In addition, follow the instructions indicated in text or symbols. Do not store or transport the device in the same box as inflammable liquids, gases, or explosives. Accessory Requirements Use only the accessories supplied or authorized by the device manufacturer. Otherwise, the performance of the device may get affected, the warranty for the device or the laws and regulations related to telecommunications terminals may become null and void, or an injury may occur. Do not use the power adapter if its cable is damaged. Otherwise, electric shocks or fires may occur. Ensure that the power adapter meets the specifications indicated on the device nameplate. Ensure that the power adapter meets the requirements of Clause 2.5 in IEC60950-1/EN60950-1 and it is tested and approved according to national or local standards. For pluggable device, the socket-outlet shall be installed near the device and shall be easily accessible. Battery and Charger Unplug the charger from the electrical plug and the device when not in use. The battery can be charged and discharged hundreds of times before it eventually wears out. When the standby time and the talk time are shorter than the normal time, replace the battery. Use the AC power supply defined in the specifications of the charger. An improper power voltage may cause a fire or a malfunction of the charger. 7 Do …

Text truncated - open the document above for the full version.

Huawei Technologies Co., Ltd. W e, HUAWEI TECHNOLOGIES CO., LTD., declare on our sole responsibility that the product under FCC Grant: FCC ID:QISS7-303U and to be sold under the name: HUAW EI MediaPad will comply with all FCC Level/Compliance guidelines. Any and all product presently shipped and to be shipped will adhere to the Grant Specifications. Huawei will ensure that all present product units will be modified as follows: 1） Reduce the WiFi power to 12dBm via software 2） Proximity sensor is only activated for 2/3G antenna, deactivated for WiFi antenna. 3） Update the software Version Sincerely, Zhang Xinghai EMC Laboratory Manager For and Behalf of: Huawei Technologies Co., Ltd. Huawei Industrial Base, Bantian, Longgang, Shenzhen, P.R China 0086-755- 89650288 [email protected]

Huawei Technologies Co., Ltd. Address：Huawei Industrial Base,Bantian Longgang,Shenzhen 518129, P.R China Post ZIP：518129 Page ：1/1 To: CETECOM Fax : NULL From:Zhang Xinghai Fax:0086-755-89652518 Tel:0086-755-89651014 Email address: [email protected] Http: www.huawei.com Subject：Letter of Confidentiality Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with the Code of Federal Regulations Title 47 Section 0.457 and 0.459 pertaining to confidential material. Huawei Technologies Co., Ltd. would like the following documents regarding this submission for FCC ID: QISS7-303U to be kept confidential: 1. Schematic diagram. 2. Block Diagram. 3. Parts list (BOM) Information. 4. Operational description. 5. Tune-up procedure The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, For and Behalf of: Huawei Technologies Co., Ltd. Zhang Xinghai EMC Laboratory Manager

HUAWEI MediaPad SECRET Page1, Total4 Photo documentation of external of product HUAWEI MediaPad SECRET Page2, Total4 HUAWEI MediaPad SECRET Page3, Total4 HUAWEI MediaPad SECRET Page4, Total4

Zur optimalen Anzeige dieses PDF-Portfolios sollte es in Acrobat oder Adobe Reader ab Version 9 geöffnet werden. Adobe Reader jetzt herunterladen

HUAWEI MediaPad SECRET Page1, Total8 Photo documentation of interior of product HUAWEI MediaPad SECRET Page2, Total8 HUAWEI MediaPad SECRET Page3, Total8 HUAWEI MediaPad SECRET Page4, Total8 HUAWEI MediaPad SECRET Page5, Total8 HUAWEI MediaPad SECRET Page6, Total8 HUAWEI MediaPad SECRET Page7, Total8 HUAWEI MediaPad SECRET Page8, Total8

Zur optimalen Anzeige dieses PDF-Portfolios sollte es in Acrobat oder Adobe Reader ab Version 9 geöffnet werden. Adobe Reader jetzt herunterladen

FCC Test Report of S7-303u FCC ID: QISS7-303U Security Level: Public Report No: SYBH(Z-RF)004082011-2004 Confidential Information of Huawei. No Distribution without Written Permission Page1, Total3 Appendix H Photos of Test Setup FCC Test Report of S7-303u FCC ID: QISS7-303U Security Level: Public Report No: SYBH(Z-RF)004082011-2004 Confidential Information of Huawei. No Distribution without Written Permission Page2, Total3 1 Radiated Spurious Emissions Radiated Spurious Emission (below 1GHz) Radiated Spurious Emission (1GHz to18GHz) FCC Test Report of S7-303u FCC ID: QISS7-303U Security Level: Public Report No: SYBH(Z-RF)004082011-2004 Confidential Information of Huawei. No Distribution without Written Permission Page3, Total3 Radiated Spurious Emission (above 18GHz) 2 Conducted Emissions Conducted Emissions for AC Ports
